OPS i5 PC - Install Guide for X Series NEC displays
Revised 12-30-2011 Page 1

OPS i5 PC - Install Guide for X Series NEC displays
Required Tools
●Philips Head Screw Driver
●Ethernet Patch Cable
Step 1
1. Remove LCD display from box and lay screen face down on
the box.
2. Carefully remove protective plastic cover to expose the
right side of the back of the LCD display where OPS slot is
located.
Revised 12-30-2011 Page 2

Step 2
1. Using Phillips head screwdriver, remove the four screws
that secure the OPS Slot Cover in place. Be sure to save
the 4 screws, you will need them to put the vented cover
on.
Step 3
1. Using Phillips head screwdriver, remove the two screws
holding the handle in place.
2. When handle is removed, place the two screws back into
the holes in the display but be sure to stop tightening as
soon as you meet resistance - screws will NOT go all the
way back in flush.
3. Set handle aside
*For 40” and 46” LCD's, the handle will not be re-installed as it will
be in the way of accessing the OPS PC. For 55” displays, where
the handle is not blocking access to the OPS PC, removing the
handle is not required.
Revised 12-30-2011 Page 3

Step 4
1. Open box containing OPS PC and remove contents - there
should be the OPS PC, CD and Option board slot cover.
Step 5
1. Using Phillips head screwdriver and the 4 screws you
saved when removing the factory cover, install the Option
board slot cover.
2. Using Phillips head screwdriver, remove the two slot
retaining screws at the front of the slot. Save these 2
screws as you will use them to secure the OPS PC in place
once installed.
*Note also in image, the 2 handle screws that have been re-
inserted in the previous steps, but that do NOT go in all the way
Revised 12-30-2011 Page 4

Step 6
1. Insert OPS PC into Option slot with fan facing away.
2. Make sure the OPS PC is seated properly, do not force.
IMPORTANT - make sure the fan is visible and facing away from
the display as you insert it.
Step 7
1. Using Phillips head screwdriver replace the 2 screws you
removed in step 5, #2 to secure OPS PC into place.
*Note the NEC logo position in image to the right.
Revised 12-30-2011 Page 5

Step 8
1. Insert standard straight through Ethernet cable into OPS
PC network port and connect to client network.
2. Now that the OPS PC is installed and the network
connection is in place, connect the power cord to the
display.
3. Stand the display upright and turn on the power (power
switch is located beside the power cord)
4. Using either the remote or the buttons on the display, select
the OPTION input. (Will show Option D on the display)
5. Verify the display powers on and that Windows starts up.
6. Rise Display content should automatically start playing in a
few minutes.
7. Now that the LCD and OPS PC have been verified to work
properly, disconnect the Ethernet cable, power down the
display, and proceed with the installation of the LCD.
