NatComm BMS2/M User manual

BMS2
USER GUIDE
For Technical Assistance
Please Phone: [phone]

Page 2 National Communications
PACKING LIST
Your BMS2 unit is supplied with the following items :
1 x BMS2 unit
1x12V/1APowerAdaptor
1 x 3.5mmAudio Plug (for connection to speaker wire).
1 x 3.5mm to RCA StereoAudio Cable (for connection toAmp).
1x 2GBMMC/SD FlashCard (forMessages andHigh RotationSongs)
1 x 2GB MMC/SD Flash Card (for Music Folders)
1 x User Guide
TABLE OF CONTENTS
Description -Page3
Operation -Page4
FlashCard Information -Page5
FlashCard Programmer -Page6
FlashCardMusic Folder Programming -Page7
FlashCard MessageProgramming -Page8
BMSControl Program -Page10-12
Encryption Facility -Page13
ModelOptions -Page 14-15
Installation,when usedwitha separateAmplifier -Page16-17
Installation,whenusedwith direct speakers -Page18-19

National Communications Page 3
DESCRIPTION
BMS2 is a High Quality Digital Message Player, designed specifically for
BackgroundMusicandMessaging applications.
Itisdesignedto play a mixture of MP3basedMusicandMessage files, where
Messages are automatically played at a User Selectable frequency.
BMS-2alsoallows foraseparate FolderofHIGH ROTATION SONGSthatcan
be loaded onto the MESSAGE CARD that can also be played at a User
Selectablefrequency.Thisadditionalfolderdoesnotneedtobeused.
As BMS-2 will only play Encrypted MP3 Files, all MP3 based Music and
Message Files must be ENCRYPTED first with our Encryption program.
The heart of BMS2 is a professional quality MP3 engine, which is controlled
byapowerfulmicroprocessor in order to provide exceptional message output
quality. Itincorporatesa powerfulamplifier, withaMono 100Voutput,designed
to drive up to TEN 100V speakers (set at 1W) operating at background audio
levels.BMS2also has aStereoLine Level output,forthose sites whichrequire
anamplifiertodrivemore thanTEN100V Speakers.
MODEL OPTIONS
InadditiontotheStandardModeldescribedabove,thereareTWOadditional
Modelsprovidedin the BMS2 range, asdetailedbelow:
Model BMS2/T - Time Programmable Music Folder and Message play
Will allow you to set MUSIC FOLDERS and INDIVIDUAL MESSAGES to
playonaTime Programmable Basis.Youcan program MUSIC FOLDERS
and INDIVIDUAL MESSAGES to play :
-DuringaspecificTimePeriodWITHINaSingle Day
- During specific DAYS of the WEEK.
- From a specified STARTDATE to a specified STOPDATE.
- To program the BMS2 to START and STOP playing on a daily basis.
Model BMS2/M - Incorporates an Internal Modem for Dial in Updates.
HasaninternalModemoptionwhichwillallowyoutoconnectitto atelephone
linesothat you canDIALIN andADD,or CHANGEaMESSAGE on theSD
Flash Card. You can also send a new Time Programmable (see above)
SET.TBLfilewhich willallowyou to changethe frequency thata MESSAGE
FILEorHIGH ROTATION FILEshouldplay.

Page 4 National Communications
OPERATION
BMS2 is designed to be left ON at all times. Power consumption is minimal
and there are no moving parts that will wear with use.
Uponconnecting thesupplied PowerAdaptor(andafterashort ‘bootup’delay),
BMS2 will begin randomly playing MUSIC FILES from your MUSIC FLASH
CARD.
It will also play MESSAGE FILES and (if required) HIGH ROTATION FILES
sequentially from your MESSAGE FLASH CARD at a user programmed
frequency.
MUSIC FILES mustbestored in Folderscontaininga MAX of250SONGSper
folder. Up to 250 Folders can be stored on the MUSIC FLASH CARD.
On power up, MUSIC FILES are played from the first folder on a completely
RANDOM basis, until the last file has played. Once all music files in the first
folder are played, BMS2 will then begin playing Music files from the second
Folder until all files have played before moving to the next Music Folder.
- The First folder is the first folder transferred to the Music Flash Card.
- The Second folder is the second folder transferred to the Music Flash Card.
- The Third folder is the third folder transferred etc, etc.
Oncethelastsong in the last Music Folder has finished,BMS2willthenmove
back to the first created Folder again and then cycle on again as above. If
power or either SD Flash Card is removed, it will restart from the first folder.
ItwillalsoSEQUENTIALLYplay through allofyourMESSAGE FILES and all
HIGH ROTATION FILES (if required) before repeating again from the first
one(s). Messages can be played after a preset number of songs (01-256) or
afterapresetnumberof minutes (0-256).
If Messages are selected to play at a fixed minute interval, then BMS2 will
automatically‘fadeout’theMusicfirst,before playing the Message. Once the
Message is complete, it will then ‘fade back in’ the Music from the same point
that it stopped the Music File.
Thefrequency thatMESSAGEFILESplay, is programmedvia theBMSDealer
ControlProgram,which creates a fileknownas SET.TBL,which will be written
automatically to your MUSIC Flash Card.

National Communications Page 5
FLASH CARD INFORMATION
BMS2 uses TWO standard SD-HC Flash Cards to store your MP3 based
Music and Messages. They must be formatted as FAT32. This is
automatically done when you use the ‘Condition Flash Card’ facility provided
with our BMS Dealer Control program
Our unique SD card loading design allows your complete Music or complete
Message programming (contained on the Flash cards) to be changed in
seconds. You do not even need to power the device down before doing this.
MESSAGE Flash Card - Each unit is currently supplied with a 4GB SD-HC
card for Messages. You should store all of the encrypted MP3 BASED
MESSAGE FILES and HIGH ROTATION FILES on this card.
MUSIC Flash Card - Each unit is currently supplied with a 4GB SD-HC
card. You can load up to 4000 minutes (33 hours) of encrypted Music at CD
quality (Mono 128kbps) onto this card.
Our BMS Dealer Control program will write a small file known as a set.tbl
file to the MUSIC Flash Card which will instruct BMS2 how frequently to
play a MESSAGE and High Rotation Files (if required).
Alternatively, you can load up from 8000 to 32000 minutes (533 hours) of
Audio by using an optionally available 8,16 or to 32GB SD Flash Card. You
can also increase play time by using a lower sampling rate for your files.
These flash cards are completely non volatile, which means that your
message is not lost in transport or when power is lost. They are designed
to be over written many times without any deterioration in quality.
The supplied Flash cards are PRE-FORMATTED.
When reusing your Flash cards, it is important that you CONDITION
each Flash card before loading replacement Music folders onto the
card. This is necessary to ERASE the file directory of the Flash Card,
as Windows does not do this and will not over write directory
information when it is full.
The BMS Dealer Control Card provides a CONDITIONING SD CARD
option, selected from the main menu.

Page 6 National Communications
FLASH CARD PROGRAMMER
Your MUSIC FILES and your MESSAGE FILES are transferred to the Flash
Card using an SD flash card programmer.
These Flash Card programmers can be built into your PC, or an external
unit can connected to your PC via a USB port.
Flash Card programmers are treated by the PC as a Removable Hard Drive
device.
Once connected to the PC, they are automatically allocated a separate
DRIVE LETTER so that you can then COPY and DELETE files to the Flash
Card inserted into this drive, just as you would do with any other Drive of
your PC.
BMS DEALER CONTROL PROGRAM
The best way to do this is to use our BMS Dealer Control Program, which
provides a simple user interface (see page 9).
You can also use Windows Explorer if you wish, however this is not
recommendedbecauseyouwillthenneedtohaveathoroughunderstanding
of where all Files, Folders and Timetables need to be placed to work
correctly.
If you do not have a copy of BMS Dealer Control Program V2.01, please
call [phone] or email : [email protected] and request a copy of
this free program.

National Communications Page 7
MUSIC FLASH CARD
Music Plays Randomly
Because of the large volumes of Music that will normally be used, BMS2
uses MUSIC SUB-FOLDERS on the MUSIC FLASH CARD. Each Sub-
Folders can have a MAX of 250 SONGS contained within it. Up to 250 Sub-
Folders can be stored on the MUSIC FLASH CARD.
As BMS-2 will only play Encrypted MP3 Files, all MP3 based Music Files
must be ENCRYPTED first with our Encryption program.
The Encryption facility incorporated in our BMS Dealer Control program will
allow you to automatically encrypt a complete folder of Music at one time.
OurBMSDealer Control Program willthenallowyou to TRANSFER complete
folders onto your SD card, one at a time.
On power up,ALL SONGS are played from the first folder on a completely
RANDOM basis, until the last file has played. Once all Music file in the first
sub-folder are played, BMS2 will then begin playing Music files from the
second sub-Folder until all files have played before moving to the next Music
Sub-Folder.
The First folder is the first folder transferred to the Music Flash Card. The
Second folder is the second folder transferred to the Music Flash Card. The
Third folder is the third folder transferred etc, etc. Once the last song in the
last Music Folder has finished, BMS2 will then move back to the first created
Folder and then cycle on again as above. If power is removed or lost or
either SD Flash Card is removed, BMS2 will RESTARTfrom the first folder.
The use of Folders presents a perfect opportunity to arrange your Music
into separate GENRE groups.
With our Model BMS2/T (Time Programmed Music and Message Play)
device, you can also program individual Music Folders to play during a
specific time period (within a single day), or for specific days of the week or
for a specified period (using a start date and stop date).
You can also use this option to START and STOP play to coincide with
business hours. See page 14 for further information.

Page 8 National Communications
MESSAGE FLASH CARD
Messages Play Sequentially
* You can load a MAX of 250 Messages onto the Message Flash Card.
* You can also load a MAX of 250 High Rotation Songs onto the
Message Flash Card.
MESSAGES must be located within a single folder, called MESSAGES .
This folder is automatically is created on your MESSAGE CARD by using
the‘ConditionMessageSDCard’facilityofthe BMS Dealer Control program.
HIGH ROTATION SONGS must be located within a single folder, called
HITS. This folder is automatically created on your MESSAGE CARD by
using the ‘Condition Message SD Card’ facility of the BMS Dealer Control
program.
Note - You do not need to use the HIGH ROTATION FOLDER. If you do
not plan to use High Rotation Songs, then leave this folder blank.
As BMS2 will only play Encrypted MP3 Files, all MP3 based Messages
and High Rotation Songs must be ENCRYPTED first with our Encryption
program.
MESSAGES and HIGH ROTATION SONGS (if used) will play IN THE
ORDER they are LOADED ONTO THE FLASH CARD.
They will PLAY every 1-256 songs, OR Messages Only can be played
every 1-256 minutes as programmed by your BMS Dealer Control Program.
Note : If you are using Windows Explorer
If the order that the files need to play is important, you MUST write them to
the Flash Card one at a time, in the order required.
If you drag more than 1 file at a time to a folder, Windows MAY load the files
randomly onto the card, in an alphanumeric fashion, based on the filename,
which means they may not play in the order required.
We recommend that you use the BMS Control Program t do this.

National Communications Page 9
FLASH CARD FOLDERS
You should use the BMS Dealer Control program (see page 10) to
CONDITION your MUSIC and MESSAGE cards and to transfer your MUSIC
Sub-Folder to the MUSIC card and your Messages (and optional High
Rotation Files) to the MESSAGE card.
MUSIC CARD
1) You should ALWAYS prepare your MUSIC Flash Card by using the
‘Condition Music SD Card’ facility provided with the BMS Control Program.
This facility will REFORMAT the card and then create a MUSIC folder on
your card.
2) LOAD your encrypted Music
Folders, into the MUSIC Folder by
using the ‘Transfer Music Folders to
SD Card’ option of the BMS program.
These folders will then be loaded as
Sub-Folders.
MESSAGE CARD
1) You should ALWAYS prepare your MESSAGE Flash Card by using the
‘ConditionMessageSD Card’ facility providedwiththeBMS Control Program.
This facility will REFORMAT the card and then create a MESSAGE folder
2) LOAD your encrypted Messages, into the MESSAGE Folder by using
the ‘Transfer Messages to SD Card’ option of the BMS program.
3) The ‘Condition Message SD Card’facility will also create a HITS folder,
which is the destination of any High Rotation Songs that you may wish to
use.
You can leave this folder blank if you wish, or you can transfer individual
files into the HITS folder using the ‘Transfer High Rotation Files to SD Card’
facility provided with the BMS Control Program.

Page 10 National Communications
BMS CONTROL PROGRAM
The BMS Control
Program has been
developedtoprovideyou
withaneasytouse,step
by step procedure for
programming up your
Flash Cards.
Youwillfindthis program
(BMS Control Program
Setup.exe) on the CD
whichhasbeensupplied
with your unit.
To Install this program,
simply‘doubleclick’this
file and then follow the
instructions.
STEP 1 - CONDITION YOUR SD FLASH CARD
ThefirststepforallprogrammingistoCONDITIONyourSDFlashCard.This
procedure ERASES all files from the Flash Cards.
Select the Drive Letter for your SD card on the first occasion that you enter
this facility. It will then be remembered during future access, providing that
the drive is not removed.

National Communications Page 11
STEP 2 - TRANSFER MUSIC FOLDER TO YOUR MUSIC CARD
ThesecondstepistoTRANSFERCOMPLETEFOLDERSofENCRYPTED
MUSIC to your MUSIC Flash Card.
Youshouldnavigatethroughtoeach
folderthatyourequiretobecopiedto
theSDFlashCard andtransferthem
oneatatimebyhighlightingthemand
then clicking the Send Icon.
Note-BMS2willonlyplayEncrypted
Music Files, so you should Encrypt
each folder first using the Encrypt
MP3filesoptionfromtheMainMenu.
STEP 3 -TRANSFER MESSAGES TO YOUR MESSAGE CARD
ThethirdstepistoTRANSFERENCRYPTEDMESSAGEStoyourSDFlash
Card.
Youshouldnavigatethroughtoeach
MESSAGE that you require to be
copied to the SD Flash Card and
transfer them one at a time by
highlighting them and then clicking
the Send Icon.
Note-BMS2willonlyplayEncrypted
MessageFiles,soyoushouldEncrypt
eachmessage firstusingtheEncrypt
MP3filesoptionfromtheMainMenu.

Page 12 National Communications
STEP 4 -TRANSFER HIGH ROTATION SONGS TOYOUR
MESSAGECARD
IfRequired -TheFouthstepistoTRANSFERENCRYPTEDHighRotation
Files (HRF) to your SD Flash Card.
You should navigate through to each ‘HRF’ that
yourequiretobecopiedtotheSDFlashCardand
transfer them one at a time by highlighting them
and then clicking the Send Icon.
Note - BMS2 will only play Encrypted Files, so
you should Encrypt each ‘HRF’ first using the
Encrypt MP3 files option from the Main Menu.
STEP 5 - MESSAGE & HITS PLAY PROGRAMMING
Load your MUSIC Flash Card into your Flash Card programmer.
Inthis section, youspecifyhow frequentlyyouwish toplaya Messageand
aHRF(ifrequired).Youcanplayamessageafter1-256songs,oratintervals
of 1-256 mins. You can play a HRF file after 1-256 songs,
MESSAGEVOLUME
You can also program BMS2 to play
Messages at a HIGHER VOLUME
than the Music by Sliding the slide
bar to the right. This actually
DECREASES the volume of the
MUSIC,relativeto MESSAGES.There
are12possiblesettings,eachposition
represents a reduction of 1.5dB,
providing you with a maximum
reductionof 18dB.
MESSAGEFREQUENCY
The software defaults to SONGS. If
youwishtochangetoMINUTES,you
should use this drop down box.
HIGHROTATIONFILESFREQUENCY
YoucanplayaHighRotationFileafterevery1-256songs,asselectedinthis
area. Allsettingsthatyouhavemadefromthispagearethensavedinafile
called : SET.TBL, which is then saved on your MUSIC Flash Card.

National Communications Page 13
ENCRYPTION FACILITY
This facility is used to
ENCRYPT all MP3 based
Music and Message files for
use with our BMS devices.
It is accessed via the Common
Functions section of the BMS
Dealer Control Program.
The Encryption process is a
demanding mathematical
manipulation of your original
MP3filesandcanbequitetime
consuming. Depending on the
power of your PC, this can take
5-10 seconds of processing
time, per minute of MP3 Music
or Message.
Youshouldfirstnavigatethrough to
the SOURCE FOLDER of the Music
Folder, MessageFileorHighRotation
File that you require to be encrypted
andthenselectifitisafullfolderora
single file to be encrypted
Youshouldthennavigatethroughto
the DESTINATION FOLDER for the
Music Folder, Message File or High
RotationFilethatitwillbeSAVEDto
oncetheyhavebeenencrypted
Note-Filesthathavebeenencrypted
arerenamed with thesamefilename, buttheextension has beenchanged
from .mp3 to .bms.
Ie: filename.mp3 - becomes - filename.bms
Tosaveconsiderabletimeandeffort,werecommendthatyouencrypt
your Music Folders (genres) in a single run.

Page 14 National Communications
TIME PROGRAMMABLE MUSIC
and MESSAGE CHANGE option
Our Model BMS2/T will allow you to set MUSIC FOLDERS and INDIVIDUAL
MESSAGES to play on a Time Programmable Basis.
You can program MUSIC FOLDERS and INDIVIDUAL MESSAGES to play
:
* During a specific Time Periods WITHIN a Single Day
* During specific DAYS of the WEEK.
* From a specified START DATE to a specified STOP DATE.
With this option, you can also program the BMS2 unit to
* START and STOP PLAYING on a Daily Basis.
A SEPARATE USER GUIDE IS SUPPLIED WITH THIS MODEL
WHICH PROVIDES FULL PROGRAMMING INSTRUCTIONS

National Communications Page 15
MODEM OPTION
to allow DIAL IN
MESSAGE or MUSIC CHANGES
Our Model BMS2/M device has an internal Modem which will allow you to
connect it to a telephone line so that you can DIAL IN and :
1) ADD or CHANGE a MESSAGE File
2) CHANGEtheSET.TBLfile
This will allow you to change the frequency that a MESSAGE File
shouldplay.
It will also allow you to change the Time Programming
A SEPARATE USER GUIDE IS SUPPLIED WITH THIS MODEL
WHICH PROVIDES FULL PROGRAMMING INSTRUCTIONS

Page 16 National Communications
BMS2 INSTALLATION
when using an Amplifier
Please refer to the Installation Diagram on page 16.
BMS2 provides a Stereo Line Level output, which is designed to connect
direct to a separate Amplifier.
The separate Amplifier is then used to power the required number of
speakers (usually 100V paging/music speakers)
The amplifier used should have a power rating (W), greater than the sum of
the tapping setting of all speakers connected to it.
If higher volume is required on one or more speakers, then you may increase
the tapping to a higher W setting.
SPEAKER CABLE
You should use figure 8 speaker cable with a power rating suitable for the
amplifier which you plan to use.
You can use ‘Light Duty’ , such as 14/0.14 for amplifiers with an output of
50W RMS or less.
For amplifiers with a power rating of greater than this, you should use ‘Heavy
Duty ‘ 24/0.20.
100V SPEAKERS
BMS2 units are designed to operate with standard 100V PAor Background
Music speakers, which are typically Ceiling Mounted or Wall Mounted.
100V Speakers are designed to connect in Parallel fashion, as indicated on
the Installation Diagrams.
This means that the amplifier connects to one speaker, direct onto the
appropriate tapping of the 100V speaker transformer. The next speaker
connects from that same point, and so on to the last speaker, in a ‘daisy
chain’ type fashion.

National Communications Page 17
INSTALLATION DIAGRAM
NATIONAL COMMUNICATIONS
BMS-2
BMS - Line Level
Units 11-12/39-47 Lawrence Drive Nerang Queensland 4211
Phone [phone] Fax [phone] www.natcomm.com.au
12V/1A
Power Supply
Audio Out
Volume Adjust
Music Card
Music Card
Message Card
Message Card
12V
Power
100V
100V Speakers
Amplifier
2.5mm Power Socket
3.5mm Audio Socket
Connect your amplifier direct to the Line Level Audio Out socket

Page 18 National Communications
INSTALLATION
when fitting speakers direct
Please refer to the Installation Diagram on page 18.
OurBMSunitsare designed topowerdirectly, uptoTEN 100V speakers,each
with a tapping setting of 1W or less. This setting will allow each speaker to
provideclear backgroundlevel audio.
If higher volume is required on one or more speakers, then you may increase
the tapping to a higher W setting, but you must also reduce the number of
speakersaccordingly.
NOTE 1. You should not connect direct to these units speakers with a
total tapping setting of more than 8W.
NOTE 2. You should not connect direct to these units speakers that do
nothavea100V transformer.Doingso may damage the unit.
A3.5mmAudio Plug is supplied to provide connection of your speaker wire to
the BMS1 unit.
SPEAKER CABLE
BMS produces a maximum output of 10 watts. For this power level, you can
use ‘Light Duty’ figure 8 speaker cable, such as 14/0.14 gauge standard or
better .
100V SPEAKERS
BMS2 is designed to operate with standard 100V PA or Background Music
speakers, which are typically Ceiling Mounted or Wall Mounted.
100VSpeakersaredesignedto connectinParallel fashion,asindicated onthe
InstallationDiagrams.
Thismeansthattheamplifierconnectstoonespeaker,directontotheappropriate
tappingof the 100Vspeakertransformer.Thenext speaker connectsfrom that
same point, and so on to the last speaker, in a ‘daisy chain’ type fashion.

National Communications Page 19
INSTALLATION DIAGRAM
NATIONAL COMMUNICATIONS
BMS-2
BMS -100V output
Units 11-12/39-47 Lawrence Drive Nerang Queensland 4211
Phone [phone] Fax [phone] www.natcomm.com.au
100V Speakers (maximum of 10)
12V/1A
Power Supply
Audio Out
Volume Adjust
Music Card
Music Card
Message Card
MessageCard
12V
Power
100V
2.5mmPower Socket
3.5mmAudio Socket
You can connect up to 10 speakers direct to the 100V Audio Output.

Page 20 National Communications
SPECIFICATIONS
Dimensions : 165w x 150d x 60h mm
Weight : 415g
PowerSupply : 240VAC to 12VAC/1A
AudioPower Output : 10W
LineOut Connector : 3.5mm Mono Socket
100Vout Connector : 3.5mm Stereo Socket
ACMACOMPLIANCE : SupplierNumber N782
WARRANTY
This device is guaranteed against defects from workmanship for a period of
two years (24 months) from the date of purchase. In the event of failure,
you should return the product, along with proof of purchase date, and a
written statement about the nature of the problem.
This Warranty shall not apply to any unit which has been subject to
alteration, modification, abuse, negligence, accident, external voltage/
lightning surge or used in any manner contrary to these instructions.
The obligation is solely to repair or replace the product. The warrantor is
not liable for any incidental or consequential damages due to such defects.
The user is responsible for freight costs to the repair point. The warrantor
will be responsible for freight costs in returning this unit back to the user.
Damage caused to this device or attached equipment, by lightning strikes
or over voltage surge is not covered under this warranty.
CASE SEALED AT FACTORY
OPENING THE CASE VOIDS THE WARRANTY
