National Instruments REM-11180 User manual

USER MANUAL
NI REM-11180
Bus Coupler for Remote I/O
This document describes the features of the NI REM-11180 and contains information about
mounting and operating the device.
EtherCAT
In
EtherCAT
Out
Service
Port
Reset
Button
Local
Bus
Ubus
Power
Supply
Microcontroller
UL(24 V)
GND
RJ45
RJ45
Isolation
Contents
REM-11180 Features................................................................................................................ 2
Ports and Connectors........................................................................................................ 3
Reset Button......................................................................................................................4
LEDs................................................................................................................................. 5
Dimensions................................................................................................................................8
Configuring the Rotary Encoding Switch.................................................................................8
Restoring Default Settings........................................................................................................ 9
Reading Error Codes from REM-11180 IOVs..........................................................................9
Diagnostics..............................................................................................................................10
Diagnosis History Object................................................................................................ 10
Diagnostic Registers........................................................................................................11
User Error Codes.............................................................................................................12
Bus Diagnostic Error Codes............................................................................................19

I/O Module Error Codes................................................................................................. 21
PDI Error Codes..............................................................................................................23
Worldwide Support and Services............................................................................................ 26
REM-11180 Features
The REM-11180 provides the following features.
Figure 1. Structure of the REM-11180
S1
S2
1
4
5
7
6
2
3
1. Bus connector
2. REM-11180
3. Ethernet connectors
4. Module function label
5. Supply voltage connector
6. Rotary encoding switch
7. LED indicators
2| ni.com | REM-11180 User Manual

Ports and Connectors
The REM-11180 provides the following ports and connectors.
Figure 2. RJ-45 Ethernet Ports
2
1
1. Ethernet In
2. Ethernet Out
Table 1. RJ-45 Ethernet Port Pinout
Fast Ethernet Signal Pin Pinout
TXD+ 1
1
2
3
4
5
6
7
8
TXD- 2
RXD+ 3
Reserved 4
Reserved 5
RXD- 6
Reserved 7
Reserved 8
Figure 3. Power Connector
a1
a2
b1
b2
24 VDC GND
GND24 VDC
REM-11180 User Manual | © National Instruments | 3

Table 2. REM-11180 Signal Descriptions
Signal Color Description
a1, a2 Red 24 VDC (UL) Supply of logic voltage (internally jumpered)
b1, b2 Blue GND Reference potential of the supply voltage (internally
jumpered)
Figure 4. Service Interface
2
1
1. Label
2. Service Interface
Note The service interface is a micro-USB port used for factory service and
configuration. You do not need to connect to this port for normal operation.
Reset Button
Pressing the reset button during normal operation restarts the bus coupler.
Figure 5. REM-11180 Reset Button
2
1
1. Label
2. Reset button
4| ni.com | REM-11180 User Manual

LEDs
The REM-11180 provides the following LEDs.
Figure 6. UL LEDs
UL
Table 3. UL LED Indicators
LED LED Color LED Pattern Indication
UL
Green Solid Communications power supply present.
— Unlit Communications power supply not present.
Figure 7. Status LEDs
RUN
ERR
RDY
D
E
Table 4. Status LED Indicators
LED LED Color LED Pattern Indication
RUN
— Off Bus coupler in Init state
Green
Flashing slowly
(2.5 Hz)
Bus coupler in Pre-Operational state
Single pulse 200 ms on, 1000 ms off; bus coupler in Safe-
Operational state
Solid Bus coupler in Operational state
Flashing (10
Hz)
Bus coupler in Bootstrap state
REM-11180 User Manual | © National Instruments | 5

Table 4. Status LED Indicators (Continued)
LED LED Color LED Pattern Indication
ERR
— Off No error
Red
Flashing slowly
(2.5 Hz)
Configuration error; a state transition initiated by the
master cannot be executed
Single pulse 200 ms on, 1000 ms off; local application error
Double pulse 200 ms on, 200 ms off, 200 ms on, 1000 ms off;
watchdog timeout
Solid Critical internal error
RDY
Green Solid Device is ready for operation.
Green/Yellow Flashing
• Communications power undervoltage or surge
voltage
• Overtemperature
Yellow
Solid Firmware/bus coupler is booting
Flashing Firmware update is being performed.
Yellow/Red Solid Firmware update has failed.
Red Solid Rotary encoding switches are set to an invalid/
reserved position
Unlit Device is not ready to operate.
6| ni.com | REM-11180 User Manual

Table 4. Status LED Indicators (Continued)
LED LED Color LED Pattern Indication
D
Green
Solid Run: Data exchange; status and data from the higher-
level system is transmitted.
Flashing Active: configuration is active, data exchange with
invalid process data, PDI channel can be used.
Yellow
Solid Ready: Device is ready to operate, no data is
exchanged.
Flashing Access in I/O check mode
Yellow Red Flashing Bus error during active I/O check
Red
Flashing Local bus error on startup
Solid
• General local bus error
• Communication error
• Local bus device has been removed or
configured device is missing.
• Reset at a local bus device
• Serious device error at a local bus device (local
bus device can no longer be reached)
E
Yellow Solid I/O warning at a local bus device
Red Solid I/O error at a local bus device
Figure 8. Ethernet LEDs
L/A
L/A
REM-11180 User Manual | © National Instruments | 7

Table 5. Ethernet LED Indicators
LED LED Color LED Pattern Indication
L/A
Green
Solid Connection present at EC IN/EC OUT.
Flashing Transmission or reception of Ethernet telegrams at EC IN /
EC OUT.
— Off Connection not present at EC IN/EC OUT.
Dimensions
The following figures show the front and side dimensions of the REM-11180. For detailed
dimensional drawings and 3D models, visit ni.com/dimensions and search for the module
number.
Figure 9. REM-11180 Dimensions
125.9 mm
(4.96 in.)
122.4 mm
(4.82 in.)
74.0 mm
(2.97 in.)
45.0 mm
(1.77 in.)
Configuring the Rotary Encoding Switch
Each bus coupler automatically receives an EtherCAT device identification address. Use the
rotary encoding switch to configure the address manually.
The S1 switch sets the tens digit and the S2 switch sets the ones digit. The code results from
the equation (S1 x 10) + S2.
The following figure shows code 77 (7 x 10 + 7).
8| ni.com | REM-11180 User Manual

Figure 10. Rotary Encoding Switch
02
4
6
8
9
x1
S2
02
4
6
8
10
12
14
x10
S1
After setting the rotary switches, restart the REM-11180 to update the address assignment.
Note NI EtherCAT master does not support the rotary encoding switch on the
REM-11180.
Restoring Default Settings
To restore the REM-11180 to default settings, follow these steps:
1. Disconnect power to the REM-11180.
2. Press and hold the reset button.
3. Power on the REM-11180.
4. Release the button when the RDY LED flashes red and green.
Reading Error Codes from REM-11180 IOVs
When you add the REM-11180 to the RT Target in the LabVIEW project, the following IOVs
are available:
Table 6. LabVIEW Project IOVs for Remote I/O Systems
IOV Data Type Purpose
Localbus Add_Error
Info U16 Indicates which I/O module is returning an error.
Localbus bus State U16 Returns the current bus state. Refer to the Diagnostic
Status Register table for more information.
REM-11180 User Manual | © National Instruments | 9

Table 6. LabVIEW Project IOVs for Remote I/O Systems (Continued)
IOV Data Type Purpose
Localbus Error_Code U16 Returns error codes for the I/O module. Refer to the
I/O Module Error Codes table for more information.
Newest Diagnosis
Message U16
Returns the new message available bit (Index 10F3hex
sub-index 04). Refer to the Diagnosis History Object
table for more information.
Diagnostics
Diagnosis History Object
The diagnosis history object (10F3hex) implements as a ring memory in Overwrite mode. The
last 16 diagnostic messages are always stored. Older messages are deleted. Bus coupler and
I/O errors are stored in the object's diagnostic messages.
Table 7. Diagnosis History Object Indicators
Code (hex) Sub-Index Data Type Indication
10F3
Record Diagnosis statistics
01 U8 Maximum number of messages
02 U8 Newest message
03 U16 Newest acknowledged message
04 Bit New message available
05 U16 Behavior setting for the object
Note Refer to Table 27: Entries of 0x10F3 Diagnosis History Object in the ETG.
1020 EtherCAT Protocol Enhancements document for Newest Acknowledged
Message definitions.
10 | ni.com | REM-11180 User Manual

Diagnostic Registers
Table 8. Diagnostic Status Register
Bit Designation Meaning
00 F_PW_BIT
I/O warning
(peripheral
warning)
The device detected a warning at the I/Os.
01 F_PF_BIT I/O error
(peripheral fault)
The device detected an I/O error
(peripheral fault).
02 F_BUS_BIT Bus error A bus error occurred.
03 F_CTRL_BIT Controller error The driver detected an internal error.
04 — — Reserved
05 F_RUN_BIT Run Data cycles are being exchanged, output
data is enabled.
06 F_ACTIVE_BIT Active
The configuration is active, PDI to the
devices is possible, output data is disabled
(substitute value behavior).
07 F_READY_BIT Ready The local bus master is ready for operation,
no data exchange over the bus.
08 F_BD_BIT Bus different
A device which does not belong to the
current configuration has been detected at
the last interface.
09 F_BASP_BIT SYS_FAIL
The controller is in the STOP state or no
application program has been loaded.
Output data is blocked (substitute value
behavior).
10 F_FORCE_BIT Force mode Force mode (start-up tool) is active.
11 to 15 — — Reserved
REM-11180 User Manual | © National Instruments | 11

Table 9. Priorities of the Error Messages
Message Priority
CTRL 1 (Highest priority)
BUS 2
PF 3
PW 4 (Lowest priority)
User Error Codes
Code
(hex)
Additional code Meaning Remedy
903 — Memory problem (e.g., buffer too
small)
Reduce the amount of
data.
904 — Inconsistent parameters Check the parameters.
905 — Invalid parameters Check the parameters.
908 Code of failed
service
Maximum number of permitted
parallel services exceeded
(Processing conflict)
Wait for the service
called previously to be
completed, and then try
again.
090A Value transmitted in
Parameter_Count
The number of parameters is
inconsistent with the service. The
Parameter_Count parameter does
not agree with the number of
subsequent words.
Match the number of
parameters.
913 Code of failed
service
The service called is not
supported.
Use a service that is
supported.
917 Code of failed
service Service decoding failed.
Restart the device.
Contact NI if the
problem persists.
918 Code of the
unknown service Call of an unknown service code. Check the call.
928 —
An exclusive service was to be
executed without the appropriate
rights.
Wait for the exclusive
rights to be enabled.
12 | ni.com | REM-11180 User Manual

Code
(hex)
Additional code Meaning Remedy
932 — Attempt to pass on the exclusive
rights without having these rights. —
933 — Another node has currently the
exclusive rights.
Wait for the exclusive
rights to be enabled.
934 — The node already has the
exclusive rights. —
937 Faulty Variable_ID Unknown Variable_ID
component. Check the call.
938 Reserved
Variable_ID An internal Variable_ID was used. Check the call.
939 Variable_ID not
enabled
The Variable_ID is not enabled.
(Password protection) Check the call.
093A Incorrect
Variable_ID
Length specification in the
Variable_ID is 0 or incorrect. Check the call.
093B Incorrect
Variable_Count
The number of variables has been
calculated incorrectly. Check the call.
0A01 — A hardware or firmware error
occurred.
Restart the device.
Contact NI if the
problem persists.
REM-11180 User Manual | © National Instruments | 13

Code
(hex)
Additional code Meaning Remedy
0A02 Current status of the
local bus master
A service was called that is not
permitted in the current status of
the local bus master.
Possible states:
0001 Ready (After restart or
reset)
0002 Load Config
(Configuration cannot be
loaded)
0004 Config Ready
(Configuration loaded
successfully)
0008 Active (Configuration
frame connected)
0010 Param Ready
(Parameterization of modules
completed)
0020 Run (Process data
traffic running)
0080 Force Mode (Startup
tool specifies outputs)
0100 Ready Fail
(Communication abort in
Ready)
0800 Active Fail
(Communication abort in
Active)
1000 Param Ready Fail
(Communication abort in
Ready parameter)
2000 Run Fail (Process data
traffic with subsystem)
4000 Force Fail (Application
timeout for all devices)
8000 Force Mode Fail
(Communication abort in
Force_Mode)
Set the local bus master
to the required state.
14 | ni.com | REM-11180 User Manual

Code
(hex)
Additional code Meaning Remedy
0A03 — Memory problem (e.g., buffer too
small)
Restart the device.
Contact NI if the
problem persists.
0A04 — Inconsistent parameters Check the call.
0A05 — Invalid parameters Check the call.
0A06 — Access not supported. Check the call.
0A07 — Object does not exist. Check the call.
0A08 Code of failed
service
Maximum number of permitted
parallel SM services exceeded.
(Processing conflict)
Wait for the service
called previously to be
completed, and then try
again.
0A0C Unknown
Variable_ID
Call of Set_Value or Read_Value
with a Variable_ID that contains
an unknown code.
Check the call.
0A0D — A firmware error occurred.
Restart the device.
Contact NI if the
problem persists.
0A18
Invalid
Used_Attributes
parameter
A reserved bit is set in
Used_Attributes. Check the parameters.
0A19 Number of bus
devices
The end of the frame was
exceeded when accessing the
configuration or line 0 was
accessed.
Check the access.
0 A1 A
Invalid
Frame_Reference
(if specified)
The frame reference specified for
the service does not exist. Check the parameters.
0A1C Number of
connected devices
Maximum number of devices
exceeded.
Reduce the bus
configuration.
0A2F — Number of devices is zero. Connect the device and
check the connection.
REM-11180 User Manual | © National Instruments | 15

Code
(hex)
Additional code Meaning Remedy
0A51 — A frame reference from 1 to 254 is
permitted only.
Currently, the value 1 is
permitted only.
0A54 — The maximum number of I/O
points was exceeded.
Reduce the number of
I/O points to the
maximum number. To
obtain the exact number,
please refer to the
documentation for your
controller.
0A60 — No configuration frames could be
assigned.
Create the configuration
frame.
0A70 — A reserved bit has been set in the
Diag_Info attribute. Check the parameters.
0A73 Device number
Device present with a chip version
in the local bus that is not
supported.
Replace the device.
0A74 Device number
Device of a manufacturer that is
not supported present in the local
bus.
Replace the device.
0A75 Device number Device is indicating a serious
error (e. g., faulty EEPROM).
Restart the device.
Contact NI if the
problem persists.
0A76 Device number The topology used by the device
is not supported by the master. Replace the device.
0A77 Device number Error at the interface.
Check the connection
between the electronics
module and bus base
module.
0A7 A — Invalid Dev_Type specified
during loading. Check the parameters.
0A7B — Invalid Dev_ID specified during
loading. Check the parameters.
16 | ni.com | REM-11180 User Manual

Code
(hex)
Additional code Meaning Remedy
0A7C — Invalid Dev_Length specified
during loading. Check the parameters.
0A81 Object index
Service (e.g,
Create_Configuration) could not
be executed due to PDI
communication malfunctions
(timeout).
Restart the device.
Contact NI if the
problem persists.
0A82 Object index
Service (e.g,
Create_Configuration) could not
be executed due to PDI
communication malfunctions
(number).
Restart the device.
Contact NI if the
problem persists.
0A83 Object index
Service (e.g,
Create_Configuration) could not
be executed due to PDI
communication malfunctions
(error).
Restart the device.
Contact NI if the
problem persists.
0A90 Device number
Device was selected for
synchronization, however it does
not support this.
Select a device that
supports
synchronization or
change the selection.
0A91 Device number
Device was selected for
synchronization, however it does
not support the specified cycle
time.
Select a different cycle
time or a different
device.
0A92 Device number
Device was selected for
synchronization, but does not
support the specified value for
Input_Delay.
Select a different value
for Input_Delay or a
different device.
0A93 Device number
Device was selected for
synchronization, but does not
support the specified value for
Output_Delay.
Select a different value
for Output_Delay or a
different device.
REM-11180 User Manual | © National Instruments | 17

Code
(hex)
Additional code Meaning Remedy
0A94 Device number
Device was selected for
synchronization, but does not
support the specified values for
Input_Delay and Output_Delay.
Selected different values
for Input_Delay and
Output_Delay or a
different device.
0AFF — Call of Reset_Driver during PDI
communication.
Restart the device.
Contact NI if the
problem persists.
0B01 — A hardware or firmware error
occurred.
Restart the device.
Contact NI if the
problem persists.
0B02 — A hardware or firmware error
occurred. —
0B03 — A hardware or firmware error
occurred. —
0B04 — A hardware or firmware error
occurred. —
0B05 — Invalid parameters Check the parameters.
0B06 — Access not supported. (E.g., write
protection)
Restart the device.
Contact NI if the
problem persists.
0B07 — Object does not exist. —
0B0C — A hardware or firmware error
occurred. —
18 | ni.com | REM-11180 User Manual

Code
(hex)
Additional code Meaning Remedy
OBC1 —
Supply voltage not available for
the local bus. Too many devices
connected or the higher-level
power supply unit is too weak.
Use a suitable power
supply unit. Check the
power consumption of
the devices; if required,
use a power module for
communications power
or install an additional
Remote I/O system.
0BDE —
Synchronization failed. Trigger
signal does not correspond to the
specification.
Check the
synchronization signal
of the higher-level
system. Make sure that
the cycle time
specification is properly
selected.
Bus Diagnostic Error Codes
Code
(hex)
Additional
code
Meaning Remedy
0BD1 —
The bus could not be activated due to
bus malfunctions.
Check the bus
configuration.
0BF1 —
0BF2 —
0BF3 —
0C01 Device
number
The configured module is not
accessible. A device present in the
configuration frame has been
removed from the physical bus
structure after the configuration frame
has been connected.
Check the configuration.
Adapt the configuration
frame if the modification
was done on purpose.
0C02 Device
number
A module has been detected that was
not configured. An additional device
was added at the end of the physical
bus structure after the configuration
frame was connected.
Check the configuration.
Adapt the configuration
frame if the modification
was done on purpose.
REM-11180 User Manual | © National Instruments | 19

Code
(hex)
Additional
code
Meaning Remedy
0C11 Device
number
The module is not located in the
configured slot. An active device was
inserted at the different location of the
physical bus structure after the
configuration frame was connected.
Check the configuration.
Adapt the configuration
frame if the modification
was done on purpose.
0C12 Device
number
The module is accessible but was not
put into operation due to missing
parameters. An active device was
replaced by an unknown device in the
physical bus structure after the
configuration frame was connected
(wrong instance ID).
Check the configuration.
Adapt the configuration
frame if the modification
was done on purpose.
0C13 Device
number
The process data length does not
correspond to the configured value.
The process data width of an active
device was changed after the
configuration frame was connected.
Check the configuration.
Adapt the configuration
frame if the modification
was done on purpose.
0C14 Device
number
The module type does not correspond
to the configured value.
Check the configuration.
Adapt the configuration
frame if the modification
was done on purpose.
0C15 Device
number
The module ID does not correspond
to the configured value.
Check the configuration.
Adapt the configuration
frame if the modification
was done on purpose.
20 | ni.com | REM-11180 User Manual
