NEC Dterm DTL-RPT-2 User manual

Notice
Note that when converting this document from its original format to a
.pdf file, some minor font and format changes may occur. When
viewing and printing this document, we cannot guarantee that your
specific PC or printer will support all of the fonts or graphics.
Therefore, when you view the document, fonts may be substituted and
your individual printer may not have the capability to print the
document correctly.

DTL-RPT-2 REPEATER GUIDE
DOC NUMBER 31142
ISSUE 1.0
Dterm Cordless DECT
730649
®

DTL-RPT-2 Cordless DECT Repeater Guide i
___________________________________________________________________________________
___________________________________________________________________________________
TABLE OF CONTENTS
Chapter 1 Legal and Warranty Information
Section 1 Important Safety Instructions ......................................................................1-1
Section 2 Important Electrical Considerations ...........................................................1-2
Section 3 FCC Regulatory Information ........................................................................1-2
3.1 Part 15 Compliance .....................................................................................1-2
3.2 Privacy Information ......................................................................................1-3
3.3 Radio Interference Information ....................................................................1-3
Section 4 I.C. Notice ......................................................................................................1-4
4.1 Terminal Equipment ....................................................................................1-4
4.2 Radio Equipment .........................................................................................1-4
Chapter 2 Getting to Know Your Repeater
Section 1 Features ...................................................................................................2-1
1.1 Specifications ..............................................................................................2-1
Section 2 Checking the Package Contents .................................................................2-2
Section 3 How it Works .................................................................................................2-2
Section 4 Setting up your Repeater .............................................................................2-5
Section 5 Installing the AC Adapter .............................................................................2-6
Section 6 Activate Registration Mode on Base ...........................................................2-7
6.1 Register Repeater to Base ..........................................................................2-7
6.2 Registration .................................................................................................2-8
6.3 Changing Registration .................................................................................2-9

___________________________________________________________________________________
ii Table of Contents
___________________________________________________________________________________
Issue 1.0 Dterm Cordless DECT
Section 7 Positioning the Repeater(s) ........................................................................ 2-9
7.1 Map the Base’s Coverage Area ..................................................................2-9
7.2 Test the Location .......................................................................................2-10
7.3 Daisy-chaining Repeaters .........................................................................2-10
7.4 Multiple Repeater Systems .......................................................................2-11
Section 8 Installing the Repeater ............................................................................... 2-12
Chapter 3 Troubleshooting and Maintenance
Section 1 Troubleshooting Chart ................................................................................ 3-1
Section 2 Maintenance ................................................................................................. 3-2

DTL-RPT-2 Cordless DECT Repeater Guide iii
___________________________________________________________________________________
___________________________________________________________________________________
List of Figures anD tables
Figure 2-1 Single Repeater Attached to Base ................................................................................2-2
Figure 2-2 Six Repeaters Attached to Base ...................................................................................2-3
Figure 2-3 Daisy-Chain Layout .......................................................................................................2-4
Figure 2-4 Combo Star and Daisy-Chain Layout ............................................................................2-4
Figure 2-5 Back View of the DTL-RPT-2 Repeater ........................................................................2-5
Table 2-1 Repeater LED Patterns .................................................................................................2-6
Figure 2-6 Removing the Adapter Cover ........................................................................................2-6
Figure 2-7 Threading the AC Adapter Cord ....................................................................................2-7
Table 2-2 Trouble Table ................................................................................................................2-8
Figure 2-8 Mapping the Base’s Coverage Area ............................................................................2-10
Figure 2-9 Incorrect Installation ....................................................................................................2-11
Figure 2-10 Correct Repeater Installation .......................................................................................2-12

iv List of Figures and Tables
___________________________________________________________________________________
___________________________________________________________________________________
Issue 1.0 Dterm Cordless DECT
THIS PAGE INTENTIONALLY LEFT BLANK

DTL-RPT-2 Cordless DECT Repeater Guide 1 - 1
___________________________________________________________________________________
Chapter 1 Legal and Warranty Information
SECTION 1IMPORTANT SAFETY INSTRUCTIONS
When using the telephone equipment, basic safety precautions should always be
followed to reduce the risk of fire, electrical shock, and injury to persons, including the
following:
Read and understand all instructions.
Follow all warnings and instructions marked on the product.
Do not use this product near water; for example, near a sink or in a wet area.
Do not place this product on an unstable cart, stand, or table. The telephone can
fall, causing serious damage to the unit.
To protect the product from overheating, do not block or cover any slots or
openings in the base unit. This product should never be placed near or over a
radiator or heat register. This product should not be placed in a built-in
installation unless the proper ventilation is provided.
This product should be operated only from the type of power source indicated
on the marking label.
Do not allow anything to rest on the power cord. Do not locate this product
where the cord will be damaged by people walking on it.
Do not overload wall outlets and extension cords, as this can result in the risk of
fire or electrical shock.
Never push objects of any kind into this product through the base unit slots, as
they may touch dangerous voltage points or short out parts that could result in a
risk of fire or electrical shock. Never spill liquid of any kind on the product.
To reduce the risk of electric shock, do not disassemble this product. Contact
qualified service personnel when some service or repair work is required.
Opening or removing covers may expose you to dangerous voltages or other
risks. Incorrect reassembly can cause electric shock when the appliance is
subsequently used.

1 - 2 Legal and Warranty Information
___________________________________________________________________________________
___________________________________________________________________________________
Issue 1.0 Dterm Cordless DECT
Unplug this product from the wall outlet and refer servicing to qualified service
personnel under the following conditions:
When the power supply cord is damaged or frayed.
If liquid has been spilled onto the product.
If the product has been exposed to water or rain.
If the product does not operate normally when following the operating
instructions. Adjust only those controls that are covered by the operating
instructions. Improper adjustment of other controls can result in damage, and
will often require extensive work by a qualified technician to restore the product
to normal operation.
If the product has been dropped, or the case has been damaged.
If the product exhibits a distinct change in performance.
SECTION 2IMPORTANT ELECTRICAL CONSIDERATIONS
Unplug all electrical appliances when you know an electrical storm is approaching.
Lightning can pass through your household wiring and damage any device connected
to it. This repeater is no exception.
Changes or modifications to this product not expressly approved by NEC Corporation
of America, or operation of this product in any way other than as detailed by this
manual, could void your authority to operate this product.
SECTION 3FCCREGULATORY INFORMATION
3.1 Part 15 Compliance
This device complies with part 15 of the FCC rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference,
and (2) This device must accept any interference received, including
interference that may cause undesired operation. Privacy of communications
may not be ensured when using this phone.
Certification numbers:
FCC ID: AMWUU228
Industry Canada IC: 513C-UU228
Do not attempt to unplug any appliance during an electrical storm.

Dterm Cordless DECT Issue 1.0
DTL-RPT-2 Cordless DECT Repeater Guide 1 - 3
___________________________________________________________________________________
___________________________________________________________________________________
3.2 Privacy Information
Cordless telephones are radio devices. Communications between the handset
and base of the cordless telephone are accomplished by means of radio
waves which are broadcast over the open airways. Because of the inherent
physical properties of radio waves, communication can be received by radio
receiving devices other than your own telephone unit, consequently, any
communications using the cordless telephone may not be private.
3.3 Radio Interference Information
Radio interference may occasionally cause buzzing and humming in your
cordless handset, or clicking noises in the base unit. This interference is
caused by external sources such as TV, fluorescent lighting, or electrical
storm. Your unit is NOT DEFECTIVE. If these noises continue and are too
distracting, check around your office to see what appliances may be causing
the problem. In addition, we recommend that the base not be plugged into a
circuit that also powers a major appliance because of the potential of
interference. For best performance, ensure that the antenna on the base unit
is fully extended.
In the unlikely event that you consistently hear other voices or distracting
transmissions on your telephone, you may be receiving radio signals for
another cordless telephone or other source of interference. If you cannot
eliminate this type of interference, you need to change to a different channel.
Finally, it should be noted that some cordless telephones operate at
frequencies that may cause interference to nearby TVs and VCRs. To
minimize or prevent such interference, the base of the cordless telephone
should not be placed near or on top of a TV or VCR. If interference is
experienced, moving the cordless telephone farther away from the TV or VCR
will often reduce or eliminate the interference.
Radio interference causes interruptions in conversation. When this happens,
your unit is not defective. When noise continues, move to a different location
while you talk. (You might even need to move the base unit.) When the
situation persists, contact National Technical Assistance Center.

1 - 4 Legal and Warranty Information
___________________________________________________________________________________
___________________________________________________________________________________
Issue 1.0 Dterm Cordless DECT
SECTION 4 I.C. NOTICE
4.1 Terminal Equipment
NOTICE: This equipment meets the applicable Industry Canada Terminal
Equipment Technical Specifications. This is confirmed by the registration
number. The abbreviation, IC, before the registration number signifies that
registration was performed based on a Declaration of Conformity indicating
that Industry Canada technical specifications were met. It does not imply that
Industry Canada approved the equipment.
4.2 Radio Equipment
The term “IC:” before the radio certification number only signifies that Industry
Canada technical specifications were met. Operation is subject to the
following two conditions: (1) this device may not cause interference, and (2)
this device must accept any interference, including interference that may
cause undesired operation of the device. “Privacy of communications may not
be ensured when using this telephone.”

DTL-RPT-2 Cordless DECT Repeater Guide 2 - 1
___________________________________________________________________________________
Chapter 2 Getting to Know Your Repeater
SECTION 1 FEATURES
Automatic registration to the base
Up to six repeaters per base station
Weather resistant design
Low power consumption
1.1 Specifications
The following specifications apply to the NEC Dterm Cordless DECT
DTL-RPT-2 Repeater.
AC Power Adapter: Input: 100 ~240VAC 50 ~60Hz
Output: 5 V DC, 500 mA
Unit weight 5 oz (142g)
Frequency Band: 1920MHz ~ 1930MHz
Transmit Power: 100mW
Receiver Sensitivity: <-96 dBm at 10-3 BER
Operating Temperature 32oto 122oF (0 to + 50oC)
Standards: Designed in accordance with the Digital Enhanced Cordless
Telecommunications (DECT) standard.
Compliant with TBR6, TBR22 (Generic Access Profile, GAP),
and ETS 300 700 - ETSI Wireless Relay Station Specification.
Weather Protection Rating IP54 (weather resistant). Protected against dust and weather
hazards such as rain and sleet; also protected against sprayed
oil and noncorrosive coolants.

2 - 2 Getting to Know Your Repeater
___________________________________________________________________________________
___________________________________________________________________________________
Issue 1.0 Dterm Cordless DECT
SECTION 2CHECKING THE PACKAGE CONTENTS
You should have received the following items:
repeater
AC adapter
Mounting screws and wall anchors
SECTION 3HOW IT WORKS
The DTL-RPT-2 Repeater repeater lets you extend the coverage area of your Dterm
DECT Cordless telephone system in all directions, including up and down. If the
repeaters are installed so their coverage area overlaps the coverage area of the base,
the base can hand-off calls to the repeaters as the user moves from one coverage
area to another. When connected to the repeater, the mobile handset operates the
exact same way as it does when connected to the base, and the hand-off from the
base to the repeater can be completely invisible to the end user, even during an active
call.
Figure 2-1 Single Repeater Attached to Base

Dterm Cordless DECT Issue 1.0
DTL-RPT-2 Cordless DECT Repeater Guide 2 - 3
___________________________________________________________________________________
___________________________________________________________________________________
Configurations
Each base supports up to six repeaters, so you can extend coverage in all directions,
including through floors and ceilings.
Figure 2-2 Six Repeaters Attached to Base

2 - 4 Getting to Know Your Repeater
___________________________________________________________________________________
___________________________________________________________________________________
Issue 1.0 Dterm Cordless DECT
In addition, the DTL-RPT-2 Repeater supports a sequential or "daisy chain" layout to
extend coverage in a single direction. Up to three repeaters can be installed in
sequence.
When a repeater powers on, it searches for signals from the base and any other
repeaters registered to the same base. The repeater will automatically connect to the
strongest available signal. You can combine "star" and "daisy chain" layouts to create
a wide variety of coverage configurations, as long as you have no more than six
repeaters per base unit.
Figure 2-3 Daisy-Chain Layout
Figure 2-4 Combo Star and Daisy-Chain Layout

Dterm Cordless DECT Issue 1.0
DTL-RPT-2 Cordless DECT Repeater Guide 2 - 5
___________________________________________________________________________________
___________________________________________________________________________________
SECTION 4SETTING UP YOUR REPEATER
Setting up the repeater involves four basic steps:
1. Install the AC adapter on the repeater unit.
2. Register the repeater to the base.
3. Position the repeater at the proper installation site.
4. Install the repeater in its final location.
Use ONLY the power adapter that came with your repeater. A different power
adapter may cause an electrical hazard or damage the repeater.
You can register up to six repeaters to a base. Repeat these steps as needed.
These procedures refer to items on the back of the DTL-RPT-2 Repeater:
Figure 2-5 Back View of the DTL-RPT-2 Repeater

2 - 6 Getting to Know Your Repeater
___________________________________________________________________________________
___________________________________________________________________________________
Issue 1.0 Dterm Cordless DECT
During registration, the LED on the front of the repeater will blink. The table explains
what the LED blink patterns indicate.
SECTION 5INSTALLING THE AC ADAPTER
1. Using both thumbs, press down on the raised ridges of the adapter cover on the
repeater until you hear a click.
2. Being careful not to angle the cover, gently pull to remove it.
Table 2-1 Repeater LED Patterns
State Meaning
Steady On The repeater is registered to a base and has a good signal
from that base (or another repeater registered to that
base).
Slow blink (one blink per
second) Standby mode. The repeater is not registered or cannot be connected to the registered base.
Flicker (2 rapid blinks per
second) The repeater is in registration mode (it is looking for a base to register to).
Figure 2-6 Removing the Adapter Cover

Dterm Cordless DECT Issue 1.0
DTL-RPT-2 Cordless DECT Repeater Guide 2 - 7
___________________________________________________________________________________
___________________________________________________________________________________
3. Insert the AC adapter connector into the yellow adapter opening. Thread the
cord according to the illustration.
4. Carefully replace the cover, and press until you hear it click. Do not angle it as
you replace it.
5. Use the AC adapter to connect the repeater to a standard 120 V AC outlet. (Do
not use an outlet controlled by a wall switch!) The LED on the repeater flashes
briefly, then remains on and steady.
SECTION 6ACTIVATE REGISTRATION MODE ON BASE
You need to activate registration mode on your base before you can register your
repeater to it. Refer to the Owner’s Manual for your base unit for registration
instructions.
You only have to activate registration on the base once, regardless of how many repeaters
you want to register (up to 6).
6.1 Register Repeater to Base
You can register up to six repeaters to each base. Repeat these steps as
needed for each repeater. The repeater seeks out the base with strongest
DECT/GAP signal and automatically registers to that base. Make sure no
other bases in range are in registration mode. If more than one base is in
registration mode at the same time, you cannot control which base the
repeaters register to.
Figure 2-7 Threading the AC Adapter Cord

2 - 8 Getting to Know Your Repeater
___________________________________________________________________________________
___________________________________________________________________________________
Issue 1.0 Dterm Cordless DECT
Before you start the registration process, be sure you have:
A working base
A working handset registered to that base
Any repeaters you want to register to that base (you must complete the
registration process separately for each repeater).
At least one of the AC adapters supplied with the repeaters. If you have
multiple repeaters to register, you can power up one repeater, register it,
power it off, and then use that AC adapter for the next repeater. The
repeater remains registered to the base, even if power is disconnected.
Use ONLY the power adapter that came with the repeater. A different adapter
may cause an electrical hazard, or damage the repeater.
6.2 Registration
1. Press and hold the registration button on the base until the Power LED
on the base begins to blink.
2. On the back of the repeater, press and hold the registration button until
the repeater LED on the front settles into a slow blinking pattern. The
repeater is now in registration mode.
3. Release the button on the repeater and wait for the LEDs on the
repeater and base to stop blinking and remain steady on (this can take
about 60 seconds).
4. The repeater is now registered to this base and is ready to use. You can
safely disconnect the power and move the repeater to the selected
location.; the repeater will stay registered to the base even if you
disconnect the AC adapter, or there is a power failure.
Table 2-2 Trouble Table
If the LED... Try...
Continues to flash Registering the repeater again.
Does not turn on (no
power to unit) - Disconnect the repeater’s AC adapter and wait about 10 seconds. Reconnect the adapter and try
these procedures again.
- Checking that only one repeater is in registration
mode. Only one repeater can be registered at a time.
- Plugging the adapter into a different outlet.
