NEC MultiSync V801 User manual

NEC MultiSync®V801
Order Code: 60003482 NEC LCD 80" Large Format Display
MultiSync®V801 is the flag ship model of NEC V Series. The
display boasts over 200cm diagonally in size making it the
ideal product for installations which require sheer size and
appearance. The Edge LED backlight technology secures a slim
design and amazing low power consumption levels. As all
other V Series Displays, V801 comes with a programmable
ambient light sensor which can help to further reduce power
consumption. The OPS slot allows for the integration of slot-in
PCs, HDSDI and other OPS based devices providing a unique
flexibility in the 80" class product range.
Ideal for attention grabbing retail signage or other size
requiring installations up to 16/7 operating time and front
projector replacement in meeting rooms.
DELIVERING GENUINE BENEFITS
Programmable Ambient Light Sensor - for reduced power
consumption and eye pleasing brightness levels.
Free Download of Multi-Display Management Software - with
NaViSet Administrator 2 you can manage all your connected
display devices from a centralized location.
Free DisplayNote Presenter Licence - present, share,
collaborate with multiple participants across multiple devices
(available until March 2014). Visit www.displaynote-nec.com.
DICOM support- for medical applications.
OUTSTANDING PERFORMANCE
NEC unique thermal monitoring and control. NEC pioneered advanced thermal control
and monitoring for public displays which is still unmatched. It secures longevity and
reliability even in very demanding installations.
•
NEC’s STv2 Slot technology which was developed in cooperation with Intel enables the
user to integrate various option boards enhancing flexibility and future functionality.
•
Peace of mind thanks to full control of the display via LAN with free NEC software and
alert emails in the unlikely event of a problem such as no signal, overheating, back light
failure etc.
•
Integrated speakers save installation costs and preserve the clean look of the display.
•
Daisy chaining via DVI (max. 9 pieces) offering high flexibility at no extra cost if the
signal needs to be passed on for videowalls or back-to-back installations.
•
Copy Settings feature via RS232 to reduce installation cost for larger role outs.
•
This document is © copyright 2013 NEC Display Solutions Europe GmbH.
All rights reserved in favour of their respective owners. All hardware and software names are brand names and/or registered trademarks of the respective manufacturers. All
specifications are subject to change without notice. Errors and omissions are excepted. 11.09.2013
www.nec-display-solutions.com

NEC MultiSync®V801
1. RGB/HV IN [R, G, B, H, V] (BNC)
2. DISPLAYPORT connector
3. HDMI connector
4. DVI connector (DVI-D)
5. VGA IN (mini D-Sub 15 pin)
6. VIDEO1 IN connector (BNC)
7. LAN port (RJ-45)
8. RS-232C (D-Sub 9 pin)
9. REMOTE IN (Black)
10. AUDIO OUT (Blue)
11. AUDIO IN 1 (Blue)
12. EXTERNAL SPEAKER TERMINAL
13. Internal/External speaker switch
SPECIAL CHARACTERISTICS
Advanced fan control, Copy display settings through RS232,
DICOM support, FREE DisplayNote Presenter, Hardware colour
calibration possible, Input name adjustment, Matrix memory,
NaViSet Administrator 2, PIN as theft protection, Rapid input
switching, Scheduler, Screen saver functions, TileMatrix (10 x 10),
User input priority definition, Various picture in picture options
Energy Efficiency Ambient light sensor; Carbon savings
meter; ECOMode
Ecological Materials Optional feet; Manuals on CD
Technical Specification NEC MultiSync®V801
DISPLAY
Panel Technology UV2A with Edge LED backlight
Active Screen Area (W x H) [mm] 1,771.2 x 996.3
Screen Size [inch/cm] 80 / 203.2
Aspect Ratio 16:9
Brightness (shipping) [cd/m2]320, (460 max)
Contrast Ratio (typ.) 5000:1
Viewing Angle [°] 176 horizontal / 176 vertical (typ. at contrast ratio 10:1)
Response Time (typ.) [ms] 6 (grey-to-grey)
Panel Refresh Rate [Hz] 60
SYNCHRONISATION RATE
Horizontal Frequency [kHz] 31.5 - 91.1 (analog and digital)
Vertical Frequency [Hz] 50 - 85
RESOLUTION
Native Resolution 1920 x 1080 at 60 Hz
Supported on digital and analogue inputs (PC) 1600 x 1200; 1360 x 768; 1280 x 1024; 1280 x 768; 1024 x 768; 832 x 624; 800 x
600; 720 x 400; 640 x 480; 640 x 400
Supported on digital inputs (Video) 1920 x 1080i (59.94/60)16:9; 1920 x 1080i (59.94/60)16:9; 720 x 576p (50)16:9;
720 x 576p (50)16:9; 720 x 576p (50)16:9; 720 x 576p (50)16:9; 720 x 576p (50)
16:9; 720 x 576p (50)16:9; 720 x 576p (50)16:9; 720 x 576p (50)16:9; 720 x 576p
(50)16:9
CONNECTIVITY
Input Video Analogue 1 x D-sub 15 pin; Composite (BNC); RGBHV for PC and Component/Composite
(BNC)
Input Video Digital 1 x DVI-D (with HDCP); 1 x HDMI 1.3 (with HDCP); 1 x DisplayPort (with HDCP)
Input Audio Analogue 1 x 3,5 mm jack
Input Audio Digital DisplayPort; 1 x HDMI
Input Control LAN 100Mbit; remote control wire (3,5mm jack); RS232
Output Video Digital 1 x DVI-D (with HDCP)
Output Audio Analogue 3,5mm jack
Output Control RS232
Remote Control LAN with SNMP; RS-232C (9-pin D-sub) Input and Output; Remote Control IR
(internal/external (optional) sensor)
OPTION SLOT
Slot Technology STv2 (compatible with Intel / NEC OPS standard)
Inrush Current [A] max. 10
Power Consumption [W] max. 61
Voltage / Current [V/A] 16/4
ELECTRICAL
Power Consumption on Mode [W] 230 shipping; 420W max. (with built-in PC 100% workload)
Power Savings Mode [W] < 0.5 (ECO Standby); < 1
Power Management VESA DPMS
ENVIRONMENTAL CONDITIONS
Operating Temperature [°C] +0 to +40
Operating Humidity [%] 20 to 80
Storage Humidity [%] 10 to 90
Storage Temperature [°C] -20 to +60
MECHANICAL
Dimensions (W x H x D) [mm] Without stand: 1,836.2 x 1,061.3 x 86.2
Weight [kg] Without stand: 60
Bezel Width [mm] 29.7
VESA Mounting [mm] 400 x 400 (FDMI); 4 holes; M8
AVAILABLE OPTIONS
Accessories Trolley (PDMHM-L); Feet (ST-801); Speaker (SP-80 SM ); Speaker (SP-RM1); Wall
mount (PDW 32-70 P+L); Wall mount (PDW T XL )
Option Slot HDSDI 1.5G, 3G; Intel Atom, Celeron and Core CPUs; Slot-In PC
ADDITIONAL FEATURES
Colour Versions Black Front Bezel, Black Back Cabinet
Safety and Ergonomics CE; TÜV GS; C-tick; FCC Class B; UL/C-UL or CSA; PSB; VCCI; RoHS
Audio Integrated Speakers (10 W + 10 W); Optional Speakers (15 W + 15 W)
Shipping Content Display; DVI-D cable; Power Cable; Remote Control; CD-ROM (User Guides/
Manuals)
