NavAtlas NT650AT Operating instructions

INSTALLATION/OWNER'S MANUAL
6.5" Amplified Wakeboard Tower Speaker
NT650AT

1
Dimensions
Preparation/Installation

NT650AT INSTALLATION
2
Clamp Mounting

3
Wiring
NOTE: Some 3rd Party Radios/
Source Units might have a preout of
1V or less, this will cause the audio
output to sound low. We recommend
the LB5V RCA line driver be used in
this situation to increase the preout
voltage and raise the sound level of
the amplifer.
12v+

NT650AT INSTALLATION
4
1.
2.
3.
Mounting Bracket Rotation

5

NT650AT INSTALLATION
6
Specifications
(Total)
(x2)

AMPLIFIER SIGNAL INPUT
USING 3RD PARTY SOURCE UNIT
When using any Navatlas amplified product, the Analog RCA input requires a
3Volt or greater pre-out from the source unit to maximize the volume
output. In developing our product, we have matched our amplifier’s preamp
sec�on to our Command Centers, radios, and Bluetooth controllers signal
output. In doing this, our product can be played at maximum volume without
clipping or distor�ng, in most cases.
When using our amplified product with 3rd party source unit,
there is a
limita�on of volume due to the radios output being a lower voltage, 2.5Volt
or lower. To solve this, there must be an RCA line driver between the source
unit and the amplifier. We recommend using the Navatlas LB5V Line Driver.
