NEC UX Series User manual

UX Series Models
Installation Manual
Large Format Display Models
MultiSync UX552
MultiSync UX552S
* Please nd your model name in the label on the rear side of monitor.
* This manual contains the precautions that must be followed by the professionals in charge of the installation.
* Please be sure to read Setup manual and User’s Manual.
NEC Display Solutions, Ltd.
2019/09/20
Ver. 1.0

English - 2
Introduction
This document describes the procedures to install the display (UX552/UX552S).
For safe and correct installation and use of this display, carefully read this document before installation.
Refer to User's manual of the applicable products for basic operation of the display.
This document expects qualied technicians who have knowledge about display installation.
After reading, please keep this document under care of the company which installed the display.
Warning
The display must be installed by qualied technicians in order to ensure proper operation and reduce the risk of bodily injury.

English
English - 3
Table of contents
1. Unpacking procedure............................................................................................................................................... 4
2. Simple electrical conductivity test before installation ............................................................................... 5
3. Precautions when installing or moving the product................................................................................... 6
4. Display external dimensions tolerances ........................................................................................................... 9
5. Allowable temperature and installation environment .............................................................................10
6. Wall mount brackets installation ....................................................................................................................... 11
7. Multiple screens installation................................................................................................................................14
8. Pins, spacers and plastic spacers........................................................................................................................ 15
9. Compatibility of optional mounting brackets.............................................................................................. 17
10. Installation procedure of options ......................................................................................................................18
11. Using External Power Supply ..............................................................................................................................19
When opening the service door........................................................................................................................................................................................... 19
DC power supply input rating ............................................................................................................................................................................................... 19
Connecting the DC power line for redundancy function (for UX series)...............................................................................................20
DC input power supply specication ...............................................................................................................................................................................20
DC power supply equipment.................................................................................................................................................................................................20
DC power input terminal connection ..............................................................................................................................................................................21
Connecting the cable...................................................................................................................................................................................................................23

English - 4
1. Unpacking procedure
Follow the procedure below to open the package.
Hooks
Fasteners
(1) Remove the fasteners and the hooks.
(2) Remove the accessories, the cushioning
materials, L-shaped protections and carton
board.
L-shaped protections
Carton board
Accessories
Cushioning materials
(3) Remove the display from the protective bag.
Protective bag

English
English - 5
2. Simple electrical conductivity test before
installation
(3) Connect the power cord to the display, while it stands vertically in the
cushioning materials.
Do not keep the display turned on for a long time in that position.
(1) Remove the display from the cushioning
materials and from the protective bag.
(2) Put the display back in the cushioning materials.

English - 6
3. Precautions when installing or moving the
product
(1) When installing or moving the display, always keep it in the standing position, do not put it on its side or upside down.
Always hold the display by the handles to move it.
(2) Do not hold the display by a part other than the handles.
(3) The display must be carried by at least 2 people.
Handle
(4) When installing the display in the portrait orientation, be sure to place the left side on the top when seen from the
front.
The display cannot be installed upside down.
Do not install the display at a tilt.
Do not install it with the screen facing downward or upside down. Otherwise, it may damage the screen.

English
English - 7
(5) Do not touch the top, bottom, left and right sides of the display. Also, do not touch the screen surface of the display.
Applying pressure or shocks on the top or left sides of the display may adversely aect the image quality.
Don’t
Don’t
Don’tDon’t
Don’t
Front side
(6) Putting the bottom of the display or the screen surface directly on the oor may damage the display.
Do not put the display directly on the oor but use the stand or the product package to keep it vertical.
Don’t
(7) When installing the display in a multiple screens conguration, do not place it in a structure that continuously
applies a load on its top or left side. Otherwise, it may adversely aect the image quality.
Don’t
Don’t
Front side

English - 8
(8) Do not bend the display when installing it.
Don’t
Don’t
Front side
(9) Pay attention not to apply vibrations or shocks to the display when installing it.
Otherwise, it may cause a malfunction.

English
English - 9
4. Display external dimensions tolerances
External dimensions tolerances of the display are as follows.
Consider these tolerances when installing the display and pay attention that it does not interfere with other parts of the
structure.
Front side
A
BTolerance
A B
±1.3 mm ±1.3 mm

English - 10
5. Allowable temperature and installation
environment
When installing the display in a narrow place (in a case embedded in a wall, etc.), leave gaps as shown in the gure below
between the display and the wall to prevent an increase in the temperature.
You may also implement suitable cooling measures.
100 mm
100 mm
30 mm
100 mm
100 mm
40°C (104°F) or less
The guaranteed ambient temperature for the display is 40°C (104°F).
When using it inside a case, take measures such as installing cooling fans in the case or air vents to keep the temperature
inside the case at a temperature of 40°C (104°F) or lower.
The display is equipped with temperature sensors and cooling fans. These fans turn on automatically when the inner
temperature is too high.
A warning is displayed in any environment that exceeds the guaranteed temperature, even when the cooling fans are
being used.
Using the display in an environment where a warning is displayed may cause a malfunction. In such a case, turn o the
main power supply.
In addition to automatic operation of the built-in cooling fans when the temperature exceeds the guaranteed temperature,
you can set the cooling fans to operate continuously under DISPLAY PROTECTION → FAN CONTROL in the OSD menu.
When using the display with an option board, some of the cooling fans may turn on automatically to cool the option board
even when the display operates within the guaranteed temperature range.
When the display is installed inside a case or when it is used with the LCD surface covered with an acrylic sheet or other
protective sheets, check the inner temperature under DISPLAY PROTECTION → HEAT STATUS in the OSD menu and then
congure the fan operation as required.

English
English - 11
6. Wall mount brackets installation
(1) Use only mounting brackets that comply with the VESA standards.
(2) Install the display only after thoroughly checking the strength of the mounting surface.
(3) Use mounting brackets strong enough to support the display.
(4) Check the strength and other safety factors before installing the display.
(5) Refer to the mounting brackets manual for details on the mounting method and on how to guarantee the
installation safety.
(6) When using M6 screws, make screw holes of 8.5 mm or less in diameter.
When using M8 screws, make screw holes of 10 mm or less in diameter.
(7) Pay attention not to leave any gap between the installation surface of the display and the mounting brackets.
Screw
The display
8.5 mm in
diameter or less
No gap
Washer
Mounting bracket
Non-threaded
part 4 mm
Mounting
bracket and
washer thickness
10 -12 mm
[With M6 screws]
Screw
The display
10 mm in
diameter or less
No gap
Washer
Mounting bracket
Non-threaded
part 4 mm
Mounting
bracket and
washer thickness
15-17 mm
[With M8 screws]
(8) When installing the display on a wall or the ceiling, install a fall protection wire rope for safety.
(9) Never attach the display to a wall or the ceiling using only the fall protection wire rope.
(10) Install the fall protection wire rope not fully stretched.
When attaching the fall protection wire rope to the handles, use the handles shown in the picture below
depending on the orientation.
When attaching the fall protection wire rope to the speaker brackets, follow the method shown in the gure
below.
(Tightening torque 139 to 189 N•cm)
Fall protection wire rope position with landscape orientation
Fall protection wire rope position
with portrait orientation

English - 12
(11) When attaching the wire rope to a display equipped with speakers (landscape orientation only)
Attach the wire rope using the speaker brackets.
Wire rope
Mounting bracket
Speaker
(12) The display fans are located at the three locations shown in the gure below.
Do not obstruct the fan vents with the mounting brackets or other parts.
There are 3 fan vents when the option board is used, and 2 fan vents when the option board is not used.
Using the display with the fan vents obstructed may cause a malfunction.
[When the option board is used]
Fan locations
[When the option board is not used]
Fan locations

English
English - 13
(13) When using the NEC wall mount kit, remove the upper cushioning materials and x the display top brackets to the
display using screws.
Upper cushioning materials
Display top bracket
Screw
Screwdriver
(14) It is possible to x the display bottom brackets by passing the screw through the holes in the lower cushioning
materials.
Since it is possible to x the brackets with the display maintained by the cushioning materials in the vertical
position, there is no risk to damage the screen.
Lower cushioning materials
Display bottom bracket
Screw
Screwdriver

English - 14
7. Multiple screens installation
(1) When installing the displays in a multiple screens conguration, turn the displays o and leave a gap of 1.0 mm
between each display.
Note that light from the back may pass through the gaps between the displays.
To prevent the light from passing through the gaps, install a plate that stops the light at the back of the displays.
This plate is not supplied by NEC.
Gap of 1 mm
Gap of 1 mm
(2) Consider the following when installing the display in a multiple screens conguration.
(a) Check that the wall to which the mounting brackets will be installed is perfectly at.
(b) Make sure that the mounting brackets used are strong enough to meet the installation requirements.
(c) Choose a structure in which load is not applied on the display top and left sides.
(d) Pay attention that the cable route does not interfere with other parts of the structure.
(e) Choose a conguration with which there is no risk that the displays bend after they have been installed.

English
English - 15
8. Pins, spacers and plastic spacers
Some display models are supplied with pins, spacers and plastic spacers.
With multiple screens conguration, installing the pins and the spacers makes it possible to secure a constant gap between
the displays.
However, the pins can be installed only on the models that have pin holes of 6 mm in diameter in their bottom and right
sides.
The pins cannot be used with the other models.
Also, the pins, spacers and plastic spacers cannot be used for installation brackets that allow the display to move (Example:
Pantograph mechanisms, slide mechanisms).
Pin hole
Front side
(1) Spacers
The spacers supplied with the display can be installed in the screw holes on the top and left sides of the display.
They are useful to prevent the display from coming into contact on their weaker sides with other displays in multiple
screens conguration. Therefore, we recommend installing these spacers in this conguration.
However, it cannot be used for installation brackets that allow the display to move back and forth or left and right
(Example: Pantograph mechanisms, slide mechanisms).
Front side
Spacer
[Installation locations]
Example: Spacer installation with multiple screens conguration
Spacer

English - 16
(2) Plastic spacers
Plastic spacers are useful to prevent the display from coming into contact on their weaker sides with other displays.
Remove the release paper from the back of the spacer double-sided tape, and stick the spacer to the edge at the
back of the display.
However, it cannot be used for installation brackets that allow the display to move (Example: Pantograph
mechanisms, slide mechanisms).
Plastic spacer
Example: Plastic spacer installation with multiple screens conguration
* Caution: When using movable installation brackets
• If pins are installed to the display, the display cannot be moved.
• If spacers or plastic spacers are installed to the display, the display may be rubbed or touched with spacers or plastic
spacers to cause abnormal images.
• When using movable brackets for installation, do not install pins, spaces and plastic spacers.
• Example of movable installation brackets are such as pantograph mechanisms, slide mechanisms.

English
English - 17
9. Compatibility of optional mounting brackets
For information on optional mounting brackets compatibility, refer to the manual supplied with the optional mounting
brackets.

English - 18
10. Installation procedure of options
For information on the installation procedure of options, refer to the manual supplied with the options.

English
English - 19
11. Using External Power Supply
When opening the service door
There is a high voltage electric parts inside the monitor.
There is charged high voltage in electric parts, so never open this door unless absolutely necessary.
Also, when opening the service door, use the prescribed procedures to ensure that you do it safely.
Connector for external power supply.
Remove the DC cover plate to see the input terminal.
Please refer to sheet "DC power input terminal connection".
DC power supply input rating
INPUT:48V 8.0A
*Do not input voltage that deviates from the rated range.
Rating label
*Please do not remove the input rating label.

English - 20
Connecting the DC power line for redundancy function (for UX series)
Always connect the DC power line supplied from the DC power supply (including protector function) unit via power line
when using the redundancy function.
Use a DC power supply unit of the following specication depending on the DC power line connection method.
Be sure that the power line cable used to connect to the input terminal for redundancy function has a core
thickness of 14AWG or 2mm2according to the requirements (based IEC60950-1) of the country where the DC48V
power supply unit is installed, and that the cable core is made of copper.
DC input power supply specication
DC input power supply specication
DC Voltage Range 48V +/- 2V
Max. Current [A] 8.0
DC power supply equipment
DC power supply requirement is as shown in the table below.
Do not connect DC power supply voltages to the monitor other than those indicated below.
Use round type UL-Listed solderless terminal for DC power line cable at US for NEC.
In addition, when clamping this terminal with the cable, use an UL listed tool.
NEC : NFPA70 National Electric Code
It is connected to the DC input terminal of monitor for redundancy function, and that it is connected according to the
procedures described in this manual.
External Power Supply Requirement
Protection O V P, O CP
Safety certications EN60950-1, CE marking *1
*1Please use a power supply compliant with the compliance of the area where the monitor is installed.
