Nanocable 10.16.2101-BK User manual

HD VIDEO CONVERTER
VGA + Audio to HDMI
10.16.2101-BK
USER MANUAL

The 10.16.2101-BK video converter, allows you to transform
the analog video signal of a computer or player with VGA and
Jack 3.5mm output, to a digital one on a monitor or TV with
HDMI input.
Features:
• Conversion of analog VGA video/stereo audio (3.5mm jack)
to HDMI digital signal.
• Compatible with DVI by using and HDMI to DVI adapter.
• Metal housing with general shielding without signal interference.
• Power LED.
• Power supply: DC 5V/1A.
Content:
1 x Converter.
1 x Power supply.
1 x User’s manual.
2

Specications:
• Signal input/output:
‒Input video signal: 0.5-1.0V.
‒DDC input signal: 5.0V p-p (TTL).
‒Maximum single link range: 1600x1200, 1080p.
‒Video output: HDMI + HDCP1.0/1.1.
‒VGA: 640x480 60Hz/72Hz/75Hz, 800x600
60Hz/72Hz/75Hz,1024x768 60Hz/70Hz/75Hz,
1280x1024 60Hz, 1600x1200 60Hz.
‒DTV/HDTV: 480i/576i/480p/576p/720p/1080i/1080p.
• Operating frequency:
‒Frequency: Up to 165MHz.
‒Video amplier bandwidth: 1.65Gbps/165MHz.
• Resolutions:
‒Interlaced (50 and 60 Hz): 480i, 576i, 1080i.
‒Progressive (50 and 60 Hz): 480p, 576p, 720p, 1080p.
3

• Environment:
‒Operating temperature: from 0º to +70ºC.
‒Operating humidity: 10% to 85% RH (non-condensing).
‒Storage temperature: -10 to +80ºC.
‒Storage humidity: 5% to 95% RH (non-condensing).
• Energy requirement:
‒External power supply: DC 5V 1A.
Installing the converter:
1. Before installation turn off all devices that you want to connect.
2. Connect the converter to the computer using a VGA cable.
3. Connect the audio from the computer to the converter using
a 3.5mm jack audio cable.
4. Connect the converter to the TV or monitor using and HDMI
cable.
4

5. Connect the power supply to the converter.
6. Turn on the computer, the display, and choose the HDMI
channel.
7. The image does not need to be adjusted, the converter will
position it automatically.
Converter parts:
VGA Jack 3,5 mm
DC 5.0 Led HDMI
INPUT
OUTPUT
5

Precautions:
• Carefully connect the cables to the equipment and the converter.
• Place in dry environments without extreme weather conditions.
• Keep away from liquids and heat sources.
• Do not attempt to open the converter or insert external
objects into it.
Warranty:
Nanocable offers a 24 months warranty from the time of purchase,
so it is necessary to have the ticket or invoice where the date
appears. The distributor or seller where you purchased this
product will respond to your claim and offer your technical service
while the warranty is in effect. The converter must show the serial
number without having been altered or deleted, if it is not intelligible,
the warranty will not be applied.
6

Out of warranty:
The warranty does not cover damage or defects caused to the
external case due to:
• Do not follow the user manual.
• Modications or alterations of any kind.
• High and low temperatures, humidity or contact with liquids.
• Wear and scratches produced in everyday use.
Converter certications:
