National Instruments IMAQ PCI-1428 User manual

IMAQ™
IMAQ PCI-1428
User Manual
High-Quality Camera Link Image
Acquisition Device for PCI
IMAQ PCI-1428 User Manual
January 2002 Edition
Part Number 322862B-01

Support
Worldwide Technical Support and Product Information
ni.com
National Instruments Corporate Headquarters
11500 North Mopac Expressway Austin, Texas 78759-3504 USA Tel: [phone]
Worldwide Offices
Australia 03 9879 5166, Austria 0662 45 79 90 0, Belgium 02 757 00 20, Brazil 011 3262 3599,
Canada (Calgary) 403 274 9391, Canada (Montreal) 514 288 5722, Canada (Ottawa) 613 233 5949,
Canada (Québec) 514 694 8521, Canada (Toronto) 905 785 0085, China (Shanghai) 021 6555 7838,
China (ShenZhen) 0755 3904939, Czech Republic 02 2423 5774, Denmark 45 76 26 00, Finland 09 725 725 11,
France 01 48 14 24 24, Germany 089 741 31 30, Greece 30 1 42 96 427, Hong Kong 2645 3186,
India 91 80 535 5406, Israel 03 6393737, Italy 02 413091, Japan 03 5472 2970, Korea 02 3451 3400,
Malaysia 603 9596711, Mexico 001 800 010 0793, Netherlands 0348 433466, New Zealand 09 914 0488,
Norway 32 27 73 00, Poland 0 22 528 94 06, Portugal 351 210 311 210, Russia 095 238 7139,
Singapore 2265886, Slovenia 386 3 425 4200, South Africa 11 805 8197, Spain 91 640 0085,
Sweden 08 587 895 00, Switzerland 056 200 51 51, Taiwan 02 2528 7227, United Kingdom 01635 523545
For further support information, see the Technical Support Resources appendix. To comment on the
documentation, send e-mail to [email protected].
©2001, 2002 National Instruments Corporation. All rights reserved.

Important Information
Warranty
The IMAQ PCI-1428 is warranted against defects in materials and workmanship for a period of one year from the date of shipment, as
evidenced by receipts or other documentation. National Instruments will, at its option, repair or replace equipment that proves to be defective
during the warranty period. This warranty includes parts and labor.
The media on which you receive National Instruments software are warranted not to fail to execute programming instructions, due to defects
in materials and workmanship, for a period of 90 days from date of shipment, as evidenced by receipts or other documentation. National
Instruments will, at its option, repair or replace software media that do not execute programming instructions if National Instruments receives
notice of such defects during the warranty period. National Instruments does not warrant that the operation of the software shall be
uninterrupted or error free.
A Return Material Authorization (RMA) number must be obtained from the factory and clearly marked on the outside of the package before
any equipment will be accepted for warranty work. National Instruments will pay the shipping costs of returning to the owner parts which are
covered by warranty.
National Instruments believes that the information in this document is accurate. The document has been carefully reviewed for technical
accuracy. In the event that technical or typographical errors exist, National Instruments reserves the right to make changes to subsequent
editions of this document without prior notice to holders of this edition. The reader should consult National Instruments if errors are suspected.
In no event shall National Instruments be liable for any damages arising out of or related to this document or the information contained in it.
EXCEPT AS SPECIFIED HEREIN, NATIONAL INSTRUMENTS MAKES NO WARRANTIES, EXPRESS OR IMPLIED, AND SPECIFICALLY DISCLAIMS ANY WARRANTY OF
MERCHANTABILITY OR FITNESS FOR APARTICULAR PURPOSE. CUSTOMER’SRIGHT TO RECOVER DAMAGES CAUSED BY FAULT OR NEGLIGENCE ON THE PART OF
NATIONAL INSTRUMENTS SHALL BE LIMITED TO THE AMOUNT THERETOFORE PAID BY THE CUSTOMER. NATIONAL INSTRUMENTS WILL NOT BE LIABLE FOR
DAMAGES RESULTING FROM LOSS OF DATA, PROFITS, USE OF PRODUCTS, OR INCIDENTAL OR CONSEQUENTIAL DAMAGES, EVEN IF ADVISED OF THE POSSIBILITY
THEREOF. This limitation of the liability of National Instruments will apply regardless of the form of action, whether in contract or tort, including
negligence. Any action against National Instruments must be brought within one year after the cause of action accrues. National Instruments
shall not be liable for any delay in performance due to causes beyond its reasonable control. The warranty provided herein does not cover
damages, defects, malfunctions, or service failures caused by owner’s failure to follow the National Instruments installation, operation, or
maintenance instructions; owner’s modification of the product; owner’s abuse, misuse, or negligent acts; and power failure or surges, fire,
flood, accident, actions of third parties, or other events outside reasonable control.
Copyright
Under the copyright laws, this publication may not be reproduced or transmitted in any form, electronic or mechanical, including photocopying,
recording, storing in an information retrieval system, or translating, in whole or in part, without the prior written consent of National
Instruments Corporation.
Trademarks
CVI™, IMAQ™, LabVIEW™, Measurement Studio™, National Instruments™, and ni.com™are trademarks of National Instruments
Corporation.
Product and company names mentioned herein are trademarks or trade names of their respective companies.
Patents
For patents covering National Instruments products, refer to the appropriate location: Help»Patents in your software, the patents.txt file
on your CD, or ni.com/patents.
WARNING REGARDING USE OF NATIONAL INSTRUMENTS PRODUCTS
(1) NATIONAL INSTRUMENTS PRODUCTS ARE NOT DESIGNED WITH COMPONENTS AND TESTING FOR A LEVEL OF
RELIABILITY SUITABLE FOR USE IN OR IN CONNECTION WITH SURGICAL IMPLANTS OR AS CRITICAL COMPONENTS IN
ANY LIFE SUPPORT SYSTEMS WHOSE FAILURE TO PERFORM CAN REASONABLY BE EXPECTED TO CAUSE SIGNIFICANT
INJURY TO A HUMAN.
(2) IN ANY APPLICATION, INCLUDING THE ABOVE, RELIABILITY OF OPERATION OF THE SOFTWARE PRODUCTS CAN BE
IMPAIRED BY ADVERSE FACTORS, INCLUDING BUT NOT LIMITED TO FLUCTUATIONS IN ELECTRICAL POWER SUPPLY,
COMPUTER HARDWARE MALFUNCTIONS, COMPUTER OPERATING SYSTEM SOFTWARE FITNESS, FITNESS OF COMPILERS
AND DEVELOPMENT SOFTWARE USED TO DEVELOP AN APPLICATION, INSTALLATION ERRORS, SOFTWARE AND
HARDWARE COMPATIBILITY PROBLEMS, MALFUNCTIONS OR FAILURES OF ELECTRONIC MONITORING OR CONTROL
DEVICES, TRANSIENT FAILURES OF ELECTRONIC SYSTEMS (HARDWARE AND/OR SOFTWARE), UNANTICIPATED USES OR
MISUSES, OR ERRORS ON THE PART OF THE USER OR APPLICATIONS DESIGNER (ADVERSE FACTORS SUCH AS THESE ARE
HEREAFTER COLLECTIVELY TERMED “SYSTEM FAILURES”). ANY APPLICATION WHERE A SYSTEM FAILURE WOULD
CREATE A RISK OF HARM TO PROPERTY OR PERSONS (INCLUDING THE RISK OF BODILY INJURY AND DEATH) SHOULD
NOT BE RELIANT SOLELY UPON ONE FORM OF ELECTRONIC SYSTEM DUE TO THE RISK OF SYSTEM FAILURE. TO AVOID
DAMAGE, INJURY, OR DEATH, THE USER OR APPLICATION DESIGNER MUST TAKE REASONABLY PRUDENT STEPS TO
PROTECT AGAINST SYSTEM FAILURES, INCLUDING BUT NOT LIMITED TO BACK-UP OR SHUT DOWN MECHANISMS.
BECAUSE EACH END-USER SYSTEM IS CUSTOMIZED AND DIFFERS FROM NATIONAL INSTRUMENTS' TESTING
PLATFORMS AND BECAUSE A USER OR APPLICATION DESIGNER MAY USE NATIONAL INSTRUMENTS PRODUCTS IN
COMBINATION WITH OTHER PRODUCTS IN A MANNER NOT EVALUATED OR CONTEMPLATED BY NATIONAL
INSTRUMENTS, THE USER OR APPLICATION DESIGNER IS ULTIMATELY RESPONSIBLE FOR VERIFYING AND VALIDATING
THE SUITABILITY OF NATIONAL INSTRUMENTS PRODUCTS WHENEVER NATIONAL INSTRUMENTS PRODUCTS ARE
INCORPORATED IN A SYSTEM OR APPLICATION, INCLUDING, WITHOUT LIMITATION, THE APPROPRIATE DESIGN,
PROCESS AND SAFETY LEVEL OF SUCH SYSTEM OR APPLICATION.

Compliance
FCC/Canada Radio Frequency Interference Compliance*
Determining FCC Class
The Federal Communications Commission (FCC) has rules to protect wireless communications from interference. The FCC
places digital electronics into two classes. These classes are known as Class A (for use in industrial-commercial locations only)
or Class B (for use in residential or commercial locations). Depending on where it is operated, this product could be subject to
restrictions in the FCC rules. (In Canada, the Department of Communications (DOC), of Industry Canada, regulates wireless
interference in much the same way.)
Digital electronics emit weak signals during normal operation that can affect radio, television, or other wireless products. By
examining the product you purchased, you can determine the FCC Class and therefore which of the two FCC/DOC Warnings
apply in the following sections. (Some products may not be labeled at all for FCC; if so, the reader should then assume these are
Class A devices.)
FCC Class A products only display a simple warning statement of one paragraph in length regarding interference and undesired
operation. Most of our products are FCC Class A. The FCC rules have restrictions regarding the locations where FCC Class A
products can be operated.
FCC Class B products display either a FCC ID code, starting with the letters EXN,
or the FCC Class B compliance mark that appears as shown here on the right.
Consult the FCC Web site http://www.fcc.gov for more information.
FCC/DOC Warnings
This equipment generates and uses radio frequency energy and, if not installed and used in strict accordance with the instructions
in this manual and the CE Mark Declaration of Conformity**, may cause interference to radio and television reception.
Classification requirements are the same for the Federal Communications Commission (FCC) and the Canadian Department
of Communications (DOC).
Changes or modifications not expressly approved by National Instruments could void the user’s authority to operate the
equipment under the FCC Rules.
Class A
Federal Communications Commission
This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC
Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated
in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and
used in accordance with the instruction manual, may cause harmful interference to radio communications. Operation of this
equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct
the interference at his own expense.
Canadian Department of Communications
This Class A digital apparatus meets all requirements of the Canadian Interference-Causing Equipment Regulations.
Cet appareil numérique de la classe A respecte toutes les exigences du Règlement sur le matériel brouilleur du Canada.
Class B
Federal Communications Commission
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the
FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can
be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of
the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.

Canadian Department of Communications
This Class B digital apparatus meets all requirements of the Canadian Interference-Causing Equipment Regulations.
Cet appareil numérique de la classe B respecte toutes les exigences du Règlement sur le matériel brouilleur du Canada.
European Union - Compliance to EEC Directives
Readers in the EU/EEC/EEA must refer to the Manufacturer's Declaration of Conformity (DoC) for information** pertaining
to the CE Mark compliance scheme. The Manufacturer includes a DoC for most every hardware product except for those bought
for OEMs, if also available from an original manufacturer that also markets in the EU, or where compliance is not required as
for electrically benign apparatus or cables.
* Certain exemptions may apply in the USA, see FCC Rules §15.103 Exempted devices, and §15.105(c). Also available in
sections of CFR 47.
** The CE Mark Declaration of Conformity will contain important supplementary information and instructions for the user or
installer.

Conventions
This manual uses the following conventions:
<> Angle brackets that contain numbers separated by an ellipsis represent a
range of values associated with a bit or signal name—for example,
DBIO<3..0>.
»The »symbol leads you through nested menu items and dialog box options
to a final action. The sequence File»Page Setup»Options directs you to
pull down the File menu, select the Page Setup item, and select Options
from the last dialog box.
This icon denotes a note, which alerts you to important information.
This icon denotes a caution, which advises you of precautions to take to
avoid injury, data loss, or a system crash.
bold Bold text denotes items that you must select or click on in the software,
such as menu items and dialog-box options. Bold text also denotes
parameter names.
italic Italic text denotes variables, emphasis, a cross reference, or an introduction
to a key concept. This font also denotes text that is a placeholder for a word
or value that you must supply.
monospace Text in this font denotes text or characters that you should enter from the
keyboard, sections of code, programming examples, and syntax examples.
This font is also used for the proper names of disk drives, paths, directories,
programs, subprograms, subroutines, device names, functions, operations,
variables, filenames and extensions, and code excerpts.

©National Instruments Corporation vii IMAQ PCI-1428 User Manual
Contents
Chapter 1
Introduction
About the IMAQ PCI-1428 ...........................................................................................1-1
Camera Link ..................................................................................................................1-2
Overview .........................................................................................................1-2
Interfacing with the PCI-1428 .......................................................................................1-2
Software Programming Choices ....................................................................................1-3
NI-IMAQ Driver Software ..............................................................................1-5
National Instruments IMAQ Vision ................................................................1-6
IMAQ Vision Builder......................................................................................1-6
Integration with DAQ......................................................................................1-7
Vision and Motion...........................................................................................1-7
Chapter 2
Installation
What You Need to Get Started ......................................................................................2-1
Optional Equipment.......................................................................................................2-2
Setting up Your IMAQ System .....................................................................................2-2
Unpacking......................................................................................................................2-4
Safety Information .........................................................................................................2-4
Installation .....................................................................................................................2-6
Configuring the PCI-1428 .............................................................................................2-7
Chapter 3
Hardware Overview
Functional Overview......................................................................................................3-1
Camera Link and PCI-1428.............................................................................3-2
Base Configuration ...........................................................................3-2
Medium Configuration......................................................................3-3
Data Transmission ...........................................................................................3-3
LUTs................................................................................................................3-3
Multiple-Tap Data Formatter ..........................................................................3-4
SDRAM...........................................................................................................3-4
Trigger Control and Mapping Circuitry ..........................................................3-4
High-Speed Timing .........................................................................................3-4
Acquisition, Scaling, ROI................................................................................3-5
Scatter-Gather DMA Controllers ....................................................................3-5
Bus Master PCI Interface ................................................................................3-5

Contents
IMAQ PCI-1428 User Manual viii ni.com
Start Conditions............................................................................................... 3-5
Acquisition Window Control .......................................................................... 3-6
Serial Interface ................................................................................................ 3-6
Chapter 4
Signal Connections
Connectors..................................................................................................................... 4-1
MDR 26-Pin Connector .................................................................................. 4-2
68-Pin VHDCI Connector............................................................................... 4-2
Connector Signal Connection Descriptions .................................................... 4-3
Appendix A
Specifications
Appendix B
Cabling
Appendix C
Technical Support Resources
Glossary
Index

©National Instruments Corporation 1-1 IMAQ PCI-1428 User Manual
1
Introduction
This chapter provides an overview of the PCI-1428 image acquisition
device, the Camera Link standard, Camera Link/PCI-1428 interfacing
guidelines, and your software programming choices.
About the IMAQ PCI-1428
The PCI-1428 is a highly flexible IMAQ device that supports a diverse
range of Camera Link-compatible cameras from various camera
companies. The PCI-1428 acquires digital images in real time and stores
the images in onboard frame memory or transfers them directly to system
memory. Featuring a high-speed data flow path, the PCI-1428 is ideal for
both industrial and scientific environments.
The PCI-1428 is easy to install and configure. It ships with NI-IMAQ, the
National Instruments complete IMAQ driver software you can use to
directly control the PCI-1428 and other National Instruments IMAQ
hardware products. With NI-IMAQ, you can quickly and easily start your
applications without having to program the device at the register level.
The PCI-1428 supports the Camera Link Base configuration, and the
VHDCI 68-pin connector provides access to the 8-bit × 4 mode of the
Camera Link Medium configuration. For further configuration
information, see the Camera Link and PCI-1428 section in Chapter 3,
Hardware Overview.
The VHDCI 68-pin connector has four external input/output (I/O) lines you
can use as triggers or as high-speed digital I/O lines.
Note To use the trigger lines as digital I/O lines, go to the LabVIEW palette, and select
Motion & Vision»Image Acquisition»Signal I/O VIs.
For more advanced digital or analog system triggering or digital I/O lines,
you can use the PCI-1428 and NI-IMAQ with the National Instruments data
acquisition (DAQ) or motion control product lines.

Chapter 1 Introduction
IMAQ PCI-1428 User Manual 1-2 ni.com
Easily synchronizing several functions to a common trigger or timing event
is a common challenge with image acquisition devices. The PCI-1428 uses
the Real-Time System Integration (RTSI) bus to solve this problem. The
RTSI bus uses National Instruments RTSI bus interface and ribbon cable to
route additional timing and trigger signals between the PCI-1428 and up to
four National Instruments DAQ, motion control, or IMAQ devices. The
RTSI bus can even synchronize multiple IMAQ hardware captures.
Detailed specifications of the PCI-1428 are in Appendix A, Specifications.
Camera Link
This section provides a brief overview of the Camera Link standard.
For more detailed information about Camera Link specifications, reference
the Specifications of the Camera Link Interface Standard for Digital
Cameras and Frame Grabbers manual. This manual is available on several
Web sites, including the Automated Imaging Association site at
machinevisiononline.org.
Overview
Developed by a consortium of camera and frame grabber manufacturers,
Camera Link is a standard for interfacing digital cameras with image
acquisition devices. Camera Link simplifies connectivity between the
image acquisition device and the camera by defining a single standard
connector for both. This standard ensures compatibility of devices bearing
the Camera Link logo.
The basis for the Camera Link standard is the National Semiconductor
Channel Link chipset, a data transmission method consisting of a
general-purpose transmitter/receiver pair. The Channel Link driver takes
28 bits of parallel digital data and a clock and serializes the stream to four
LVDS (EIA-644) data streams and an LVDS clock, providing high-speed
data transmission across 10 wires and over distances of up to 10 m.
Interfacing with the PCI-1428
The Camera Link standard defines physical connections between image
acquisition devices and Camera Link cameras, and it allows for flexibility
of image format and data transfer protocols. The camera manufacturer
defines image parameters, such as image resolution and the number of bits
per pixel. Camera control parameters, such as frame-on-demand and
exposure control signals, are also defined by the camera manufacturer.

Chapter 1 Introduction
©National Instruments Corporation 1-3 IMAQ PCI-1428 User Manual
These variable parameters are defined on a per-camera basis in a camera
file (camera_model.icd) supplied by National Instruments. The
NI-IMAQ driver software uses the information in this camera file to
program the PCI-1428 to acquire images from a specific camera. Without
this camera file, the driver does not have the information necessary to
configure the PCI-1428 for acquisition.
Measurement & Automation Explorer (MAX), the National Instruments
configuration utility, provides a simple interface for associating a camera
file with the PCI-1428. Use the following guidelines to access the camera
file in MAX:
1. Launch MAX, and expand the Devices and Interfaces branch of the
configuration tree.
2. Expand the IMAQ PCI-1428 branch.
3. Right-click Channel 0, and select Camera.
4. Select your camera from the pop-up menu. If your camera is not in
the pop-up menu, verify that the camera file is installed in the
NI-IMAQ/Data directory.
Many camera files are installed on your computer when you install
NI-IMAQ, and many more are available for download from the National
Instruments Camera Advisor at ni.com\camera. When installing new
camera files, save them to the Data folder located at Program Files\
National Instruments\NI-IMAQ\Data.
Contact National Instruments technical support to request camera files not
available in the Camera Advisor. See Appendix C, Technical Support
Resources, for information on National Instruments technical support.
Software Programming Choices
Use NI-IMAQ, the National Instruments image acquisition driver software,
to program your IMAQ device to acquire, display, and save images. You
can use NI-IMAQ with other National Instruments software for a complete
image acquisition and analysis solution, as shown in Figure 1-1.
NI-IMAQ works with LabVIEW, LabWindows/CVI, Visual C++, and
Visual Basic. National Instruments IMAQ Vision adds powerful image
processing and analysis to these programming environments. You can also
use IMAQ Vision Builder to quickly and easily prototype your IMAQ
image analysis applications.

Chapter 1 Introduction
IMAQ PCI-1428 User Manual 1-4 ni.com
Figure 1-1. The Relationship between the Programming Environment,
NI-IMAQ, and Hardware
Vision Software
IMAQ Vision
Gauging and
Measurement
Pattern
Matching
Blob
Analysis
Analysis
Morphology
Display
and ROI
Color Matching
and Analysis
Filters
Application Software
Measurement Studio
(LabWindows/CVI, Visual C++, Visual Basic)
LabVIEW
Driver Software
NI-MotionNI-DAQNI-IMAQ
Hardware
ValueMotion/
FlexMotion
DAQIMAQ

Chapter 1 Introduction
©National Instruments Corporation 1-5 IMAQ PCI-1428 User Manual
NI-IMAQ Driver Software
The NI-IMAQ driver software is included with your IMAQ device.
NI-IMAQ has an extensive library of functions you can call from your
application programming environment. These functions include routines
for video configuration, image acquisition (continuous and single-shot),
memory buffer allocation, trigger control, and device configuration,
as shown in Figure 1-2.
Figure 1-2. NI-IMAQ Functions
The NI-IMAQ driver software performs all functions required for acquiring
and saving images, but it does not perform any image analysis. For image
analysis functionality, refer to the National Instruments IMAQ Vision
section in this chapter.
For maximum flexibility and performance, NI-IMAQ features both
high-level and low-level functions. Examples of high-level functions
include the functions to acquire images in single-shot or continuous mode.
An example of a low-level function is configuring an image sequence, since
it requires advanced understanding of the IMAQ device and image
acquisition.
NI-IMAQ internally resolves many of the complex issues between the
computer and the IMAQ device, such as programming interrupts and DMA
controllers.
NI-IMAQ is also the interface path between LabVIEW, LabWindows/CVI,
or a text-based programming environment and your IMAQ device. The
NI-IMAQ software kit includes a series of libraries for image acquisition
for LabVIEW and Measurement Studio, which contains libraries for
LabWindows/CVI, Visual C++, and Visual Basic.
NI-IMAQ
Buffer ControlImage
Acquisition
Camera Control Lookup Table
Control
DAQ
Synchronization
Triggering
and Timing

Chapter 1 Introduction
IMAQ PCI-1428 User Manual 1-6 ni.com
National Instruments IMAQ Vision
IMAQ Vision is an image acquisition, processing, and analysis library of
more than 200 functions for grayscale, color, and binary image display,
image processing, pattern matching, shape matching, blob analysis,
gauging, and measurement.
For unique image processing, you can use IMAQ Vision functions
individually or in combination. With IMAQ Vision you can acquire,
display, manipulate, and store images as well as perform image analysis,
processing, and interpretation. Using IMAQ Vision, imaging novices and
experts can program the most basic or complicated image applications
without knowledge of any algorithm implementations.
IMAQ Vision is available for LabVIEW and Measurement Studio, which
includes support for LabWindows/CVI, Visual C++, and Visual Basic.
IMAQ Vision Builder
IMAQ Vision Builder is an interactive prototyping tool for machine vision
and scientific imaging developers. With IMAQ Vision Builder, you can
prototype vision software quickly or test how various vision image
processing functions work.
As shown in Figure 1-3, IMAQ Vision Builder generates a Builder file,
which is a text description containing a recipe of the machine vision
and image processing functions. This Builder file provides a guide you can
use for developing applications into any development environment, such as
LabWindows/CVI or Visual Basic, using the IMAQ Vision machine vision
and image processing libraries. Using the LabVIEW VI creation wizard,
you can create a LabVIEW VI that performs the prototype that you created
in IMAQ Vision Builder.

Chapter 1 Introduction
©National Instruments Corporation 1-7 IMAQ PCI-1428 User Manual
Figure 1-3. IMAQ Vision Builder and Application Development Tools
Integration with DAQ
Any platform that supports NI-IMAQ also supports NI-DAQ and a variety
of National Instruments DAQ devices, allowing your IMAQ device and
NI-IMAQ development to integrate with National Instruments DAQ
products.
Vision and Motion
With National Instruments IMAQ hardware and IMAQ Vision
pattern-matching software, you can quickly and accurately locate objects in
instances where objects vary in size, orientation, focus, and even when the
part is poorly illuminated. Use National Instruments high-performance
stepper and servo motion control products with pattern-matching software
for inspection and guidance applications, such as locating alignment
markers on semiconductor wafers, guiding robotic arms, inspecting the
quality of manufactured parts, and locating cells.
Application
Software
Prototype
Vision Application
Development
IMAQ
Vision Builder
Builder File
IMAQ Vision
IMAQ Vision
LabVIEW

©National Instruments Corporation 2-1 IMAQ PCI-1428 User Manual
2
Installation
This chapter contains a list of necessary and optional items for getting
started acquiring images with your IMAQ device. This chapter also
explains how to unpack, configure, and install your IMAQ device.
What You Need to Get Started
You need the following items to set up and use the PCI-1428:
❑PCI-1428
❑Getting Started with Your IMAQ System
❑IMAQ PCI-1428 User Manual
❑NI-IMAQ Release Notes
❑NI-IMAQ for Windows 2000/NT/Me/9xand documentation
❑Pentium-based PCI computer running Windows XP/2000/Me/NT/9x
❑Camera Link camera
❑MDR 26-pin Camera Link cable from 3M
❑Optional software packages and documentation:
– IMAQ Vision for LabVIEW or Measurement Studio
(LabWindows/CVI, Visual C++, Visual Basic)
–IMAQVisionBuilder
–LabVIEW
– Measurement Studio (LabWindows/CVI, tools for Visual Basic)

Chapter 2 Installation
IMAQ PCI-1428 User Manual 2-2 ni.com
Optional Equipment
National Instruments offers a variety of products for use with the PCI-1428,
including the following:
• MDR 26-pin Camera Link cable from 3M for Base configuration
• IMAQ D6804 breakout cable (for external triggering only)
• RTSI bus cables for connecting the PCI-1428 to other IMAQ,
motion control, or DAQ devices
• Other National Instruments DAQ devices for enhanced triggering,
timing, or input/output
For more specific information about these products, refer to the
National Instruments catalog or Web site, or call the office nearest you.
Setting up Your IMAQ System
Use Figure 2-1 while installing software and hardware, configuring
hardware, and using NI-IMAQ in application programs.
Follow the instructions in the Getting Started with Your IMAQ System
document while installing the NI-IMAQ software and IMAQ hardware.
When accessing the NI-IMAQ device drivers through a programming
environment, read the NI-IMAQ Release Notes and the NI-IMAQ User
Manual for help in getting started.

Chapter 2 Installation
©National Instruments Corporation 2-3 IMAQ PCI-1428 User Manual
Figure 2-1. How to Set up Your IMAQ System
Measurement Studio
(LabWindows/CVI, Visual C++,
Borland C++)
LabVIEW What
application software
are you using?
Configure your hardware using
Measurement & Automation Explorer and
online help.
Read the
Getting Started with Your IMAQ System
document and the NI-IMAQ release notes to install
your NI-IMAQ software, IMAQ hardware,
and documentation.
Measurement
Studio
(Visual Basic) Read Chapter 1,
Introduction
to NI-IMAQ
, in the
NI-IMAQ User Manual .
Read the sections in
chapters 2 and 3 in the
NI-IMAQ
User Manual
that apply to the
function groups you
will use in your application.
Look at the self-documented
example source code on your
distribution CD for your
application language
and environment.
Use the
NI-IMAQ Function
Reference Manual
when you
need specific information about
individual NI-IMAQ functions.
If you are using IMAQ Vision for
LabWindows/CVI, read the
documentation for IMAQ Vision
for LabWindows/CVI.
Read:
•The section in chapter 4 in the
NI-IMAQ User Manual for
information on using LabVIEW
with your IMAQ hardware.
•NI-IMAQ VI online help
•Your IMAQ Vision for
LabVIEW documentation
if you are using IMAQ
Vision for LabVIEW
Read the NI-IMAQ User Manual
for information on using
NI-IMAQ in your
application environment.

Chapter 2 Installation
IMAQ PCI-1428 User Manual 2-4 ni.com
Unpacking
The PCI-1428 ships in an antistatic package to prevent electrostatic
discharge from damaging board components. To avoid such damage in
handling the board, take the following precautions:
• Ground yourself via a grounding strap or by holding a grounded object,
such as your computer chassis.
• Touch the antistatic package to a metal part of your computer chassis
before removing the board from the package.
• Remove the board from the package and inspect the board for loose
components or any other signs of damage. Notify National Instruments
if the board appears damaged in any way. Do not install a damaged
board in your computer.
•Never touch the exposed pins of connectors.
Safety Information
Caution The following paragraphs contain important safety information you must follow
when installing and operating the device.
Do not operate the device in a manner not specified in the documentation.
Misuse of the device may result in a hazard and may compromise the safety
protection built into the device. If the device is damaged, turn it off and do
not use it until service-trained personnel can check its safety. If necessary,
return the device to National Instruments for repair.
Keep away from live circuits. Do not remove equipment covers or shields
unless you are trained to do so. If signal wires are connected to the device,
hazardous voltages can exist even when the equipment is turned off. To
avoid a shock hazard, do not perform procedures involving cover or shield
removal unless you are qualified to do so. Disconnect all field power prior
to removing covers or shields.
If the device is rated for use with hazardous voltages (>30 Vrms, 42.4 Vpk,
or 60 Vdc), it may require a safety earth-ground connection wire. See the
device specifications for maximum voltage ratings.
Because of the danger of introducing additional hazards, do not install
unauthorized parts or modify the device. Use the device only with the
chassis, modules, accessories, and cables specified in the installation

Chapter 2 Installation
©National Instruments Corporation 2-5 IMAQ PCI-1428 User Manual
instructions. All covers and filler panels must be installed while operating
the device.
Do not operate the device in an explosive atmosphere or where flammable
gases or fumes may be present. Operate the device only at or below the
pollution degree stated in the specifications. Pollution consists of any
foreign matter—solid, liquid, or gas—that may reduce dielectric strength
or surface resistivity. Pollution degrees are listed below.
• Pollution Degree 1—No pollution or only dry, nonconductive
pollution occurs. The pollution has no effect.
• Pollution Degree 2—Normally only nonconductive pollution occurs.
Occasionally, nonconductive pollution becomes conductive because of
condensation.
• Pollution Degree 3—Conductive pollution or dry, nonconductive
pollution occurs. Nonconductive pollution becomes conductive
because of condensation.
Clean the device and accessories by brushing off light dust with a soft,
nonmetallic brush. Remove other contaminants with a stiff, nonmetallic
brush. The unit must be completely dry and free from contaminants before
returning it to service.
You must insulate signal connections for the maximum voltage for which
the device is rated. Do not exceed the maximum ratings for the device.
Remove power from signal lines before connection to or disconnection
from the device.
Operate this device only at or below the installation category stated in the
specifications. Installation categories are listed below.
• Installation Category IV—for measurements performed at the source
of the low-voltage (<1000 V) installation. Examples include electricity
meters, measurements on primary overcurrent protection devices,
and ripple-control units.
• Installation Category III—for measurements performed in the building
installation. Examples include measurements on distribution boards,
circuit-breakers, wiring (including cables), bus bars, junction boxes,
switches, socket outlets in the fixed installation, equipment for
industrial use, and some other types of equipment, such as stationary
motors permanently connected to the fixed installation.
• Installation Category II—for measurements performed on circuits
directly connected to the low-voltage installation. Examples include
