NEFF N24ZA11G1 User manual

neff -home.com
Accessory drawer
User manual and installation
instructions
N24ZA11G1

en Safety
2
Table of contents
INFORMATION FOR USE
1 Safety...................................................................2
2 Preventing material damage ..............................2
3 Environmental protection and saving en-
ergy ......................................................................3
4 Basic operation ...................................................3
5 Cleaning and servicing.......................................3
6 Customer Service................................................3
7 INSTALLATION INSTRUCTIONS ........................4
1 Safety
Observe the following safety instructions.
1.1 General information
¡Read this instruction manual carefully.
¡Keep the instruction manual and the
product information safe for future refer-
ence or for the next owner.
¡Do not install the appliance if it has been
damaged in transit.
1.2 Intended use
Only use this appliance:
¡To store cookware.
¡in private households and in enclosed
spaces in a domestic environment.
1.3 Restriction on user group
This appliance may be used by children aged
8 or over and by people who have reduced
physical, sensory or mental abilities or inad-
equate experience and/or knowledge,
provided that they are supervised or have
been instructed on how to use the appliance
safely and have understood the resulting
dangers.
Do not let children play with the appliance.
Children must not perform cleaning or user
maintenance unless they are at least 15 years
old and are being supervised.
Keep children under the age of 8 years away
from the appliance and power cable.
1.4 Safe use
WARNING‒Risk of suffocation!
Children may put packaging material over
their heads or wrap themselves up in it and
suffocate.
▶Keep packaging material away from chil-
dren.
▶Do not let children play with packaging ma-
terial.
Children may breathe in or swallow small
parts, causing them to suffocate.
▶Keep small parts away from children.
▶Do not let children play with small parts.
WARNING‒Risk of harm to health!
The silicone mat is not food-safe.
▶Do not store any food in the accessory
drawer.
▶Do not allow food to come into contact with
the silicone mat.
2 Preventing material damage
ATTENTION!
Excessive weight may damage the appliance.
▶The appliance has a maximum load capacity of
25kg.
Moisture may damage the appliance.
▶Do not use the appliance to store food and drinks.
The humidity of the food may cause corrosion dam-
age.
The silicone mat is not heat-resistant.
▶Do not use the silicone mat in a warming drawer or
in an oven.

Environmental protection and saving energy en
3
3 Environmental protection and saving energy
3.1 Disposing of packaging
The packaging materials are environmentally compat-
ible and can be recycled.
▶Sort the individual components by type and dispose
of them separately.
4 Basic operation
4.1 Opening the appliance
▶Press on the appliance's panel.
aThe appliance opens and can be pulled out.
4.2 Closing the appliance
▶Slide the appliance in until it engages.
5 Cleaning and servicing
To keep your appliance working efficiently for a long
time, it is important to clean and maintain it carefully.
5.1 Cleaning products
You can obtain suitable cleaning products from after-
sales service or the online shop.
ATTENTION!
Unsuitable cleaning products may damage the sur-
faces of the appliance.
▶Do not use harsh or abrasive detergents.
▶Do not use cleaning products with a high alcohol
content.
▶Do not use hard scouring pads or cleaning
sponges.
▶Only use glass cleaners, glass scrapers or stainless
steel care products if recommended in the cleaning
instructions for the relevant part.
▶Wash sponge cloths thoroughly before use.
5.2 Cleaning the appliance
ATTENTION!
Heat may damage the silicone mat.
▶Do not clean the silicone mat in the dishwasher.
1. Remove the silicone mat.
2. Clean the appliance and silicone mat with a damp
cloth and neutral cleaning agents, such as washing-
up liquid and water.
3. Dry with a soft cloth.
4. Place the silicone mat into the dried appliance.
5.3 Cleaning the stainless steel surfaces
1. Always remove limescale, grease, starch or albumin
stains immediately.
Corrosion may form under such stains.
2. Clean with water and some washing-up liquid.
3. Dry with a soft cloth.
5.4 Cleaning the glass front
▶Clean the glass front using a glass cleaning product
and a soft cloth.
‒Do not use any abrasive sponges that may
scratch or any glass scrapers.
6 Customer Service
Function-relevant genuine spare parts according to the
corresponding Ecodesign Order can be obtained from
Customer Service for a period of at least 10 years from
the date on which your appliance was placed on the
market within the European Economic Area.
Note:Under the terms of the manufacturer's warranty
the use of Customer Service is free of charge.
Detailed information on the warranty period and terms
of warranty in your country is available from our after-
sales service, your retailer or on our website.
If you contact Customer Service, you will require the
product number (E-Nr.) and the production number
(FD) of your appliance.
The contact details for Customer Service can be found
in the enclosed Customer Service directory or on our
website.
6.1 Product number (E-Nr.) and production
number (FD)
You can find the product number (E-Nr.) and the pro-
duction number (FD) on the appliance's rating plate.
Make a note of your appliance's details and the Cus-
tomer Service telephone number to find them again
quickly.

en Installation instructions
4
7 Installation instructions
Observe this information when installing the appliance.
7.1 Scope of delivery
After unpacking all parts, check for any transport dam-
age and for completeness of delivery.
7.2 Appliance dimensions
You will find the dimensions of the appliance here
7.3 Installation in the cabinet
You will find the dimensions of the appliance here
14cm
7.4 Safe installation
Follow these safety instructions when installing the ap-
pliance.
WARNING‒Risk of suffocation!
Children may put packaging material over their heads
or wrap themselves up in it and suffocate.
▶Keep packaging material away from children.
▶Do not let children play with packaging material.
WARNING‒Risk of injury!
Sharp-edged parts may be accessible during installa-
tion.
▶Wear protective gloves.

Installation instructions en
5
7.5 Installation
Fitted units
This is where you can find information about safe in-
stallation.
ATTENTION!
When the door is opened, the appliance may tip over.
▶Above the appliance, provide a fixed intermediate
floor in the fitted unit.
▶When combined with an oven, provide a fixed inter-
mediate floor above the oven.
If no intermediate floor is possible above the appliance
or above the oven, install tilt protection for the appli-
ance →Page5. Suitable tilt protection can be ob-
tained from customer service, on our website or in the
online shop.
Combining with other appliances
You can combine the accessory drawer with a max-
imum of one more appliance from the same appliance
series.
No intermediate floor is required between the appli-
ances.
When installing appliances under an oven, combi-
steam oven or steam oven, no tilt protection is re-
quired.
When installing under the fully automatic coffee ma-
chine, install the tilt protection for the fully automatic
coffee machine.
For the following combinations, install tilt protection on
the accessory drawer:
¡Accessory drawer separately, including when in-
stalling below an intermediate floor
¡Accessory drawer under microwave
¡Accessory drawer under hob
¡Accessory drawer with accessory drawer, at least
on the upper appliance
¡Accessory drawer with warming drawer, at least on
the upper appliance
¡Accessory drawer with vacuum-sealing drawer, at
least on the upper appliance
Suitable tilt protection can be obtained from customer
service, on our website or in the online shop.
→"Fitting tilt protection", Page5
Fitting tilt protection
Suitable tilt protection (order number: 12039458) can
be obtained from customer service, on our website or
in the online shop.
1. Measure a clearance of 518mm from the front
edge of the unit and mark it on both sides in the fit-
ted unit.
2. Screw the two brackets into the elongated hole on
the mark.
3. Place the appliance on a flat surface.
4. Unscrew the two lower screws on the back of the
appliance.

en Installation instructions
6
5. Use the two screws to tighten the two metal retain-
ers on the back of the appliance.
‒Ensure that the metal retainers are aligned ex-
actly with the edge of the appliance.
6. Slide the appliance into the fitted unit and check
whether the tilt protection engages.
7. If required, correct the position of the bracket with
the elongated hole.
8. Finally, screw the brackets to the fitted unit.
9. Push the appliance into the fitted unit.
10. Remove the adhesive strip from the appliance front.
11. Open the appliance carefully and check whether the
tilt protection is working.
Inserting the design profiles
1. Fold together the fastening elements.
2. Hook the fastening elements into the openings at
the bottom and push down until they engage.
Insert the red fastening elements into the upper
opening.
Insert the green fastening elements into the lower
opening.
3. Remove the protective film from the design profiles.
4. Insert the design profiles on both sides of the appli-
ance.
5. Check the clearances of the design profiles.
Adjusting design profiles
WARNING‒Risk of injury!
Parts that are accessible during installation may have
sharp edges and may lead to cutting injuries.
▶Wear protective gloves.

Installation instructions en
7
ATTENTION!
Unsuitable tools may damage the surface of the appli-
ance.
▶Only use plastic tools.
▶Do not use pointed or sharp tools.
1. Pull the design profiles forwards to remove them. If
necessary, carefully loosen and remove the design
profiles using a plastic tool.
2. Adjust the fastening elements and re-attach the
design profiles.
Installing the appliance
1. Push the appliance all the way into the fitted unit.
2. Centre the appliance.
3. Remove the adhesive strip from the appliance front.
4. Open the appliance.
5. Screw the appliance to the fitted unit.
Adjusting the appliance front
Adjust the appliance front upwards or downwards if ne-
cessary.
1. Open the appliance.
2. Undo the screws on the side of the panel.
3. Align the appliance front upwards or downwards.
Alignments of maximum -3 to +3mm are possible.
4. Tighten the screws.
Combining the accessory drawer with another
appliance
ATTENTION!
Sharp edges on the appliance may damage the panel
of the accessory drawer.
▶Do not damage the accessory drawer cover when
sliding the appliance in.
1. Only combine suitable appliances of the same
brand and series.
2. First fit the accessory drawer.
3. Slide the appliance onto the accessory drawer into
the built-in cabinet.
4. Observe the installation instructions for the appli-
ance.

Register your product online
neff -home.com
BSH Hausgeräte GmbH
Carl-Wery-Straße 34
81739 München, GERMANY
*9001778135*
9001778135
030605
en
Valid within Great Britain:
Imported to Great Britain by
BSH Home Appliances Ltd.
Grand Union House
Old Wolverton Road
Wolverton, Milton Keynes
MK12 5PT
United Kingdom
