NEC MultiSync®Residential Series
40" and 46" LCD displays
Large-Screen LCD
FULL HD 1080p EXPERIENCE
> Industry-leading 3-year parts and labor warranty
(including backlight) provides peace of mind
> Full HD 1080p resolution provides stunning detail for
video and broadcast applications
> Six-way color control allows for precise and simplified
color, color temperature and saturation adjustment
> Rapid Response™ technology delivers virtually
uninterrupted, undistorted viewing of high-speed, full-
motion video
> Advanced AccuBlend™ converts non-native resolutions
to the display’s resolution
> Multiple aspect ratio control allows flexibility with
today’s many source choices
> GammaComp™ programmable lookup table, SpectraViewII™ Color
Calibration Solution and adjustable color temperature provide unrivaled
control of color performance
> CableComp™ long cable compensation provides flexibility when installing
the display at distances far from a connected PC and keyboard
> Thermostatic cooling fans protect the display from overheating and
extend its life
> Available HD tuner, speakers and wall mount enhance the
visual experience
> Environmental friendliness (RoHS-compliant, low power
consumption, biodegradable plastics) maximizes the user’s
investment and helps them be “green”
> Windows® Vista certification
maximizes the display’s
resolution capabilities
> Digital video interface with
HDCP supports high-definition
components
> Open architecture expansion
slot allows for adaptation to
changes and updates in
technology

NEC Display Solutions
500 Park Boulevard, Suite 1100
Itasca, IL 60143
866-NEC-MORE
MultiSync SC40
40”
0.461mm
55 @ native resolution
450cd/m2adjustable
1000:1
178 Vert., 178 Hor. (89U/89D/89L/89R) @ CR>10
Rapid Response (8ms grey-to-grey)
256 RGB Level, more than 16.7 million
Manual (2600 - 10,000 degrees K)
34.9 x 19.6 in. / 885.6 x 498.2mm
16:9
1.6, 1.6, 1.8, 1.8 in. / 40.6, 40.6, 46.6, 46.6mm
31.5-91.1 KHz (Analog/Digital)
50-85 Hz (Analog/Digital)
ANALOG RGB 0.7 Vp-p/75 Ohms
Separate sync: TTL Level (Positive/Negative)
Composite sync: TTL Level (Positive/Negative)
Composite sync on green: (0.3Vp-p negative, 0.7Vp-p positive)
DVI-D with HDCP, Analog D-sub, Analog BNC, Composite RCA or S-
Video, HDMI with HDCP, Component BNC, Audio 1( minijack), Audio 2
and 3 Stereo (RCA) / Internal Speaker: None, ATSC, Qam, NTSC, RS232,
DDC-CI, IR Remote
Daisychain RGB2, RGB3, Daisychain Video1, Daisychain - Selected Audio
in, RS-232, 15W x 15W
640 x 400 @ 56.2 Hz
720 x 400 @ 70-85Hz
640 x 480 @ 50-85 Hz
800 x 600 @ 50-85 Hz
832 x 624 @ 74.5 Hz
1024 x 768 @ 50-85 Hz
1280 x 1024 @ 50-85 Hz
1600 x 1200 @ 60 Hz
1280 x 768 @ 50-85 Hz
1360 x 768 @ 50-85 Hz
1920 x 1080 @ 60 Hz
NTSC/PAL,SECAM,4.43NTSC,Pal60 HDTV,480i, 480p, 720p, 1080i, 1080p
1920 x 1080 @ 60 Hz
1920 x 1080 @ 60 Hz
English, German, Spanish, French, Italian, Swedish, Japanese
Power management, Plug and Play (DDC/CI, DDC2B), PIP (remote), multi-
level zoom, FullScan, 6-axis color, CableComp, TileComp, screen saver,
Rapid Response, video ready (tuner available), infrared remote control
included, motion-adaptive 3D-Y/C comb filter, sRGB color, sleep timer,
24x7 scheduler, GammaComp and gamma adjustment, film mode, black
level expansion, Faroudja scaling
AC 100-120V / AC 220-240V @ 50/60 Hz
Internal
300W
<5W
0W
38.7 x 24.7 x 15.7in. / 981.8 x 627.4 x 400mm
38.7 x 22.9 x 5.6 in. / 981.8 x 582.4 x 142.5mm
71.9 lbs. / 32.6 kg
200 x 200mm (8 hole) / 200 x 100mm (6 hole)
5-40°C / 41-104°F
10-80%
4200m / 13,780 ft.
-20-60°C / -4-140°F
10-90%
12,000m / 39,370 ft.
UL 60950/CSA C22.2 No. 950/TUV-GS/EN60950/FCC-B/DOC-B/EN55022-
B/EN55024/EN61000-3-2/EN1000-3-3/CE
AC power cord,user manual, wireless remote control, batteries, 15-pin
RGB (VGA) cable, CD-ROM
External speakers, stand, ATSC/NTSC/QAM tuner,
tilting wall mount (WMK3260-L)
3 year parts and labor, including backlight
M - F (7am - 7pm CST)
MultiSync SC46
46”
0.53
47 @ native resolution
450cd/m2adjustable
1200:1
178 Vert., 178 Hor. (89U/89D/89L/89R) @ CR>10
Rapid Response (8ms grey-to-grey)
256 RGB Level, more than 16.7 million
Manual (2600 - 10,000 degrees K)
40.1 x 22.5 in. / 1018.1 x 572.7mm
16:9
1.6, 1.6, 1.8, 1.8 in. / 40.6, 40.6, 46.6, 46.6mm
31.5-91.1 KHz (Analog/Digital)
50-85 Hz (Analog/Digital)
ANALOG RGB 0.7 Vp-p / 75 Ohms
Separate sync: TTL Level (Positive/Negative)
Composite sync: TTL Level (Positive/Negative)
Composite sync on green: (0.3Vp-p negative, 0.7Vp-p positive)
DVI-D with HDCP, Analog D-sub, Analog BNC, Composite RCA or S-
Video, HDMI with HDCP, Component BNC, Audio 1( minijack), Audio 2
and 3 Stereo (RCA) / Internal Speaker: None, ATSC, Qam, NTSC, RS232,
DDC-CI, IR Remote
Daisychain RGB2, RGB3, Daisychain Video1, Daisychain - Selected Audio
in, RS-232, 15W x 15W
640 x 400 @ 56.2 Hz
720 x 400 @ 70-85 Hz
640 x 480 @ 50-85 Hz
800 x 600 @ 50-85 Hz
832 x 624 @ 74.5 Hz
1024 x 768 @ 50-85 Hz
1280 x 1024 @ 50-85 Hz
1600 x 1200 @ 60 Hz
1280 x 768 @ 50-85 Hz
1360 x 768 @ 50-85 Hz
1920 x 1080 @ 60 Hz
NTSC/PAL,SECAM,4.43NTSC,Pal60 HDTV,480i, 480p, 720p, 1080i, 1080p
1920 x 1080 @ 60 Hz
1920 x 1080 @ 60 Hz
English, German, Spanish, French, Italian, Swedish, Japanese
Power management, Plug and Play (DDC/CI, DDC2B), PIP (remote), multi-
level zoom, FullScan, 6-axis color, CableComp, TileComp, screen saver,
Rapid Response, video ready (tuner available), infrared remote control
included, motion-adaptive 3D-Y/C comb filter, sRGB color, sleep timer,
24x7 scheduler, GammaComp and gamma adjustment, film mode, black
level expansion, Faroudja scaling
AC 100-120V / AC 220-240V @ 50/60 Hz
Internal
340W
<5W
0W
43.8 x 27.7 x 15.7 in. / 1112.8 x 704.4 x 400mm
43.8 x 26 x 5.6 in. / 1112.8 x 659.4 x 142.5mm
86.6 lbs. / 39.3 kg
200 x 200mm (8 hole) / 200 x 100mm (6 hole)
5-40°C / 41-104°F
10-80%
4200m / 13,780 ft.
-20-60°C / -4-140°F
10-90%
12,000m / 39,370 ft.
UL 60950/CSA C22.2 No. 950/TUV-GS/EN60950/FCC-B/DOC-B/EN55022-
B/EN55024/EN61000-3-2/EN1000-3-3/CE
AC power cord,user manual, wireless remote control, batteries, 15-pin
RGB (VGA) cable, CD-ROM
External speakers, stand, ATSC/NTSC/QAM tuner,
tilting wall mount (WMK3260-L)
3 year parts and labor, including backlight
M - F (7am - 7pm CST)
Model
Display
Viewable Size Image
Pixel Pitch
Pixels Per Inch
Brightness
Contrast Ratio
Viewing Angle
Response Time
Display Colors
Color Control
Active Screen Area (WxH)
Screen Aspect Ratio
Bezel Width (T, B, L, R)
Synchronization Range
Horizontal
Vertical
Input Signal
Video
Sync
Inputs
Outputs
Resolutions Supported
Native Resolution
Recommended Resolution
Languages
Additional Features
Voltage Rating
Power Supply
Power Consumption (typical)
On
Power Savings Mode
Vacation Mode
Dimensions (WxHxD)
Net (with stand)
Net (without stand)
Weight
Net (with stand)
VESA Hole Configuration Specifications
Environmental Conditions
Operating Temperature
Operating Humidity
Operating Altitude
Storage Temperature
Storage Humidity
Storage Altitude
Regulatory Approvals
Included Accessories
Optional Accessories
On-Site Limited Warranty
Technical Support
Advanced AccuBlend, CableComp, GammaComp and SpectraViewII are
trademarks and MultiSync is a registered trademark of NEC Display Solutions.
All other brand or product names are trademarks or registered trademarks of
their respective holders. Product specifications subject to change. 6/08 ver. 3.
©2008 NEC Display Solutions of America, Inc. All rights reserved.
