NAUTICAST A2 User manual
Installation Guide
1001001-3
RECOMMENDED PHYSICAL INSTALLATION
Transponder unit should be mounted in a protected area and compass
safe distances kept in mind (see table on the right). VHF antenna must be
mounted vertically, free of reflective objects, minimum distance to other
VHF antennas 1.5m and out of the radar beam. GPS antenna must have
an omnidirectional view of the sky for ideal reception.
SYSTEM MODE
Important: The Nauticast A2 can operate in two different system modes,
Class A mode (default) and Inland mode.
Inland mode is applicable to European river going vessels. Set mode in:
Main MenuConfigSystem SettingsSystem Mode
Instructions only relevant for Inland AIS operation will be in
brown print.
This installation guide serves as a complement to the
product manual (Art.No. 1001001-2), included on the
Nauticast Data Card (USB-Stick).
Installation of the
Nauticast A2 AIS System should always be planned
and executed by authorized personnel.
Please visit our web-site for the latest information
regarding the Nauticast A2. www.nauticast.com
Physical
Nauticast A2
Size W x H x D: 238x87x173 (mm)
Gimbal Mount
Size W x H x D: 252x95x65 (mm)
Power
Input 12/24 VDC
Power Consumption: 20W (60W peak)
Required power on current: 4A
GPS Receiver (AIS internal)
Receiver: 50 CH
Frequency: L1 (1575.42 MHz)
Update Rate: 2 Hz
Position accuracy (SA off)
Position <2.0 m DGPS (CEP, 50%)
Position <2.5 m GPS (CEP, 50%)
Antenna feeding: 5 VDC
Electrical Interfaces
RS 422 Port Default speed (bps)
Pilot In/Out 38400
ECDIS In/Out 38400
LR In/Out 9600
Sensor 1 In 4800
Sensor 2 In 4800
Sensor 3 In 4800
RS 232 Port Default speed (bps)
RS232 In/Out 38400
Signal connector: 26 pin HD-SUB (M)
RS-232 connector: 9 pin D-SUB (M)
Power connector: 4 pin ConXall (M)
GPS 50 ohm antenna connector TNC female
VHF 50 ohm antenna connector BNC female
Chassis GND screw size: M6
Cables (recommended)
VHF and GPS
RG214/U
Sensors e.g. Gyro
RFE-HFI 2x2x0.75 mm2
Blue Sign Installation
Install Resistor connecting brown and orange
wires:
12V: 2.2kΩ
24V: 10 kΩ
VHF Transceiver
Frequency 156-163 MHz
Output power 1/12.5 W
Channel bandwidth 25 kHz
Bit Rate 9600 bps
Intervals between position reports 1-180 s
Modulation FM-GMSK/GFSK
Transmitter 1
Receivers 3
Transceiver Sensitivity <-107 dBm
Environmental data
Protected environment (IEC 60945)
Operating temperature -15 °C to 55 °C
Compass safe distance
60 cm to standard magnetic compass
45 cm to steering magnetic compass
The Nauticast A2 AIS System is compliant
with the following Standards
IMO Performance Standard for AIS (MSC 74(69)
Annex 3)
ITU-R M. 1371-5
ITU-R M. 825-3
ITU-R M. 1084-5
IEC 61993-2 Edition 2
IEC 61162-1/2 Edition 4 (NMEA 0183, Version 4.0)
IEC 61108-1 Edition 2
IEC 60945 Edition 4
IEC 62288 Edition 2
IALA Guidelines on AIS
Inland Test Standard Ed. 2.0
Specifications subject to change without notice
Installation Guide
1001001-3
SYSTEM CONFIGURATION
NOTE: Set correct System mode (CLASS A / Inland before proceeding)
Set up the following parameters under:
Main Menu Config Ship Static
Class A Mode
Inland Mode
MMSI
MMSI
IMO
IMO = 0
Call Sign
Call Sign
Ship Name
Ship Name
Height over Keel
Height over Keel
Ship Type
ERI Code / Euro type
Ship Dimension*
SOG/COG/HDG quality
-
Euro number
Ship and Convoy total Dimensions*
*SET SHIP DIMENSIONS
There are two methods for setting Ship Dimensions: configuration
parameter “Ship Size Mode” in the view “Config-> Interfaces ->
Miscellaneous” can be set to Standard Mode or Simplified Mode
(default). This choice is only available in Class A system mode!
If external ECDIS will be used for full AIS configuration, Standard Mode is
recommended unless the ECDIS integration has been verified with A2.
Standard Mode (not available in Inland mode)
In this mode data is entered exactly as is will be reported on VHF link.
Input:
•
A, B, C, D
for internal antenna [m]
•
A, B, C, D
for external antenna [m]
Simplified Mode (default)
In Simplified mode the transponder will automatically calculate and
correctly round the A,B,C and D values reported on the VHF link from
Length, Beam, C and B.
Input:
•
Ship length x.x
[m] (one decimal precision)
•
Ship beam x.x
[m] (one decimal precision)
•
C, B
for internal antenna relative to ship x.x [m] (one
decimal precision)
•
C, B
for external antenna relative to ship x.x [m] (one
decimal precision)
Inland Mode Convoy Setting (Inland only):
Set Length, Beam, C and B parameters as above.
Specify any extra convoy size in
Main MenuVoyageConvoy Settings
.
Extra convoy size on each side (value = 0 if convoy not used):
•
Bow x.x
[m] (one decimal precision)
•
Stern x.x
[m] (one decimal precision)
•
Port side x.x
[m] (one decimal precision)
•
Starboard x.x
[m] (one decimal precision)
A,B,C and D values reported on the VHF link will be calculated from
Length, Beam, C,B and any extra convoy sizes.
This mode will make it easier for Inland AIS users to quickly change all
relevant dimensions when changing convoy configuration, but may cause
problems for external ECDIS integrations.
Installation Guide
1001001-3
SYSTEM FUNCTIONAL TEST
Please consult the product manual, included on the Nauticast Data Card
(USB-Stick), if any problems are detected.
SYSTEM POWER UP
The Nauticast A2 will start to operate when power is connected, the device
does not have a power switch. The system is fully operational within 2
minutes.
TRANSPONDER STATUS LEDs
Normal operation can be verified using the LEDs on the front. Tx and Rx
LEDs will flash during VHF Tx and Rx. Status LEDs on the transponder
signal these operational states:
SYSTEM STATUS
STATUS LED
Normal Operation
Solid GREEN
Unacknowledged active alarms
Flashing RED
Acknowledged active alarms
Solid RED
Power failure
OFF
Note: LEDs will behave differently during a system boot. Allow two
minutes from power-on before checking of LED status.
ALARM LIST
Make sure no unexpected alarms are active.
Main Menu Alarms
Disable any active alarms not applicable for the installation in the Alarm
Config View
. Main Menu Config Alarm
TIME AND DATE
Verify system time and date in the upper right corner. If incorrect, the
transponder internal GPS does not have a position fix. This will also be
indicated by an alarm “UTC Sync Invalid”.
GPS STATUS
Verify GPS antenna installation quality in the GPS Status View
Main Menu Status GPS Status
VHF Communication Test
Verify two way VHF communication with other vessels in the Comm. Test
View.
Menu Maintenance Comm. Test
.
Mounting
The Nauticast A2 can be panel or gimbal mounted (optional accessories
1001005 or 1001006). For flush mounting, remove the gimbal mount
jacket. Use the cutout dimensions in the figure below. Do not exceed the
cutout area, the screw holes may be too close to the cutout. A 1:1 scale
cutout drawing is included on the Data Card. If printed, verify scale has
not changed by measuring given dimensions.
Blue Sign Installation
BLUE SIGN
SWITCH
Power cable brown
Power cable orange
external resistor
12V: 2.2kΩ
24V: 10kΩ
Installation Guide
1001001-3
Nauticast A2 Signal Cable DSUB-OPEN, 1001003
26-pin High Density D-Sub, female. Out/Tx = Data from transponder.
Pin
In/Out
Signal Name
Signal Type
Colour
1
Out
ECDIS - TxB (+)
RS422
White
2
Out
ECDIS - TxA (-)
RS422
Brown
3
In
Sensor1 - RxB (+)
RS422
Green
4
In
Sensor1 - RxA (-)
RS422
Yellow
5
In
Sensor2 - RxB (+)
RS422
Grey
6
In
Sensor2 - RxA (-)
RS422
Pink
7
In
Long Range - RxB (+)
RS422
Blue
8
In
Long Range - RxA (-)
RS422
Red
9
-
Long Range - GND
RS422
Black
10
-
ECDIS - GND
RS422
Violet
11
In
ECDIS –RxB (+)
RS422
Grey / Pink
12
In
ECDIS –RxA (-)
RS422
Red / Blue
13
-
Sensor1 –GND
RS422
White / Green
14
-
Sensor2 –GND
RS422
Brown / Green
15
In
Sensor3 –RxB (+)
RS422
White / Yellow
16
In
Sensor3 –RxA (-)
RS422
Yellow /
Brown
17
Out
Long Range –TxB (+)
RS422
White / Grey
18
Out
Long Range –TxA (-)
RS422
Grey / Brown
19
-
Alarm Relay –GND
-
White / Pink
20
Out
Alarm Relay –Out
-
Pink / Brown
21
-
GND
-
White / Blue
22
-
TX test pin (do not connect!)
-
23
-
Sensor3 –GND
RS422
White / Red
24
-
Alarm Relay - VCC
-
Brown / Red
25
In/Out
CAN (+)
Diff. CAN bus
White/Black
26
In/Out
CAN (-)
Diff. CAN bus
Brown/Black
A2 Power Cable, 1001001-1
4-pin male circular ConXall, female.
5A Fuse.
Pin
Signal Name
Colour
1
12/24VDC positive
Red
2
GND
Black
3*
External Switch
(R)
Brown
4*
External Switch
(F)
Orange
*See manual on documentation
CD/USB-Stick for details on
external switch installation.
Transponder 232 pinout
Tx = from transponder.
Default 38400 bps.
Pin
Signal Name
1
Not Connected
2
AIS Data Tx
3
AIS Data Rx
4
Not Connected
5
GND
6
Not Connected
7
Not Connected
8
Not Connected
9
Not Connected
Use a standard DE9F to
DE9M Serial Cable.
System overview
