Nebula Ne-spark User manual

STAGE EFFECT MACHINE

USER MANUAL

1.Introduction:

Thank you for choosing the “spark” machine.

We recommend that you carefully read these operating instructions before commissioning the

unit. Please follow the instructions in this manual. This is the only way to ensure safe operation,

proper use and long service life.

Feature:

◆Environmental protection,safety:no gunpowder and no irritant

◆Support wireless control and DMX, operate is more easy and convenient.

Maintenance：

◆Please clean the machine regularly. It will reduce the replacement and repair cost of spare parts.

◆Do not use for a long time, to clean the machine and make extra powder out.

Product description：

1. handle 2. Spark nozzle 3. Power in

4.Fuse 5. Power switch 6. USB connector for update

7.DMX in/out 8. Power Output 9. Power Input

10. Digital display board 11. Remote control connector

2.Safety instructions:

◆Keep away from humidity, water and dust! Avoid placing the device in a location with high

humidity or excessive dust.

◆Place the device on a firm ground!

To avoid vibrations always place the device on a firm ground.

◆Do not use chemicals for cleaning!

Use a clean and dry cleaning rag to remove dust. Metal parts can be cleaned with a damped cleaning

rag. Before cleaning always unplug the device from the power supply.

◆If the device is not working properly!

If problems occur unplug the device from the power supply. The user should not try to service the

device independently. All repairs and service must be performed by a qualified technician.

◆Eye Protection

The eye protection warning icon is Shown to indicate that you must be protect your eyes when close to

the machine during machine operation.

◆The safety distance to the audience must be 2meter

Never aim the nozzle on people and keep a distance from 1 meter to the nozzle.Don't spray on the

food.

◆ATTENTION!

Damages caused by the disregard of this user manual are not subject to warranty. The dealer will not

accept liability for any consequent secondary failures. Only skilled workers are allowed to carry out

the electrical connections. All electrical and mechanical connections have to be carried out according

to the European safety standards.

Outdoor powder cannot be used indoors!When using outdoor powder, there should be no carpet

around the spark machine, and other inflammable articles!

The powder should not be exposed to the air. If a bag of powder is not used up, it should be kept in a

sealed condition and not exposed to open fire.

◆NOTE: Machine must be vertical if has powder in the tank. Must take out all powder when machine

shipped.

3.Technical data:

Wireless Controllers ---Instructions:

There is a receiver and a transmitter with 12 buttons

When the heating is complete, the green indicator on receiver will light on ; when the heating is not

finished, the red indicator lights on. Only when the machine finished the warming up and ready ,the

device can work .

4.Specification :

Operation:

5.1Before using：

Never stand directly below the device when it is being mounted, removed or serviced.Have a

qualified technician to check the device annually and additionally before placing into service if stored

for an extended period of time.

Rated voltage

AC220V/50Hz

Rated power

700 W

fuse

3.15 A

Pre-heating

time

6 min

Spark max

height

2-5M

Spark height

change

support

Wireless

controller

Support (Optional)

Display screen

Digital display board

DMX

support

DMX channel

DMX range

1-512

Net weight

6.86 Kg

Gross weight

8 Kg

Machine size

200*200*255mm

Carton size

285*285*331mm

Install the device in a secure location that is inaccessible to unauthorized persons.This machine

can only be used by adults.

Make sure there is no flammable material within a 10ft radius of the device.There can be no

objects blocking the use of the machine.

Be sure that the local power outlet match that or the required voltage for your machine.

Can not join any flammable liquid, such as oil andgas.

Be sure the lid is well covered before use the machine,or the spark will splash out.

5.2Usage method：

◆Place the unit on a flat,dry surface. The machine CAN NOT be sidelong or upside down, please

pay attention to keep upright only. Otherwise the spark will not be vertical and probably make the

machine damaged.

◆fill the powder reservoir with our powder only then tighten the cap.

◆Connect with the correct power supply and switch on the power button

◆Connect the W-9 receiver

◆You can see “OFF” at display board .then use W-12 transmitter –press power button on

transmitter to activate the buttons function ,then press ON(Pre-heat)button to have the device start

to preheating ,at that time you can see the display change to different data.

◆When finished warming up , it will show “FFF” ,and ready LED(above the display board) will

light on

◆At that time ,you can use transmitter to have it work .or use DMX to have it work .below some

more description FYI:

OFF :Indicates that the machine is powdered but did not start to warming up

FFF: The green light indicates that the machine is ready to Work.

DMX:Red light flashes to indicate a successful DMX

FAULT:Red light indicate error alarm.

6. DMX CHANNELS:

When using the DMX mode, two channels are occupied.

First channel

Function

Fountain off

1-255

Fountain on

Second Channel

Function

0-20

Pre-heat off，And the first channel

is invalid

50-100

Pre-heat on，And the first channel

is valid

150-200

Clear Materical ，And the first

channel is invalid

7. IMPORTANT NOTES:

1. This machine can be put upright only!

2. Add powder and TIGHTEN the cap !

3. NEVER POUR SPARK POWDER INTO THE SPARK DISCHARGE OPENING! THIS CAN BE

DANGEROUS! SPARK POWDER MUST ONLY BE ADDED TO THE STORAGE TANK THAT

REQUIRES THE REMOVAL OF THE PROTECTIVE CAP. DO NOT OVERFILL! AFTER FILLING

REPLACE CAP AND TIGHTEN.

4. Please do not test the spark for a long time, which will reduce the use time of the machine

sparking .

5. After each time use before shipped ,please clear granules from storage tank, allow machine to

cool, then remove tank cap and invert machine to shake granules out of tank.

6. The powder should not be exposed to the air. If a bag of powder is not used up, it should be

kept in a sealed condition and not exposed to open fire. Store or dispose of properly!

7. Damages caused by the disregard of this user manual are not subject to warranty. The dealer

will not accept liability for any consequent secondary failures. Only skilled workers are allowed

to carry out the electrical connections.

8. Outdoor powder cannot be used indoors! When using outdoor powder, there should be no

carpet around the spark machine, and other inflammable articles and must be outside !

9. Do not allow machine to run out of powder.

10. The machine should have minimum 1M clearance all around.

11. Keep away from Children.

8. Warranty Instructions:

◆Warranty period：one year(the date of purchase)

◆IF the buyers do not user the same supplier’s powder,the machine warranty period will b e 3 month.

The buyer will pay for the expenses if there are any components changes.

◆In such In the following cases, the product will not be guaranteed:

A: the product has been incorrectly operated and used inadvertently, for example, over load, over

pressure, and firing;

B: the product was broken because of careless handling;

C: due to poor use of environmental factors and sound quality problems, such as: humidity, voltage

instability, etc.;

D: products have been modified by non factory personnel.

◆products comply with the warranty provisions, the factory will not charge maintenance fees and

accessories costs, for more than the warranty period of the product, only the corresponding parts,

finished goods costs.

◆the contents of this warranty card, the company has the right to interpret, if the user is unknown,

please contact the local distributors.

◆not covered by the warranty include: packing box, packaging, product shell and hanger, remote

control transmitter battery.

WARRANTY CARD

MODEL:____________________________________________________________________________________________(REQUIRED)

NAME:______________________________________________________________________________________________(REQUIRED)

DATE OF PURCHASE:_____________________________________________________________________________(REQUIRED)

DEALER NAME:___________________________________________________________________________________(REQUIRED)

ADDRESS OF DEALER:_________________________________PROVINCE_______________________________________CITY

_______________________________________________DISTRICT________________________________________________________

NOTES:Fill out the warranty card clearly so that we can solve it for you soon!Please send back the

machine with warranty card for repairs.

RECORD CARD FOR MANUFACTURER

1.MAINTENANCE:

SYMPTOM(FOR USER):
