National Gp30 User manual

Read Manual Before Operating Machine

402600 Rev B

GP30 GRINDER

OPERATING MANUAL

Table of Contents

1.0 Technical Data.............................................1

2.0 Safety Instructions .........................................2

3.0 General Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

4.0 Transportation.............................................8

5.0 Starting the Machine .......................................9

6.0 Operation of the Machine...................................11

7.0 Maintenance Schedule.....................................12

8.0 Troubleshooting / Diagnostics ..............................12

9.0 Reference Guide & Procedures..............................13

10.0 Warranty ................................................21

Please note: The following safety instructions must be followed as

shown in this operating manual. Failure to do so may result in

hazard to health or possible death.

1.0 Technical Data

1.1 Rating

1.2 Unit Specifications

1.3 Operative Range and Correct Usage

1.4 Stand-by Power Supply (Generator)

1.5 Advice for Operators of Grinding Machines

1.6 Machine Type Designation

1.1 Rating

Machine: GP30 Grinder

Manufacturer: National Flooring Equipment (NFE)

9250 Xylon Ave. N

Minneapolis, MN 55445

1.2 Unit Specifications

Dimensions:

Length 86 in 218 cm

Width 30 in 76 cm

Height 52 in 132 cm

Weight 1,320 lbs 599 kg

Connected loads of the electrical system:

Power 30 HP

Electrical Connection 220/230 VAC 3-Phase 60 Hz

1.3 Operative Range and Correct Usage

The GP30 is designed to be used on clean, dry or wet horizontal surfaces without

obstacles. The machine cannot be used for other purposes. The manufacturer will not

be liable for damages resulting from incorrect usage. In case of wrong usage the user is

responsible for all risks.

1.4 Stand–by Power Supply (Generator)

If the GP30 is operated using a generator, the generator must be operated in accordance

with the current local electrical directives (this applies in particular to the protective

ground conductor) to ensure that all safety devices are functioning and ensure the ability to

eliminate possible damage to electrical components.

1.5 Advice for Operators of Grinding Machines

During the operation of the GP30 it may be possible to exceed the acceptable noise

level of 85 dB(A). This is dependent on the different locations and the local circumstances.

When the noise level is 85 dB(A) or more, the machine operator and the persons working near

the machine must wear sound-insulating devices.

1.6 Machine Type Designation

Machine Type: GP30

Working Width: 30 in (72cm)

Drive: Manual

Grinding Capacity: Variable

Dust Hose Connection: 3 in (76mm) x 25 ft (8m)

2.0 Safety Instructions

2.1 Explanation of Warnings and Symbols

2.2 Organizational Measures

2.3 Personnel Selection and Qualification

2.4 Safety Precautions Applicable to Different Operating Conditions

2.5 Repair Work, Maintenance Activities, and Default Repair on the Jobsite

2.6 Safety-off Position

2.7 Dangerous Aspects of the Machine

2.8 Electrical Engineering Regulations

2.9 Special Instructions

2.1 Explanation of Warnings and Symbols

The following symbols are used in this manual to highlight areas of particular

importance:

Operational Safety

Safety precautions that are to be taken to ensure prevention of injury.

Safety Goggles / Ear Protection

Information, instructions, and restrictions with regards to possible risks to persons or

extensive material damages.

Electrical Warning

Warning against dangerous voltages.

2.2 Organizational Measures

The Operating Instructions are to be kept near where the machine is located and must

be reachable at all times.

In addition to this manual, general and legal regulations regarding accident prevention and

environmental protection must be complied with. These may for example relate to the handling of

hazardous substances or to the provision and wearing of personal protection equipment, as well

as compliance with local traffic regulations. This manual must be supplemented by instructions

containing the duty to supervise and report particular local working practices, work organization,

work procedures, and personnel allocation.

Personnel working with or on the machine must have read this manual before starting work; in

particular the section on safety.

From time to time the working practices of the staff are to be checked for awareness of safety and

hazards.

Personnel must tie back long hair and not wear loose clothing or jewelry. There is a risk of injury if

loose items become stuck or are drawn into moving machinery.

Use personal protection equipment if necessary or required by regulations. Take notice

of all safety and hazard notices on the machine.

All safety and hazard notices on the machine must be kept complete and legible. For replacement

labels, contact NFE.

If safety-critical changes occur to the machine or its performance, the machine must be shut down

immediately! The cause of the fault must be established and repaired before starting the work

again.

Changes, add-ons, or conversions to the machine which might have an influence on the

safety of the machine must not be undertaken without the permission of the manufacturer.

Spare parts must always comply with the technical requirements and the specifications of the

manufacturer. This is always guaranteed when using spare parts from NFE.

Inspection intervals specified in this manual must be complied with. At the same time it is necessary

to meet the legal requirements.

The location and the operation of fire extinguishers must be made known on each building site.

Take note of the procedures for fire reporting and fighting fires.

2.3 Personnel Selection and Qualification

Only reliable personnel are allowed to work on or operate the machine. Note the statutory minimum

age. Specify clearly the responsibilities of personnel for operation, setting up, servicing and

maintenance work. Define responsibilities regarding traffic safety regulations and empower operator

to decline instructions from third parties which are not complying with the safety requirements.

Personnel being trained may only be deployed under constant supervision of an experienced

operator.

Work on the electrical parts of the equipment may only be undertaken by a skilled

electrician or by a trained person under the guidance and supervision of a skilled

electrician in accordance with the electrical engineering regulations.

2.4 Safety Precautions Applicable to Different Operating Conditions

Avoid any method of working that impairs safety! All precautions must be taken so that the machine

is only used in a safe and functional status.

Only operate the machine when all safety devices and related safety equipment, e.g.

detachable safety devices, emergency stops, and suction devices, are present and

operational!

The machine has to be visually checked at least once a day for any damage or defects. In the event

of operational malfunctions the machine must be shut down immediately and secured. The fault

must be rectified before starting the machine again.

Secure the work area around the machine in public areas; provide a safety distance of

at least 10 feet around the machine.

All persons in the proximity of the machine must wear safety glasses with lateral

protection, as well as safety shoes. Ear protection may be required. The operator is

obliged to wear close fitting protective clothing.

Use only extension cables that are sized and marked in accordance with the overall power

consumption of the machine and the valid local guidelines.

Before starting the machine, make sure that no one will be endangered when the machines starts

running.

Do not switch off or remove the exhaust or ventilation devices when the machine is

running.

2.5 Repair Work, Maintenance Activities, and Default Repair on the Jobsite

Before starting any service work on the machine, put the machine in the safety off

position (section 2.6) to prevent the machine from being turned on accidentally.

Adjustments, servicing, inspection work, and inspection intervals specified in this manual, as well

as any information on the replacement of parts and systems of the machine must be complied with.

These activities can only be undertaken by qualified personnel. Before starting any maintenance or

repair work, the operator of the machine must be informed about it.

The dust bin of the connected dust collector must be emptied before transportation. Handle in

accordance with the local disposal regulations.

Do not use any aggressive cleaning materials on the machine; use lint-free cleaning cloths.

Always re-tighten any screws that are undone during servicing and maintenance work.

If safety devices need to be dismantled during setup, maintenance, or repair work, they must be

reinstalled and inspected immediately after completion of the service or repair work.

Make sure that materials and replacement parts are disposed of safely and in an environmentally-

friendly manner.

Make sure that electrical components used for replacement purpose comply with the original parts

and are correctly adjusted if necessary.

2.6 Safety Off Position

The safety off position is the position of the machine when it cannot generate any hazard.

How to put machine in safety off position:

• Turn off the grinder.

• Turn off the dust collector.

• Wait for all drives to stop.

• Pull out main plugs.

• Secure machine against unintended start-up.

2.7 Dangerous Aspects of the Machine

Every machine, if not used according to the regulations, may be hazardous for operating,

setup and service personnel. The operating authority is responsible for compliance with

the safety regulations during operation and maintenance of safety devices supplied with the

machine, as well as the provision of additional safety devices.

2.8 Electrical Engineering Regulations

The machine must only be started when all guards and dust collection parts are attached

and machine is standing flat on work surface.

If work on electrified parts is necessary, a second person must be deployed who can pull out the

plug in an emergency. The working area must be sealed with a red and white safety chain and a

danger sign. Use tools that are insulated against voltages.

Only start work once familiar with the electrical engineering regulations that apply to the area.

Only use voltage testers that comply with the regulations when troubleshooting. From time to time,

check voltage tester to ensure it is operationally efficient.

2.9 Special Instructions

Use proper tools for work. Damaged tools must be repaired or replaced immediately.

Use the required safety equipment and safety clothes (e.g. safety glasses, safety shoes, safety

gloves).

Instruct operators and repair personnel on the following:

• Cleaning and repair work are only allowed if the machine is shut off and in the safety off position.

• Opening or removing safety devices while the machine is running is not allowed.

• Replace all safety covers and devices after cleaning, repair, or maintenance work.

• Do not touch moving parts and do not walk into the working path of the machine.

• Before restarting machine, make sure all personnel are a safe distance away from the work

area after initial start-up.

3.0 General Information

3.1 Operative Range

3.2 Scope of Supply

3.3 Operating Features

3.4 Electric Motor

3.5 Cutting Area

3.6 Couplers & Tool Plates / Stone Holders

3.7 Variable Speed Drive

3.8 Tooling Change

3.9 Care & Maintenance

3.1 Operative Range

The GP30 is a grinding machine with counter rotating heads that is used for preparation and

polishing horizontal surfaces. Grinding the surface according to NFE specifications thoroughly

removes surface contaminants, coats of paint, sealants, and thin coatings.

A suitable dust collection unit must be connected to the machine in order to collect the dust being

produced by the grinding process. The proper dust collection system ensures dust-free operation

of the machine and clean air at the workspace.

3.2 Scope of Supply

Provided with machine:

• GP30

• Manual (1)

3.3 Operating Features

Key Button Controls Start / Stop

Pushing the key button "Start" will turn the controls on and start the motor. Pushing the key button

“Stop” will stop the motor.

Up / Down Arrows

While powered on but without the motor running, the red up and down arrow buttons can be used

to set the motor speed faster or slower than the base RPM of the motor.

Rotation

While powered on but without the motor running, the “Rotation” button is used to change the

rotation of the motor. Press the “Rotation” button and press “Enter” within 2 seconds to change the

motor rotation. To change back to previous rotation repeat the process

Auto/Man and Prog/Run

These buttons are for drive diagnostics and programming and are not used by the operator.

"Dead Man" Key

The "dead man" key is intended to be used for the safety of the operator and protection of the

machine from excess damage in the event of an emergency. Lanyard must be worn by operator for

this safety device to work properly. Pull key out to stop the machine motor.

Manual On/Off Switch

The on/off switch is used to turn on or off all power supplied to the grinder.

3.4 Electric Motor

The motor is responsible for turning the gears which turn the abrasive tools on the floor. The motor

is controlled exclusively by the VSD which inputs specific power to generate a given RPM.

3.5 Cutting Area

The area inside the stainless steel shroud and directly beneath the gear deck is the cutting area.

This is the area in which the tools turn to produce the grinding action. It is also the area that keeps

the dust from grinding contained and subsequently evacuated through the dust collection ports.

3.6 Couplers & Tool Plates

The grinder is outfitted with couplers and tool plates. The couplers attach to the tool plates and

provide flex for smooth operation of the diamond tools. The tool plate holds the tools in place for

the grinding application.

3.7 Variable Speed Drive (VSD)

The VSD contains all controls and instruments used for supervision and control of the machine.

The VSD is responsible for monitoring incoming power as well as changing the electronic frequency

to allow the motor to run at different speeds. This unit is a closed panel that is intended to be

operated only with the keypad.

3.8 Tooling Change

In order to change the tooling, first ensure that the grinder is switched off and disconnected from

the electrical source. Place all pocket weights provided in the weight holders on either side of the

VSD.

Then, push machine down by the handle in a controlled manner until the grinder is resting on the

top casters. Tap the tooling from the outside edging to remove, and install new tooling by sliding

the tooling outward.

Machine must only be tilted back on firm, level surface. There is danger of machine

falling if all weights are not used and surface is not level.

3.9 Care & Maintenance

Regular maintenance of the machine and its parts is imperative for functioning and safety.

In order to prevent unnecessary downtimes, it is recommended to keep original spare and wear

parts in stock.

The following maintenance should take place before and after every operation of

machine:

1. Clean all surfaces with a dry, lint-free cloth.

2. Inspect all electrical cables for cuts and replace damaged cords

3. Check that all electrical connections are secure and snug.

4. Inspect gear box for any signs of oil leakage.

5. Verify functionality of dead man key.

4.0 Transportation

4.1 Transportation

4.2 Transportation by Vehicle

4.3 Operation Conditions

4.1 Transportation

In order to transport the machine from a vehicle to the working area, place the pocket weights in

the weight baskets and tilt the machine back so it rests on the back casters.

When transporting the machine with hoisting equipment like a crane or a lift, check the total weight

permitted (see section 1-Dimensions). Use only qualified hoisting equipment, as well as ropes and

chains.

Do not fix any rope or chain to the handle. The machine must be placed on a pallet or platform

designed to hold the weight of the machine; the platform or pallet can then be lifted or hoisted from

the appropriate points.

***When transporting GP machines by vehicle or trailer, it is mandatory to move all pocket weights

to the head of the grinder, or off the machine. Failure to do so will result in damage to the handle

frame that is not covered under warranty.

4.2 Transportation by Vehicle

When transporting the machine with a vehicle, proceed in such a manner that damage due to the

effects of use of force or incorrect loading and unloading is avoided. Use at least two straps to

tighten the machine to the vehicle. Make sure that all parts of the machine are stationary.

4.3 Operation Conditions

Check the surface to be treated for loose parts (stones, screws, etc.). The surface must be swept

if necessary. Make sure that the machine can travel over all inequalities on the surface. Small

inequalities like floor joints less than ¼ inch will not get in the way.

The machine must be operated in accordance with instructions given in section 5—Starting the

Machine.

5.0 Starting the Machine

5.1 Preparing for Initial Operation

5.2 Initial operation

5.1 Preparing for Initial Operation

Before start-up, ensure all existing protective housings are fitted and the dust collector is connected

properly.

Carefully handle all plugs, cables, hoses, and operating devices. Avoid any contact with live wires.

Work on the electrical system must only be done by qualified specialists.

Carry out the following checks before any start-up:

• Check whether all machine parts are assembled safely and correctly.

• Check all screws and fasteners for tightness.

• Check the tool holders to ensure that the proper tools are in place and secure.

• Check the tightness of the hose connections and the condition of the hose to the filter.

• Make sure the container of the dust collector is empty. Comply with local waste treatment

regulations regarding the removed material.

• Check the electrical connections for dirt and foreign body deposits.

• Check the electrical motors for dirt and other contaminants.

1. Place the grinder in the area where work is to begin.

2. Place weights on grinding head beside motor.

3. Check the main power cable and the dust hose for damage. Replace or repair all damaged

parts before starting the machine.

4. Connect the grinder and dust collector using the dust hose.

5. Connect the supply cable of the GP machine* with the site supply. Make sure that the correct

electric supply is available.

*An authorized electrician must verify proper voltage before turning on the machine!

Damage to VSD will occur if voltage is incorrect.

5.2 Initial Operation

Attention! Before you plug the equipment to a power supply make sure the power supply

is equivalent to the data shown on the machine label.

Start-up procedure:

1. Turn on the dust collector.

2. Ensure plug is connected correctly to the power source.

3. Ensure dust hose is connected correctly to dust collector and machine.

4. Check that the main switch is turned on and the dead man switch is in place, with the lanyard

around the operator’s wrist.

5. Place downward pressure on handle; press the ‘Start’ button.

6. Release pressure from handle and immediately begin moving the machine from side-to-side

to prevent the tools from digging into the concrete surface and creating an uneven profile.

When grinding in work area is complete, push the ‘Stop’ button to stop the grinding motor.

7. The dust bin of the collection unit needs to be emptied regularly.*

*Do not overfill the bin to avoid dust exposure when opening the bin.

6.0 Operation of the Machine

6.1 Daily Operation

6.2 Failure

6.3 Safety Switch Off

6.4 Restart

6.1 Daily Operation

Carry out grinding operation in parallel tracks so that the dust hose and electric cable do not

become twisted. Make sure that no vehicles, such as forklift trucks, or other equipment run over

the electric cable or dust hose.

The speed of moving the grinding machine over the work surface will influence the final finish and

production.

In the case that the surface shows different characteristics, i.e. different hardness or different

coating thicknesses, a uniform grinding result will be achieved by varying the speed of movement

over the surface.

6.2 Failure

Local safety regulations are valid in any case for the operation of the machine. Ensure all parts

have come to a standstill before inspection or maintenance work starts. Always place machine in

the safety off position (as described in section 2).

6.3 Safety Switch Off

See section 2—Safety Instructions.

6.4 Restart

See section 5—Starting the Machine.

7.0 Maintenance Schedule

7.1 Maintenance and Inspection

Operating Hours / Time Period Inspection Points / Maintenance Instructions

Daily — Prior to Operation • Check all electrical cables for cuts or damage.

• Check the hose connections for tightness.

• Check the dust collector hose for damage.

• Empty waste from the dust collector.

• Check Morflex Coupler, tool plate, and diamond tooling

for wear and damage.

• Check that shroud and rubber seal are in good working

condition.

• Check the electric connections for sediments of dirt or

foreign bodies.

• Check the electric motor for dirt and other contaminants.

• Check gearbox assembly for any leaks of oil from motor.

Daily — After Operation • Check for debris in the dust ports under gear box and

near the handle.

• Check for dirt build-up on VSD and electric motor.

8.0 Troubleshooting / Diagnostics

8.1 Diagnosis of Failures

8.2 Diagnosis of Electrical Failure

8.1 Diagnosis of Failures

Failure Possible Reasons for Failure Corrective Actions

Unusual Vibrations. Uneven or loose surface being

ground.

Verify suitability of substrate

being ground.

Loose or damaged tooling. Inspect tooling to make sure that

all connecting hardware is tight

and tool is firmly seated to holder.

Damaged or worn coupler. Replace coupler.

Note: For additional maintenance and repair information, reference this machine’s Service Manual.

Failure Possible Reasons for Failure Corrective Actions

Unusual Noise. Uneven or loose surface being

ground.

Verify suitability of substrate being

ground.

Loose or damaged tooling. Inspect tooling to make sure that

all connecting hardware is tight

and tool is firmly seated to holder.

Shroud is dragging on the floor. Adjust shroud and tighten to no

more than ¼ inch above floor.

Reduced performance

or no performance.

Diamond tooling is worn or

damaged.

Inspect diamond tooling for

remaining abrasive. If depleted,

replace with new tooling.

Dust being produced. Shroud is out of adjustment. Adjust shroud and tighten to no

more than 2 mm above floor.

Dust hose is clogged. Inspect dust hose and ports for

debris that may be clogging hose.

Dust collector malfunction. Verify dust collector is operating

properly.

8.2 Diagnosis of Electrical Failure

Failure Possible Reasons for Failure Corrective Actions

Motor does not start up. Missing Phase. Check power supply.

Faulty switch or relays. Get diagnosis and replacement

by a skilled electrician.

Emergency Stop. Unlock the emergency stop

button.

Motor stops during

operation.

Current power is too high. Disconnect plug.

Supply circuit breaker is

disengaged.

Reset circuit breaker or replace

fuse.

Motor is damaged. Inspect motor.

9.0 Reference Guide & Procedures

9.1 Concrete Prep Diamond Tooling

9.2 Polished Concrete - EGT Polishing System (Dry Steps)

9.3 Polished Concrete - CLC Polishing System (Dry-Wet-Dry Steps)

9.1 Concrete Prep Diamond Tooling

NFE offers diamond tooling for any phase of the grinding or polishing process. Below is a list of those

tools and their applications.

1) #0 Prep Tool (leaves a smooth profile)

Description

The #0 Prep Tool (401922) is a metal bond preparation tool that has the EG attachment

system as a standard for use on any GP machine. Its uses are to remove adhesives, thin-

sets, surface inequalities of +/-.16 in (4 mm) and epoxy coatings with thickness of less

than .16 in (4 mm). The #0 Prep Tool is designed to be used as a dry removal tool only.

The #0 Prep Tool is made for use on concrete and should never be chosen to grind

terrazzo, marble, or granite. The concrete profile after using the #0 Prep Tool will be one

that is consistently scratched and resembles 80 grit sand paper. Approximate life of the #0

Prep Tool is 30,000 SF (2,787 M2).

Execution

1. Attach the #0 Prep Tools to the GP30 and place it in operating position. Attach appropriate power* and

vacuum dust collection hose to the GP machine.

2. With weights in neutral position** or off machine, start the machine and adjust speed to 45Hz.

3. Upon starting the machine, continuously move machine in side-to-side pattern ensuring that machine

is will grind the floor evenly. If for any reason the machine cannot be continuously moved, i.e. cord

management, adjacent work, obstacles, etc., stop the machine until it can be operated as specified

above. Upon satisfactory completion of surface prep, remove machine and use a dust collector to

clean the surface.

* Power source Voltage will vary by machine being used and should be verified for compatibility before

connecting machine to it. Dust collection by appropriate dust collector is compulsory as harmful and

damaging dust will be produced if dust collection is not used or is of inadequate capacity. The life of the

#0 Prep Tool will also be significantly reduced if vacuum is not of appropriate capacity.

**The GP machines all have pocket weights for the purpose of varying the grinding pressure of the

machine. It is suggested to begin with the #0 Prep Tool with no added weight to gauge performance.

If the tool is not aggressive enough, simply add more weight to the grinding head of the machine to

increase grinding pressure. If #0 Prep Tool is too aggressive, simply add more weight to the handle to

reduce grinding pressure.

Flooring Condition Qualifications

Use of the #0 Prep Tool requires that the surface to be treated is completely dry. For floors that have

adhesives or built-up contaminants, a scraping of the floor will improve performance but is not required.

As a general rule, it is best to inspect floor BEFORE beginning to note or mark obstacles such as floor

drains, protrusions from floor and elevation changes in excess of .16 in (4 mm).

Machinery Qualifications

The #0 Prep Tool is designed to attach to and work perfectly with any GP machine. Quantity of #0 Prep

Tool will vary by model:

• GP30: 12 pieces

2) #00 PCD Prep Tool (leaves a rough profile)

Description

The #00 Prep Tool is a combination PCD/metal bond preparation tool that has the EG

attachment system as a standard for use on any GP machine. The #00 Prep Tool is

directional. This means that any set of #00 Prep tools will always contain 50% right-hand

tools (401924) and 50% left-hand tools (401923). Its uses are to remove adhesives, thin-

sets, surface inequalities of +/-.16 in (4mm) and epoxy coatings with thickness of less

than .16 in (4 mm). The #00 Prep Tool is designed to be used as a dry removal tool only.

The #00 Prep Tool is made for use on

concrete and should never be chosen to grind terrazzo,

marble, or granite. The concrete profile after using the #00

Prep Tool will be one that is considered rough to the touch

having up to .04 in (1 mm) deep grooves. Approximate life

of the #00 Prep Tool is 30,000SF (2,787 M2).

Execution

1. Attach the #00 Prep tools to the machine by placing

the right-hand tools (#00R) in the tool holders that are

turning clockwise and the left-hand tools (#00L) in the

tool holders that are turning counter-clockwise.

2. Place the machine in the operating position. Attach

appropriate power* and dust collection hose to the machine.

3. With weights in neutral position** or off machine, start the machine and adjust speed to 40Hz.

4. Upon starting the machine, continuously move machine in side-to-side pattern ensuring that machine

is continuously moved while running. If for any reason the machine cannot be continuously moved,

i.e. cord management, adjacent work, obstacles, etc., stop the machine until it can be operated as

specified above.

5. Upon satisfactory completion of surface prep, remove machine and use a dust collector to clean the

surface.

* Power source voltage will vary by machine being used and should be verified for compatibility before

connecting machine to it. Dust collection by appropriate dust collector is compulsory as harmful and

damaging dust will be produced if dust collection is not used or is of inadequate capacity. The life of the

#00 Prep Tool will also be significantly reduced if vacuum is not of appropriate capacity.

** The GP machines all have pocket weights for the purpose of varying the grinding pressure of the

machine. It is suggested to begin with the #00 Prep Tool with no added weight to gauge performance.

If the tool is not aggressive enough, simply add more weight to the grinding head of the machine to

increase grinding pressure. If #00 Prep Tool is too aggressive, simply add more weight to the handle to

reduce grinding pressure.

Flooring Condition Qualifications

Use of the #00 Prep Tool requires that the surface to be treated is completely dry. For floors that have

excessive adhesives or built-up contaminants, a scraping of the floor will improve performance, but is

not required. As a general rule, it is best to inspect floor BEFORE beginning to note or mark obstacles

such as floor drains, protrusions from floor, and elevation changes in excess of .16 in (4 mm).

Machinery Qualifications

The #00 Prep Tool is designed to attach to and work perfectly with any GP machine. Quantity of #00

Prep Tool will vary by model:

• GP30: 6 Right-Hand (401924), 6 Left-Hand (401923)

9.2 Polished Concrete - EGT Polishing System (Dry Steps)

The EGT Diamond System is a coordinated metal and resin bonded diamond system to produce a

polished concrete floor using any of the GP machines. The system is only to be used dry and in

sequence as numbered by tools #1 through #8. All tools are painted gray or use gray velcro backings

to indicate a matched system.

EGT #1 & #2

These are metal bond tools that have the same face design and can be clearly identified by

the number on back as “#1” (401907) and “#2” (401908). Both tools feature the patented EG

attachment system. Approximate life of #1 is 30,000 SF (2,787 M2). Approximate life of #2 is

35,000 SF (3,251 M2).

EGT #3

3This is a metal bond tool that has the pictured face design and can be clearly identified by the

number on back as “#3” (401909). This tool features the patented EG attachment system.

Approximate life of #3 is 35,000 SF (3,251 M2).

EGT #4

This is a 3” resin bonded tool that has the pictured face design and can be clearly identified

by the number on back as “#4” (401910). This tool features gray Velcro backing. Approximate

life of #4 is 20,000 SF (1,858 M2).

EGT #5, #6, #7, & #8

#5 (401911), #6 (401912), #7 (401913) & #8 (401914) are 3” resin bonded tools that

have the pictured face design and can be clearly identified by the number on back

as “#5,” “#6,” “#7,” “#8.” These tools feature gray Velcro backing. Approximate life of

#5, #6, and #8 is 12,000 SF (1,115 M2). Approximate life of #7 is 10,000 SF (930 M2).

Execution of EGT Polishing System

1. Attach the EGT #1 tools to the machine and place it in operating position. Attach appropriate power*

and vacuum dust collection hose to the machine. With 50% of weights on head of machine and 50%

in basket over wheels, set speed to 35Hz on VSD and start machine. Upon satisfactory completion of

step #1, remove machine from area and use a dust collector to clean the surface.

2. Attach the EGT #2 tools to the machine and place it in operating position. Attach appropriate power*

and dust collection hose to the machine. With 100% of weights on head of machine, set speed to 35Hz

on VSD and start machine. Upon satisfactory completion of step #2, remove machine from area and
