NEC MultiSync® EA222WMe
Fully featured office monitors with outstanding ecological performance and display quality
Highly efficient LED panel Technology saves more than 50% energy
•
Ecologics and Ergonomics complying to standards EPEAT Gold and TCO 5.0
•
ErgoDesign®: Height adjustable stand (110 mm) with 90° Pivot features
•
Information on Carbon Footprint with unique integrated Carbon Meter
•
Ambient light sensor for optimized brightness levels
•

LCDs • Projectors • Plasmas • LCDs • Projectors • Plasmas • LCDs • Projectors • Plasmas • LCDs • Projectors • Plasmas • LCDs
NEC MultiSync® EA222WMe
TECHNICAL SPECIFICATIONS
Panel Technology W-LED TN TFT
Screen Size [inch/cm] 22.0 / 55.9
Pixel Pitch [mm] 0.282
Viewing Angle [°] 176 horizontal / 170 vertical (typ. at contrast ratio 5:1)
170 horizontal / 160 vertical (typ. at contrast ratio 10:1)
Contrast Ratio (typ.) 1000:1 (30000:1 (typ.) dynamic contrast ratio)
Brightness (typ.) [cd/m²] 250
Response Time (typ.) [ms] 5
Colours [Mio.] 16.77
Horizontal Frequency [kHz] 30 - 82
Vertical Frequency [Hz] 56 - 75
Optimum Resolution 1680 x 1050 at 60 Hz
Supported Resolutions 1680 x 1050; 1440 x 900; 1400 x 1050; 1360 x 768; 1280 x 1024; 1152 x 864; 1024 x 768; 832
x 624; 800 x 600; 640 x 480
Connectors Digital: 1 x Display Port; Digital: USB ver. 2.0 (1 down / 4 up); Digital: 1 x DVI-D (with HDCP); Analog:
1 x mini D-sub 15 pin
Plug & Play VESA DDC/CI; DDC2B/2Bi; EDID Standard
Adjust Functions Audio Volume / Lock-Out; Auto Adjust; Brightness; Colour Temperature Control; Contrast; DV Mode;
EcoMode; Fine Adjust (analog); Intelligent Power Management; Language Select; LED Brightness;
Monitor Information; NTAA (Non-Touch-Auto-Adjustment); On-Screen-Display (OSD) lock-out; Power-
Off Timer; sRGB
Safety and Ergonomics EPEAT™ Gold; CE; TCO 5.0; TÜV Ergonomics; TÜV GS; GEEA/Energy Label; Energy Star 5.0; FCC
Class B; PCT/Gost; UL/C-UL or CSA; CCC; ISO 9241-307 (pixel failure class I); MPR II/ MPR III; RoHS
Power Consumption on Mode [W] 23 (typ.); 17 (Eco Mode 1); 13 (Eco Mode 2)
Stand-by Mode [W] < 0.5
Power Supply 100-120 V/220-240 V; 1.0 A/0.5 A; integrated power supply
Ambient Temperature (operating) [°C] +5 to +35
Ambient Humidity (operating) [%] 20 to 80
VESA Mounting [mm] 100 x 100
ErgoDesign®: Height adjustable Stand [mm] 110
Screen Tilt / Swivel / Rotate [°] -5 to +30 / -170 to +170 / 0 to 90 (landscape to portrait mode)
Dimensions (W x H x D) [mm] 508 x 382 x 220
Without stand: 507.8 x 332.1 x 71.8
Bezel Width [mm] 16.0
Weight [kg] 7.0; Without stand: 4.5
Cable Management yes
Kensington Lock yes
Benefits 16:10 wide format; Ambient light sensor for optimized brightness levels; Carbon Footprint Meter;
Carbon Savings Meter; integrated USB Hub; NaViSet®and NaViSet®Administrator compatible; sRGB
Support; TORO™ Design; Windows 7 compatible; WindowsVistaCertifiedLogo
Audio Functions 1W + 1W (De-activateable)
Colour Versions Silver Front Bezel; White Back Cabinet
Black Front Bezel, Black Back Cabinet
Shipping Content Monitor; Power Cable; Signal Cable DVI-D - DVI-D; Signal Cable VGA - VGA; CD-ROM; Sales Office
List; User Manual
Warranty 3 years warranty incl. backlight
