NEC MultiSync®MD213MC
21.3” high-bright, high-resolution, 3MP color LCD display
ideal for color and grayscale medical imaging applications
Medical Desktop
Designed exclusively for the demanding needs of medical imaging
and PACS, including CR and DR, the NEC MultiSync MD213MC,
a 21.3” 3-Megapixel (MP) color display, features the flexibility of a
color display with image performance rivaling grayscale displays.
Benefits you’ll realize from this medically certified display include:
• NEC’s UA-SFT 3MP (1536 x 2048) liquid crystal technology offers
high brightness without compromising contrast or viewing angles,
making the image quality outstanding for color or grayscale images
• ColorComp™ digital uniformity correction reduces screen uniform-
mity errors and compensates for differences in color/grayscale and
luminance across the entire screen
• Integrated tri-stimulus (three-color) sensor receives more light
information than standard (brightness only) sensors and, therefore,
is extremely accurate and stable
• Each NEC MultiSync MD213MC monitor is calibrated out of the
box to the DICOM grayscale display function for luminance.
• 12-bit gamma provides for more nely detailed, high-denition
rendering of color images and crisper display of even the most
delicate shadings and color differences
• GammaComp™ MD software, included with each display, ensures
consistent image quality. The software provides a simple interface
for conformance to the DICOM standard, while providing an easy-
to-use QA environment for medical imaging. Optionally, Gamma-
Comp MD Administrator provides computer networks with central-
ized control and management of multiple display systems.
• FDA 510(k) approved for use in digital radiology applications

NEC Display Solutions
500 Park Boulevard, Suite 1100
Itasca, IL 60143
866-NEC-MORE
MultiSync is a registered trademark, and ColorComp and
GammaComp are trademarks of NEC Display Solutions. All other
brand or product names are trademarks or registered trademarks of
their respective holders. Product specications subject to change.
12/09 Ver. 3.
©2009 NEC Display Solutions of America, Inc. All rights reserved.
Model
Display
Viewable Size Image
Pixel Pitch
Pixels Per Inch
Brightness (typical)
Contrast Ratio (typical)
Viewing Angle (typical)
Response Time (typical)
Panel Bit Depth
Synchronization Range
Horizontal
Vertical
Video Bandwidth
Input Signal
Video
Sync
Inputs
Native Resolution
Additional Features
Voltage Rating
Power Consumption (typical)
On
Power Savings Mode
Dimensions (WxHxD)
Net (with stand)
Net (without stand)
Net Weight
(with stand)
(without stand)
VESA Hole Configuration
Specifications
Environmental Conditions
Operating Temperature
Operating Humidity
Operating Altitude
Storage Temperature
Storage Humidity
Storage Altitude
Safety Standards
Limited Warranty**
MultiSync MD213MC
21.3"
0.21mm
120
400 cd/m2 calibrated / 800 cd/m2max
750:1
176° Vert., 176° Hor. (88U/88D/88L/88R)@ CR>10
Rapid Response™ 24ms (12ms Gray-to-Gray)
12-bit internal LUTs, displays 16.7 million colors out of 68.5
billion color palette and up to 1024 shades of gray out of 4096
31.5 - 93.8 KHz (Analog) / 31.5 - 95.4 KHz (Digital)
30 - 85 Hz
25.2 - 209.3 MHz (DualLink)
Analog RGB 0.7 Vp-p/75 Ohms
Separate sync: TTL Level (Positive/Negative)
Composite sync: TTL Level (Positive/Negative)
DVI-D and DVI-I
2048 x 1536 @ 60 Hz landscape /
1536 x 2048 @ 60 Hz portrait
Ultra-thin frame (bezel), No Touch Auto Adjust™, VESA
Mount, tilt, swivel, height-adjustable stand (5.9 in./150mm),
pivot, vacation switch, 12-bit LUTs, black level adjustment,
AmbiBright, ColorComp uniformity correction, overdrive,
Digital CableComp™, GammaComp™ MD software, stand-
alone calibration
AC 100-120V / AC 220-240V
105W
2W
18. x 17.1 - 23 x 12 in. / 467.8 x 434.3 - 584.3 x 306mm
18.4 x 14.2 x 4.4 in. / 467.8 x 361.6 x 110.7mm
23.5 lbs. / 10.7 kg
16.5 lbs. / 7.5 kg
100 x 100mm
5-35° C / 41-95° F
30-80%
3000m / 9842 ft.
-10-60° C / 14-140° F
10-85%
12,192m / 40,000 ft.
UL/C-UL, UL60601-1, Gost/PCT, PSB, CCC, FCC Class B/
Canadian DOC, C-tick, MPR II / MPR III, VCCI (class 2),
JIS C 61000-3-2, static electricity guideline, low emission
guideline, US Mercury regulations, WEEE, RoHs, SASO,
Energy Star, J-Moss, FDA 510(k), CE-MDD, IRAM, TUV GM,
EPEAT, AAPM-TG-18, DIN V 6868-587 (Germany) CATB
5 years parts and labor, including Advanced Overnight
Exchange
* Digital only
** Backlight usage limited to 30,000 hours at 400 cd/m2or less
The MD213MC’s design allows you to adjust the display
to your exact ergonomic preferences. In addition to
tilt and swivel functionality, the height adjusts up to
150mm, and the display pivots between landscape to
portrait orientations.
Achieve complete color and brightness uniformity. By
nature, LCD panels contain uniformity errors, which
are visible as slightly brighter or darker areas on the
screen. To combat this inherent trait, each MultiSync
MD213MC display is individually characterized during
production using a fully automated system that measures
multiple points across the screen at different gray levels.
These measurements are used to build a 3-D correction
matrix stored inside the display. This data is used to
compensate for the uniformity not only as a function
of position on the screen but of gray level as well. In
turn, this technology, called ColorComp, reduces the
non-uniformity to virtually unnoticeable levels and
applies a digital correction to each pixel on the screen to
compensate for differences in color and luminance.
For consistent image quality the
built in front sensor constantly
monitors and maintains
brightness for optimal DICOM
GSDF calibration and for non-
assisted conformance, calibration
and reporting functions,the
sensor is capable of measuring
monitor brightness, white-point
and contrast response.
0. 0
5. 0
10. 0
15. 0
20. 0
25. 0
30. 0
35. 0
40. 0
45. 0
50. 0
0 20 40 60 80 100
Bef o r e
Af ter
Ambient
light
For optimal image viewing in any lighting condition,
the MD213MC’s built-in ambient light sensor can
automatically adjust the calibration of the display to suit
the environment.
