Navos 407632 User manual

Step 1
Begin by removing the shift knob on manual transmission
equipped vehicles or the shifter trim bezel on an automatic
car.
Step 2
Open the center console. Pull up on the back of the center
console trim to remove.
Step 3
Unplug all electrical connections. This includes the connec-
tion on the front left of the panel and the connection on the
right side of the panel if applicable.
Step 5
Unplug the HVAC connector on the bottom right of the
panel, remove the panel from the vehicle. Remove the (6)
White clips from the panel and transfer them to the Navos
panel. Store the factory dash panel in a safe location. This
will not be reused.
Step 4
Remove the (2) 8mm screws securing the dash trim panel to
the vehicle. Then using a soft pry tool, gently pull the panel
from the dash board. **Note: Steps 4-6 will be slightly
dierent but very similar for vehicles with factory navigation.
Step 6
Remove the (4) 8mm screws that secure the upper display (A)
to the vehicle. Disconnect and remove the display. Next,
remove the (4) 8mm screws that secure the CD player (B) to
the vehicle. Disconnect the (2) plugs and (1) antenna **Note:
pull on the antenna from the black metal collar, pulling the
cable can cause damage to the antenna. Place A and B with
the dash panel removed in step (5)
2010-2014 OE Style Touch
Screen Navigation
AA
B

Step 8
Unplug the factory AUX connector from the center console.
Plug in the factory integrated AUX cable for the Navos unit.
The red and white RCA cables will connect to inputs cable for
the navigation unit.
Step 9
(Sync Vehicles Only)
Access the factory Sync module by lowering the glove box.
Open the glove box and apply rm pressure to either side
while gently pulling it down.
Step 10
(Sync Vehicles Only)
Locate the USB connector on the Sync Module.
User Instructions
Sku: 407632
Step 7
(Dual Climate Control Only)
To retain the “Auto”Fan speed control, remove the (2) T20
screws securing temperature sensor to the factory dash
panel. Relocate the sensor to the passenger side foot well.
There is space where the dash meets the carpet.
Step 11
(Sync Vehicles Only)
Remove the USB cable from the Sync module.
Step 12
(Sync Vehicles Only)
Connect the Navos Sync Adapter to the Factory Sync USB.
Route the Navos cable to the opening in the dash board. This
Adapter cable will be connected to the USB labeled“Media”
coming o the back of the navigation unit. The factory Sync
module will no longer have a USB cable connected to it.
Close the glove box.
Factory Sync USB
Sync Adapter to
Navos

User Instructions
Step 13
Connect the antenna adapter to the factory antenna. Ensure
the antenna is pressed all the way into the socket, it is a tight
t. **Note: Failure to do so will result in poor/no radio
reception.
Step 14
GPS Antenna- Connect this to the metal bracing behind the
dash board. Keep the antenna facing up and the magnet
side down. **Critical for GPS Reception: Loosely loop any
extra wire. If wound too tight signal loss is possible. Attach
the GPS Antenna to the“GPS” location on the navigation unit.
Step 15
Route the Microphone adapter as desired. Common
placement locations are on the sun visor or on top of the
steering column. Route the microphone plug to the back of
the navigation unit labeled“Mic”.
Step 16
Connect the main wiring harness to the vehicles factory
plugs. See the diagrams following Step 21 for addition
information.
**Note: Be sure to connect the 2/4 Pin AMP/SWC plug from
the back of the navigation unit to the main wiring harness,
failure to do so will result in NO AUDIO. Please see the Wiring
Diagram for location.
Sku:
Step 17
Install the iLink USB dongle into the “iLink” USB port coming
out of the back of the navigation unit. Then, plug in the USB
extension in to dongle. Route the cable to the glove box or
center console for easy access.
Step 18
Before re-installing the dash panel and console panel, turn
the vehicle on and test to make sure the navigation unit
powers up. Turn on the radio to ensure reception, doing so
may require you to back the car out of the garage.

User Instructions
Main Harness
Connect to Factory
Wiring Harness
Shaker Amplier
Integration Harness
Amplier Output
Harness
AMP/SWC
Required
Plug
With Shaker Audio
(Amplied)
Vehicle Wiring Congurations Depending on Factory Options
Connect to Factory
Wiring Harness
Main Harness
Not Used
Without Shaker Audio
(Not Amplied)
AMP/SWC
Required
Plug
Step 19
Place the GPS MicroSD card in the“Nav” slot on the front of
the dash panel. Test GPS functionality (GPS MicroSD card
must be in the unit for the navigation to work).
“MMC” Can be used to load audio to the unit using a
dierent MicroSD card (not supplied).
Step 20
Re-install the Navigation/dash panel by neatly tucking the
wires behind the navigation unit. ** Note: There is a notch in
the bottom right side of the dash panel to allow the AUX
adapter harness to pass through without getting pinched.
Step 21
Finish the install by pressing in the appropriate dash panel
ller plugs. If your car came factory equipped with heated
seats, use the heat seater plugs. If you do not have factory
heated seats install the blank plugs. Enjoy.
Sku: 407632
Harness Notes:
Cars with factory ampliers may require the use of the amplier integration harness, this will provide a lower level output from the Navos to match the
factory amp. Not all cars will require this harness.
If the speaker output level is very high use the amplier integration harness. If the audio output is very low, remove the amp integration harness and plug
the main harness directly into the Navos.
Additionally there is a "Factory Amplier" setting in the sound menu that can be used to ne tune the output level of the head unit to any given installation.

GPS Micro SD
Main Harness
Panel Plugs
Microphone
Antenna Adapter
USB Extension
GPS Antenna
Sync Adapter
Shaker Amplier
Integration Harness
(If Equipped)
Sirius Radio Adapter
(Optional)
**Note: Additional
Hardware is required
for Satellite radio
Factory
Aux-adapter
Amplier Output
Harness
(Shaker Audio
Equipped Otherwise
Optional)
Input Harness
(Optional)
Video Outputs
(Optional)
GPS Antenna
AM/FM Antenna
Main Harness
Microphone
Inputs Outputs
Video Output
Sirius Antenna
System
Media
AMP/SWC
(2/4) Pin
Connector
Contents:
(1) Navigation Unit with Dash Panel
(1) Main Harness
(1) Shaker Amplier Integration Harness
(1) Amplier Output Harness
(1) Input Harness
(1) Video Output Harness
(1) Factory Aux Adapter Harness
(1) Sirius Radio Adapter Harness
(1) Microphone
(1) GPS Antenna
(1) USB Extension
(1) Antenna Adapter
(1) Sync Adapter
(1) GPS Micro SD
(1) Panel Plugs
(1) iLink USB Dongle

GPS
ANTENNA
AM/FM
ANTENNA
ADAPTER
SHAKER AMPLIFIER INTEGRATION HARNESS
(CONNECT AS SHOWN WHEN INSTALLING
WITH SHAKER AUDIO SYSTEM)
VEHICLE
CONNECTION
HARNESS
AMPLIFIER OUTPUT
HARNESS
INPUT HARNESS
SIRIUS XM
AMPLIFIER OUTPUT
HARNESS
VEHICLE
CONNECTION
HARNESS
REMOTE TURN ON
OEM USB
RETENTION CABLE
LEFT AUDIO INRIGHT AUDIO IN
OEM AUX IN
RETENTION CABLE
iLink Pro
iLink Pro
User Instructions
Sku: 407632

Factory Shaker Audio to Navos Wiring Harness
Factory Base Audio to Navos Wiring Harness
Navos Unit
No Audio Trouble Shooting Required Wiring
Ensure the (2/4) Pin
AMP/SWC Plug o the
back of the Navos Unit is
connected to the circled
red (2/4) pin plug on the
main wiring harness.
