NEO Coolcam P2P IP CAMERA User manual

P2P IP CAMERA
Quick Installation Manual
O-P
Network Camera Installation Manual
HBP

1
Network Camera Installation Manual
1. Hardware installation
1.1 Hardware connection
Connect the power supply and network cable. Check if the power indicator
(green) and the network indicator (yellow) is working properly. Then the
camera head will rotate automatically.
Note: picture is for reference only. Actual product may vary.
Power indicator: Green LED is on while power is on.
I/O port：Connect to a PIR or alarm sensors.
Network indicator: Yellow LED blinks when transferring data
Power supply: 5V
RJ45: Connect to the WiFi router
SD slot: Micro SD card
WIFI antenna: Receiving a wireless signal
Audio output: Connect to a speaker.
To reset the camera, please find the “RESET” button at the bottom of the pan and
tilt camera or at the end of the tail wire of the dome camera. Then use paper clip
to reach the reset button to press and hold for 30 seconds until you hear ticking
noise and/or device rebooting. PLEASE NOTE: resetting the camera is only
necessary if you have forgotten the password or moving the camera from one
network to another network.
Tips
T/F
Fig 1.1
WIFI antenna
I/O port
Power input
Power indicator
RJ45
Network indicator
Audio out
Reset Button
SD slot

2
Network Camera Installation Manual
1.2 Network connection
If you camera has one key set up feature, you do not need to connect the network
cable between the camera and WiFi router.) Skip to 1.4.
1.3 Wifi Connectin using WPS button (If your router or camera does
not have WPS button, please skip this step.)
If your WiFi router and camera both have WPS button, then you can connect the
camera to the WiFi router using WPS button as below:
Fig 1.2
T/F
0 t1 t1+2 t1+10 time
Press WPS button on router Within specified time press WPS
button on IP camera
WPS Routers time range. WPS time range (IP camera).
Reset camera time range.
1. Press the Router WPS button at 0 second, the Router will set a time range (the
red area), press the IPCAM WPS button during the time range then the WPS is
workable;
2. Press the IPCAM WPS during the red time range, such as start at t1 and end at
t1+2(the blue area);
3.If press the IPCAM WPS more than 10 seconds, the camera will be reset, such
as press at t1 more than t1+10, it is reset function not WPS function.

3
Network Camera Installation Manual
1.4 WiFi Connection using “one key setup.”
Fig 1.4a Fig 1.4b Fig 1.4c
Fig 2.1a Fig 2.1b Fig 2.1c
Plug in the power adapter to the camera. The camera head will rotate to initialize
for about 10 seconds. For the first time installation, after downloading and installing
“coolcamHBP” app, tap on add camera and tap on “one key setup wifi” icon or
choose skip (only if camera wifi setup is done.)
While the camera gives a ring tone sound, choose WiFi router from the list which you
want to connect the camera to. Then, input Wi-Fi password and tap on “one key
setup wifi.” Normally it takes about 40 seconds for the camera to connect to your
Wi-Fi router. When it is done, you will hear a short burst of ringing sound.
2. iPhone and Ipad App introduction
2.1 App download
From App Store, search for app name “coolcamHBP”, and then choose “ ”
to download and install it.

4
Network Camera Installation Manual
Fig 2.2a Fig 2.2b Fig 2.2c
Fig 2.2d
2.2 Add camera
There are 3 ways to add camera to the app: Lan Search, QR Code Scan and
Manual input.
Factory default user name is “admin” default password is “admin”.
Please note that the password on some models are empty. In this case, leave the
password section empty and proceed to complete the adding procedure.
Fig 2.2e Fig 2.2f
Method 1:Tap“ ” to add cameras, then tap Search network. This will find all the
cameras in the same network. By selecting camera from the search list, it will
automatically add the Camera ID and Username in the system. Then name your
camera by your choice and input factory default password. Once all of the information
have been added, tap “Done” on the right top corner to finish adding process.
Method 2:Tap“ ” to add cameras, then tap Scan QR code. This will bring up a
camera scan on your screen so that you may find and scan the QR code which will
automatically add the Camera ID and Username in the system. The QR Code, which
looks like a square barcode (refer to 3rd picture below), can be found on the sticker
located at the bottom of the camera. Then name your camera by your choice and input
factory default password. Once all of the information have been added, tap “Save” on
the right top corner to finish adding process.
+
Add D evice
+
Add D evice

5
Network Camera Installation Manual
Fig 2.2g
Method 3:Tap“ ” to add camera, then manually input all the information into the
system. Name your camera by your choice, input the Camera ID, then input Username
and finally input factory default password. Once all of the information have been added,
tap “Save” on the right top corner to finish adding process.
Fig 2.2h Fig 2.2i
TIP
When the password is same as the factory default password, it will remind you (Fig 2.2i)
to modify the password for security reason. But, you may cancel it to skip the process.
3. Liveview Screen
3.1 Single Screen View
Fig 3.1a Fig 3.1b
+
Add D evice

6
Network Camera Installation Manual
Control icons explained.
monitor/
intercom talk Snapshot Record
Video
alarm
switch
preset
position
switch
Infrared
lamp switch flip top to
bottom
Flips
around resolution current
setting
Monitor/intercom – Listen to the audio of the camera.
Talk – Talk back to the camera for two way audio
Snapshot – Take picture of the screen and store on camera's memory.
Record – Record video of the live view and store on camera's memory.
Alarm on – Turn on alarm.
Preset – Tap on the icon to point the camera to preset position.
Set position on pan and tilt camera by pressing and hold for 3 seconds.
IR light – Turn on IR LED light.
Up-down flip – Flipping image upside down.
Right & left – Used in pan and tilt camera for moving camera right and left.
VGA – Resolution settings; QVGA, VGA, 720P(only for HD camera),
1080P(only for 1080P camera)
Environment mode - Set 50Hz (Europe) or / 60 Hz(USA)
Fig 3.2a
Fig 3.2b
3.2 Multi view screen

7
Network Camera Installation Manual
Fig 4.2a Fig 4.2b
Fig 4.1a Fig 4.1b Fig 4.1c
Fig 4.2c
4. Parameter Setting
Click on ” to enter setting. You will see Security Code setting, wifi settings, SD
card settings, alarm settings, FTP settings, mail settings and reboot camera.
4.1 Security Code Setting
In camera list, Tap on
“
“ ”to enter edit interface, Tap on “Advanced setting” to modify
the security password. The factory default ID and password is both “admin”.
4.2 WIFI setting
Tap on wifi network in “Advanced setting” to auto search for camera's nearby wifi
hotpot. Choose the WiFi router you want to connect the camera to. Then, enter
WiFi password and tap “Join” located on top right corner. After successful setting,
camera will reboot. After reboot, LAN cable can be unplugged.

8
Network Camera Installation Manual
Fig 4.3bFig 4.3a
4.3. SD Card Setting
For motion detection setting: Turn on “Guard”, choose the sensitivity, alarm SD
card recording, push notification, and remote saving pictures.
Fig 4.4a Fig 4.4b
4.4. SD Card Setting
In Advanced mode, tap on SD card to format the SD card.
Warning: tapping “Continue” will erase all data.

9
Network Camera Installation Manual
4.5 Alarm Setting
4.5a For motion detection
setting, Follow below
setting
Fig 4.5a Fig 4.5b
Turn on Local Time Correction
to Synchronize time with
your phone.
Fig 4.6
5.1 Check alarm push notification live video
Tap on the push notifications, it will connect you to live video of the camera triggered.
To check recorded event video, please go to 5.2 below.
4.5b For external alarm
setting, Follow below
setting
4.6 Time setting
Fig 5.1a Fig 5.1b

10
Network Camera Installation Manual
Fig 5.3a Fig 5.3b Fig 5.4c
6. Introduction of Android App
6.1 App download
From Play Store, search for app name “coolcamHBP”, and then choose “ ” to
download and install it.
6.2 Add Camera
There are 3 ways to add camera to the app: Lan Search, QR Code Scan and
Manual input.
Factory default user name is “admin” default password is “admin”.
Please note that the password on some models are empty. In this case, leave the
password section empty and proceed to complete the adding procedure.
Method 1：By LAN Search
Tap to add cameras, tap Search, select camera from the Search results list.
Then, name your camera and input factory default password.
“ ”
Fig 6.2a Fig 6.2b Fig 6.2c
5.2 Check Event Video
Tap on “Event” icon. Tap on video file. View event video
+
Add D evice

11
Network Camera Installation Manual
Method 2：By QR Code Scan
Tap“ ” to add cameras, tap Scan QR code, scan the QR code located at the bottom
of the camera. Then, name your camera and input factory default password.
Fig 6.2d Fig 6.2f Fig 6.2e
Method 3: Manually add
Tap to add cameras, type in camera's UID and password manually to connect to
the camera.
“ ”
Fig 6.2g Fig 6.2i Fig 6.2h
Tip
When the password is same as the factory default password, it will remind you to modify
the password for security reason. But, you may cancel it skip the process.
+
Add D evice

Fig 7.1a Fig 7.1b
12
Network Camera Installation Manual
7. Live View Screen
7.1 Single view Screen
Tap on the picture to see live view
7.2 Multi-view Screen
Tap on the quad view icon on top left corner to see quad view.
Fig 7.2a Fig 7.2b
Control icons explained.
monitor/
intercom talk Snapshot Record
Video
alarm
switch
preset
position
switch
Infrared
lamp switch flip top to
bottom
Flips
around resolution current
setting

13
Network Camera Installation Manual
Monitor/intercom – Listen to the audio of the camera.
Talk – Talk back to the camera for two way audio
Snapshot – Take picture of the screen and store on camera's memory.
Record – Record video of the live view and store on camera's memory.
Alarm on – Turn on alarm.
Preset – Tap on the icon to point the camera to preset position.
Set position on pan and tilt camera by pressing and hold for 3 seconds.
IR light – Turn on IR LED light.
Up-down flip – Flipping image up side down.
Right & left – Used in pan and tilt camera for moving camera right and left.
VGA – Resolution settings; QVGA, VGA, 720P(only for HD camera),
1080P(only for 1080P camera)
Environment mode - Set 50Hz (Europe) or / 60 Hz(USA)
8. Parameter settings
Choose camera and Tap“ ” located on the right of the camera list. Then tap on edit
camera to modify user name, password, advanced setting, alarm setting and time setting.
Fig 8a Fig 8b Fig 8c
8.1 Modify the password of the camera
Tap the "Modify Security code" in the "Advanced Settings", and Change Password.
Fig 8.1a Fig 8.1b

14
Network Camera Installation Manual
Fig 8.2a Fig 8.2b
Fig 8.3 Fig 8.4
8.2 WIFI Settings
In the “Advanced Setting”, Tap “Manage WIFI networks”, select your WIFI router you want
to connect the camera to. Then input password of the WiFi router. After successful setting,
camera will reboot. After reboot, LAN cable can be unplugged.
8.3 Record Setting
In the record settings, you can
select full time recording or alarm
event(motion detection) recording.
8.4 Alarm Setting
In the “Alarm Setting”, turn off guard switch and
open “alarm linkage(PIR)” to turn on motion
detection by PIR sensor only. Alarm SD card
recording and push notification can be turn on or off.

15
Network Camera Installation Manual
Fig 9.1a
Fig 9.2a
9.2 View Snapshot Stored in your phone.
9.1. Check the Event Video
Tap on Event message Select video file from the list View event video
Fig 9.1b Fig 9.1c
Fig 9.2b Fig 9.2c

16
Network Camera Installation Manual
Fig 9.3a Fig 9.3b Fig 9.3c
9.3 View Recorded Video Stored in your phone.

17
Network Camera Installation Manual
TIPS
*When you first install Micro SD card, Micro SD card required to be formatted in
the APP.
*After the camera is powered on for about 30s, the camera will rotate a circle
automatically.
*After the camera is added in LAN successfully, no further setup is required for
remote access.
*In setting up a wireless connection, please make sure the wireless signal
strength is strong.
*After the device is connected to the power and network cable, the green light
will be on and the yellow light will be blinking continuously.
*If the built-in speaker sound is too weak, you can connect to an external speakers.
*If you forget your password, you can restore the factory default settings by
resetting the camera.

Network Camera Installation Manual
Restore the Factory Default Settings
Find the "RESET" button at the bottom of the camera, make sure power is connected
during resetting. Press and hold it for approximately 30 to 40 seconds to restores the
factory settings (Yellow LED will become solid and then device will automatically restart).
For tech support, please contact [e-mail]
or visit www.ismartzon.com
T/F
18

Eu Environmental protection
Waste electronic products should not be household waste .
If there is a corresponding Facilities , recycling .
The recycling proposal , please consult the relevant functional
departments of local government or retailers.
