Neon DS-TT-02 Series User manual

This document applies to version 2 of the NEON Temperature Transmitter (DS-TT-02-XX)
Product Manual
Transmitter
Temperature
Version A3
NEON-Temperature-Transmitter_User-Manual_DS-TT-02-xx_4001_A3 24-11-2022

Contents
1 TWTG NEON 4
1.1 NEON Product Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
1.2 Related Documents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
2 Getting Started 5
2.1 Compatibility of this manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
2.2 What you will need . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
2.3 What is in the box . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
2.4 Product Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
2.5 Product Type Identification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
2.6 Component Names . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
2.7 Product Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
3 Warnings 10
3.1 ATEX / IECEx . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
3.1.1 Specific Conditions of Use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
3.1.2 Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
3.1.3 Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
3.1.4 Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
3.1.5 Output parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
3.2 General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
3.2.1 Transport and Storage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
3.2.2 Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
3.2.3 Warranty will be void in case of . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
4 Avertissements 12
4.1 ATEX / IECEx . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
4.1.1 Conditions spécifiques d’utilisation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
4.1.2 Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
4.1.3 Fonctionnement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
4.1.4 Entretien . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
4.1.5 Output parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
4.2 Informations générales . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
4.2.1 Transport et stockage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
4.2.2 Garantie . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
4.2.3 La garantie sera annulée dans les cas suivants: . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
5 Provisioning 14
5.1 User Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
5.2 Operating the Device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
5.2.1 Read device status . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
5.2.2 Device Activation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
5.2.3 Device Deactivation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
5.3 Product Identification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
5.3.1 NFC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
5.3.2 Data Matrix Code . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
NEON-Temperature-Transmitter_User-Manual_DS-TT-02-xx_4001_A3 2 of 34

CONTENTS
6 Installation 19
6.1 Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
6.2 Mounting Bracket Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
6.3 Installation Methods . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
6.3.1 Installation using mounting holes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
6.3.2 Installation using threaded holes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
6.3.3 Installation using bandclamp . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
6.4 Using the Temperature Transmitter with Thermocouples . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
6.4.1 Cold Junction Compensation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
6.4.2 Assessed Connectors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
6.4.3 Selecting a thermocouple wire . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
6.4.4 Connecting a thermocouple wire to the temperature interface . . . . . . . . . . . . . . . . . . . . 23
6.5 Using the Temperature Transmitter with a RTD (3-wire) . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
6.5.1 Connecting a RTD (3-wire) sensor to the temperature interface . . . . . . . . . . . . . . . . . . . 24
7 Product Functionalities 25
7.1 Application Event Message . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
7.1.1 Event-triggers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
7.1.2 Content application event message . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
7.2 Device Status . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
7.3 Default Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
8 Maintenance 27
8.1 Battery Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
8.1.1 Battery Replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
8.1.2 Required tools . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
8.1.3 Disassembly of device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
8.1.4 Built-In Self-Test Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
8.1.5 Assembly of device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
9 Accessories and Spare Parts 31
10 EU Declaration of Conformity 32
11 FCC and ISED Declarations 33
3 of 34 NEON-Temperature-Transmitter_User-Manual_DS-TT-02-xx_4001_A3

1 TWTG NEON
1 TWTG NEON
1.1 NEON Product Introduction
NEON stands for a standardised approach to collecting data points from the operational environment and in doing so,
creates a general approach to integrated data collection within existing IT ecosystems.
The TWTG NEON product range supports all industrial customers moving towards LoRaWAN as the Industrial IoT
network of the future.
The LoRaWAN network gives industrial operations a secure solution, which scales-up to tens of thousands of sensors,
covers complete sites with only a small amount of gateways and best of all – the low-power approach means that the
lifetime of the NEON products is extended dramatically.
1.2 Related Documents
Document Name Document Number
NEON Data Sheet 6015_N02-09_Data-Sheet-NEON-Temperature-Transmitter
NEON Communication Protocol 6020_N02-09_Communication-Protocol-NEON-Temperature-Transmitter
Table 1: Related documents
NEON-Temperature-Transmitter_User-Manual_DS-TT-02-xx_4001_A3 4 of 34

2 GETTING STARTED
2 Getting Started
2.1 Compatibility of this manual
This manual is meant to be used with products of from a specific production batch. See Serial Number for an explanation
on how to retrieve the production batch code from the serial number.
This manual is applicable to version 2 of the NEON Temperature Transmitter.
See chapter Product Type Identification to determine the revision of the product.
2.2 What you will need
In order to deploy the NEON Temperature Transmitter, a compatible and operational LoRaWAN network architecture is
required. This manual does not contain any instructions of how to setup and install LoRaWAN networks.
TWTG offers radio network planning and IT-architecture design services to fully integrate the products in the NEON
product line.
2.3 What is in the box
When the product is delivered check the components for damage and whether all box items mentioned below are
included.
Box Items
NEON Temperature Transmitter 1 battery assembly (included in the product)
1 mounting bracket (mounted on the product)
M12 connector (mounted on the product)
Declaration of Conformity Declaration of Conformity, containing a link to latest version of this
product manual and other relevant product documentation
Table 2: Box Items
5 of 34 NEON-Temperature-Transmitter_User-Manual_DS-TT-02-xx_4001_A3

2 GETTING STARTED
2.4 Product Specifications
Product
Product name TWTG NEON Temperature Transmitter
Type identification DS-TT-02-XX
Supported temperature sensors Thermocouple Type-K (other types configurable over LoRa)
RTD PT100
Environmental conditions
Operating temperature range Transmitter -40°C - 70°C
Storage temperature range 10°C - 30°C
Operating humidity range 0% - 100% RH
Altitude Up to 3000 m
Water & dust resistance IP65
Pollution degree 3
Usage Indoor and outdoor
Mechanical
Material Molded plastic
Weight (including mounting bracket) 330 g
Dimensions 100x70x57 mm
Installation
Transmitter Band clamp or bolts (not included)
Maximum cable length Limited by equipment output parameters, see Selecting a
thermocouple wire
Power Supply specifications
Battery rated voltage 3.6 V
Battery rated capacity 17 Ah
Functional specifications
Output LoRaWAN
Input M12 connector for thermocouple or RTD input
Input insulation rating 500VAC / 1 min
Connectivity
Protocol LoRaWAN
Frequency band 863-870 MHz
902-928 MHz (compatible)
Maximum RF output power +13 dBm
Provisioning
QR / Serial number Serial number (read only)
NFC Serial number (read only)
NEON-Temperature-Transmitter_User-Manual_DS-TT-02-xx_4001_A3 6 of 34

2 GETTING STARTED
Certifications
ATEX certificate number DEKRA 20ATEX0004X
IECEx certificate number IECEx DEK 20.0004X
ATEX IECex marking Ex II 1G Ex ia IIC T4 Ga
Applicable ATEX/IECEx standards EN 60079-0
EN 60079-11
FM US certificate number FM22US0061X
FM CA certificate number FM22CA0043X
US Marking IS Class I, Division 1, Group ABCD T4
Class I, Zone 0 Ex ia IIC T4 Ga
CA Marking IS Class I, Division 1, Group ABCD T4
Ex II 1G AEx ia IIC T4 Ga
IMDA Dealer License DA108442
CE EN 300 220-1
EN 300 220-2
EN 61010-1:2010 + A1:2019 + A1:2019/AC:2019
EN 62311
EN 60529
EN 301 489-1
EN 301 489-3
UKCA Radio Regulation 2017
FCC FCC CFR 47, Part 15, Subpart C
FCC CFR 47, Part 15, Subpart B
ISED USA FCC Part 15.209, 15.247, 15.205 RSS-247, RSS-Gen
ICES CAN ICES-003(B) / NMB-003(B)
Manufacturer information
Name TWTG R&D BV
Address Schaardijk 386
2909 LA Capelle a/d IJssel
The Netherlands
Table 3: Product specifications. See also "NEON datasheet" in Related documents for a detailed overview of specifications.
7 of 34 NEON-Temperature-Transmitter_User-Manual_DS-TT-02-xx_4001_A3

2 GETTING STARTED
2.5 Product Type Identification
D S - T T - 0 2 - 0 0
Co ≤ 80 μF Lo ≤ 10 mH
Po = 44 mW
T T 0 2 2 0 0 2 A A 0 0 0 0 1
Figure 1: Example Drawing "Front Panel"
AA-BB-CC-DD
AA - Product Family DS
BB - Product Variant TT = Temperature Transmitter
CC - Main Revision E.g. 02
DD - Region E.g. 00 = Global
Table 4: Product Nomenclature
AABBCCDDEEFFFFF
AA - Product Variant TT = Temperature Transmitter
BB - Product Revision E.g. 02
CC - Production Year E.g. 22 = 2022
DD - Region E.g. 00 = Global
EE - Production Batch E.g. AA
FFFFF - Serial Number E.g. 00001
Table 5: Serial Number
NEON-Temperature-Transmitter_User-Manual_DS-TT-02-xx_4001_A3 8 of 34

2 GETTING STARTED
2.6 Component Names
3
2
5
1
4
Figure 2: Component Names
Number Description
1 Neon Transmitter
2 Data Matrix Code
3 NFC
4 Mounting Bracket
5 M12 Connector Dust Cap
Table 6: Component Names
2.7 Product Dimensions
114
48
84
64
-4,5
CAP
57
Figure 3: Neon Transmitter Dimensions (mm)
9 of 34 NEON-Temperature-Transmitter_User-Manual_DS-TT-02-xx_4001_A3

3 WARNINGS
3 Warnings
3.1 ATEX / IECEx
3.1.1 Specific Conditions of Use
WARNING - POTENTIAL ELECTROSTATIC CHARGING HAZARD
• The product shall be installed in such a way that the risk for electrostatic discharges is minimised;
• When the equipment is used in hazardous locations, avoid any actions which generate electrostatic discharge;
–Cleaning: The equipment shall only be cleaned using a wet cloth;
–Installation: Touch non-metallic parts with an insulating object;
–Environment: Do not use the product in environments with powerful charge generating processes.
3.1.2 Installation
• This equipment shall be installed according to NEN-EN-IEC 60079-14 and the installation instructions;
• This equipment is intended for fixed installations only;
• This equipment is intended for use in restricted access areas only.
• To comply with FCC/IC RF exposure limits for general population / uncontrolled exposure, the antenna(s) used for
this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not
be co-located or operating in conjunction with any other antenna or transmitter.
WARNING - DO NOT OPEN WHEN AN EXPLOSIVE ATHMOSPHERE IS PRESENT
• Under no circumstances shall the equipment enclosure be opened within a hazardous area
3.1.3 Operation
• The connector of this equipment shall not be connected when an explosive atmosphere is present;
• The thermocouple or RTD shall either be earthed or have an infallible isolation to earth with an dielectric strength
of 500 VAC/1minute or greater;
• This equipment shall only be used in environments where electromagnetic field strength is limited according to
NEN-EN-IEC 60079-14;
• This equipment is only intended for use in combination with NFC Forum Tag 2 Type technical specification
compatible readers;
• This equipment shall only be used within ambient temperatures between -40 °C and +70 °C.
3.1.4 Service
• This equipment shall only be opened by TWTG or by a competent instructed person;
–The battery is serviceable by said persons;
–Only replace the battery in a non-hazardous location;
–Only use Tadiran S1P1/SL-2780/323/TWT battery assembly;
• Changes or modifications not expressly approved by the party responsible for compliance could void the user’s
authority to operate the equipment.
• If damage to the enclosure is evident, a trained and competent person shall be immediately informed, who shall
remove the device from service as soon as possible;
• If the equipment is or has been in contact with chemical materials, clean it appropriately.
NEON-Temperature-Transmitter_User-Manual_DS-TT-02-xx_4001_A3 10 of 34

3 WARNINGS
3.1.5 Output parameters
The maximum output parameters are limited by the NEON Transmitter. When selecting the temperature sensor to be
used with the transmitter, the following values must be taken into account:
2
3
4
Temperature Transmitter
Uo = 3.98 V
Io = 1328 mA
Po = 472 mW
Co = 26 uF
Lo = 10 uH
1
2
3
4
NEON Transmitter
Simple apparatus
Uo < Ui, Io < Ii, Po < Pi,
Co > Ci, Lo > Li
Control drawing
Uo = 3.98 V
Io = 44 mA
Po = 44 mW
Co = 80 uF
Lo = 10 mH
Ci = 4 uF
Li = 0 uH
Figure 4: Intrinsic Safety Limiting Values
3.2 General
3.2.1 Transport and Storage
• The product must be kept in its original packaging until it reaches the installation site to prevent damage while in
transit;
• The storage location must be dry;
• The product must not be exposed to vibrations or impact during storage.
3.2.2 Warranty
• The warranty covers the period noted on the quotation;
• If the device doesn’t function as documented, the customer should contact TWTG and provide the following
information;
–Model specification;
–Serial number;
–Circumstances under which the problems developed;
–Any previously generated data;
• The party responsible for the costs of solving the problem shall be determined by TWTG on the basis of an
investigation conducted by TWTG.
3.2.3 Warranty will be void in case of
• Malfunction due to ignoring the design specifications;
• Malfunction due to modification of the product carried out by the user;
• Deferred maintenance of the product or the installation location.
11 of 34 NEON-Temperature-Transmitter_User-Manual_DS-TT-02-xx_4001_A3

4 AVERTISSEMENTS
4 Avertissements
4.1 ATEX / IECEx
4.1.1 Conditions spécifiques d’utilisation
ATTENTION – RISQUE POTENTIEL DE DECHARGES ELECTROSTATIQUES
• Le produit doit obligatoirement être installé de manière à minimiser le risque de décharges électrostatiques;
• Lorsque l’équipement est utilisé dans un environnement dangereux, évitez strictement toute action générant une
décharge électrostatique;
–Nettoyage: L’équipement doit être nettoyé uniquement à l’aide d’un chiffon humide;
–Installation: Toucher les parties non métalliques qu’avec un objet isolant;
–Environnement: N’utilisez pas le produit dans des environnements générant de fortes charges d’électricité.
4.1.2 Installation
• Cet équipement doit être installé conformément à la norme NEN-EN-IEC 60079-14 et aux instructions d’installation;
• Cet équipement est uniquement destiné aux installations fixes;
• Cet équipement est uniquement destiné à être utilisé dans des zones à accès restreint.
ATTENTION – NE PAS OUVRIR DANS UNE ATMOSPHÈRE EXPLOSIVE
• Le boîtier de l’équipement ne doit en aucun cas être ouvert dans une zone dangereuse.
4.1.3 Fonctionnement
• Le connecteur de cet équipement ne doit être utilisé qu’avec un équipement externe tel qu’indiqué dans le "product
matrix";
• Le connecteur de cet équipement ne doit jamais être connecté dans une atmosphère explosive;
• Le thermocouple ou le détecteur de température à résistance doit être mis à la terre ou avoir une isolation absolue
avec une rigidité diélectrique de 500 V/1 minute ou plus;
• Cet équipement ne doit être utilisé que dans un environnement où l’intensité du champ magnétique est limitée
conformément à la norme EN 60079-14;
• Cet équipement est uniquement destiné à être utilisé en combinaison avec des lecteurs compatibles dont les
spécifications techniques respectent la norme des tags NFC de Type 2;
• Cet équipement ne doit être utilisé qu’à des températures comprises entre 40° C et 70° C.
4.1.4 Entretien
• Cette pièce d’équipement ne doit être ouverte que par TWTG ou par une personne compétente et selon le guide
d’utilisation;
–La batterie peut être mise à neuf par ces personnes;
–Ne remplacez la batterie que dans un endroit sans danger;
–Utilisez uniquement l’ensemble de batterie Tadiran S1P1/SL-2780/323/TWT ;
• Si le boîtier est endommagé, informez immédiatement une personne compétente pour qu’elle vienne récupérer
l’équipement;
• Si l’équipement est (ou a été) en contact avec des substances chimiques, nettoyez-le de manière appropriée.
NEON-Temperature-Transmitter_User-Manual_DS-TT-02-xx_4001_A3 12 of 34

4 AVERTISSEMENTS
4.1.5 Output parameters
The maximum output parameters are limited by the NEON Transmitter. When selecting the temperature sensor to be
used with the transmitter, the following values must be taken into account:
2
3
4
Temperature Transmitter
Uo = 3.98 V
Io = 1328 mA
Po = 472 mW
Co = 26 uF
Lo = 10 uH
1
2
3
4
NEON Transmitter
Simple apparatus
Uo < Ui, Io < Ii, Po < Pi,
Co > Ci, Lo > Li
Control drawing
Uo = 3.98 V
Io = 44 mA
Po = 44 mW
Co = 80 uF
Lo = 10 mH
Ci = 4 uF
Li = 0 uH
Figure 5: Intrinsic Safety Limiting Values
4.2 Informations générales
4.2.1 Transport et stockage
• Le produit doit être conservé dans son emballage jusqu’à ce qu’il atteigne le site d’installation pour éviter tout
dommage pendant le transit;
• Le lieu de stockage doit être sec;
• L’appareil ne doit pas être exposé à des vibrations ou à des chocs pendant le transport et le stockage.
4.2.2 Garantie
• La garantie couvre la période indiquée sur le devis;
• Si l’appareil ne fonctionne pas comme prévu, le client doit contactez TWTG et fournir les éléments suivants;
–Spécifications du modèle;
–Numéro de série;
–Les circonstances dans lesquelles les problèmes sont survenus;
–Toutes les données précédemment générées;
• La partie responsable des coûts de résolution du problème sera déterminée par TWTG sur la base d’une enquête
privée menée par TWTG.
4.2.3 La garantie sera annulée dans les cas suivants:
• Non-respect des spécifications du modèle;
• Modification du produit effectuée par l’utilisateur;
• Entretient non conforme aux spécifications du produit;
• Utilisation dans un endroit non conforme aux spécifications.
13 of 34 NEON-Temperature-Transmitter_User-Manual_DS-TT-02-xx_4001_A3

5 PROVISIONING
5 Provisioning
5.1 User Interface
The product contains one Light Emitting Diode (LED) to communicate with the user. In order to interact with the device
a button is present on the right side of the NFC label.
LED Button
Figure 6: NEON Temperature Transmitter Interface
NEON-Temperature-Transmitter_User-Manual_DS-TT-02-xx_4001_A3 14 of 34

5 PROVISIONING
5.2 Operating the Device
5.2.1 Read device status
Press and Release Press and Hold Release
Green
Activated
Red
Deactivated
White
Connected
White Blinking
Connecting
1. Press and Release the button button:
•2.1 Green: Device is activated
•2.2 Red: Device is deactivated
15 of 34 NEON-Temperature-Transmitter_User-Manual_DS-TT-02-xx_4001_A3

5 PROVISIONING
5.2.2 Device Activation
Press and Release Press and Hold Release
Green
Activated
Red
Deactivated
White
Connected
White Blinking
Connecting
1. Press & hold the button and the device will
immediately show it’s status:
•2.1 Red: Deactivated, or
•2.2 Green: Already Activated
Note: Release the button if it’s already activated
otherwise the deactivation procedure will start.
3. Hold the button for 5 more seconds to start
activation:
•4. Blinking White: Connecting to the Network
5. Within a typical maximum of 3 minutes* the
device will show:
•5.1 White: Sending activation message, or
•5.2 Red: Network failure
6. Within a typical maximum of 3 minutes* the
device will show:
•6.1 Green: Activation succeeded, or
•6.2 Red: Network failure
Notes:
• *All timeout and retry values are valid for the default configuration, the maximum timeout might be longer when
process is performed repeatedly due to RF duty cycle limitations.
NEON-Temperature-Transmitter_User-Manual_DS-TT-02-xx_4001_A3 16 of 34

5 PROVISIONING
5.2.3 Device Deactivation
Press and Release Press and Hold Release
Green
Activated
Red
Deactivated
White
Connected
White Blinking
Connecting
1. Press and hold the button, the device will
show:
•2.1 Green: Activated
•2.2 Red: Already Deactivated, or
Note: Release the button if it is already deactivated
otherwise the activation procedure will start.
Hold the button for 5 more seconds if the device
is activated:
•3. Red: Deactivation Succeeded
NOTE: The deactivation procedure will always
succeed. An attempt for sending a status message
will be performed. This will not be shown as blinking
white LED.
17 of 34 NEON-Temperature-Transmitter_User-Manual_DS-TT-02-xx_4001_A3

5 PROVISIONING
5.3 Product Identification
5.3.1 NFC
The NFC label is located in the identification sticker and programmed with the serial number of the device. The serial
number read from the NFC can be used as unique identifyer for provisioning and registration.
5.3.2 Data Matrix Code
The Data Matrix Code label also represents the serial number of the device. The serial number read from the QR code
can be used as unique identifyer for provisioning and registration. See Serial Number for a detailed label description.
D S - T T - 0 2 - 0 0
Co ≤ 80 μF Lo ≤ 10 mH
Po = 44 mW
T T 0 2 2 0 0 2 A A 0 0 0 0 1
Figure 7: NFC and Data Matrix Code code Location
NEON-Temperature-Transmitter_User-Manual_DS-TT-02-xx_4001_A3 18 of 34

6 INSTALLATION
6 Installation
6.1 Precautions
WARNING
• Avoid placing wiring close to noise sources such as large motors or power supplies;
• To comply with FCC/IC RF exposure limits for general population / uncontrolled exposure, the antenna(s) used for
this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not
be co-located or operating in conjunction with any other antenna or transmitter;
• Only connect the M12 connector to the Temperature Transmitter when there is no explosive atmosphere present;
• The equipment must be installed in accordance with EN 60079-14.
6.2 Mounting Bracket Dimensions
8 22
25,5
4,4
74
Figure 8: Product Dimensions
19 of 34 NEON-Temperature-Transmitter_User-Manual_DS-TT-02-xx_4001_A3

6 INSTALLATION
6.3 Installation Methods
6.3.1 Installation using mounting holes
Place the bracket against the (flat) desired surface and use the screw holes or slots to fix in place.
Note: Slots and screw holes are designed for M4 fasteners.
Figure 9: Product Mounting Holes
6.3.2 Installation using threaded holes
Note: Threaded hole accepts M5 bolts.
Figure 10: Product Threaded Mounting Holes
NEON-Temperature-Transmitter_User-Manual_DS-TT-02-xx_4001_A3 20 of 34
