Neilsen CT5182 User manual

It is absolutely prohibited to use the pump with your hands wet, barefoot or while standing
in water.
WARNING: The use of batteries of adequate capacity that are not sufficiently charged
creates decreased pump speed, reduced flow, and insufficient suction that may lead to the
lack of suitable Diesel oil flow.
ASSEMBLY AND DISASSEMBLY
The motor pump has no separate accessories and therefore does not require assembly.
The motor must be disassembled only and exclusively at authorized assistance centers or
by qualified technicians.
MECHANICAL RISKS
Risks created by extreme surrounding temperature.
Remember that excessively low temperature (-30℃) can freeze the diesel oil inside the
pump and that this can cause serious damage to all parts of the motor pump.
Excessively high temperature (40℃in the shade) can cause the sagging or dilatation
of the unit’s plastic parts. We recommend fastening the unit in a well-ventilated area
protected from direct sunlight.
MAINTENANCE AND TROUBLE SHOOTING
Maintenance
Maintenance operations can be performed only after first disconnecting the power supply
plug. The motor pump does not require any special maintenance inside, and for this
reason must never be disassembled. It is important to keep the suction and delivery
sections perfectly clean and free from all clogging.
Trouble Shooting
CAUTION: Please read this manual carefully before operating the pump！
PROBLEMS CAUSES SOLUTIONS
The pump fails
to turn
No power supply
Impeller jammed
Motor malfunction
Check the clamps and the safety
devices.
Disassemble, check for signs of
damage or clogging.
Reassemble.
Contact your local dealer.
Low pump flow.
Tank liquid level too low.
By-pass valve jammed.
Filter clogged.
Air in the suction tube.
Decreased pump rotation
speed.
Leakage of Diesel oil.
The suction tube is resting on
the bottom of the tank.
Excessive suction height.
Fill up the tank.
Clean and re-assemble.
Clean the filter.
Make sure that the suction tube is
not damaged.
Check and correct pump voltage.
Check the connectors and
gaskets.
Raise the tube in the tank.
Lower the level of the pump.
WARNINGS
It is absolutely prohibited to abandon the pump while filling in order to prevent the potential
overflow of Diesel oil.
Never start the pump before first connecting the suction and delivery tubes.
After closing the gun, switch off the motor pump as quickly as possible.
Technical Specifications:
Voltage: DC 12V
Power: 175W
Load current: 10Amps
Speed: 3600RPM
Flowing: 45L/min
Max. lift distance: 10M
Max. Suction: 3M
Inlet/Outlet diameter: 25mm
After inserting the suction tube in the tank and the gun in the filling hole, switch on the pump,
gradually release the gun’s lever and begin the transfer of the Diesel oil.
Starting
After checking to make sure that all the tubes have been adequately sealed, that the power
supply cable has been connected to its attachment and the gun is in the rest position, the pump
can be started.
12V DIESEL ELECTRIC FUEL TRANSFER PUMP
OIL DISPENSER
CT5182

Warning
The user must absolutely observe the accident-prevention measures in force, and must
lso respect the indications provided in the following chapters.
Never shift the motor pump during operation for any reason whatsoever.
Before using the motor pump, always make sure that the power supply cable and all the
ther devices are in perfect working condition.
Before starting the motor pump, make sure that you are not barefoot, that your hands are
ot wet, and that you are not even partially standing in water.
The motor pumps are constructed in such way that all the moving parts are protected by
asings. Never remove any of these casings when the motor pump is running for any
eason whatsoever.
t is very important to keep the motor pumps’ power socket protected from sprays of water,
ain and atmospheric agents in general and all the other liquids.
Not for use with gasoline or alcohol.
Not for use in hazardous locations.
mproper use or installation of this product can cause serious bodily injury or death.
Do NOT smoke near pump or use pump near an open flame.
Do not use this product for fluid transfer into aircraft.
• This product is not suited for use with fluids for human consumption or fluids containing
water.
• Do not dispense fluid that is thicker than diesel fuel. Motor may overheat.
SAFETY INSTRUCTIONS
To ensure safe and efficient operation, it is essential to read and follow each of these
warnings and precautions.
1. Disconnect power to pump before servicing pump.
2. A diesel compatible filter should be used on pump outlet to ensure that no foreign
material is transferred to fuel tank.
3. Tank or barrel should be anchored to prevent tipping in both the full and empty
conditions.
4. The pump should never be left running unattended.
HANDING AND TRANSPORT
Unpacking
Whenever the packaging appears to have been damaged, check the motor pump for signs
of damage during transport of handling.
WARNING: Before installing and using the motor pump, check the identification plate to
make sure that the model and its characteristics correspond to those specified.
Handling disassembly and transport
Although the reduced size and weight of the motor pump will not create particular problems in
transport, we recommend the following:
Never move the motor pump for any reason without first unplugging the power supply plug from
the socket or disconnecting the electrical power supply.
Unscrew and remove the delivery and suction tubes.
Unscrew the bolts or screws used to anchor the motor pump in place.
Never move or drag the motor pump by pulling its power supply cable.
USE AND STARTING
Electrical power supply connection:
Before using, first make sure pump is to use DC power or AC power.
If the pump’s power is DC power:
(1)Connect the pump’s clamps to a battery capable of delivering the current and voltage
required for the operation of the pump.
(2)If a motor vehicle battery is used to power the pump, we recommended first removing it from
the vehicle and standing it on a stable surface in a comfortable position.
(3)The pump can be connected to a battery mounted in a motor vehicle only if the vehicle is
parked outdoors and only if the pumps’ electrical cables and connection piping are long enough
to provide the pump with solid support.
(4)The use of extension cords for the electric cables connected to the clamps is prohibited .If
the length of the cables supplied with the machine is not sufficient to power the pump, the
clamps must be substituted with jack plugs of adequate section by a specialized electrician.
(5)The pump can be connected to a battery-charger only of adequate power equipped with
terminals, never make connections to clamps coming from the battery charger and connect the
pumps’ clamps directly to the battery charger’s terminals in order to prevent the generation of
sparks that might cause fires.
(6)Make sure that the voltage of the pump (indicated on the identification plate) corresponds to
the voltage of the battery.
(7)Make to always respect polarity: connect the black clamps to the - pole and the red clamps to
the + pole.
Be extremely careful (when connecting the pump to the battery) to avoid making contact
between opposite poles and creating sparks (which can cause fire). We recommend connecting
the negative pole first and then the positive pole.
(8)Position the pump securely and make sure that the lengths of both the power supply cables
and the piping are sufficient to ensure solid positioning.
If the pump’s power is AC power:
(1) Power overload current protection switch must be installed
(2) Position the pump securely and make sure that the lengths of both the power supply cables
and the piping are sufficient to ensure solid positioning.
•
a
•
•
o
•
n
•
c
r
•I
r
•
•
•I
•
•
EC DECLARATION OF CONFORMITY
We CANNON TOOLS LTD
20 Station road, Rowley Regis, West Midlands,B65 0JU.U.K.
Declare that the following machine complies with the appropriate basic safety and
desabevitceriDCEehtfostnemeriuqerhtlaeh on its design and type, as brought
into circulation by us.
In case of alteration of the machine, not agreed upon by us, this declaration will
lose its validity.
Product description: 12V DIESEL ELECTRIC FUEL TRANSFER PUMP OIL DISPENSER
Model: CT 5182
Applicable EC Directives:
EC Low Voltage D irective 2014/35/EU
EC Directive of Electromagnetic Compatibility 2014/30/EU
Harmonized standards：
N 60335-1, EN 60335-2-41, EN 55014-1, EN 55014-2E,00121OSINE
EN 61000-3-2, EN 61000-3-3 ,EN 61000-6-1, EN 61000-6-3
20 Station Road, Rowley Regis, West Midlands, B65 0JU.U.K.
Mr. Gurcharan Tony Singh Sanghera
Managing Director
CANNON TOOLS LTD
2019-04-08
EC Machinery Directive 2006/42/EC
