Native Instruments Guitar Rig Kontrol Application guide

HARDWARE REFERENCE

The information in this document is subject to change without notice and does not represent a
commitment on the part of Native Instruments GmbH. The software described by this document is
subject to a License Agreement and may not be copied to other media. No part of this publication
may be copied, reproduced or otherwise transmitted or recorded, for any purpose, without prior
written permission by Native Instruments GmbH, hereinafter referred to as Native Instruments. All
product and company names are ™ or ® trademarks of their respective owners.
Hardware Reference written by Alexander Stamm, edited by Patryk Korman
Document Version: 1.0 (07/2009)
Product Version: 4.0 (07/2009)
Special thanks to the Beta Test Team, who were invaluable not just in tracking down bugs, but in
making this a better product.

Germany
Native Instruments GmbH
Schlesische Str. 28
D-10997 Berlin
Germany
[e-mail]
www.native-instruments.de
USA
Native Instruments North America, Inc.
5631 Hollywood Boulevard
Los Angeles, CA 90028
USA
[e-mail]
www.native-instruments.com
© Native Instruments GmbH, 2009. All rights reserved.

GUITAR RIG KONTROL Hardware Reference – IV
Table Of Content
1 Welcome to the World of GUITAR RIG 4!..............................................................................7
2 Before you Start – Important Notes ....................................................................................8
2.1 Serial Numbers & Nameplate ...................................................................................8
2.2 Using the Unit Safely...............................................................................................8
2.2.1 Warning........................................................................................... 8
2.2.2 Caution ........................................................................................... 9
2.2.3 Disposal Notice ................................................................................ 9
2.3 Disclaimer ..............................................................................................................9
3 The RIG KONTROL Hardware............................................................................................. 10
3.1 Top Panel ............................................................................................................. 10
3.2 Rear Panel............................................................................................................ 11
4 Installation under Windows XP / Windows Vista ............................................................... 13
4.1 Software Installation............................................................................................. 13
4.2 Hardware Installation............................................................................................ 15
4.3 Conguration ........................................................................................................ 18
4.3.1 Conguring GUITAR RIG 4 ................................................................. 18
4.3.2 Using the RIG KONTROL as your Default Audio Interface...................... 20
4.4 Audio Connections and Levels................................................................................22
4.4.1 Connecting your Instrument and Adjusting the Input Level.................... 22
4.4.2 Connecting a Second Instrument ...................................................... 23
4.4.3 The Input Level of GUITAR RIG 4 ....................................................... 24
4.4.4 Connecting the Output..................................................................... 25
5 Installation under Mac OS X ............................................................................................26
5.1 Software Installation.............................................................................................26
5.2 Hardware Installation............................................................................................28
5.3 Conguration ........................................................................................................28

GUITAR RIG KONTROL Hardware Reference – V
5.3.1 Conguring GUITAR RIG 4 ................................................................. 29
5.3.2 Using RIG KONTROL as your Default Audio Interface........................... 31
5.4 Audio Connections and Levels................................................................................32
5.4.1 Connecting your Instrument and Adjusting the Input Level.................... 32
5.4.2 Connecting a Second Instrument ...................................................... 33
5.4.3 The Input Level of GUITAR RIG 4 ....................................................... 34
5.4.4 Connecting the Output..................................................................... 35
6 Using the RIG KONTROL as a Controller Interface ..............................................................36
6.1 Activating the RIG KONTROL in GUITAR RIG 4 ............................................................36
6.2 Using MIDI Controllers with the RIG KONTROL MIDI Interface ...................................37
6.3 Using Additional Footswitches and Pedals..............................................................38
7 Troubleshooting ..............................................................................................................39
7.1 Audio Issues .........................................................................................................40
7.1.1 No Sound or Low Volume................................................................. 40
7.1.2 Distorted Signal.............................................................................. 40
7.1.3 Noise .............................................................................................41
7.1.4 Ground Loops..................................................................................41
7.2 Hardware-Related Problems ..................................................................................42
7.2.1 Driver Issues .................................................................................. 42
7.2.2 USB Issues.................................................................................... 42
7.2.3 Using the RIG KONTROL with a Laptop.............................................. 43
8 TechnicalSpecications .................................................................................................44
8.1 Jacks and Sockets ................................................................................................44
8.2 AudioSpecications..............................................................................................45
8.3 Power Supply........................................................................................................48
8.4 Dimensions and Weight .........................................................................................48
8.5 EnvironmentalSpecications:................................................................................48
8.6 System Requirements............................................................................................48
8.6.1 General System Specications.......................................................... 48

GUITAR RIG KONTROL Hardware Reference – VI
8.6.2 Supported Driver Formats ................................................................ 49
8.6.3 Supported Platforms ....................................................................... 49

GUITAR RIG KONTROL Hardware Reference – 7
SPRACHE IN Paragraph-Style “05 - STANDARD Fließtext” passend einstellen
1 Welcome to the World of GUITAR RIG 4!
GUITAR RIG KONTROL EDITION is the complete solution for guitar and bass players.
The stage-ready RIG KONTROL foot pedal integrates seamlessly with the GUITAR RIG 4
software and provides studio-quality sound with its built-in audio interface. It is designed
and optimized for GUITAR RIG 4, but as it complies with industry standards and features
full MIDI support, it works perfectly with most professional audio software.
The RIG KONTROL connects to your computer via high-speed USB 2.0, which also provides
its power supply. It features two inputs, suited either for instrument or line level signals.
A two-channel line-out connects to your monitoring system, and a stereo jack allows for
headphone monitoring at an independent volume.
As a controller, the RIG KONTROL offers 9 switches and a pedal, giving you control over
almost all of GUITAR RIG 4’s functions. Moreover, it features MIDI connections as well as
two analogue inputs to connect external controllers.
In the following chapters you will learn more about the RIG KONTROL and how to make the
best use of it. Please read this manual carefully in order to get acquainted with the product.

GUITAR RIG KONTROL Hardware Reference – 8
2 Before you Start – Important Notes
First things rst; before using GUITAR RIG 4, it is advised that you read this chapter carefully.
2.1 Serial Numbers & Nameplate
GUITAR RIG KONTROL EDITION comes with two serial numbers. The RIG KONTROL
serial number can be found on the bottom of the hardware, along with the nameplate listing
the product model name and other technical information. The serial number for activating
GUITAR RIG 4 is located on the sleeve of the product CD.
2.2 Using the Unit Safely
Please read the following instructions thoroughly to prevent from health risks and
damaging the product.
2.2.1 Warning
To prevent hearing damage, always follow these important security advices:
► This Product, in combination with an amplier, headphones or speakers, can produce
sounds in decibel ranges that may cause hearing damage.
► For protection, set all volume levels to a minimum before using the RIG KONTROL .
Gradually raise the volume controls while music is playing to set the desired
listening level.
► Do not operate it at high volume levels for long periods. If you experience any hearing
problems or ringing in the ears, consult an audiologist immediately.

GUITAR RIG KONTROL Hardware Reference – 9
2.2.2 Caution
To make sure that the RIG KONTROL or any device connected is not damaged during
usage or maintenance, it is important that you follow these instructions:
► Do not open the device or attempt to disassemble or modify the internal parts. The
device contains no user-serviceable parts. If it appears to be malfunctioning,
discontinue use immediately and have it inspected by qualied service personnel.
►Do not expose the unit to rain, use it near water or in damp or wet conditions.
►Do not allow any objects or liquids of any kind to penetrate the unit.
► Never use or store the unit in areas that are subject to temperature extremes (e.g.
direct sunlight in an enclosed vehicle or near heat-generating equipment) or high
levels of vibration.
► Do not place the RIG KONTROL in an unstable position where it is possible the unit
could accidentally fall. Remove all connected cables before moving the unit.
► Before turning the power on or off for any component, set all volume levels to their minimum.
►Do not use excessive force on the knobs or connectors.
► When cleaning the RIG KONTROL, use a soft, dry cloth. Never use paint thinners,
solvents, cleaning uids or chemical-impregnated wiping cloths.
2.2.3 Disposal Notice
Should this product become damaged beyond repair, or if you wish to dispose it, please observe
the regulations of your area and country that relate to the disposal of electronic products.
2.3 Disclaimer
Native Instruments GmbH cannot be held responsible for damage or lost or destroyed data
caused by improper use or modication to the RIG KONTROL.
The information contained in this manual is believed to be correct at the time of printing
or digital release. However, Native Instruments reserves the right to make changes to the
specications at any time without notice or obligation to update existing units.

GUITAR RIG KONTROL Hardware Reference – 10
3 The RIG KONTROL Hardware
This section will give you an overview of the RIG KONTROL hardware.
3.1 Top Panel
1 The footswitches can be assigned in the software to perform tasks such as stepping
through presets, or turning individual components on and off. Each switch has an LED
to indicate whether it is activated. The top row is labeled with the most frequently used
functions of GUITAR RIG 4, matching their pre-congured assignments.
2 The expression pedal can be used to control any continuous parameter of the
software, such as volume or wah-wah. There is an additional freely assignable switch
underneath the tip of the pedal.
3 Shows the number of the currently activated GUITAR RIG 4 preset.
4 This LED-Meter shows the level of the audio signal at the input. The red LEDs indicate
clipping and should never light up. Turn the according input gain down if it does.
