OPERATING INSTRUCTIONS AND SPECIFICATIONS
NI 9146
Ethernet Expansion Chassis for C Series Modules
Figure 1. NI 9146 Front Panel
This document describes how to connect the NI 9146 to a network and
how to use the features of the NI 9146. This document also contains
specifications for the NI 9146.
1LEDs
2 RJ-45 Ethernet Port
3 Power Connector
4 Reset Button
C
V
POWER POWER
STATUS
USER FPGA1
NI 9146
INPUT
9-30 V
15 W MAX
M
N
S
AN
NI
TIO
RT UT
LA
EN S
ACT/
LINK
10/100
1
2
3
RESET
4

NI 9146 Operating Instructions and Specifications 2 ni.com
Safety Guidelines
Operate the NI 9146 only as described in these operating instructions.
Safety Guidelines for Hazardous Locations
The NI 9146 is suitable for use in Class I, Division 2, Groups A, B, C, D,
T4 hazardous locations; Class 1, Zone 2, AEx nC IIC T4 and Ex nL IIC T4
hazardous locations; and nonhazardous locations only. Follow these
guidelines if you are installing the NI 9146 in a potentially explosive
environment. Not following these guidelines may result in serious injury or
death.
Caution Do not disconnect the power supply wires and connectors from the controller
unless power has been switched off.
Caution Substitution of components may impair suitability for Class I, Division 2.
Caution For Zone 2 applications, install the CompactRIO system in an enclosure rated to
at least IP 54 as defined by IEC 60529 and EN 60529.
Special Conditions for Hazardous Locations Use
in Europe
Some chassis have been evaluated as Ex nA nL IIC T4 equipment under
DEMKO Certificate No. 07 ATEX 0626664X. Each such chassis is marked
II 3G and is suitable for use in Zone 2 hazardous locations, in ambient
temperatures of –40 ≤Ta ≤ 70 °C.
Special Conditions for Marine Applications
Some chassis are Lloyd’s Register (LR) Type Approved for marine
applications. To verify Lloyd’s Register certification, visit ni.com/
certification and search for the LR certificate, or look for the
Lloyd’s Register mark on the chassis.
What You Need to Install the NI 9146 Ethernet
Expansion Chassis
❑NI 9146 Ethernet expansion chassis
❑NI-RIO Software DVD
❑C Series I/O modules

©National Instruments 3 NI 9146 Operating Instructions and Specifications
❑DIN rail mount kit (for DIN rail mounting only)
❑Panel mount kit (for panel mounting only)
❑Two M4 or number 8 flathead screws (for mounting the chassis
without one of the listed mounting kits)
❑A number 2 Phillips screwdriver
❑Power supply
❑Ethernet cable
Notes Visit ni.com/info and enter the Info Code rdsoftwareversion to determine
which software you need to use the NI 9146.
Mounting the Chassis
You can mount the chassis horizontally on a flat, vertical, metallic surface
such as a panel or wall. The maximum allowable ambient temperature
for operation in this configuration is 70 °C. Figure 2 shows the chassis
mounted horizontally.
Figure 2. NI 9146 Mounted Horizontally
You can also mount the chassis on a panel or wall in other orientations, on
a non-metallic surface, on a 35 mm DIN rail, on a rack, in an enclosure, or
on a desktop. Mounting the chassis in these or other configurations can
reduce the maximum allowable ambient temperature and can affect the
typical accuracy of modules in the chassis.
Note For information about how different mounting configurations can cause temperature
derating, go to ni.com/info and enter the Info Code criomounting.
Note For information about typical accuracy specifications for modules, go to ni.com/
info and enter the Info Code criotypical.
C
V
RESET
POWER POWER
POWER
STATUS
STATUS
USER FPGA1
USER FPGA1
NI 9146
INPUT
9-30 V
15 W MAX
M
N
S
AN
NI
TIO
RT UT
LA
EN S
ACT/
LINK
10/100
Up

NI 9146 Operating Instructions and Specifications 4 ni.com
Note Measure the ambient temperature at each side of the chassis, 63.5 mm (2.5 in.) from
the side and 25.4 mm (1 in.) forward from the rear of the chassis, as shown in Figure 3.
Caution Your installation must meet the following requirements for space and cabling
clearance:
• Allow 25.4 mm (1 in.) on the top and the bottom of the chassis for air circulation.
• Allow 50.8 mm (2 in.) in front of modules for cabling clearance for common
connectors, such as the 10-terminal, detachable screw terminal connector, as shown
in Figure 3.
Figure 3. NI 9146, Bottom View with Dimensions
Note Go to ni.com/info and enter the Info Code rdcrioconn to find the minimum
cabling clearance for C Series modules with other connector types.
Figure 4. NI 9146, Front View with Dimensions
1 Measure ambient temperature here. 2 Chassis Grounding Screw
4 mm
(0.16 in.)
178.1 mm
(7.01 in.)
29.1 mm
(1.14 in.)
64.3mm
(2.53in.)
48.4 mm
(1.91 in.)
Cabling Clearance
50.8 mm (2.00 in.)
2
25.4 mm
(1 in.)
63.5 mm
(2.50 in.)
1
63.5 mm
(2.50 in.)
1
25.4 mm
(1 in.)
C
V
RESET
POWER POWERPOWER
STATUS
STATUS
USER FPGA1USER FPGA1
NI 9146
INPUT
9-30 V
15 W MAX
M
N
S
AN
NI
TIO
RT UT
LA
EN S
ACT/
LINK
10/100
87.3mm
(3.44 in.)
41.1 mm
(1.62 in.)
47.0 mm
(1.85 in.)
47.2 mm
(1.86 in.)
30.6 mm
(1.2 in.)
Cooling Outline 25.4 mm (1 in.)
Cooling Outline 25.4 mm (1 in.)

©National Instruments 5 NI 9146 Operating Instructions and Specifications
Figure 5. NI 9146, Side View with Dimensions
The following sections contain instructions for the mounting methods.
Before using any of these mounting methods, record the serial number from
the back of the chassis. You will be unable to read the serial number after
you have mounted the chassis.
Caution Make sure that no I/O modules are in the chassis before mounting it.
Mounting the Chassis on a Flat Surface
Using the NI 9904 Panel Mount Kit
Panel or wall mounting is the best method for applications that are subject
to high shock and vibration. You can use the NI 9904 panel mount kit to
mount the NI 9146 on a flat surface. Complete the following steps.
1. Fasten the chassis to the panel mount kit using a number 2 Phillips
screwdriver and two M4 ×25 screws. National Instruments provides
these screws with the panel mount kit. You must use these screws
because they are the correct depth and thread for the panel. Tighten the
screws to a maximum torque of 1.3 N ⋅m (11.5 lb ⋅in.).
]
2X M4X0.7
44.0 mm
(1.73in.)
74.0 mm
(2.91 in.)
29.1 mm
(1.15 in.)
44.1 mm
(1.54 in.)

NI 9146 Operating Instructions and Specifications 6 ni.com
Figure 6. Installing the Panel Mount Accessory on the NI 9146
Figure 7. Dimensions of NI 9146 with Panel Mount Accessory Installed
2. Fasten the NI 9904 panel to the wall using the screwdriver and screws
that are appropriate for the wall surface. The maximum screw size is
M4 or number 8.
Caution Make sure that no I/O modules are in the chassis before removing it from the
panel.
C
V
RESET
POWER POWER
POWER
STATUS
STATUS
USER FPGA1
USER FPGA1
NI 9146
INPUT
9-30 V
15 W MAX
M
N
S
AN
NI
TIO
RT UT
LA
EN S
ACT/
LINK
10/100
29.5 mm
(1.16 in.)
9.5 mm
(0.38 in.)
27.3mm
(1.08 in.)
215.9 mm
(8.5 in.)
235.0 mm
(9.25 in.)
31.7 mm
(1.25 in.) 63.5 mm
(2.50 in.)
88.1 mm
(3.47 in.)
7.2 mm
(0.29 in.)

©National Instruments 7 NI 9146 Operating Instructions and Specifications
Mounting the Chassis Directly on a Flat Surface
Using the Mounting Holes
Panel or wall mounting is the best method for applications that are subject
to high shock and vibration. If you do not have the NI 9904 panel mount kit
and do not require the portability that the NI 9904 affords, you can mount
the chassis directly on a flat surface using the mounting holes. Complete
the following steps.
1. Align the chassis on the surface.
2. Fasten the chassis to the surface using M4 or number 8 flathead screws,
as shown in Figure 8. National Instruments does not provide these
screws with the chassis.
Figure 8. Mounting the Chassis Directly on a Flat Surface
Caution Make sure that no I/O modules are in the chassis before removing it from the
surface.
Mounting the Chassis on a DIN Rail
You can order the NI 9912 DIN rail mount kit if you want to mount the
chassis on a DIN rail. You need one clip for mounting the chassis on a
standard 35 mm DIN rail. Complete the following steps to mount the
chassis on a DIN rail.
1. Fasten the DIN rail clip to the chassis using a number 2 Phillips
screwdriver and two M4 ×25 screws. National Instruments provides
these screws with the DIN rail mount kit. Tighten the screws to a
maximum torque of 1.3 N ⋅m (11.5 lb ⋅in.).
C
V
RESET
POWER POWER
POWER
STATUS
STATUS
USER FPGA1
USER FPGA1
NI 9146
INPUT
9-30 V
15 W MAX
M
N
S
AN
NI
TIO
RT UT
LA
EN S
ACT/
LINK
10/100

NI 9146 Operating Instructions and Specifications 8 ni.com
Figure 9. Installing the DIN Rail Clip on the NI 9146
2. Insert one edge of the DIN rail into the deeper opening of the DIN rail
clip, as shown in Figure 10.
Figure 10. One Edge of the DIN Rail Inserted in a Clip
3. Press down firmly on the chassis to compress the spring until the clip
locks in place on the DIN rail.
Caution Make sure that no I/O modules are in the chassis before removing it from the
DIN rail.
1 DIN Rail Clip 2 DIN Rail 3 DIN Rail Spring
3
2
1

©National Instruments 9 NI 9146 Operating Instructions and Specifications
Mounting the Chassis on a Desktop
Using the NI 9901 Desktop Mounting Kit
You can use the NI 9901 desktop mounting kit to mount the chassis on a
desktop. You must install the adapter bracket using two M3 ×20 screws.
The adapter bracket and the screws are included in the kit. Refer to the
NI 9901 documentation for information about mounting the chassis on a
desktop.
Installing C Series I/O Modules in the Chassis
Figure 11 shows the mechanical dimensions of C Series I/O modules.
Figure 11. C Series I/O Module, Front and Side View with Dimensions
Complete the following steps to install a C Series I/O module in the chassis.
1. Make sure that no I/O-side power is connected to the I/O module. If the
system is in a nonhazardous location, the chassis power can be on
when you install I/O modules.
2. Align the I/O module with an I/O module slot in the chassis as shown
in Figure 12. The module slots are labeled 1 to 4, left to right.
88.1 mm
(3.47 in.)
70.7 mm
(2.78 in.)
22.9 mm
(0.9 in.)

NI 9146 Operating Instructions and Specifications 10 ni.com
Figure 12. Installing an I/O Module in the Chassis
3. Squeeze the latches and insert the I/O module into the module slot.
4. Press firmly on the connector side of the I/O module until the latches
lock the I/O module into place.
5. Repeat these steps to install additional I/O modules.
Removing I/O Modules from the Chassis
Complete the following steps to remove a C Series I/O module from the
chassis.
1. Make sure that no I/O-side power is connected to the I/O module. If the
system is in a nonhazardous location, the chassis power can be on
when you remove I/O modules.
2. Squeeze the latches on both sides of the module and pull the module
out of the chassis.
1 Insertion Groove 2 Latch
1
2

©National Instruments 11 NI 9146 Operating Instructions and Specifications
Connecting the Chassis to Earth Ground
You must connect the chassis grounding screw to earth ground. Refer to
Figure 3 for the location of the grounding screw. Complete the following
steps to connect to earth ground:
1. Attach a ring lug to a 1.6 mm2(14 AWG) or larger wire.
2. Remove the grounding screw from the grounding terminal on the right
side of the chassis.
3. Attach the ring lug to the grounding terminal.
4. Tighten the grounding screw to 0.5 N · m (4.4 lb · in.) of torque.
5. Attach the other end of the wire to earth ground using a method
appropriate for the application.
Note If you use shielded cabling to connect to a C Series I/O module with a plastic
connector, you must attach the cable shield to the chassis grounding terminal using
1.3 mm2(16 AWG) or larger wire. Use shorter wire for better EMC performance.
For more information about earth ground connections, go to ni.com/info
and enter the Info Code earthground.
Connecting the Chassis to a Network
Connect the chassis to an Ethernet network using Ethernet port 1 on the
front panel. Use a standard Category 5 (CAT-5) or better shielded,
twisted-pair Ethernet cable to connect the chassis to an Ethernet hub or a
computer.
Caution To prevent data loss and to maintain the integrity of your Ethernet installation,
do not use a cable longer than 100 m.
The first time you power up the chassis, it attempts to initiate a DHCP
network connection. If the chassis is unable to initiate a DHCP connection,
it connects to the network with a link-local IP address with the form
169.254.x.x. After powerup, you must install software on the chassis and
configure the network settings in Measurement & Automation Explorer
(MAX).
Note Installing software may change the network behavior of the chassis. For information
about network behavior by installed software version, go to ni.com/info and enter the
Info Code ipconfigcrio.

NI 9146 Operating Instructions and Specifications 12 ni.com
Wiring Power to the Chassis
The NI 9146 requires an external power supply that meets the
specifications in the Power Requirements section. The NI 9146 filters and
regulates the supplied power and provides power for all of the I/O modules.
The NI 9146 has one layer of reverse-voltage protection. Complete the
following steps to connect a power supply to the chassis.
1. Ensure that the power supply is turned off.
Caution Do not install or remove the power connector from the front panel of the NI 9146
while power is applied.
2. Connect the positive lead of the power supply to the V terminal of the
COMBICON power connector shipped with the NI 9146, and tighten
the terminal screw. Figure 13 shows the terminal screws, which secure
the wires in the screw terminals, and the connector screws, which
secure the power connector on the front panel.
Figure 13. COMBICON Power Connector
3. Connect the negative lead of the power supply to the C terminal of the
power connector and tighten the terminal screw.
4. Install the power connector on the front panel of the NI 9146 and
tighten the connector screws.
5. Turn on the power supply.
Powering On the NI 9146
When you apply power to the NI 9146, the chassis runs a power-on self test
(POST). During the POST, the Power and Status LEDs turn on. The Status
LED turns off, indicating that the POST is complete. If the LEDs do not
behave in this way when the system powers on, refer to the Understanding
LED Indications section.
1 Terminal Screws 2 Connector Screws
C
V
2
2
1

©National Instruments 13 NI 9146 Operating Instructions and Specifications
Restarting the NI 9146 Using the Reset Button
Pressing the Reset button restarts the NI 9146. The FPGA continues to run
unless you have selected the Autoload VI on device reboot chassis reset
option. Refer to the Chassis Startup Options section for more information.
To restart the NI 9146 in safe mode, hold the Reset button down for about
5 s, until the Status LED lights yellow, then release the button. The chassis
reboots and the Status LED starts blinking three times every few seconds.
The chassis is now in Safe Mode. Refer to the MAX help for information
about safe mode.
Chassis Startup Options
Table 1 lists the startup options available for the NI 9146. These options
determine how the chassis behaves when it starts up in various conditions.
Use the RIO Device Setup utility to select startup options. Access the
RIO Device Setup utility by selecting Start»All Programs»National
Instruments»NI-RIO»RIO Device Setup.
Configuring IP Settings
When you power on the NI 9146 for the first time, it boots into safe mode
because there is no software installed on it. This section describes how to
configure the IP settings and install software on the chassis.
Complete the following steps.
1. Launch MAX on the host computer and expand Remote Systems in
the MAX configuration tree. MAX lists the NI 9146 as the model name
of the chassis followed by the serial number, for example,
NI9146-XXXXXXXX.
The chassis automatically attempts to connect to the network using
DHCP. If DHCP is not available, the chassis connects to the network
with a link-local IP address with the form 169.254.x.x. You must
connect the chassis directly to the host computer to configure it in this
state.
Table 1. NI 9146 Reset Options
Startup Option Behavior
Do Not Autoload VI Does not load the FPGA bit stream from flash memory.
Autoload VI on device powerup Loads the FPGA bit stream from flash memory to the FPGA
when the chassis powers on.
Autoload VI on device reboot Loads the FPGA bit stream from flash to the FPGA when you
reboot the chassis either with or without cycling power.

NI 9146 Operating Instructions and Specifications 14 ni.com
2. Select the chassis under Remote Systems to see the Network Settings
tab in the middle pane of MAX.
3. Enter a name for the chassis in the Name field.
4. Select settings for the chassis in the IP Settings section, then
click Apply.
Note For information about configuring network settings, refer to the Configuring
Network Settings book of the MAX Remote Systems Help. In MAX, click Help»Help
Topics»Remote Systems. On the Contents tab, browse to LabVIEW Real-Time Target
Configuration»Configuring Network Settings.
5. When you click Apply, you are prompted to reboot the chassis for the
changes to take effect. Click Yes. You can also reboot the chassis by
right-clicking the name under Remote Systems and selecting Reboot.
6. After rebooting, the chassis appears under Remote Systems with the
assigned name. Expand the chassis and select Software.
7. Click Add/Remove Software in the toolbar to launch the
LabVIEW Real-Time Software Wizard.
8. Install the Recommended Software Set that appears in the
LabVIEW Real-Time Software Wizard.
For more information about configuring the chassis in MAX, refer to the
MAX Help.
For information about installing and using LabVIEW FPGA, refer to the
LabVIEW FPGA User Manual.
Understanding LED Indications
Figure 14. NI 9146 LEDs
POWER LED
The POWER LED is lit while the NI 9146 is powered on. This LED
indicates that the power supply connected to the chassis is adequate.
POWER POWER
STATUS
USER FPGA1

©National Instruments 15 NI 9146 Operating Instructions and Specifications
STATUS LED
The STATUS LED is off during normal operation. The NI 9146 indicates
specific error conditions by flashing the STATUS LED a certain number of
times every few seconds, as shown in Table 2.
USER FPGA1 LED
You can use the USER FPGA LED to help debug your application or easily
retrieve application status. Use the LabVIEW FPGA Module and NI-RIO
software to define the USER FPGA1 LED to meet the needs of your
application. Refer to LabVIEW Help for information about programming
this LED.
Troubleshooting Network Communication
If the NI 9146 cannot communicate with the network, you can perform the
following troubleshooting steps.
1. Hold the Reset button down for about 5 s, until the Status LED lights
yellow, then release the button. The chassis reboots and the Status LED
starts blinking three times every few seconds. The chassis is now in
Safe Mode.
2. Repeat step 1. The Status LED repeats the same behavior. The chassis
is now in Safe Mode with IP Reset.
3. Configure the IP and other network settings in MAX.
4. Press and release the Reset button to reboot the chassis.
Table 2. Status LED Indications
Number of Flashes
Every Few Seconds Indication
2The chassis has detected an error in its software. This usually occurs
when an attempt to upgrade the software is interrupted. Reinstall
software on the chassis. Refer to the Measurement & Automation
Explorer Help for information about installing software on the chassis.
3The chassis is in safe mode. Refer to the Measurement & Automation
Explorer Help for information about safe mode.
4The software has crashed twice without rebooting or cycling power
between crashes. This usually occurs when the chassis runs out of
memory. Review your RT VI and check the memory usage. Modify
the VI as necessary to solve the memory usage issue.
Continuously flashing
or solid
The chassis has detected an unrecoverable error. Contact National
Instruments.

NI 9146 Operating Instructions and Specifications 16 ni.com
Where to Go from Here
Now that you have set up the NI 9146 and configured it on your network,
you can start using it in your applications. The following figure shows the
main components of the CompactRIO documentation that you may find
helpful as you program and use the NI 9146.
Figure 15. CompactRIO Documentation
ThisDocument
Installation and
Specifications
ni.com/info
rdcriostartup
Troubleshooting Tips,
Tutorials, Examples,
and More
MAX Help for
CompactRIO
Network
Configuration
LabVIEW Help»
NI-RIO»C Series
Reference and
Procedures
Using CompactRIO
in Your Application

©National Instruments 17 NI 9146 Operating Instructions and Specifications
Specifications
The following specifications are typical for the –40 to 70 °C operating
temperature range unless otherwise noted.
Network
Network interface................................... 10BaseT and 100BaseTX
Ethernet
Compatibility ......................................... IEEE 802.3
Communication rates ............................. 10 Mbps, 100 Mbps,
auto-negotiated
Maximum cabling distance .................... 100 m/segment
Reconfigurable FPGA
FPGA type.............................................. Xilinx Spartan-6 LX 45
Number of flip-flops .............................. 54,576
Number of 6-input LUTs ....................... 27,288
Number of DSP 48s ............................... 58
Available block RAM ............................ 2,088 kbits
Number of DMA channels..................... 5
Power Requirements
Caution You must use a UL Listed ITE power supply marked LPS with the NI 9146.
Recommended power supply ................. 24 W, 24 VDC
Power consumption................................ 15 W maximum
Power supply input range....................... 9 to 30 V
Note The power consumption specifications in this document are maximum values for a
LabVIEW FPGA application compiled at 40 MHz. Your application power requirements
may be different. To calculate the power requirements of the NI 9146, add the power
consumption/dissipation for the chassis and the I/O modules you are using. Keep in mind
that the resulting total power consumption is a maximum value and that the NI 9146 may
require less power in your application. For more information about the I/O module power
requirements, refer to the module operating instructions.

NI 9146 Operating Instructions and Specifications 18 ni.com
Physical Characteristics
If you need to clean the chassis, wipe it with a dry towel.
Screw-terminal wiring ............................0.5 to 2.5 mm2(24 to 12 AWG)
copper conductor wire with
10 mm (0.39 in.) of insulation
stripped from the end
Torque for screw terminals.....................0.5 to 0.6 N · m
(4.4 to 5.3 lb · in.)
Weight ....................................................643 g (22.7 oz)
Environmental
Operating temperature
(IEC 60068-2-1, IEC 60068-2-2) ...........–40 to 70 °C
Note To meet this operating temperature range, you must compile your LabVIEW FPGA
application at 40 MHz or slower and follow the guidelines in the installation instructions
for your system.
Storage temperature
(IEC 60068-2-1, IEC 60068-2-2) ...........–40 to 85 °C
Ingress protection ...................................IP 40
Operating humidity
(IEC 60068-2-56) ...................................10 to 90% RH, noncondensing
Storage humidity
(IEC 60068-2-56) ...................................5 to 95% RH, noncondensing
Maximum altitude...................................2,000 m
Pollution Degree (IEC 60664) ................2
Indoor use only
Shock and Vibration
To meet these specifications, you must panel mount the chassis and affix
ferrules to the ends of the power terminal wires.
Operating shock
(IEC 60068-2-27) ...................................30 g, 11 ms half sine
50 g, 3 ms half sine,
18 shocks at 6 orientations

©National Instruments 19 NI 9146 Operating Instructions and Specifications
Operating vibration, random
(IEC 60068-2-64) ................................... 5 grms, 10 to 500 Hz
Operating vibration, sinusoidal
(IEC 60068-2-6)..................................... 5 g, 10 to 500 Hz
Safety Voltages
Connect only voltages that are within these limits.
V terminal to C terminal ........................ 30 V max,
Measurement Category I
Measurement Category I is for measurements performed on circuits not
directly connected to the electrical distribution system referred to as
MAINS voltage. MAINS is a hazardous live electrical supply system that
powers equipment. This category is for measurements of voltages from
specially protected secondary circuits. Such voltage measurements include
signal levels, special equipment, limited-energy parts of equipment,
circuits powered by regulated low-voltage sources, and electronics.
Caution Do not connect the system to signals or use for measurements within
Measurement Categories II, III, or IV.
Safety Standards
This product meets the requirements of the following standards of safety
for electrical equipment for measurement, control, and laboratory use:
• IEC 61010-1, EN 61010-1
• UL 61010-1, CSA 61010-1
Note For UL and other safety certifications, refer to the product label or the Online
Product Certification section.
Electromagnetic Compatibility
This product meets the requirements of the following EMC standards for
electrical equipment for measurement, control, and laboratory use:
• EN 61326 (IEC 61326): Class A emissions; Industrial immunity
• EN 55011 (CISPR 11): Group 1, Class A emissions
• AS/NZS CISPR 11: Group 1, Class A emissions
• FCC 47 CFR Part 15B: Class A emissions
• ICES-001: Class A emissions

NI 9146 Operating Instructions and Specifications 20 ni.com
Note For the standards applied to assess the EMC of this product, refer to the Online
Product Certification section.
Note For EMC compliance, operate this product according to the documentation.
CE Compliance
This product meets the essential requirements of applicable European
Directives as follows:
• 2006/95/EC; Low-Voltage Directive (safety)
• 2004/108/EEC; Electromagnetic Compatibility Directive (EMC)
Online Product Certification
Refer to the Declaration of Conformity (DoC) for this product for
additional regulatory compliance information. To obtain product
certifications and the DoC for this product, visit ni.com/
certification, search by model number or product line, and
click the appropriate link in the Certification column.
Environmental Management
NI is committed to designing and manufacturing products in an
environmentally responsible manner. NI recognizes that eliminating
certain hazardous substances from our products is beneficial to the
environment and to NI customers.
For additional environmental information, refer to the NI and the
Environment Web page at ni.com/environment. This page contains the
environmental regulations and directives with which NI complies, as well
as other environmental information not included in this document.
Waste Electrical and Electronic Equipment (WEEE)
EU Customers At the end of the product life cycle, all products must be sent to a WEEE
recycling center. For more information about WEEE recycling centers, National
Instruments WEEE initiatives, and compliance with WEEE Directive 2002/96/EC on
Waste and Electronic Equipment, visit ni.com/environment/weee.
⬉ᄤֵᙃѻક∵ᶧ᥻ࠊㅵ⧚ࡲ⊩ ˄Ё೑
RoHS
˅
Ё೑ᅶ᠋ National Instruments ヺড়Ё೑⬉ᄤֵᙃѻકЁ䰤ࠊՓ⫼ᶤѯ᳝ᆇ⠽䋼ᣛҸ (RoHS)DŽ
݇Ѣ National Instruments Ё೑ RoHS ড়㾘ᗻֵᙃˈ䇋ⱏᔩ ni.com/environment/rohs_chinaDŽ
(For information about China RoHS compliance, go to ni.com/environment/rohs_china.)
