NEC MultiSync®V551
Order Code: 60003170 NEC LCD 55" Large Format Display
MultiSync® V551 is the ultimate best in class product in the
entry level segment. This display comes with NEC’s new Dual
Slot as well as with integrated speakers. An impressive line-up
of interfaces including DisplayPort, DVI daisy chain and LAN
with SNMP. The V Series delivers unbeatable functionality and
performance for value demanding users.
Ideal for cost efficient retail signage, conferencing applications
and lobby or reception installations.
DELIVERING GENUINE BENEFITS
DICOM support- for medical applications.
Functionality - can be extended with additional interfaces and
playback devices through the option slot which avoid
additional cables and mounting brackets.
Intelligent Power Management Features - for reduced total
cost of ownership (TCO)
Ease of Installation and Operation - free LAN control software
for central, convenient and cost-efficient maintenance and
control. Automatic alarm emails notify the user of problems if
they should occur.
Free DisplayNote Presenter Licence - present, share,
collaborate with multiple participants across multiple devices
(available until March 2014). Visit www.displaynote-nec.com.
Free Download of Multi-Display Management Software - with
NaViSet Administrator 2 you can manage all your connected
display devices from a centralized location.
OUTSTANDING PERFORMANCE
Uniform and controlled heat management enables the user to monitor and control the
heat inside the display with user controllable fans. Heat management is crucial for
larger walls and mission critical installations to secure reliability and longevity.
•
NEC’s Dual Slot technology allows for the integration of traditional NEC Option Slot
products and the new OPS Standard Option, such as single board computers without
the need to stow external equipment.
•
Peace of mind thanks to full control of the display via LAN with free NEC software and
alert emails in the unlikely event of a problem such as no signal, overheating, back light
failure etc.
•
Integrated speakers save installation costs and preserve the clean look of the display.
•
Daisy chaining via DVI (max. 9 pieces) offering high flexibility at no extra cost if the
signal needs to be passed on for videowalls or back-to-back installations.
•
Copy Settings feature via RS232 to reduce installation cost for larger role outs.
•
This document is © copyright 2013 NEC Display Solutions Europe GmbH.
All rights reserved in favour of their respective owners. All hardware and software names are brand names and/or registered trademarks of the respective manufacturers. All
specifications are subject to change without notice. Errors and omissions are excepted. 11.09.2013
www.nec-display-solutions.com

NEC MultiSync®V551
1. Power (AC in)
2. Main switch (on/off)
3. LAN with SNMP
4. Remote Control in / out
5. External control RS-232 in / out
6. DisplayPort in
7. DVI in / out
8. HDMI in
9. RGB in
10. RGB HV in (RGB, Component, Composite)
11. Composite in
12. Composite out
13. Audio out
14. S-Video in
15. Audio in
16. External speaker
17. Internal / external speaker switch
SPECIAL CHARACTERISTICS
Advanced fan control, Copy display settings through RS232, Daisy
chaining via DVI (max. 9 units), DICOM support, FREE DisplayNote
Presenter, Hardware colour calibration possible, Input name
adjustment, Matrix memory, NaViSet Administrator 2, OSD
rotation for portrait mode, Scheduler, Screen saver functions,
TileMatrix (10 x 10), User input priority definition, Various picture
in picture options
Energy Efficiency Carbon savings meter; ECOMode
Ecological Materials Optional feet; Manuals on CD
Ecological Standards Energy Star 5.1
Technical Specification NEC MultiSync®V551
DISPLAY
Panel Technology S-PVA with CCFL backlights
Active Screen Area (W x H) [mm] 1,210 x 680
Screen Size [inch/cm] 55 / 139.7
Aspect Ratio 16:9
Brightness (shipping) [cd/m2]340, (450 max)
Contrast Ratio (typ.) 3500:1
Viewing Angle [°] 178 horizontal / 178 vertical (typ. at contrast ratio 10:1)
Response Time (typ.) [ms] 8 (grey-to-grey)
Panel Refresh Rate [Hz] 60
SYNCHRONISATION RATE
Horizontal Frequency [kHz] 31.5 - 91.1 (analog and digital)
Vertical Frequency [Hz] 50 - 85
RESOLUTION
Native Resolution 1920 x 1080 at 60 Hz
Supported on digital and analogue inputs (PC) 1920 x 1080; 1680 x 1050; 1600 x 1200; 1400 x 1050; 1366 x 786; 1280 x 1024;
1280 x 960; 1280 x 800; 1280 x 768; 1280 x 720; 1140 x 900; 1024 x 768; 800 x
600; 720 x 576; 720 x 480; 720 x 400; 640 x 480
Supported on digital inputs (Video) 1920 x 1080i (59.94/60)16:9; 1920 x 1080p (59.94/60)16:9; 1920 x 1080p (50)
16:9; 1920 x 1080p (23.97/24)16:9; 1920 x 1080p (25)16:9; 1920 x 1080p
(29.97/30)16:9; 1280 x 720p (50)16:9; 720 x 576p (50)16:9; 720 x 480p
(59.94/60)16:9
CONNECTIVITY
Input Video Analogue 1 x D-sub 15 pin; 1 x S-Video; Composite (RCA); RGBHV for PC and Component/
Composite (BNC)
Input Video Digital 1 x DVI-D (with HDCP); 1 x HDMI 1.3; 1 x DisplayPort
Input Audio Analogue 2 x Cinch (RCA); 2 x 3,5 mm jack
Input Audio Digital DisplayPort; 1 x HDMI
Input Control LAN 100Mbit; remote control wire (3,5mm jack); RS232
Output Video Analogue Composite (BNC)
Output Video Digital [value1] x DVI-D
Output Audio Analogue 3,5mm jack
Output Control remote control wire (3,5mm jack); RS232
Remote Control LAN with SNMP; RS-232C (9-pin D-sub) Input and Output; Remote Control IR
(internal/external (optional) sensor)
OPTION SLOT
Slot Technology Dual Slot (STv1 + STv2)
Inrush Current [A] max. 10
Power Consumption [W] max. 61
Voltage / Current [V/A] 16/4
ELECTRICAL
Power Consumption on Mode [W] 200 (typ.); 350 (max.)
Power Savings Mode [W] < 0.5 (ECO Standby); < 1
Power Management VESA DPMS
ENVIRONMENTAL CONDITIONS
Operating Temperature [°C] +5 to +40
Operating Humidity [%] 20 to 80
Storage Humidity [%] 10 to 90
Storage Temperature [°C] -20 to +60
MECHANICAL
Dimensions (W x H x D) [mm] Without stand: 1,317.8 x 775.6 x 118.9
Weight [kg] Without stand: 38.4
Bezel Width [mm] 52.1 (left and right); 45.6 (top and bottom)
VESA Mounting [mm] 400 x 400 (FDMI); 4 holes; M6
AVAILABLE OPTIONS
Accessories Feet (ST-5220); Speaker (SP-RM1); Wall mount (PDW 32-70 L+P); Wall mount
(PDW S 32-55 L)
Option Slot Built-in PC; CAT 5 receiver; DVI daisy chain board; HD-SDI board; Media Player
ADDITIONAL FEATURES
Colour Versions Black Front Bezel, Black Back Cabinet
Safety and Ergonomics CE; TÜV GS; C-tick; Energy Star 5.1; FCC Class B; UL/C-UL or CSA; PSB; VCCI;
RoHS
Plug and Play VESA DDC2Bi
Audio Integrated Speakers (10 W + 10 W); Optional Speakers (15 W + 15 W)
Shipping Content Display; Power Cable; VGA cable; Free LAN control software (download); Remote
Control
Warranty 3 years warranty incl. backlight
