Napoleon GD27 - N User manual

1
WS-415-090/04.03.00
WW
WW
WARNING:ARNING:
ARNING:ARNING:
ARNING: If the information in these instructions is not followed exactly, a fire or
explosion may result causing property damage, personal injury or death.
FOR YOUR SAFETYFOR YOUR SAFETY
FOR YOUR SAFETYFOR YOUR SAFETY
FOR YOUR SAFETY
Do not store or use gasoline or other flammable vapours and liquids in the vicinity of
this or any other appliance.
WHAWHA
WHAWHA
WHATT
TT
TTT
TT
TO DO IF YOU SMELLO DO IF YOU SMELL
O DO IF YOU SMELLO DO IF YOU SMELL
O DO IF YOU SMELL GAS:GAS:
GAS:GAS:
GAS:
• Do not try to light any appliance.
• Do not touch any electrical switch.
• Do not use any phone in your building.
Installation and service must be performed by a qualified installer, service
agency or the gas supplier.
• Immediately call your gas supplier from
a neighbour's phone. Follow the gas
supplier's instructions.
• If you cannot reach your gas supplier,
call the fire department.
LISTED DIRECT VENT MILLIVOLLISTED DIRECT VENT MILLIVOL
LISTED DIRECT VENT MILLIVOLLISTED DIRECT VENT MILLIVOL
LISTED DIRECT VENT MILLIVOLTT
TT
T
GAS-FIRED WALL FURNACEGAS-FIRED WALL FURNACE
GAS-FIRED WALL FURNACEGAS-FIRED WALL FURNACE
GAS-FIRED WALL FURNACE
INSTINST
INSTINST
INSTALLAALLA
ALLAALLA
ALLATION AND OPERATION AND OPERA
TION AND OPERATION AND OPERA
TION AND OPERATION INSTRUCTIONS FOR:TION INSTRUCTIONS FOR:
TION INSTRUCTIONS FOR:TION INSTRUCTIONS FOR:
TION INSTRUCTIONS FOR:
NATURAL GAS MODEL
GD27 - NGD27 - N
GD27 - NGD27 - N
GD27 - N
PROPANE GAS MODEL
GD27 - PGD27 - P
GD27 - PGD27 - P
GD27 - P
CERTIFIEDFORCANADAAND UNITED STATES USINGANSI/ AGA / CGAMETHODS
INSTALLER:THESEINSTRUCTIONSMUSTBECONVEYEDTOANDREMAIN WITHTHEHOMEOWNER.
CERTIFIED UNDER CANADIAN AND AMERICAN NATIONAL STANDARDS, CSA 2.33, AND ANSI Z21.88 RESPECTIVELY FOR VENTED GAS FIREPLACE HEATERS
Fax:[phone] Email:[email protected]
Web:www.napoleon.on.ca
Wolf Steel Ltd., RR#1, 9 Napoleon Rd.,
Barrie, On., Canada L4M 4Y8 [phone]
R-2000

2
WS-415-090/04.03.00
TABLE of CONTENTS
PG 15 OPTIONAL BLOWER INSTALLATION
16 OPTIONAL FAN &THERMOSTATIC
SENSOR
17 OPERATION / MAINTENANCE
Operating Instructions
Maintenance
18 ADJUSTMENTS
Pilot Burner Adjustment
Venturi Adjustment
Restricting Vertical Vents
19-20 REPLACEMENTS
Ordering Replacement Parts
Replacement Parts
Vent Kits
Terminal Kits
Accessories
21-22 TROUBLE SHOOTING GUIDE
PG 2-4 INTRODUCTION
Warranty
General Instructions
General Information
Care of Glass & Plated Parts
5-7 VENTING
Venting Lengths
Air Terminal Locations
Special Installation Example
8-12 INSTALLATION
Wall & Ceiling Protection
Using Flexible Vent Components
Fireplace Vent Connection
Using Rigid Vent Components
Gas Installation
Mobile Home Installation
Framing
13-14 FINISHING
Log Placement
Optional Glowing Embers
Door, Louvre & Trim Removal & Installation
PLEASE RETAIN THIS MANUAL FOR FUTURE REFERENCE
WARNING
••
••
• Do not burn wood or other materials in this fireplace.
• Adults and especially children should be alerted to the hazards of high surface temperatures
and should stay away to avoid burns or clothing ignition. Supervise young children when they
are in the same room as the fireplace.
• Due to high temperatures, the fireplace should be located out of traffic and away from furniture
and draperies.
• Clothing or other flammable material should not be placed on or near the fireplace.
• Any safety screen or guard removed for servicing must be replaced prior to operating the fire-
place.
• It is imperative that the control compartments, burners and circulating blower and its passage-
way in the fireplace and venting system are kept clean. The fireplace and its venting system
should be inspected before use and at least annually by a qualified service person. More fre-
quent cleaning may be required due to excessive lint from carpeting, bedding material, etc. The
fireplacearea mustbe keptclear andfree fromcombustible materials,gasoline andother flam-
mable vapours and liquids.
• Under no circumstances should this fireplace be modified.
• Thisfireplacemust not be connectedtoa chimney fluepipeservinga separate solidfuelburning
appliance.
• Do not use this fireplace if any part has been under water. Immediately call a qualified service
technician to inspect the fireplace and to replace any part of the control system and any gas
control which has been under water.
• Do not operate the fireplace with the glass door removed, cracked or broken. Replacement of
the glass should be done by a licensed or qualified service person. Use only with a glass door
certified with the fireplace.
• Do not strike or slam shut the fireplace glass door.

3
WS-415-090/04.03.00
NAPOLEON gas fireplaces are manufactured under the strict Standard of the world recognized
ISO9002 Quality Assurance Certificate.
NAPOLEON products are designed with superior components and materials, assembled by trained craftsmen
who take great pride in their work. The burner and valve assembly are leak and test-fired at a quality test
station. The complete fireplace is thoroughly inspected by a qualified technician before packaging to ensure that
you, the customer, receives the quality product that you expect from NAPOLEON.
NAPOLEON GAS FIREPLACE PRESIDENT'S LIFETIME LIMITED WARRANTY
The following materials and workmanship in your newThe following materials and workmanship in your new
The following materials and workmanship in your newThe following materials and workmanship in your new
The following materials and workmanship in your new NAPOLEONNAPOLEON
NAPOLEONNAPOLEON
NAPOLEON gas fireplace aregas fireplace are
gas fireplace aregas fireplace are
gas fireplace are
warranted against defects for as long as you own the fireplace. This covers: combustionwarranted against defects for as long as you own the fireplace. This covers: combustion
warranted against defects for as long as you own the fireplace. This covers: combustionwarranted against defects for as long as you own the fireplace. This covers: combustion
warranted against defects for as long as you own the fireplace. This covers: combustion
chamber, heat exchanger, stainless steel burner, phazer™ logs and embers, ceramic glasschamber, heat exchanger, stainless steel burner, phazer™ logs and embers, ceramic glass
chamber, heat exchanger, stainless steel burner, phazer™ logs and embers, ceramic glasschamber, heat exchanger, stainless steel burner, phazer™ logs and embers, ceramic glass
chamber, heat exchanger, stainless steel burner, phazer™ logs and embers, ceramic glass
(thermal breakage only), gold plated parts against tarnishing, porcelainized enamelled com-(thermal breakage only), gold plated parts against tarnishing, porcelainized enamelled com-
(thermal breakage only), gold plated parts against tarnishing, porcelainized enamelled com-(thermal breakage only), gold plated parts against tarnishing, porcelainized enamelled com-
(thermal breakage only), gold plated parts against tarnishing, porcelainized enamelled com-
ponents and aluminum extrusion trims.ponents and aluminum extrusion trims.
ponents and aluminum extrusion trims.ponents and aluminum extrusion trims.
ponents and aluminum extrusion trims.
Electrical (110V and millivolt) components and wearable parts such as blowers, gas valves,Electrical (110V and millivolt) components and wearable parts such as blowers, gas valves,
Electrical (110V and millivolt) components and wearable parts such as blowers, gas valves,Electrical (110V and millivolt) components and wearable parts such as blowers, gas valves,
Electrical (110V and millivolt) components and wearable parts such as blowers, gas valves,
thermal switch, switches, wiring, remote controls, ignitor, gasketing, and pilot assembly arethermal switch, switches, wiring, remote controls, ignitor, gasketing, and pilot assembly are
thermal switch, switches, wiring, remote controls, ignitor, gasketing, and pilot assembly arethermal switch, switches, wiring, remote controls, ignitor, gasketing, and pilot assembly are
thermal switch, switches, wiring, remote controls, ignitor, gasketing, and pilot assembly are
covered andcovered and
covered andcovered and
covered and NAPOLEONNAPOLEON
NAPOLEONNAPOLEON
NAPOLEON will provide replacement parts free of charge during the first yearwill provide replacement parts free of charge during the first year
will provide replacement parts free of charge during the first yearwill provide replacement parts free of charge during the first year
will provide replacement parts free of charge during the first year
of the limited warranty.of the limited warranty.
of the limited warranty.of the limited warranty.
of the limited warranty.
Labour related to warranty repair is covered free of charge during the first year. RepairLabour related to warranty repair is covered free of charge during the first year. Repair
Labour related to warranty repair is covered free of charge during the first year. RepairLabour related to warranty repair is covered free of charge during the first year. Repair
Labour related to warranty repair is covered free of charge during the first year. Repair
work, however, requires the prior approval of an authorized company official. Labour costswork, however, requires the prior approval of an authorized company official. Labour costs
work, however, requires the prior approval of an authorized company official. Labour costswork, however, requires the prior approval of an authorized company official. Labour costs
work, however, requires the prior approval of an authorized company official. Labour costs
to the account ofto the account of
to the account ofto the account of
to the account of NAPOLEONNAPOLEON
NAPOLEONNAPOLEON
NAPOLEON are based on a predetermined rate schedule and any repairare based on a predetermined rate schedule and any repair
are based on a predetermined rate schedule and any repairare based on a predetermined rate schedule and any repair
are based on a predetermined rate schedule and any repair
work must be done through an authorizedwork must be done through an authorized
work must be done through an authorizedwork must be done through an authorized
work must be done through an authorized NAPOLEONNAPOLEON
NAPOLEONNAPOLEON
NAPOLEON dealer.dealer.
dealer.dealer.
dealer.
CONDITIONS AND LIMITATIONS
NAPOLEONwarrants itsproductsagainst manufacturingdefectsto theoriginal purchaser only-- i.e., theindividual or legalentity (registered customer)whose nameappearson the
warrantyregistrationcard filed withNAPOLEON--provided that thepurchasewasmadethrough anauthorizedNAPOLEONdealerand issubjecttothefollowing conditions andlimitations:
Thisfactory warrantyisnontransferable andmaynot beextendedwhatsoever byanyof ourrepresentatives.
Thegas fireplace mustbeinstalled byalicenced,authorized servicetechnicianor contractor. Installationmustbe done inaccordancewith the installationinstructionsincluded with the
productand alllocaland nationalbuildingand fire codes.
Thislimited warrantydoesnot coverdamagescaused bymisuse,lack of maintenance,accident, alterations, abuseor neglect andparts installed fromother manufacturers willnullify
this warranty.
Thislimited warranty furtherdoesnotcover any scratches,dents,corrosionor discolouringcausedbyexcessive heat, abrasiveandchemicalcleaners norchippingonporcelain enamel
parts,mechanical breakageofPHAZER™ logs andembers, nor anyventing components usedin the installationof the fireplace.
NAPOLEONwarrants itsstainlesssteelburnersagainst defects inworkmanshipandmaterial for life,subjecttothe following conditions:Duringthefirst 10 yearsNAPOLEONwillreplace
or repair the defective parts at our option free of charge. From 10 years to life, NAPOLEON will provide replacement burners at 50% of the current retail price.
Inthe firstyearonly, thiswarrantyextends totherepair orreplacementof warranted partswhichare defectiveinmaterial or workmanshipprovided that theproducthas beenoperated
inaccordance withtheoperation instructionsandunder normalconditions.
After the first year, with respect to this President's Limited Lifetime Warranty, NAPOLEONmay, at its discretion, fully dischargeall obligations withrespectto thiswarrantyby refunding
tothe originalwarranted purchaser thewholesale price ofany warranted butdefective part(s).
Afterthe first year,NAPOLEON will notberesponsible forinstallation,labouror anyothercosts or expensesrelatedto the reinstallationofa warrantedpart,andsuch expensesarenot
coveredby thiswarranty.
Notwithstandingany provisions containedinthis President's LimitedLifetimeWarranty,NAPOLEON’S responsibilityunderthiswarranty isdefinedasabove anditshallnot in anyevent
extendto anyincidental,consequentialor indirectdamages.
Thiswarranty defines theobligationsandliability of NAPOLEON withrespecttotheNAPOLEON gasfireplaceandany other warrantiesexpressedorimplied with respecttothisproduct,
itscomponents oraccessories are excluded.
NAPOLEONneither assumes,nor authorizes anythird party toassume, onitsbehalf, anyotherliabilities withrespect to thesale ofthisproduct. NAPOLEONwillnot beresponsible
for:over-firing, downdrafts,spillage caused byenvironmental conditionssuchas rooftops,buildings, nearby trees,hills, mountains,inadequate vents orventilation, excessive venting
configurations,insufficient makeupair, ornegativeair pressureswhich may ormay notbe caused bymechanical systemssuchas exhaustfans, furnaces, clothesdryers, etc.
Anydamages tofireplace,combustion chamber, heatexchanger, brass trimorother component duetowater, weatherdamage,long periods ofdampness, condensation, damaging
chemicals or cleaners will not be the responsibility of NAPOLEON.
The bill of sale or copy will be required together with a serial number and a model number when making any warranty claims from your authorized dealer. The warranty registration
cardmust bereturned within fourteendays toregisterthe warranty.
NAPOLEONreserves theright to haveits representativeinspectany productor part thereofprior to honouringany warrantyclaim.
ALLSPECIFICATIONSAND DESIGNSARE SUBJECT TOCHANGEWITHOUT PRIOR NOTICEDUE TO ON-GOINGPRODUCTIMPROVEMENTS. NAPOLEON®ISA REGISTERED
TRADEMARKOFWOLFSTEEL LTD. PATENTSU.S.5.303.693.801- CAN. 2.073.411,2.082.915.© WOLF STEELLTD.

4
WS-415-090/04.03.00
CARE OF GLASS, AND PLATED PARTS
Do not use abrasive cleaners to clean plated parts. Buff
lightly with a clean dry cloth. The glass is 3/16" ceramic
glass available from your Napoleon / Wolf Steel Ltd. dealer.
DO NOT SUBSTITUTE MATERIALS. Clean the glass after
the first 10 hours of operation with a recommended gas
fireplace glass cleaner. Thereafter clean as required. DO
NOT CLEAN GLASS WHEN HOT! If the glass is not kept
clean permanent discolouration and / or blemishes may
result.
No external electricity (110 volts or 24 volts) is
required for the gas system operation.
Purge all gas lines with the glass door of the fire-
placeremoved. Assurethat a continuous gas flow
is at the burner before installing the door.
Under extreme vent configurations, allow several
minutes (5-15) for the flame to stabilize after igni-
tion.
Sixinches isthe minimum bend radius allowed for
the 7" diameter flexible liner.
Provideadequateventilation air. Provideadequate
accessibility clearance for servicing and operat-
ingthe fireplace. Never obstructthe front opening
of the fireplace.
Objects placed in front of the fireplace must be
kept a minimum of 48" from the front face of the
unit.
Expansion / contraction nosies during heating up
and cooling down cycles are normal and are to be
expected.
GENERAL INSTRUCTIONS
THIS GAS FIREPLACE SHOULD BE INSTALLED AND
SERVICED BY A QUALIFIED INSTALLER to conform with
local codes. In absence of local codes, install to the cur-
rent CAN/CGA -B149 Installation Code in Canada or to the
National Fuel Gas Code, ANSI Z223.1-1988, and NFPA
54-1988 in the United States. Mobile home installation
must conform with local codes or in the absence of local
codes, install to the current standard for gas equipped
mobile housing CAN/CSA ZA240 MH Series in Canada or
ANSI Z223.1-1988 and NFPA 54-1988 in the United States.
The fireplace and its individual shutoff valve must be dis-
connected from the gas supply piping system during any
pressure testing of that system at test pressures in ex-
cess of 1/2 psig (3.5 kPa). The fireplace must be isolated
from the gas supply piping system by closing its individual
manual shutoff valve during any pressure testing of the
gas supply piping system at test pressures equal to or
less than 1/2 psig (3.5 kPa).
If the optional fan or blower is installed, the junction box
must be electrically connected and grounded in accordance
with local codes. In the absence of local codes, use the
current CSA C22.1 CANADIAN ELECTRICAL CODE in
Canada or the ANSI/NFPA 70-1996 NATIONAL ELECTRI-
CAL CODE in the United States.
GENERAL INFORMATION
FORYOUR SATISFACTION,THIS FIREPLACE HAS BEEN
TEST-FIRED TO ASSURE ITS OPERATION AND QUAL-
ITY! Maximum input is 27,000 BTU/hr for natural gas and
propane. When the fireplace is installed at elevations above
4,500ft, and in the absense of specific recommendations
from the local authority having jurisdiction, the certified high
altitude input rating shall be reduced at the rate of 4% for
each additional 1,000ft. Maximum output for natural gas is
23,220 BTU/hr at an efficiency of 86% with the fan on, and
23,814 BTU/hr for propane at an efficiency of 88% with the
fan on. Minimum A.F.U.E. (annual fuel utilization efficiency)
rating is 64% for natural gas and 65% for propane.
Minimum inlet gas supply pressure is 4.5 inches water
column for natural gas and 11 inches water column for
propane. Maximum inlet gas pressure is 7 inches water
column for natural gas and 13 inches water column for
propane. Manifold pressure under flow conditions is 3.5
inches water column for natural gas and 10 inches water
column for propane.
This fireplace is approved for bathroom, bedroom and bed-
sitting room installations and is suitable for mobile home
installation. The natural gas model can only be installed in
a mobile home that is permanently positioned on its site
and fueled with natural gas.
FIGURE1

5
WS-415-090/04.03.00
VENTING LENGTHS AND AIR TERMI-
NAL LOCATIONS
Use only Napoleon or Simpson Dura-Vent Model DV-GS
venting components. Minimum and maximum vent lengths,
for both horizontal and vertical installations, and air termi-
nal locations for either system are set out in this manual
and must be adhered to. For Simpson Dura-Vent, follow
the installation procedure provided with the venting com-
ponents.
When using Napoleon venting components, use only the
following vent kits: WALL TERMINAL KIT GD222, or 1/12
TO 7/12 PITCH ROOF TERMINAL KITGD110, 8/12 TO 12/
12 ROOF TERMINAL KIT GD111, FLAT ROOF TERMINAL
KIT GD112 or PERISCOPE KIT GD201 (for wall penetration
below grade) in conjunction with the various terminations,
use either the 5 foot vent kit GD220 or the 10 foot vent kit
GD330.
These vent kits allow for either
horizontal or vertical venting of
the fireplace. FIGURES 2, 3, 5 &
6. The maximum number of 4"
flexible connections is two hori-
zontally or three vertically (ex-
cluding the fireplace and the air
terminal connections).
For optimum flame appearance
and fireplace performance,
keep the vent length and num-
ber of elbows to a minimum.
The air terminal must remain
unobstructed at all times. Exam-
ine the air terminal at least once
a year to verify that it is unob-
structed and undamaged.
When terminating vertically, the vertical rise is a minimum
3 feet and a maximum 40 feet above the fireplace.
For safe and proper operation of the fireplace follow the
ventinginstructionexactly.
Deviationfrom the minimum vertical vent length can cre-
atedifficultyin burnerstart-up and/orcarboning.
If verticalrisesgreater than57inchesarenecessary,the
increasedrisemustbedeductedfromthehorizontalrun.
Providea means for visuallychecking the vent connec-
tiontothefireplaceafterthe fireplace is installed.
Use a firestop when penetrating interior walls, floor or
ceiling.
Vent lengths that pass through unheated spaces (at-
tics, garages, crawl spaces) should be insulated with
the insulation wrapped in a protective sleeve to mini-
mizecondensation.
The fireplace must be installed against finished walls.
Donot install against a vapour barrierorexposed insu-
lation.
Horizontal runs may have a 0 inch rise per foot in all cases
usingSimpsonDura-Ventor Napoleonflexibleor rigidvent-
ingcomponentswhenventing asillustratedinFigures 3a-c.
FIGURE2
When venting, the horizontal run must be kept to a mini-
mum of 11 inches or a maximum of 20 feet. If a 20 foot
horizontal run is required, the fireplace must have a mini-
mum vertical rise immediately off the fireplace of 57
inches. FIGURES 3a-c.
VENTING
Minimum clearance to combustible construction
from fireplace to vent surfaces:
sides, back, bottom and top 0 inches
vent pipe 1 inch
recesseddepth 13-3/4 inches
FIGURES3a - d

6
WS-415-090/04.03.00
Aterminal shall not terminatedirectly above a sidewalk
orpaveddrivewaywhichislocatedbetweeentwosingle
family dwellings and serves both dwellings. Local
codes or regulations may require different clearances.
Donot allowtheinside linerto bunch upon horizontal or
vertical runs and elbows. Keep it pulled tight. A 1¼" air
gapall around between the inner liner andouter liner is
required for safe operation. Use a firestop when pen-
etratinginterior walls, floor or ceiling.
CALCULATED HORIZONTAL VENT RUN IN FEET
REQUIREDVERTI-
CAL RISE FROM
FIREPLACE TO
FIRST ELBOW IN
INCHES
FIGURE4
B
C
A
FIGURE5
Use the chart on this page to calculate horizontal runs for
vertical rises between 10 and 57 inches. FIGURE 4.
When calculating maximum run lengths, include 5 feet for
each 90° or 45° elbow.
(DO NOT INCLUDE THE FIRST ELBOW DIRECTLY OFF
THE UNIT.)
SPECIAL INSTALLATION EXAMPLE
When a horizontal offset is
required in a through-the-
roof installation, the follow-
ing procedure for vent
length calculations must be
followed:
In an installation as shown
in FIGURE 5, lengths A and
C are known based on
room height and roof re-
quirements. Any 90° and
45° elbows must be calcu-
lated as 5 feet of venting
each
exceptfortheoneim-exceptfortheoneim-
exceptfortheoneim-exceptfortheoneim-
exceptfortheoneim-
mediatelyatthe fireplacemediatelyatthe fireplace
mediatelyatthe fireplacemediatelyatthe fireplace
mediatelyatthe fireplace
which is excludedwhich is excluded
which is excludedwhich is excluded
which is excluded
.
The allowable horizontal run can be calculated using these
parameters. In this example, the total vertical height is 20
feet (length "A" is required to be 11 feet while length "C"
needs to be 9 feet). The maximum vertical length is 40 feet
and all runs and elbows must be subtracted from this maxi-
mum vertical length.
The maximum allowable horizontal run that "B" can be is:
40 ft. (maximum vertical run length)
-11 ft. (through the roof vertical rise "A")
-10 ft. (2 - 90° elbow)
- 9 ft. (vertical run "C")
10 ft. (maximum allowable horizontal length for "B")
The length of "B" must never be greater than the length
of "A" and "C" combined.

7
WS-415-090/04.03.00
FIGURE6
AIRAIR
AIRAIR
AIR TERMINTERMIN
TERMINTERMIN
TERMINAL INSTAL INST
AL INSTAL INST
AL INSTALLAALLA
ALLAALLA
ALLATIONS:TIONS:
TIONS:TIONS:
TIONS:
**
**
* Recommended to prevent condensation on windows and thermal breakage
****
****
** It is recommended to use a heat shield and to maximize the distance to vinyl clad soffits.
******
******
*** The periscope GD-201 requires a minimum 18 inches clearance from an inside corner.
********
********
**** This is a recommended distance. For additional requirements check local codes.
††
††
† Three feet above if within 10 feet horizontally.
‡‡
‡‡
‡ A vent shall not terminate directly above a sidewalk or paved driveway that is located between two single family
dwellings and serves both dwellings.
††††
††††
†† Permitted only if the veranda, porch, deck or balcony is fully open on a minimum of two sides beneath the floor.
†*†*
†*†*
†* Recommenced to prevent recirculation of exhaust products. For additional requirements check local codes.
A
B
C
D
E
F
G
H
I
J
K
L
M
N
O
12INCHES
9INCHES
12 INCHES*
18 INCHES**
12 INCHES**
0INCHES
0 INCHES***
2 INCHES***
3FEET****
3FEET****
9INCHES
3FEET†
7FEET****
12INCHES****
16INCHES
2FEET†*
Clearanceabove grade, verandaporch,deck or balcony.
Clearancetowindowsordoorsthatopen.
Clearancetopermanently closed windows.
Verticalclearancetoventilatedsoffitlocatedabove theterminalwithin
a horizontal distance of 2 feet from the centerline of the terminal.
Clearanceto unventilated soffit.
Clearancetoanoutside corner wall.
Clearance to an inside non-combustible corner wall or protruding
non-combustible obstructions (chimney, etc.).
Clearance to an inside combustible corner wall or protruding com-
bustible obstructions ( vent chase, etc.).
Clearancetoeach side of the centerline extendedabovethe meter
/ regulator assembly.
Clearancetoa service regulator vent outlet.
Clearance to a non-mechanical air supply inlet to the building or a
combustion air inlet to any other appliance.
Clearance to a mechanical air supply inlet.
Clearance above a paved sidewalk or paved driveway located on
public property unless fitted with a heat shield kit GD-301.
Clearanceundera veranda, porch, deck or balcony.
Clearanceabove theroof.
Clearancefrom an adjacent wallincludingneighbouring buildings.
CANADIAN U.S.A.
12INCHES
12INCHES
12 INCHES*
18 INCHES**
12 INCHES**
0INCHES
0 INCHES***
2 INCHES***
3FEET
6FEET
12INCHES
6FEET
7FEET‡
12INCHES††
16INCHES
2FEET†*
INSTALLATIONS

8
WS-415-090/04.03.00
VERTICAL INSTALLA-
TION: This application
occurs when venting
through a roof.
FIGURE 2. Installation
kits for various roof
pitches are available
from your Napoleon
dealer. See Accesso-
ries to order the specific
kit required.
1. Determine the air terminal location, cut and frame 9½
inch openings in the ceiling and the roof to provide the
minimum 1 inch clearance between the fireplace pipe /
liner and any combustible material. Try to center the ex-
haust pipe location midway between two joist to prevent
having to cut them. Use a plumb bob to line up the center of
the openings.
Do not fill this space with any type of material.
A vent pipe shield will
prevent any materials
such as insulation,
from filling up the 1" air
space around the
pipe. FIGURE 11 Nail
headers between the
joist for extra support.
2. Apply a bead of caulking (not supplied) to the frame-
work or to the Wolf Steel vent pipe shield plate or equiva-
lent (in the case of a finished ceiling), and secure over the
opening in the ceiling. FIGURE 10. A firestop mustbeplaced
on the bottom of each framed opening in a roof or ceiling
that the venting system passes through. FIGURE 9. Apply a
bead of caulking all around and place a firestop spacer
over the vent shield to restrict cold air from being drawn
into the room or around the fireplace. Ensure that both
spacer and shield maintain the required clearance to com-
bustibles. Once the vent pipe / liner is installed in its final
position, apply sealant between the pipe / liner and the
firestop spacer.
3. In the attic, after the pipe / liner has been installed,
slide the vent pipe collar down to cover up the open end of
the shield and tighten. This will prevent any materials, such
as insulation, from filling up the 1" air space around the
pipe.
Foroptimumperformance,itisrecommendedthatForoptimumperformance,itisrecommendedthat
Foroptimumperformance,itisrecommendedthatForoptimumperformance,itisrecommendedthat
Foroptimumperformance,itisrecommendedthat
all horizontal runs have a minimum ¼ inch riseall horizontal runs have a minimum ¼ inch rise
all horizontal runs have a minimum ¼ inch riseall horizontal runs have a minimum ¼ inch rise
all horizontal runs have a minimum ¼ inch rise
per foot.per foot.
per foot.per foot.
per foot.
FF
FF
For safe and proper operation of the fireplace, fol-or safe and proper operation of the fireplace, fol-
or safe and proper operation of the fireplace, fol-or safe and proper operation of the fireplace, fol-
or safe and proper operation of the fireplace, fol-
low the vlow the v
low the vlow the v
low the venting instrenting instr
enting instrenting instr
enting instructions euctions e
uctions euctions e
uctions exactlyxactly
xactlyxactly
xactly..
..
.
HORIZONTAL INSTALLA-
TION: This application oc-
curs when venting through an
exterior wall. FIGURES 3a-c.
Having determined the air ter-
minal location, cut and frame
a hole in an exterior wall with
a minimum square or round
opening of 9½". (As an alter-
native to framing, a vent pipe
shield may be installed, en-
suring a 1" clearance to com-
bustibles. See Figure 8.)
1. Mark and cut the vent pipe shield to the determined
depth of the combustible wall. Apply a bead of caulking
(not supplied) to the framework or to the shield plate (in
the case of a finished wall) and secure the shield through
the opening to the interior wall. The final location of the
vent pipe shield should maintain the required clearance to
the 7" vent pipe / liner. Do not fill this cavity with any type of
material. Apply a bead of caulking all around and place a
firestop spacer over the vent shield to restrict cold air from
being drawn into the room or around the fireplace. Ensure
that both spacer and shield maintain the required clear-
ance to combustibles. Once the vent pipe / liner is installed
in its final position, apply sealant between the pipe / liner
and the firestop spacer.
FIGURE8
OR
FIGURE9
FIGURE10
FIGURE11
VENT PIPE
SHIELD
VENT
PIPE
COLLAR
FIGURE7
INSTALLATION
WALL AND CEILING PROTECTION

9
WS-415-090/04.03.00
VERTICAL VENTING INSTALLATION
1. Fasten the roof support to the roof using the screws
provided. The roof support is optional. The venting is to be
adequately supported using either an alternate method
suitable to the authority having jurisdiction or the optional
roof support.
2. Stretch the 4" diameter aluminum flexible liner to the
required length. Slip the liner a minimum of 2" over the
inner sleeve of the air terminal and secure with 3 #8
screws. Seal using a heavy bead of the high temperature
sealant.
3. Repeat using 7" diameter aluminum flexible liner.
4. Thread the air terminal
pipe assembly down through
the roof. The air terminal must
be located vertically and
plumb. Attach the air terminal
assembly to the roof support,
ensuring that a minimum 16"
of air terminal will penetrate
the roof when fastened.
DONOT CLAMP THEFLEXIBLE ALUMINUMLINER.
FIGURE13
FIGURE12
For optimum performance, it is recommended
that all horizontal runs have a minimum ¼ inch
rise per foot.
For safe and proper operation of the fireplace,
follow the venting instructions exactly.
HORIZONTAL AIR TERMINAL INSTAL-
LATION
INSTALLATION
USING FLEXIBLE VENT COMPONENTS
1. Stretch the 4" diameter aluminum flexible liner to the
required length taking into account the additional length
needed for the finished wall surface. Apply a heavy bead of
the high temperature sealant, supplied with the unit, to the
inside of the 4" liner approximately 1" from the end. Slip the
liner a minimum of 2" over the fireplace vent collar and
secure with 3 #8 screws.
2. Using the 7" diameter flexible aluminum liner, apply
sealant, slide a minimum of 2" over the fireplace combus-
tion air collar and secure with 3 #8 screws.
3. Insert the liners through the firestop. Position and
secure the fireplace using the nailing tabs (2 per side)
and/or secure to the floor using screws inserted through
the two ¼" diameter holes in the front left and right corners
of the base. The liners should be flush with the exterior
wall.
The air teminal plate may be recessed into the exte-
rior wall or siding by 1½", the depth of the return flange.
4. From outside, apply a bead of the high temperature
sealant to the inside of both liners, approximately 1" from
the end of each liner.
5. Holding the air terminal (lettering in an upright, read-
able position), insert into both liners with a twisting motion
to ensure that both the terminal sleeves engage into the
liners / sealant. Secure the terminal to the exterior wall and
make weather tight by sealing with caulking (not supplied).
EXTENDED HORIZONTAL AIR TERMI-
NAL INSTALLATION
If more than one length of liner needs to be used to reach
the fireplace, couple them together as illustrated below.
Seal the joints using the same procedure as before. The
vent system must be supported approximately every 3 feet
for both vertical and horizontal runs. Use Napoleon sup-
port ring assemblies, GA-GD-010.370 or equivalent non-
combustible strapping to maintain the minimum clearance
to combustibles as well as to prevent sagging.
Spacers are attached to the 4" inner flex liner at prede-
termined intervals to maintain a 1-1/4" air gap to the 7"
outer liner. These spacers must not be removed.
FIGURE14

10
WS-415-090/04.03.00
Spacers are attached to the 4" inner flex liner at prede-
termined intervals to maintain a 1-1/4" air gap to the 7"
outer liner. These spacers must not be removed.
7. If more liner needs to be used to reach the fireplace,
follow the same procedure as found in EXTENDED HORI-
ZONTAL AIR TERMINAL INSTALLATION. Theventsystem
must be supported approximately every 3 feet for both ver-
tical and horizontal runs. Use Napoleon support ring as-
sembly GA-GD-010.370 or equivalent noncombustible
strapping to maintain the minimum clearance to combus-
tibles as well as to prevent sagging.
FIREPLACE VENT CONNECTION
1. Install the 4
inch diameter alu-
minum flexible
liner to the fire-
place. Secure with
3 screws and flat
washers. Seal the
joint and screw
holes using the
high temperature
sealant provided.
2. Install the 7 inch diameter aluminum flexible liner to
the fireplace. Attach and seal the joints.
3. Move the fireplace into position. The two holes in the
fireplace base located behind the lower louvre assembly
may be used to attach the fireplace to the floor using
screws.
5. Remove nails
from the shingles,
above and to the sides
of the chimney. Place
theflashing over the air
terminal and slide it
underneath the sides
and upper edge of the
shingles.
Ensure that the air terminal is properly centered within the
flashing, giving a 3/4" margin all around. Fasten to the roof.
Do not nail through the lower portion of the flashing. Make
weather-tight by sealing with caulking. Where possible,
cover the sides and top edges of the flashing with roofing
material.
6. Apply a heavy
bead of weatherproof
caulking 2 inches
above the flashing.
Slide the storm collar
around the air terminal
and down to the caulk-
ing. Tighten to ensure
that a weather-tight
seal between the air
terminal and the collar is achieved. Attach the other storm
collar centered between the air intake and the air exhaust
slots onto the air terminal. Tighten securely. Attach the ver-
tical rain cap.
FIGURE15
FIGURE16
FIGURE17
For safe and proper operation of the fireplace,
follow the venting instructions exactly.
For optimum performance, it is recommended
that all horizontal runs have a minimum ¼ inch
rise per foot.
The vent system must be supported approximately every 3
feet for both vertical and horizontal runs. Use Napoleon
vent spacers WS-615-33 or equivalent every 3 feet and ei-
ther side of each elbow to maintain the minimum 1¼" clear-
ance between the outer and inner vent pipes. Use Napo-
leon support ring assembly GA-GD-010.370 or equivalent
noncombustible strapping to maintain the minimum clear-
ance to combustibles for both vertical and horizontal runs.
INSTALLATION
USING RIGID VENT COMPONENTS
HORIZONTAL AIR TERMINAL INSTAL-
LATION
1. Movethe fireplace into position. Measure theventlength
required between terminal and fireplace taking into account
the additional length needed for the finished wall surface
and any 1¼" overlaps between venting components.
2. Apply high temperature sealant to the outer edge of the
4" inner collar of the fireplace. Attach the first vent compo-
nent and secure using 3 self tapping screws. Repeat us-
ing 7" piping.
3. Holding the air terminal (lettering in an upright, read-
able position), insert into both vent pipes with a twisting
motion to ensure that both the terminal sleeves engage
into the vent pipes and the sealant. Secure the terminal to
the exterior wall and make weather tight by sealing with
caulking (not supplied).
The air terminal mounting plate may be recessed
into the exterior wall or siding by 1½", the depth
of the return flange.
FIGURE18

11
WS-415-090/04.03.00
8. Apply a heavy bead of waterproof caulking 2 inches
above the flashing. Slide the storm collar around the air
terminal and down to the caulking. Tighten to ensure that a
weather-tight seal between the air terminal and the collar
is achieved. Attach the other storm collar centered between
the air intake and air exhaust slots onto the air terminal.
Tighten securely. Attach the rain cap.
9. Continue adding rigid venting sections, sealing and
securing as above. Attach a 4" collapsed telescopic pipe to
the last section of rigid piping. Secure with screws and
seal. Repeat using a 7" telescopic pipe.
10. Run a bead of high temperature sealant around the
outside of the 4" elbow. Pull the adjustable pipe a mini-
mum 2" onto the elbow. Secure with 3 screws. Repeat with
the 7" telescopic pipe.
11. In the attic, slide the vent pipe collar down to cover up
the open end of the shield and tighten. This will prevent any
materials, such as insulation, from filling up the 1" air space
around the pipe.
GAS INSTALLATION
Proceed once the vent installation is complete.
1. Route a 3/8" N.P.T. black iron gas line, 1/2" type-L cop-
per tubing or equivalent to the fireplace.
2. For ease of accessibility, an optional remote wall switch
or millivolt thermostat may be installed in a convenient loca-
tion. Route 2-strand (solid core) millivolt wire through the
electrical hole located at the bottom left side of the unit. The
recommended maximum lead length depends on wire size:
WIRESIZE MAX. LENGTH
14gauge 100 feet
16gauge 60 feet
18gauge 40 feet
Attach the two leads to
terminals 1 and 3 lo-
cated on the gas valve.
Donot connecteither the wallswitch, thermostat orgas
valve to electricity (110 volts).
3. Install rigid black pipe, 1/2" type-L copper tubing or, if
local codes permit, a 3/8" flex connector and shutoff valve
to the gas line and the fireplace gas valve. Seal and tighten
securely. An adapter fitting is required between the gas
valve and the copper tubing or flex connector.
DONOTKINKFLEXIBLE
CONNECTOR.
4. Check for gas leaks by brushing on a soap and water
solution. Do not use open flame.
Purge all gas lines with the glass door of the fireplace
removed. Assure that a continuous gas flow is at the
burnerbeforere-installingthe door.
EXTENDED HORIZONTAL AIR TERMI-
NAL INSTALLATION
1. Follow the instructions for "Horizontal Air Terminal In-
stallations".
2. Continue adding
components alternating
inner and outer venting.
Ensure that all 4" vent-
ing and elbows have
sufficient vent spacers
attached and each
component is sealed
and securely fastened
to the one prior.
Attach the 4" telescopic sleeve to the vent run. Repeat using
a 7" telescopic sleeve. Seal and secure as before. To facili-
tate completion, attach 4" and 7" couplers to the air terminal.
3. Install the air terminal. See item 3, Horizontal Air Ter-
minal Installation. Extend the 4" telescopic sleeve; apply
sealant and connect to the air terminal assembly. Fasten
with self tapping screws. Repeat using the 7" telescopic
sleeve.
VERTICAL VENTING INSTALLATION
1. Attach 4" and 7" elbows to the fireplace. Apply high
temperature sealant and secure the joints with 3 screws.
2. Move the fireplace into po-
sition.
3. Fasten the roof support to
the roof using the screws
provided.The roof support is op-
tional. The venting is to be ad-
equately supported using either
an alternate method suitable to
the authority having jurisdiction
or the optional roof support.
4. Apply high temperature sealant to the outer edge of the
inner sleeve of the air terminal. Slip a 4" diameter coupler a
minimum of 2" over the sleeve and secure using 3 screws.
5.Apply high temperature sealant to the outer edge of the
of the outside sleeve of the air terminal. Slip a 7" diameter
coupler over the sleeve and secure as before. Trim the 7"
coupler even with the 4" coupler end.
6.Thread the air terminal pipe assembly down through
the roof support and attach, ensuring that a minimum 16"
of air terminal will penetrate the roof when fastened.
FIGURE 16. If the attic space is tight, we recommend
threading the Wolf Steel vent pipe collar or equivalent
loosely onto the air terminal assembly as it is passed
through the attic. FIGURE 11. The air terminal must be lo-
cated vertically and plumb.
7.Remove nails from the shingles, above and to the
sides of the chimney. Place the flashing over the air termi-
nal and slide it underneath the sides and upper edge of the
shingles. Ensure that the air terminal is properly centered
within the flashing, giving a 3/4" margin all around. Fasten
to the roof. Do NOT nail through the lower portion of the
flashing. Make weather-tight by sealing with caulking. Where
possible, cover the sides and top edges of the flashing
with roofing material.
FIGURE22
P
I
P
I
3
1
2
L
O
T
N
O
L
O
T
H
I
L
O
F
F
O
FIGURE21
VENTING
TELESCOPIC SLEEVE
20"
COUPLER
AIR TERMINAL
FIGURE19
FIGURE20

12
WS-415-090/04.03.00
FIGURES26
FIGURES25
FIGURE24
FIGURE23
To install the fireplace face flush with the finished wall,
position the framework to accomodate the thickness of the
finished wall. Pull out the four nailing tabs, attached on either
side of the fireplace and secure to the 2x4 framing to facilitate
drywall installation.
Combustible materials may be installed flush with the front
of the fireplace but must not cover any of the black face-
areas of the fireplace. Non-combustible material (brick,
stone or ceramic tile) may protrude in these areas.
It is not necessary to install a hearth extension with this
fireplace system.
Objects placed in front of the fireplace must be kept a
minimum of 48" from the front face of the unit.
Combustible mantle clearance can vary according to the
mantle depth. FIGURES 26. Use the graph to help evaluate
the clearance needed.
MOBILE HOME INSTALLATION
In Canada, mobile home installation may be vented hori-
zontally or vertically. In the United States, it may only be
installed vertically. See "Vertical Venting" for installation.
The fireplace is equipped with two 1/4" diameter holes
located in the front left and right corners of the base. For
mobile home installations, the fireplace must be fastened
in place. Use screws, inserted through the holes in the
base to secure. It is recommended that the fireplace be
secured in all installations.
Always turn off the pilot and the fuel supply at the
source, prior to moving the mobile home.
After moving the mobile home and prior to lighting the
fireplace, ensurethatthe logs arepositioned correctly.
FRAMING
It is best to frame your fireplace after it is positioned and
the vent system is installed. Use 2x4's and frame to local
building codes. FIGURE 23-25.

13
WS-415-090/04.03.00
LOG PLACEMENT
PHAZERTM logs and glowing embers (available as an op-
tion from your Napoleon dealer), exclusive to Napoleon
Fireplaces, provide a unique and realistic glowing effect
that is different in every installation. Take the time to care-
fully position the glowing embers for a maximum glowing
effect.
1. Place the front log, as shown, centered along the inside
front edge of the burner tray.
2. Place the back log onto the log support bracket, located
on the rear wall of the combustion chamber, pushing it as
close to the firebox wall as possible.
3. & 4. Set the two smaller logs into the pockets and
grooves of the front and back logs, respectively.
FIGURE28
FINISHING
POSITIONINGTHE LOGSIMPROPERLYWILLCAUSE
FLAMEIMPINGEMENTANDCARBONING.
Log colours may vary. During the initial use of the fireplace,
the colours will become more uniform as colour pigments
burn in during the heat activated curing process.
OPTIONAL GLOWING EMBERS
Tear the embers into pieces and place beneath the front
log covering all of the burner area beneath and in front of
the hollowed out section of the log. Care should be taken
to shred the embers into thin, small irregular pieces as
only the exposed edges of the fibre hairs will glow.
THE EMBER MATERIAL WILL ONLY GLOW WHEN EX-
POSEDTODIRECTFLAME;HOWEVER,CARE SHOULDBE
TAKENTONOTBLOCK THEBURNER PORTS.
Blocked burner ports can cause an incorrect flame pat-
tern, carbon deposits and delayed ignition. PHAZERTM logs
glow when exposed to direct flame. Use only certified "glow-
ing embers" and PHAZERTM logs available from your Na-
poleon / Wolf Steel Ltd. dealer.
1
2
3
4
FIGURES27

14
WS-415-090/04.03.00
DOOR AND TRIM INSTALLATION:Whenre-install-
ing, retighten screws snugly. DO NOT OVER-TIGHTEN.
The top and bottom door tim may be installed next. Attach
magnets to the bottom door trim approximately 4" from
either end. Lift up the top trim and hook over the top of the
door. The bottom trim is inserted into the bottom door sill.
Push in to engage the magnets. Centre both side trims.
The louvre assemblies are
installed as illustrated in
FIGURES31.
Optional plated door trim, door side trim, webbed facias,
arched door facias and bay door kits are available at your
local Napoleon / Wolf Steel dealer.
DOOR, LOUVRE AND TRIM REMOVAL
& INSTALLATION
Ensure that the door is properly clipped onto the steel
lip to prevent overheating, glass breakage and/or dis-
colouration of the upper trim.
DOOR REMOVAL: Both top and bottom door trim must
be removed prior to door removal. Lift up the top trim and
unhook from the door. The bottom trim may be pulled off
and lifted out of the bottom door sill.
Remove the five screws securing the sides and bottom of
the door. Lift up and out.
FIGURE29
FIGURE30
FIGURES31
DOOR
STEEL LIP

15
WS-415-090/04.03.00
INSTALLATION TO BE DONE BY A QUALIFIED IN-
STALLER and must be electrically connected and
grounded in accordance with local codes. In the absence
of local codes, use the current CSA C22.1 CANADIAN ELECTRI-
CAL CODE in Canada orthe ANSI/NFPA 70-1996 NATIONAL ELEC-
TRICAL CODE in the United States
If the fireplace was not previously equipped with a
blower: route a grounded 2-wire, 60hz power cable to the
receptacle / junction box. At this point, it must be strain
relieved and insulated.
The three slots in the
mounting bracket
allow ease of adjust-
ment when attaching
the blower. For a
quiet running blower,
do not allow the as-
sembly to sit on the
firebox base.
Slide the vibration reducing pad (A) into the clip (C) and
onto the threaded stud (B) at the other end, piercing a hole
into the pad. The blower must be able to be positioned
entirely onto the pad.
Tilt the blower onto its side. Slide it past the controls and
into the clip (C). Secure to the threaded stud using the lock
washer and wing nut provided. Ensure that the blower
does not touch the fireplace base or the firebox.
C
NOTE
OFFSET
FIGURE33
red
white
black
FIGURE32
FIGURE37
RECEPTACLE /
THERMODISC
GROUND
SCREW
JUNCTION BOX
FIGURE36
Attach the connectors from the black and white wires to the
thermodisc and secure the thermodisc bracket to the se-
curing stud at the bottom left of the unit using a lock washer
and wing nut. Ensure that the thermodisc touches the fire-
box wall.
Attach the connectors from the black and red wires to the
blower.
Attach and secure the variable speed switch using the nut
provided. Plug the harness cord into the receptacle.
OPTIONAL BLOWER INSTALLATION
FIGURE35
FIGURE34
C
C
A
B
Thewire harness providedin thiskit isauniversal
harness. When installed, ensure that any excess
wire is contained, preventing it from making con-
tact with moving or hot objects.
Drywall dust will penetrate into the blower bear-
ings, causing irreparable damage. Care must be
taken to prevent drywall dust from coming into
contact with the blower or its compartment. Any
damage resulting from this condition is not cov-
ered by the warranty policy.
Because the blower is thermally activated, when
turnedon,itwill automaticallystartapproximately
10minutes afterlighting thefireplace andwill run
for approximately 30-45 after the fireplace has
been turned off. Use of the fan increases the out-
put of heat.

16
WS-415-090/04.03.00
If the fireplace was not previously equipped with a fan:
route a grounded 2-wire, 60hz power cable to the junction
box. At this point, it must be strain relieved and insulated.
The wire harness provided in this kit is a universal har-
ness. When installed, ensure that any excess wire is con-
tained, preventing it from making contact with moving or
hot objects.
Position the vibration reducing
pad into the clip and onto the
threaded stud at the other end,
piercing a hole into the pad.
The fan assembly must be
able to be positioned entirely
onto the pad.
Slide the fan assembly past
the controls and and into the
clip. Secure using the lock
washer and nut provided.
Attach the connectors from the black and white wires to the
thermodisc and secure the thermodisc bracket to the se-
curing stud at the bottom left of the unit using a lock washer
and wing nut. Ensure that the thermodisc touches the fire-
box wall.
RECEPTACLE /
JUNCTION BOX
SLOTS
OPEN ENDED
VARIABLE SPEED/
BRACKET
PIEZO IGNITOR
OPTIONAL THERMOSTATIC
SENSOR
JUNCTION BOX
THERMODISC
SENSOR ASSEMBLY
BRACKET
RECEPTACLE /
FIGURE39
FIGURE38
FIGURE40
FIGURE41
ELECTRICAL INSTALLATION TO BE DONE BY A QUALI-
FIED INSTALLER and must be connected and grounded
in accordance with local codes. In the absence of local
codes, usethe current CSA C22.1CANADIAN ELECTRICAL CODE in
Canada or the ANSI/NFPA 70-1996 NATIONAL ELECTRICAL CODE
in the United States.
OPTIONAL FAN INSTALLATION
THERMOSTATIC SENSOR CONTROL
This otional kit is meant to be used only in conjunction with
the GD65 Fan Kit, shown above, which may be ordered
from your Wolf Steel / Napoleon dealer.
With the thermostatic sensor option, the fan, when turned
on, becomes thermally activated, and will automatically
run approximately 10 minutes after the fireplace has been
lit and for approximately 30-45 minutes after the fireplace
has been turned off.
Use of the fan increases the output of heat.
Unplug the power cord from the receptacle. Connect all
wires as shown.
Attach and secure the sensor assembly bracket to the se-
curing stud located next to the receptacle/junction box at
the bottom left of the unit using the lock washer and wing
nut. Ensure that the thermodisc touches the firebox wall.
Plug the power cord back into the receptacle.
When installed, ensure that any excess wire is contained,
preventing it from making contact with moving or hot ob-
jects.

17
WS-415-090/04.03.00
WHATTODO IF YOUSMELL GAS:
• Turn off all gas to the fireplace.
• Open windows.
• Do not try to light any appliance.
• Do not touch any electric switch; do not use any phone
in your building.
• Immediately call your gas supplier from a neighbour's
phone. Follow the gas supplier's instructions.
• If you cannot reach your gas supplier, call the fire de-
partment.
FORYOURSAFETYREADBEFORELIGHTING:
A. This fireplace is equipped with a pilot which must be lit
by hand while following these instructions exactly.
B. Before operating smell all around the fireplace area for
gas and next to the floor because some gas is heavier
than air and will settle on the floor.
C. Use only your hand to turn the gas control knob. Never
use tools. If the knob will not turn by hand, do not try to
repair it. Call a qualified service technician. Force or at-
tempted repair may result in a fire or explosion.
D. Do not use this fireplace if any part has been under
water. Immediately call a qualified service technician to
inspect the fireplace and replace any part of the control
system and any gas control which has been under water.
5. Turn gas knob counter-clockwise to pilot.
6. Depress slightly and hold gas knob while lighting the
pilot with the push button ignitor. Keep knob depressed for
one minute, then release. If pilot does not continue to burn,
repeat steps 3 through 5.
7. With pilot lit, depress and turn gas knob counter-clock-
wise to on.
8. If equipped with remote on-off switch/thermostat, main
burner may not come on when you
turn valve to on. Remote switch
must be in the on position to ignite
burner.
9. Turn on all electric power to the fireplace.
2. Push in gas control knob slightly and turn clock-
wise to off. Do not force.
TOTURNOFFGAS
1. Turn off all electric power to the fireplace if service is to
be performed.
P
I
N
O
L
O
T
F
F
O
GAS KNOB
FLAME
ADJUSTMENT
KNOB
O
T
P
I
L
L
O
I
H
T
P
I
L
O
N
O
F
F
O
PILOT
ON/OFF
KNOB
OPERATION / MAINTENANCE
weather season, the fireplace may emit a slight odour for a
few hours. This is caused by dust particles in the heat ex-
changer burning off. In both cases, open a window to suffi-
cientlyventilatethe room.
Purgethe gasline withtheglass
door removed. Assure that a continuous gas flow is at
the burner before re-installing the door.
OPERATING INSTRUCTIONS
When lit for the first time, the fireplace will emit a slight
odour for a few hours. This is a normal temporary condi-
tion caused by the curing of the logs and the "burn-in" of
internal paints and lubricants used in the manufacturing
process and will not occur again. After extended periods of
non-operation such as following a vacation or a warm
LIGHTINGINSTRUCTIONS
WARNING: The gas valve has an interlock device which
will not allow the pilot burner to be lit until the thermo-
couple has cooled. Allow approximately 60 seconds for
the thermocouple to cool.
Whenlightingandre-lighting,thegasknobcannot be turned
from pilot to off unless the knob is depressed slightly.
1. Stop! Read the above safety information on this label.
2. Turn off all electric power to the fireplace.
3. Turn the gas knob clockwise to off.
4. Wait five (5) minutes to clear out any gas. If you smell
gas including near the floor. Stop! Follow "B" in the above
safety information on this label. If you don't smell gas go the
next step.
3. Check to see that all burner ports are burning. Clean out
any of the ports which may not be burning or are not burning
properly.
4. Check to see that the pilot flame is large enough to engulf
the thermocouple and thermopile and reaches toward the
burner with the third jet.
5. Replace the cleaned logs.
6. Check to see that the main burner ignites completely on
all openings when the gas knob for the burner is turned on.
A 5 to 10 second total light-up period is satisfactory. If ignition
takes longer, consult your Napoleon dealer / distributor.
7. Check that the gasketing on the sides, top and bottom of
the door is not broken or missing. Replace if necessary.
MAINTENANCE
TURN OFF THE GAS AND ELECTRICAL POWER
BEFORE SERVICING THE FIREPLACE.
CAUTION: Label all wires prior to disconnection when ser-
vicing controls. Wiring errors can cause improper and dan-
gerousoperation.Verify proper operation after servicing.This
fireplace and its venting system should be inspected be-
fore use and at least annually by a qualified service person.
The fireplace area must be kept clear and free of combus-
tible materials, gasoline or other flammable vapours and
liquids. The flow of combustion and ventilation air must not
be obstructed.
1. In order to properly clean the burner and pilot assembly,
remove the logs to expose both assemblies.
2. Keep the control compartment, logs, burner, air shutter
opening and the area surrounding the logs clean by vacu-
uming or brushing, at least once a year.

18
WS-415-090/04.03.00
ADJUSTMENTS
PILOT BURNER ADJUSTMENT
Adjust the pilot screw to provide properly sized flame. Turn
in a clockwise direction to reduce the gas flow.
FLAME MUST ENVELOP
UPPER 3/8" TO 1/2" OF
THERMOCOUPLE &
THERMOPILE
PILOT
THERMOPILE BURNER
ELECTRODE
THERMO-
COUPLE
FIGURE43
P
I
P
I
PILOT SCREW
L
O
T
N
O
L
O
T
H
I
L
O
F
F
O
FIGURE42
FIGURE44
FIGURE45
RESTRICTOR
BAFFLE PLATE
PLATE
VENTURI ADJUSTMENT
Natural gas models have air shutters set at 1/16 (.063)
inch open. Propane gas models have air shutters set at ¼
(.250) inch open. Closing the air shutter will cause a more
yellow flame, but can lead to carboning. Opening the air
shutter will cause a more blue flame, but can cause flame
lifting from the burner ports. The flame may not appear
yellow immediately; allow 15 to 30 minutes for the final
flame colour to be established.
AIR SHUTTER ADJUSTMENT MUST ONLY BE DONE BY A
QUALIFIEDGASINSTALLER!
RESTRICTING VERTICAL VENTS: Vertical installa-
tions running longer than 10 feet may display a very active
flame. If this appearance is not desirable, remove the baffle
plate from the rear wall of the firebox, exposing the flue gas
outlet opening. Bend the restrictor plate up into the flue
opening. Replace the baffle plate. This reduces the velocity
of the exhaust gases, slowing down the flame pattern and
creating a more traditional gentle appearance. Specific in-
structions are shown in "Trouble Shooting".

19
WS-415-090/04.03.00
P
I
L
O
T
P
I
N
O
I
L
O
T
H
L
O
F
F
O
WS-135-053
WS-135-055
WS-135-056
WS-135-054
REPLACEMENTS
ORDERING REPLACEMENT PARTS
Contact your dealer or the factory for questions concerning prices and policies on replacement parts. Normally all parts
can be ordered through your Napoleon dealer or distributor. When ordering replacement parts always give the following
information:
1. MODEL &SERIAL NUMBER OF FIREPLACE 3. PART NUMBER 5. FINISH
2. INSTALLATION DATE OF FIREPLACE 4. DESCRIPTION OF PART
REPLACEMENT PARTS FORFOR
FORFOR
FOR WW
WW
WARRANTYARRANTY
ARRANTYARRANTY
ARRANTY REPLAREPLA
REPLAREPLA
REPLACEMENTCEMENT
CEMENTCEMENT
CEMENT PP
PP
PARAR
ARAR
ARTSTS
TSTS
TS,,
,,
, AA
AA
A PHOPHO
PHOPHO
PHOTT
TT
TOCOPYOCOPY
OCOPYOCOPY
OCOPY OFOF
OFOF
OF THETHE
THETHE
THE
ORIGINALORIGINAL
ORIGINALORIGINAL
ORIGINAL
INVOICEINVOICE
INVOICEINVOICE
INVOICE WILLWILL
WILLWILL
WILL BEBE
BEBE
BE REQUIREDREQUIRED
REQUIREDREQUIRED
REQUIRED TOTO
TOTO
TO HONOURHONOUR
HONOURHONOUR
HONOUR THETHE
THETHE
THE CLAIMCLAIM
CLAIMCLAIM
CLAIM..
..
.
PART NO. DESCRIPTION
GD-225.36 BLACK DOOR FRAME
WS-300-20 GLASS ONLY
GD-010.402 GLASSc/wGASKET
GD-321-K BLACK DOOR C/W GLASS
GD-562.09 DOOR GASKET (100 INCHES)
WS-455-11 #40 NATURAL GAS ORIFICE
WS-455-033 #53 PROPANE GAS ORIFICE
WS-357-01 PIEZO IGNITER
WS-680-04 THERMOPILE
WS-680-05 THERMOCOUPLE
WS-100-38 NATURAL GAS PILOT ASSEMBLY
WS-100-39 PROPANE GAS PILOT ASSEMBLY
GD-715.136 TOP DOOR TRIM
GD-010.376 BOTTOM DOOR TRIM
GD-715.11 POLISHED BRASS UPPER LOUVRE
GD-010.391 POLISHED BRASS LOWER LOUVRE ASSEMBLY
WS573-008 HIGH TEMPERATURE SEALANT
WS-135-053 BACK LOG
WS-135-054 FRONT LOG
WS-135-056 RIGHT LOG
WS-135-055 LEFT LOG
GL-617 LOG SET ASSEMBLY
WS-100-35 BURNER
WS-660-5 ON/OFF TOGGLE SWITCH
WS-455-23 #51 NATURAL GAS PILOT ORIFICE
WS-455-24 #30 PROPANE GAS PILOT ORIFICE
WS-725-25 NATURAL GAS VALVE
WS-725-26 PROPANE GAS VALVE
WS-750-09 IGNITER WIRE
WS385-33 NAPOLEONLOGO
WS-430-001 CERAMIC MAGNET
GD-020.042 PKG OF 5 DOOR SCREWS
GD660 STANDARD WALL SWITCH & 20FT OF WIRE
FLEXIBLE VENT KITS
GD220 (5 FT)
PART NO. DESCRIPTION
GD-010.397 4" FLEXIBLE ALUMINUM LINER-(5 FT) C/WSPACERS
WS-410-17 7" FLEXIBLE ALUMINUM LINER -(5 FT)
GD330 (10 FT)
PART NO. DESCRIPTION
WS-410-018 7" FLEXIBLE ALUMINUM LINER -(10 FT)
GS10.300 4" FLEXIBLE ALUMINUM LINER - (10 FT) C/WSPACERS
GD10.370 WALL SUPPORT ASSEMBLY

20
WS-415-090/04.03.00
GZ550-1-KT
GD36 GD65
GD320B-KT
GD-780KT
GD250K
TERMINAL KITS
PERISCOPEPERISCOPE
PERISCOPEPERISCOPE
PERISCOPE - GD201- GD201
- GD201- GD201
- GD201
WALL TERMINAL KITWALL TERMINAL KIT
WALL TERMINAL KITWALL TERMINAL KIT
WALL TERMINAL KIT - GD222- GD222
- GD222- GD222
- GD222
ROOF TERMINAL KITS:ROOF TERMINAL KITS:
ROOF TERMINAL KITS:ROOF TERMINAL KITS:
ROOF TERMINAL KITS: 1/12 TO 7/12 PITCH1/12 TO 7/12 PITCH
1/12 TO 7/12 PITCH1/12 TO 7/12 PITCH
1/12 TO 7/12 PITCH --
--
-GD110GD110
GD110GD110
GD110
8/12 TO 12/12 PITCH8/12 TO 12/12 PITCH
8/12 TO 12/12 PITCH8/12 TO 12/12 PITCH
8/12 TO 12/12 PITCH --
--
-GD111GD111
GD111GD111
GD111
FLAFLA
FLAFLA
FLAT ROOFT ROOF
T ROOFT ROOF
T ROOF --
--
-GD112GD112
GD112GD112
GD112
PART NO. DESCRIPTION
GD-010.569 AIR TERMINAL
GD-120.036 VERTICAL CAP
WS-170-063 STORMCOLLAR
GD-010.567 ROOF SUPPORT
WS-263-054 / WS-263-055 / WS-263-056 ROOF FLASHING
ACCESSORIES
PART NO. DESCRIPTION
GD2AB 2" TRIM KIT - ANTIQUE BRASS
GD2PB 2" TRIM KIT - POLISHED BRASS
GD2C 2" TRIM KIT - CHROME
GD3AB 3" TRIM KIT - ANTIQUE BRASS
GD3PB 3" TRIM KIT - POLISHED BRASS
GD3C 3" TRIM KIT - CHROME
GD6AB 6" TRIM KIT - ANTIQUE BRASS
GD6PB 6" TRIM KIT - POLISHED BRASS
GD6C 6" TRIM KIT - CHROME
GD43AB 4" - 3D TRIM KIT - ANTIQUE BRASS
GD43PB 4" - 3D TRIM KIT - POLISHED BRASS
WS175-1 4" COUPLER
WS175-13 7" COUPLER
WS573-008 HI-TEMPERATURESEALANT
GD202-PB DOOR TRIM KIT - POLISHED BRASS
WS690-1 MILLIVOLTTHERMOSTAT
GD-780KT DECORATIVE BRICK PANELS
GD-361.16 GLOWING EMBERS
GD-500.96 FIRE STOP - FLEXIBLE VENTING
GD-500.136 FIRE STOP - RIGID VENTING
GD-101 WINDSHIELD KIT
GD-301 HEAT GUARD
GD-303 VINYL SIDING SHIELD
GD10.370 WALL SUPPORT ASSEMBLY
GD-225-K DOOR FACIA - BLACK
GD-225-PB DOOR FACIA - POLISHED BRASS
GD-225-AB DOOR FACIA - ANTIQUE BRASS
GD-225C DOOR FACIA - CHROME
GD250-K WEBBED DOOR FACIA
GD203 DOOR SIDE TRIM
GDLAB ANTIQUE BRASS LOUVRE KIT
GDLC CHROME LOUVRE KIT
GDLK BLACK LOUVRE KIT
GDLPB POLISHED BRASS LOUVRE KIT
GDLPB POLISHED BRASS LOUVRE KIT
WS660-2 HAND HELD WIRELESS REMOTE SWITCH
WS-660-010 REMOTE CONTROL - ADVANTAGE
WS-660-011 REMOTE CONTROL - ADVANTAGE PLUS
GZ550-1-KT BLOWER KIT
GD65 FAN KIT
GD36 THERMOSTATIC SENSOR CONTROL KIT FOR USE WITH GD65 ONLY
WS500-33 V.S.S. MOUNTING PLATE FOR WALL SWITCH
KB35 VARIABLE SPEED SWITCH
WS-175-053 DURA-VENT ZERO CLEARANCE ADAPTOR
GD320B-KT BAY WINDOW KIT
