NANO D2 User manual

User Guide
D2pneumatic heatless desiccant dryer
revision: REV;2022-019 document: 17-100-0119
© 2022 Air & Gas Solutions LLC.
www.n-psi.co.uk

about us
Experience. Customer. Service.
Experience.
Service.
Our team is comprised of and supported by individuals spanning all
disciplines from research & development, engineering & manufacturing,
marketing & sales and service & support. Our backgrounds are in air
and gas purication and our experience in this eld spans a wide range
of industries. We combine this knowledge and experience to ensure
our products and services are designed and provided to meet the
objectives and expectations of you - our Customer
We recognise that our Customers are not only our valuable distribution
partners who sell and support our products or the machine builders
who depend on them as protection for their equipment. They are the
contractors who install them, the manufacturers who use them in
their processes and the service people who maintain them. At nano
we have developed our products, packaging and support materials to
ensure they exceed all of our Customers’ expectations.
At nano we recognise that world-class customer service is the most
important component to any successful business. Your business
needs to exceed your customers’ expectations to stand out from your
competitors and our service must positively impact your business so
you can be successful in doing so. Our commitment is simple… we
will stand behind our products and ensure that our customer service
is unrivaled in the industry.
Customer.

table of contents
section description page
1
1.1 general information 4
1.2 manufacturer details and support
1.3 document introduction
5
1.4 warranty guidelines
1.5 packaging
1.6 damage to packaging
1.7 general safety
6
1.8 intended use of the product
1.9 personnel
1.10 safe handling
2
2.1 technical specication
7
2.2 ow rates
2.3 correction factors
2.4 product dimensions 8
2.5 product overview 9
2.6 system layout 10
2.7 site location
3
3.1 maintenance and servicing
11
3.2 cleaning
3.3 daily checks
3.4 service schedule and breakdown 12
3.5 service kits and spares 13
4
4.1 service record 14
4.2 trouble shooting 15
4.3 process and instrumentation diagram 16
4.4 notes 17

4
pneumatic heatless desiccant dryer
D2
range: series 2 heatless desiccant pneumatically operated air dryers
models: NDM-060, 070, 080, 090, 100, 110, 120, 130 - PNU
doc no: 17-100-0119
issue: 002
1.2 manufacturers details and support
nano-purication solutions ltd. (Manufacturer)
address: Dukesway
Team Valley Trading Estate Gateshead
NE11 0PZ
United Kingdom
telephone: [phone]
internet: www.n-psi.co.uk
email [email protected]
germany - nano-purication solutions GmbH.
address: Erkelenz
Germany
telephone: [phone]
internet: www.n-psi.de
email [email protected]
usa - nano-purication solutions inc.
address: 5509 David Cox Road
Charlotte,
NC 28269
USA
telephone: [phone]
internet: www.n-psi.com
email: [email protected]
canada - nano-purication solutions inc.
address: 7 Petrie Street
St. Catharines,
Ontario
L2P 3J6
Canada
telephone: [phone]
internet: www.n-psi.com
email: [email protected]
1.1 general information
This manual is copyrighted, all rights reserved. It may not, in whole or in part, be copied, photocopied, reproduced, translated, or
reduced to any electronic medium or machine readable form without prior consent in writing from Air & Gas Solutions LLC. It may not
be distributed through the internet or computer bulletin board systems without prior consent from Air & Gas Solutions LLC.
NOTES: Highlight important sections of information where particular care and
attention should be paid.
CAUTIONS:Indicate any situation or operation that may result in potential
damage to the product, injury to the user, or render the product unsafe.
WARNING:This product can expose you to chemicals including lead, which is
known to the State of California to cause cancer and/or birth defects or other
reproductive harm. For more information, go to www.P65Warning.ca.gov.
annotations

5
pneumatic heatless desiccant dryer
D2
1.3 document introduction
This manual provides factory prescribed installation and maintenance procedures for a series 2 heatless desiccant compressed air
dryer. The procedures illustrated in this document are only to be performed by authorized personnel. For further information regarding
the procedures outlined in this document contact the manufacturer before proceeding. Be sure to read this document carefully before
attempting to install or operate the dryer. This document should be permanently available at the dryer installation site and be kept in
an easily accessible place alongside the dryer.
1.4 warranty guidelines
All products are supplied with a 2 year manufacturer’s warranty from the date of purchase, when installed and maintained in accor-
dance with the manufacturers guidelines. Only genuine service parts should be used and no modications made.
1.5 packaging
All products are securely packaged in a specically designed wooden packing box. The dryer will be held in a horizontal position by
wooden struts; using straps to secure the product to the box base. The box top cover can be removed by removing the 4 xing screws
and lifting off in one piece.
1.6 damage to packaging
Check immediately to establish whether damage has occurred to the external packaging and if the damage extends to the product
inside. If there is damage to a product, contact the relevant supplier immediately.
The support packing box permits limited longitudinal stacking; however the central section of the packing box should not
be considered load bearing.
In no circumstances must a damaged product be used in operation. Using damaged products can lead to
irreparable functional faults or cause serious physical harm.

6
pneumatic heatless desiccant dryer
D2
1.7 general safety
No modications must be made to the product. Any modications may reduce the operational safety of the product and invalidate the
manufacturer’s warranty. This could potentially result in damage to the product and serious personal injury.
For your own safety, when carrying out work on this product, all relevant national safety regulations must be complied with relating to
pressurized and electrical systems.
1.8 intended use of the product
The dryer is exclusively intended for the treatment of compressed air, which is free from bulk water, oil and solid matter constituents.
The product should be located within a building and protected from extreme conditions and weather. The dryer must be operated only
in accordance with the data on the rating plate. Any operations that do not comply with those stated on the product rating label will
render the warranty void.
This product is only designed to operate at pressures of between 6 to 16 barg (58 to 232 psig).
It is not suitable for pressures in excess of 16 barg (232 psig).
IMPORTANT: It is essential that the system into which the dryer is installed is fitted with a pressure limiting/relief
device. This device should be between the compressor and the dryer. The device must be set to prevent the maximum
working pressure of 16 barg (232 psig) from being exceeded.
1.9 personnel
Only authorized, competent and trained personnel are permitted to work on this product. This user guide is intended solely for such
personnel and is to be used only as a reference; it should not be used to replace conventional training.
1.10 safe handling
Please ensure the relevant safe engineering practices and handling procedures are employed when handling, installing and operating
this product. Ensure that the equipment is depressurized and isolated prior to carrying out any of the scheduled maintenance
instructions specied within this user guide.
In no circumstances must a damaged product be used in operation.
Using damaged products can lead to irreparable functional faults or cause serious physical harm.
A suitable lifting aid must be used to minimize the
risk of physical injury or damage to the product.

7
pneumatic heatless desiccant dryer
D2
2.1 technical specication
specifications standard
maximum water content (ISO class) (4) class 2 -40°C (-40°F) pdp
minimum operating pressure 6 barg (87 psig)
maximum operating pressure 16 barg (232 psig)
recommended operating temp range 1.5 to 35°C (35 to 95°F)
design operating temperature range 1.5 to 50°C (35 to 122°F)
All dryers should be preceded by a coalescing filter regardless of oil or oil free applications, a 0.01mg/m1grade
coalescing filter must be installed on the inlet to the dryer.
2.2 ow rates
model inlet flow rate connection
Nm3/hr scfm inlet outlet
NDM-060-PNU 58 34.1
1”
BSPP or NPT
1”
BSPP or NPT
NDM-070-PNU 70 41.2
NDM-080-PNU 90 52.9
NDM-090-PNU 112 65.9
NDM-100-PNU 150 88.2
NDM-110-PNU 180 105.9
NDM-120-PNU 224 131.8
NDM-130-PNU 301 177
2.3 correction factors
inlet air pressure (barg) 6 7 8 9 10 11 12 13 14 16
correction factor 0.88 1.00 1.13 1.25 1.38 1.50 1.63 1.75 1.88 2.13
inlet air temperature °C 25 30 35 40 45 50
°F 77 86 95 104 113 122
correction factor 1.00 1.00 1.00 0.97 0.88 0.73

8
pneumatic heatless desiccant dryer
D2
2.4 product dimensions
model A B C D E weight
mm inches mm inches mm inches mm inches mm inches kg lbs
NDM-060-PNU 735 28.9
426 16.7 316 12.4 234 9.2
681 26.81 44.0 97
NDM-070-PNU 735 28.9 681 26.81 44.0 97
NDM-080-PNU 915 36.0 861 33.89 54.0 119
NDM-090-PNU 915 36.0 861 33.89 54.0 119
NDM-100-PNU 1090 42.9 1036 40.78 64.0 141
NDM-110-PNU 1240 48.8 1240 48.81 77.0 169
NDM-120-PNU 1490 58.6 1490 58.66 89.0 196
NDM-130-PNU 1840 72.4 1840 72.44 109.0 240
DIMENSION A
OUTLET DIMENSION E
INLET DIMENSION D
DIMENSION B
DIMENSION C

9
pneumatic heatless desiccant dryer
D2
2.5 product overview
number description number description
1 compressed air inlet 6 inlet valve ‘A’
2 compressed air outlet 7 inlet valve ‘B’
3 dryer column 8 exhaust valve ‘B’
4exhaust silencer 9pneumatic control box
5exhaust valve ‘A’ 10 purge control
2
10 10
2
1
3
1
9
5
6 7
4
8

10
pneumatic heatless desiccant dryer
D2
2.6 system layout
2.7 site location
When selecting an installation site for the dryer, ensure the following conditions are met:
• Installation site should be located indoors on a at surface protected from the weather and other harmful conditions.
• The ambient temperature must not drop below 1°C (33.8°F) or exceed 50°C (122°F).
• The installation site should be level and able to support the weight of the product
• Ensure sufcient space around the product, to allow access for operation and maintenance.
• Take into account the noise generated by the dryer exhausting while in use when considering location.
IMPORTANT: It is essential that the system into which the dryer module is installed is tted with a pressure limiting/
relief device. This device should be installed between the compressor and the dryer module.
by pass)
NRV

11
pneumatic heatless desiccant dryer
D2
3.1 maintenance and servicing
Maintenance operations should only be carried
out by authorized, suitably trained personnel.
• Maintenance operation should only be conducted when the system has been shut down and fully depressurized.
• Isolate the dryer from the compressed air supply ensuring the system is in a safe condition for maintenance to be carried out.
• All gasket seals removed during maintenance operations must be replaced with new gaskets.
• All connections must be isolated and removed with care, paying particular attention to the areas that become pressurized.
• Do not modify or adjust the control settings.
• Only certied and approved replacement parts should be used.
• Always check all connections for leakage and secure seating.
• Ensure all loose parts are removed or secured to the dryer and it is in safe working condition before operation.
3.2 cleaning
Clean the equipment with a damp cloth only and avoid excessive moisture. If required a mild detergant may be used, however do not
use abrasives or solvents as these may cause damage.
3.3 daily checks
• Check the dryers for any external damage.
(assess and eliminate any defects found)
• Remove any loose dust or dirt from the dryer, clean all surfaces that appear to have attracted unwanted contaminants.
• Always check all connections for leakage and secure seating.
• Ensure all loose parts are removed or secured to the dryer before operation.

12
pneumatic heatless desiccant dryer
D2
3.4 service schedule and breakdown
service year 1
(12 months)
year 2
(24 months)
year 3
(36 months)
year 4
(48 months)
year 5
(60 months)
year 6
(72 months)
year 7
(84 months)
year 8
(96 months)
A
B   
C 
When contacting your service provider be sure to provide the part number and serial number of your dryer,
this can be found on the rating plate located top right hand side of the dryer.
• Service A - Every 1 year (12 months)
Replace external exhaust silencer/mufer element
• Service B - Every 2 years (24 months)
Replace desiccant cartridges
Replace top manifold gasket seals
• Service C - Every 4 year (48 months)
Replace exhaust valve diaphragms
Replace inlet valve diaphragms
Replace outlet check valve seals

13
pneumatic heatless desiccant dryer
D2
3.5 service kits and spares
model service A service B service C
standard -40˚F (-40˚F)
NDM-060-PNU
ESK-130
NDK-060
(x1) OVSK-130
or
(x2) NDB-100
NDM-070-PNU NDK-070
NDM-080-PNU NDK-080
NDM-090-PNU NDK-090
NDM-100-PNU NDK-100
NDM-110-PNU NDK-110 (x1) OVSK / (x1) NDB-100
or
(x1) NDB-130
NDM-120-PNU NDK-120
NDM-130-PNU NDK-130
kit number description kit contents
ESK-130 Replacement exhaust silencer/mufer element (x1) Exhaust Silencer/Mufer Element
NDK-060 Replacement desiccant cartridges for NDM-060
(x2) Desiccant Cartridge (x2) Gasket Seals
NDK-070 Replacement desiccant cartridges for NDM-070
NDK-080 Replacement desiccant cartridges for NDM-080
NDK-090 Replacement desiccant cartridges for NDM-090
NDK-100 Replacement desiccant cartridges for NDM-100
NDK-110 Replacement desiccant cartridges for NDM-110
NDK-120 Replacement desiccant cartridges for NDM-120
NDK-130 Replacement desiccant cartridges for NDM-130
OVSK-130 Replacement outlet valve seals (x2) Outlet Valve Seal Set
NDB-100 Valve Diaphragm Kit (x2) Valve Diaphragms
NDB-130 Valve Diaphragm Kit (x2) Valve Diaphragms
Replacement parts
RCK PNU-NC Pneumatic Pilot Operator (x2) Normally closed actuators
RCK PNU-NO Pneumatic Pilot Operator (x2) Normally open actuators

14
pneumatic heatless desiccant dryer
D2
4.1 service record
part number serial number
installed by installation date
service
interval
hour run
(if applicaple) date serviced by comments / observations
print sign
year 1
year 2
year 3
year 4
year 5
year 6
year 7
year 8
year 9
year 10
year 11
year 12

15
pneumatic heatless desiccant dryer
D2
4.2 trouble shooting
problem problem caused solution
Poor dew-point
performance
Insufcient inlet pressure Inlet pressure should be a minimum of 6 barg (87 psig) if not then
adjust inlet pressure settings.
Moist or contaminated desiccant Eliminate the cause of contamination, replace desiccant cartridges (do
not re-use).
Excessive inlet air temperature Check against the technical specication
Insufcient purge air Purge incorrectly adjusted, consult the service personnel to adjust
settings (factory pre-set).
Exhaust silencer blocked Replace exhaust silencer/mufer element.
Failure of
dryer to cycle
Controller not functioning correctly Ensure the controller is functioning correctly and cams are turning
insufcient inlet pressure Inlet pressure should be a minimum of 4 barg (58 psig) if not then
adjust inlet pressure settings.
failure to de-pressurize when
cycling Exhaust valve functioning correctly; replace valve
outlet ow stops Check inlet air supply
erratic air ow from exhaust Faulty or damaged valves, carry out service

16
pneumatic heatless desiccant dryer
D2
4.3 process and instrumentation diagram
INLET ‘B’
VALVE
INLET ‘A’
VALVE
COMPRESSED
AIR INLET

17
pneumatic heatless desiccant dryer
D2
5.0 notes

18
pneumatic heatless desiccant dryer
D2
6.0 notes

19
pneumatic heatless desiccant dryer
D2
notes

nano-purication solutions
gateshead, united kingdom
tel: [phone]
[email protected]
www.n-psi.co.uk
nano-purication solutions
charlotte, north carolina
tel: [phone]
[email protected]
www.n-psi.com
nano-purication solutions
st. catharines, ontario, canada
tel: [phone]
[email protected]
www.n-psi.com
nano-purication solutions
new bethlehem, pennsylvania
tel: [phone]
[email protected]
www.airtak.com
nano-purication solutions
erkelenz, germany
tel: [phone]
[email protected]
www.n-psi.de
Experience. Customer. Service.
