NavAtlas N652L Operating instructions

INSTALLATION/OWNER'S MANUAL
6.5" 2-Way Speakers
N652L

N652L INSTALLATION
2
Preparation/Installation
Please read entire manual before installation.
Before You Start
• Disconnect negative battery terminal. Consult a qualified technician for
instructions.
• Use extreme caution when drilling holes to avoid damaging fuel lines,
hydraulic lines or existing wiring.
• If additional wiring is required, we recommend that you run all wires
prior to mounting your speaker in place.
• Use the highest quality connectors for a reliable installation and to
minimize signal and power loss.
• Use caution before you drill or cut! Be careful not to cut or drill into gas
tanks, fuel lines, hydraulic lines, vacuum lines or electrical wiring.
• Avoid running wires over, near, or through sharp edged surfaces. We
suggest you also use rubber grommets to protect any wires routed
through metal.
Mounting and Installation
• Determine where the speakers will be mounted. Ensure an area large
enough for the speaker to mount evenly. Be sure the mounting location
is deep enough for the speaker to fit.
• Using an appropriate tool, cut a 6" diameter mounting hole.
• Use the speaker as a template to mark the locations for the mounting
screws. Drill the mounting screw holes with a 1/8" pilot bit. Route speaker
wires and connect to speakers, observing speaker polarity.
• Install speaker into opening using supplied hardware and test for
correct operation.

N652L INSTALLATION
3
Mounting
N652L
101mm
148mm
72mm 29.5mm
The diagrams featured above are to be used in conjunction
with the specifications matrix below:
Fractional Inches
N652L 6.50” 7.51" 2.67" 6.00” 1.1"
Grill Dimensions
(HxWxD) or (HxDiameter)
Outside Diameter
Cut-out Diameter Mounting Depth
Mounting Height

N652L INSTALLATION
4
The LED lighting elements of your speaker provides you with a unique custom
touch to your vehicle. The interior of your vehicle will never sound or look ordi-
nary again. Let your imagination take you there.
The lighting features of all NAVATLAS products require a 12 volt DC power
source to operate. The speaker has two distinct sets of input terminals. The
first is labeled audio input terminals and the second is labeled LED lighting
inputs. The inputs are clearly marked with a label positioned directly above the
terminal housing. The polarity (+ and -) indicators for each set of inputs also
appear on these labels.
1. Do not connect Amplifier or any audio source to LED lighting inputs.
Inputs are designed for switched 12 volt DC power source only.
2. See fig. 1a, (illustrates wiring diagram) be sure to maintain polarity.
Be sure to connect to a constant switched 12 volt DC source.
Correct connection would be the positive (+) 12 volt wire to the Positive
(+) LED Lighting input terminal and connect the Negative
(-) LED lighting input terminal to a good chassis ground.
Note: There are no serviceable parts inside or attached to the speaker assem-
bly. Removal or tampering with any part or portion of the speaker and/or its
assemblies will damage the product and void the limited warranty.
Lighting Hook-Up Recommendations
LED
TERMINALS
Ground
12-Volt Source
Speaker Wire Terminalls
Audio
Source
Illumination Connections (Rear View)

N652L INSTALLATION
5
Limited One Year Warranty
EXCHANGE ONLY ON FACTORY DEFECTS, PHYSICAL
DAMAGE IS NOT COVERED BY WARRANTY.

N652L INSTALLATION
N652L
6.5"
Santoprene
Aluminum Dome
1"
120W
240W
89dB
60Hz - 20kHz
4 Ohms
UV-resistant ABS
Woofer size
Woofer surround
Tweeter type
Tweeter size
RMS Power
Peak Power
Sensitivity
Frequency response
Impendence
Basket material
Specifications
Support Line: 1-562-946-7471
9AM-5PM PST Monday-Friday
www.navatlas.com
All rights reserved.
NSA0218-V01
Design and specifications subject to change without notice.
