Nave TPMS TP001 User manual

TP001TPMS
Tire pressure monitoring system
Manual

Index:
1.Notice of usage
2.Specification
3.Installation of battery
4.QR code sticker
5.App installation & device installation
6.Error code & status
7.Program pause
8.Notice
9.Warranty
Package includes :
1.TPMS set (including sensor/ CR2032 battery/ bolt)
2.Wrench*1
- 4 sensors for car version
- 2 sensors for motorcycle version
- single sensor package
CR2032
3V

1.Notice of usage
Reminder:
1.Using chemical sealing system inside the tire
could lead to TPMS malfunction.
2.Regularly check tire valve & external treads to
make sure they work properly, as TPMS is only an
optional safety equipment.
3.TPMS wireless signals could be lost by
interference,wrongly operation and installation
could also lead to signal loss.
4.Proper tire pressure and good maintenance will
save your gasoline consumption and a safe
journey.

2.Specification
2.4-GHz/Bluetooth/Low Energy Compliant
Dimension: Width:24.4mm* Height:22.68mm
Weight: 7.5g±0.2g(per sensor)
Transmission
distance: 10~30m line of sight
Operation temp: -20℃~85℃
Tir pressure
range: 0 KPa~800KPa
Battery: CR-2032 (3.0V)
Max power
consumption: 107μA
Transmission
interface: Bluetooth BT 4.0 (BLE)
RF
Output Power：0dBm

3.Installation of battery
1.Open the lid counter-clockwise. 2.Insert CR2032 battery with “+”
facing up.
3.lose the lid clock-wise 4.Finish
Notice:
Please only use CR2032 battery for battery
swap. Wrong battery could lead to malfunction
and damage.

4.QR code sticker
QR code sticker is included inside the package, please do not lost it.
QR code sticker number should match with TPMS sensor number
, please pair the sensors by order on your phone app.
1
1
QR Code
編碼貼紙僅此一份，請妥善保管，如遺失，恕不補發。

5.App & TPMS installation & usage
A.Please search “nAve TPMS”, and
installation for free.
5-1.APP download
B.Open the app, the app ca be used with your phone eit-
her vertically or horizontally.
nAve TPMS
版本15.0.1
nAve TPMS

Instructions
Vehicle selection back Set Up
Language
Auto-Lock
Forced Alert
English
5-2.App setup
Click “ ” for setting
A.Choose your language: Japanese, English,Chinese (sim-
plified), Chinese (traditional)
B.B.Choose “always-on” mode, then the app will
always on.
C.Turn on alarm overwrite mode, system alarm sound
will function even in phone silent mode. Adjust the vol-
ume to 50%~100%.

5-3.Build up new vehicle info
Press “ ” enter vehicle info
A.Press picture area to choose picture from database or
to take a photo.
B.Name your vehicle by pressing name area
C.Choose vehicle spec, then press finish.
D.To redo or edit, press the picture 3 secs.
使用說明
車輛選擇
4 wheel
2 wheel
2 front wheel / 1 rear wheel
1 front wheel / 2 rear wheel
Back
OK
My Car
Type Selection
My Car
My Motor
My Car 2
Instructions
Vehicle selection
Select
Edit / Delete
Vehicle data
DeleteEdit

Scan QR code
camra on
Back Back
Enter QR code
Touch 3 seconds
to connect
Touch 3 seconds
to connect
Touch 3 seconds
to connect
Touch 3 seconds
to connect
(L)Front Tire1 (R)Front Tire2
(L)Rear Tire3 (R)Rear Tire4
Back
setting
setting
5-4.Pairing the sensor
Pairing the sensor on your App, please follow serial
number and pair in order.
A.Press 3 sec for pairing mode.
B.Scan QR code with your phone for pairing, or enter the
serial number below QR code for pairing.

5-5.Installation of sensors
4.Finish, then apply soap water on the sensor to see
if leaking.
1.Lock the bolt onto the valve clock-wise.
2.Lock the sensor (with battery ) onto the valve
clock-wise.
3.Use wrench to fasten the bot counter clock-wise
, so the sensor & bolt will lock tightly.

Back
Psi
42
34
30
70
OK
Temperature Unit
Pressure Max
Pressure Min
Temperature Max
Pressure Unit
Standard pressure
Stop
Back My Car Monitoring...
(L)Front Tire1 (R)Front Tire2
(L)Rear Tire3 (R)Rear Tire4
setting
setting
Press setup button to setup tire pressure.
Follow the suggested tire pressure range form tire com-
pany, tire pressure range can be set up automaticallyor
manually.
5-6.Tire pressure setup

6.Error code
A.Wrong tire pressure
Too low or too high, the background color will turn red + alarm sound
B. Wrong tire temperature
Too low or too high, the background color will turn red + alarm sound
C. Sensor malfunction:
1.Please check if the sensor is missing
2.Please re-pair, choose then ” a gain or
scan QR code to re-pair.
3.If the sensor is mail-functional, please contact your dealer.
pause connect
Stop
Back My Car Monitoring...
(L)Front Tire1 (R)Front Tire2
(L)Rear Tire3 (R)Rear Tire4
Please Check Tire !
Alarm
setting
setting
Stop
Back My Car Monitoring...
(L)Front Tire1 (R)Front Tire2
(L)Rear Tire3 (R)Rear Tire4
Please Check Tire !
Alarm
setting
setting
Loss of signal
connecting...
Stop
Back My Car Monitoring...
(L)Front Tire1 (R)Front Tire2
(L)Rear Tire3 (R)Rear Tire4
Please Check Tire !
Alarm
setting
setting

1.Press “ ”button on right top of your app screen
to pause.
2.Press “ ” button again on right top to resume.
pause
connect
StopStop
Back My Car Monitoring...
(L)Front Tire1 (R)Front Tire2
(L)Rear Tire3 (R)Rear Tire4
setting
setting
Connect
Back
setting
setting
My Car Monitoring...
(L)Front Tire1 (R)Front Tire2
(L)Rear Tire3 (R)Rear Tire4
Stop
7.Program pause

8.Notice
1.TPMS cannot guarantee the safety of your trip, please check your tire
regularly.
2.Please pull over whenever you sees/hears alarm.
3.TPMS cannot detect any instant tire damage from outside environm-
ent.
4. Do not operate TPMS and drive at the same time.
5.Sensor battery life varies by battery quality and usage.
6.please only use CR2032 battery for battery swap. Wrong battery cou-
ld lead to malfunction and damage.
7.Recycle the dead battery
8.Battery power shortens by regular usage and battery life could also s-
horten under -20C environment.
9.Sensor could not be working if battery voltage is too low, please cha-
nge batteries.
10.Tire pressure varies when temperature inside/outside the tire varies.
11.Please park your vehicle properly to avoid any damage/lost to TPMS.
12.TPMS device is IP67 certified, but please do not soak the sensor into
water or chemicals for a long time.
13.Please consult tire vendor or professionals for related tire index.

9.Warranty
Thank you for purchasing this device, we provide limited one year wa-
rranty upon your purchase date, please do not lost your QR coe sticker
, warranty card.
Below conditions are not within our warranty:
1.Product damaged by nature cause
2.Product damaged by miss-use
3.Product damaged by not following the manual instruction
4.Product failure not caused by product
5.Use non-original parts.
6.Product failure by battery out.
Disclaimer:
This TPMS device is only an optional accessory, any car accidents by dri-
ver behavior or by damaged tire is not a responsibility to the manufact-
urer.
