Nemo ASASHI 4P User manual

60"
90"
100"
for detailed setup, care, and repair instructions, visit:
www.nemoequipment.com/support
Capacity: 4
Avg Minimum Weight: 10 lbs, 8 oz (4.7 kg)
Avg Packaged Weight: 10 lbs, 15 oz (5.0 kg)
“On the Fly” Weight: 6 lbs, 8 oz (3.0 kg) [Fly, Poles, and Footprint only]
Packed Dimensions: 19" × 8" dia. (48 × 20 cm)
Frame: Aluminum Poles
Shell Fabric: No-See-Um Mesh / 30D PU Nylon
Fly Fabric: 75D PU Polyester
Floor Fabric: 70D PU Nylon
Floor Dimensions: 100" × 90" (254 × 229 cm)
Interior Height: 60" (152 cm)
Floor Area: 63 ft² (5.9 m²)
Vestibule Area: 17 ft² (1.6 m²)
ASASHI™ 4P
4 PERSON
ASASHI™ 4P
Family-Style Comfort
Great adventure doesn’t always need to be miles from the nearest outpost of
civilization. But finding a big tent to pitch at J Tree or along the Kancamagus
Highway with all the style, quality, comfort, and protection of a high-end
backcountry shelter can be a challenge. Asashi™ 4P takes the highly efficient
pole configuration from our Losi™ series and expands it into a spacious 4
person design. Setup is straightforward thanks to contiguous pole sleeves
and an intuitive, symmetrical design. Includes aluminum poles, eight interior
pockets, four Light Pockets™, roll-up style stuff sack, stakes, and repair kit.

7
1
2
5
6
10
8
9
4
3
11
12
13
14
1. Main Poles
2. Ridge Poles
3. Mesh Canopy
4. Light Pocket™
5. Pole Sleeves
6. Adjustable Corner Anchors
7. Mesh Door
8. High Splash Guard Floor
9. Four Corner Pockets
10. Four Pockets with
Water Bottle Holders
11. Overlap Vent in Rain Fly
12. UVX Window
13. Vestibule Door
14. Adjustable Fly Attachment
ASASHI™ 4P Innovations
1. Unique Pole Configuration: The ridge poles
on Asashi™ 4P run the long direction on the tent
and terminate above the ground. This design adds
significant interior volume and provides nearly
vertical walls on all sides of the tent. The steep
walls mean you can sit straight up anywhere inside
Asashi™ 4P with ease.
2. On the Fly Configuration: Ditch your inner tent
for a lightweight tarp structure created by your fly,
poles, and footprint. This is ideal for a sunny day
at the beach or on those backpacking trips where
every ounce counts. Setup is simple with Velcro®
wraps located on the fly.

4. Interchangeable Vestibule Options: Versatility
is key when you’re planning adventures. Having
multiple vestibule options keeps you flexible and
ready for all scenarios. The Standard Vestibule is
great when you’re travelling light and just need to
stow your backpacks and other small pieces of gear.
If you’re in full base camp mode, swap the Standard
Vestibule for a Garage™ to hold bulky gear, or use
the Link™ to create communal protected spaces
when camping in large groups.
5. Storage Space: Don’t clutter your sleeping space
with odds and ends. Four individual gear pockets
with integrated water bottle holders are just an
arm’s reach away. For even more storage capacity,
use the optional Gear Caddy or Gear Loft to hold
essential items or to dry out damp clothing.
6. Direct Guy-Out Points: Keep your tent anchored
and secure in windy conditions with multiple
guy-out points. Since bigger tents can be more
susceptible to high winds because of their taller
profile and larger surface area, these strategically
placed guy-outs pass through the fly and attach
directly to the poles to help spread the load and
keep your tent firmly in place.
7. Light Pocket™: Asashi™ 4P includes four special
pockets for your headlamps with a light diffusing
fabric. Place your lamp in the pockets in the canopy
with the light facing towards the inside of the tent,
and the Light Pocket™ will help cast an even glow
throughout the tent interior.
8. UVX Window: The vestibule includes a UVX
window so you can check conditions outside
without exposing your gear to the elements.
The window is optically clear, non-yellowing,
non-clouding, UV resistant, and remains flexible
in cold temperatures.

Optional Accessories
1. Footprint: The Footprint is a 70D abrasion-
resistant nylon fabric ground sheet perfectly sized
to fit underneath your tent. The fabric is PU coated
for waterproofness. The Footprint reduces wear and
tear on your tent floor from contact with the ground.
2. Pawprint™: The Pawprint™ is a removable liner
perfectly sized to fit inside your tent. It has the dual
function of protecting your tent floor from boots
and paws, and of adding serious comfort. The
Pawprint™ is made of a machine-washable brushed
polyester that is very soft to the touch. Place your
sleeping pads between the Pawprint™ and floor to
help them stay in place.
3. Garage™: Increase your gear storage capacity with
the Asashi™ 4P Garage™. The Garage’s™ cavernous
interior can hold it all: several bikes, climbing gear,
table and chairs, or any other equipment to suit
your adventures. A large side door gives easy access,
and the tall interior height provides enough space
to enjoy the shade while sitting and relaxing. To
convert the Garage™ into an extra sleeping space,
add the optional Asashi™ 4P Garage™ Footprint.
4. Link™: Enhance the living space between two
Asashi™ 4Ps with the Asashi™ 4P Link™. Whether
used as a communal meeting space, a versatile
entrance, a sleeping area for pets, or covered storage
for your gear, the Asashi™ 4P Link™ is sure to become
a favorite accessory for all trips and adventures.
6. Gear Loft: The Asashi™ 4P Gear Loft adds overhead
storage without compromising on floor space or
elbow room. The adjustable mesh loft is perfect for
drying clothes or stashing gear for quick access.
7. Gear Caddy: An optional Gear Caddy can be
added for even more storage in Asashi™ 4P. Multiple
organizing compartments help you stash gear
for quick access.

®
Stake Corners (optional)
Secure the corner anchors by pounding the stakes into the
ground with a rock or hard object. If the ground is too hard,
trap the stakes under a rock or another heavy object.
Main Poles
Jake’s Feet
Slide the two main poles through the long pole sleeves
running corner to corner on the tent.
Ridge Poles
Slide ridge poles through shorter pole sleeves. Insert the ends
into grommets on the sides of the tent.Use finger loops to help
pull webbing on and off pole tips.
Attach Fly
Clip the corners of your tent fly to the Jake’s Feet. Proper tension
ensures maximum water shedding and wind resistance. Pull firmly
on the adjustable corner anchors.
Press the ball ends of poles into the fittings (Jake’s Feet)
at the corners of the inner tent.
Remember to leave no trace. Before leaving your campsite take a thorough look
around making sure you have not left anything behind, out of place, or damaged.
©2010 NEMO Equipment, Inc.
1
2
3
4
5
To contact NEMO Customer Service
Email: [email protected]
Phone: [phone]
ASASHI™
INSTRUCTIONS FOR SETUP
