Neptune X-PRO Assembly instructions

NEPTUNE X-PRO TOP DISCHARGE
FULL INVERTER HEAT PUMP
INSTALLATION GUIDE
AND USER MANUAL
THANK YOU FOR PURCHASING A NEPTUNE FULL INVERTER HEAT PUMP.
Please read the manual thoroughly before installing or using the product.
Only qualified technicians must install the product. Keep this manual for future reference.

TABLE OF CONTENTS Page
SECTION 1: IMPORTANT WARNINGS AND SAFETY INFORMATION .................................................................. 4-5
SECTION 2: TRANSPORT, STORAGE AND HANDLING ........................................................................................... 5
SECTION 3: PACKAGING CONTENTS ....................................................................................................................... 5
SECTION 4: PRODUCT SPECIFICATIONS .............................................................................................................. 6-8
4.1: PRODUCT DIMENSIONS ................................................................................................................................. 6
4.2: TECHNICAL DATA .......................................................................................................................................... 7-8
4.3: OPERATING CONDITIONS .............................................................................................................................. 8
SECTION 5: INSTALLATION ................................................................................................................................... 8-16
5.1: IMPORTANT INSTALLATION INFORMATION .................................................................................................. 8
5.2: POSITIONING AND LOCATION OF HEAT PUMP ............................................................................................ 9
5.3: INSTALLATION OF THE HEAT PUMP ......................................................................................................... 9-11
5.4: WIRING OF THE HEAT PUMP ........................................................................................................................ 11
5.5: WIRING DIAGRAM: SINGLE PHASE 230V 50Hz .......................................................................................... 12
5.6: WIRING DIAGRAM: 3 PHASE 400V 50Hz ..................................................................................................... 12
5.7: WIRING DIAGRAM FOR EXTREME WINTER CONDITIONS: SINGLE PHASE 230V ≤500W ..................... 13
5.8: WIRING DIAGRAM FOR EXTREME WINTER CONDITIONS: SINGLE PHASE 230V >500W ..................... 14
5.9: WIRING DIAGRAM FOR EXTREME WINTER CONDITIONS: 3 PHASE 230V 400W .................................. 15
5.10: PARALLEL CONNECTION WITH FILTRATION CLOCK .............................................................................. 16
SECTION 6: INITIAL START-UP ........................................................................................................................... 16-17
6.1: PRE-STARTUP INSPECTION ......................................................................................................................... 16
6.2: INITIAL STARTUP ...................................................................................................................................... 16-17
SECTION 7: OPERATING INSTRUCTIONS ......................................................................................................... 17-21
7.1: IMPORTANT OPERATING INFORMATION .................................................................................................... 17
7.2: HEAT PUMP TOUCHPAD OVERVIEW ........................................................................................................... 18
7.3: HEAT PUMP LCD SCREEN OVERVIEW ........................................................................................................ 19
7.4: STANDBY MODE ............................................................................................................................................ 19
7.5: TURNING ON THE HEAT PUMP .................................................................................................................... 19
7.6: SETTING THE TEMPERATURE ..................................................................................................................... 20
7.7: SETTING THE HEATING/COOLING MODE ................................................................................................... 20
7.8: SETTING THE SPEED (TURBO/SMART/SILENCE MODE) .......................................................................... 20
7.9: VIEWING REAL-TIME POWER CONSUMPTION OR COMPRESSOR PERCENTAGE ............................... 21
7.10: CHANGING TEMPERATURE BETWEEN oC AND oF ................................................................................... 21
7.11: DEFROSTING ................................................................................................................................................ 21
SECTION 8: WIFI SETUP ...................................................................................................................................... 21-26
8.1: APP DOWNLOAD AND ACCOUNT REGISTRATION ................................................................................ 21-22
8.2: PAIRING YOUR DEVICE WITH THE HEAT PUMP VIA AUTO-DISCOVERY/BLUETOOTH ......................... 22
8.3: PAIRING YOUR DEVICE WITH THE HEAT PUMP VIA MANUALLY ADDING ............................................... 23
8.4: PAIRING YOUR DEVICE WITH THE HEAT PUMP VIA AP MODE ................................................................ 24
8.5: RE-PAIRING YOUR DEVICE .......................................................................................................................... 25
8.6: APP FEATURES .............................................................................................................................................. 25
8.7: SHARE DEVICES WITH FAMILY MEMBERS ................................................................................................. 26
8.8: CREATE A FAMILY .......................................................................................................................................... 26
SECTION 9: MAINTENANCE ..................................................................................................................................... 27
9.1: REGULAR MAINTENANCE ............................................................................................................................ 27
9.2: ANNUAL MAINTENANCE – QUALIFIED TECHNICIAN ONLY ....................................................................... 27
SECTION 10: WINTERISING ................................................................................................................................. 27-28
SECTION 11: TROUBLESHOOTING .................................................................................................................... 28-29
SECTION 12: SCHEMATICS – NHX10TD, NHX13TD, NHX17TD, NHX21TD, NHX26TD, NHX32TD ................ 30-31
SECTION 13: SCHEMATICS – NHX32TD3 ........................................................................................................... 32-33
SECTION 14: SCHEMATICS – NHX40TD3 ........................................................................................................... 34-35
SECTION 15: WARRANTY & PRODUCT REGISTRATION ...................................................................................... 36

Page 4 of 38 Visit www.neptuneheating.com.au for more information
SECTION 1: IMPORTANT WARNINGS AND SAFETY INFORMATION
This manual contains important information about the installation, operation, and safe use of this
product. This information should be given to the owner and/or operator of the heat pump. When
installing and using the heat pump, basic safety precautions should always be followed. Failure to
follow safety warnings and instructions in this manual can result in serious injury and/or damage to your
equipment. Read and follow all warning notices and instructions which are included in this manual.
This Full Inverter Heat Pump contains R32 refrigerant gas which is a
flammable substance under certain conditions.
GENERAL WARNINGS
•Read the instructions before installing and using the heat pump.
•Failure to follow these instructions and comply with all applicable codes may cause serious bodily injury
and/or property damage and will void the warranty.
•Installers/operators must follow manufacturer’s instructions and keep in compliance with national or local
standards for installation. Under no circumstances will the manufacturer be held responsible for any
outcome incurred by failure to comply with applicable standards or local regulations.
•Turn off the power during thunderstorms and severe weather.
•Do not use or store combustible gas or liquid such as thinners, paint or fuel near the heat pump.
•Always keep the heat pump in the upright position especially when storing or moving the heat pump.
•The heat pump is designed for heating swimming pools; do not use it for any other purpose.
•The surroundings of the heat pump must be kept clear to avoid restricting ventilation.
•The heat pump must be kept away from any source of fire.
•Do not put anything into the inlet or outlet, and do not remove the fan cover.
•This product contains electrical equipment. Dispose of the product in accordance with local regulations.
INSTALLATION, SERVICE AND MAINTENANCE WARNINGS
•Gas leakage tests must be done before and after installation.
•Installation, removal and service of the heat pump must be handled by a professional pool builder/service
agent. Repairs should be carried out in a well ventilated area.
•The heat pump must be positioned on a concrete base.
•The frame must be secured using M10 bolts. Frame/brackets must be of a suitable strength and anti-rust
treated.
•Do not lift the heat pump using the water unions.
•The heat pump must be installed in a well ventilated, outside area.
•Ensure power is disconnected during installation or service.
•Stop installation if there is any gas leakage. The unit must be returned to the authorised dealer.
•Vacuum completely before welding. Field welding is not allowed.
•Always comply with the national and local electrical codes and standards.
•Ensure electrical cable size is adequate for heater requirements at the installation location.
•Always use a qualified electrician to perform any electrical work. A licenced electrician must read these
instructions before installing.
•Ground the heat pump to protect yourself against short circuits inside the unit.
•Check that there is adequate voltage and current available at the heater connection to run the unit.
Voltage ranges outside of the required parameters will damage the heat pump and void the warranty.
•Ensure the power cable and circuit breaker are of suitable size for the heat pump being installed.
•To ensure heating efficiency, the water pipe length should be 10m or less between the pool and the heat
pump.
•The heat pump must be earthed.
•Hard/rigid plumbing must be used for the inlet and outlet water unions.
•The heat pump must be maintained/serviced by a qualified professional.
•The main power switch should be out of the reach of children.
•Use only genuine replacement parts supplied by the manufacturer for service and repair.
•Do not try to repair the heat pump yourself or open the casing. In case of malfunction, switch off the main
power immediately and contact your authorised dealer.

Visit www.neptuneheating.com.au for more information Page 5 of 38
DISCLAIMER
Information in this manual is intended to provide general information on a particular subject(s) in good faith and is not
an exhaustive treatment of such subject(s). Its use is beyond the control of the author, contributor, publishers, and
distributors and should not be relied upon without consulting your local Professional for comprehensive advice. This
manual includes subject(s) that should only be performed by or under the direction and advice of your local
Professional and under no circumstances should the manual be used as a substitute for such professionals. No
representations or warranties are made that the content, advice, and recommendations in this manual are current, free
from errors or omissions, or appropriate for the user’s circumstances or abilities. No liability is accepted for any loss
suffered as a result of any user’s reliance on such content. All information in this document is subject to change at any
time without notice.
SECTION 2: TRANSPORT, STORAGE AND HANDLING
•Sealing is not allowed during transportation.
•Transporting goods at a constant speed is needed to avoid sudden acceleration or sudden braking, so as to
reduce the collision of goods.
•The unit must be kept away from any source of fire.
•The heat pump must be stored in a bright, wide and open space with adequate ventilation.
•Do not lift the heat pump using the water unions.
•Do not use or store combustible gas or liquid such as thinners, paint and fuel near the heat pump.
•Always keep the heat pump in the upright position especially when storing or moving the heat pump.
SECTION 3: PACKAGING CONTENTS
The following items are included in the packaging of the heat pump. Please contact your authorised dealer if any items
are damaged or missing.
(1) Heat Pump x 1
(2) Unions x 2
(3) Rubber Foot x 4
(4) Bolt Assembly x 4
(5) User Manual x 1
1
2
3
4
5

Page 6 of 38 Visit www.neptuneheating.com.au for more information
SECTION 4: PRODUCT SPECIFICATIONS
4.1: PRODUCT DIMENSIONS
UNITS (mm)
A
B
C
D
E
F
G
H
MODEL
NHX10TD
685
441
753
710
688
300
75.5
668
NHX13TD
685
441
753
710
688
280
75.5
668
NHX17TD
685
463
775
710
688
350
75.5
668
NHX21TD
685
463
775
710
688
390
75.5
668
NHX26TD
685
463
775
710
688
460
75.5
743
NHX32TD
703
555
955
729
707
640
75.5
917
NHX32TD3
703
555
955
729
707
640
75.5
917
NHX40TD3
819
555
955
845
823
650
75.5
917
NOTE: This data is subject to change without notice.

Visit www.neptuneheating.com.au for more information Page 7 of 38
4.2: TECHNICAL DATA
Model
NHX10TD
NHX13TD
NHX17TD
NHX21TD
NHX26TD
NHX32TD
NHX32TD3
NHX40TD3
Advised pool volume (L)
20,000 -
40,000
25,000 –
50,000
30,000 –
60,000
40,000 –
75,000
50,000 –
100,000
65,000 –
120,000
65,000 –
120,000
90,000 –
160,000
Working air temp (℃)
-15~43
Performance Condition: Air 26°C, Water 26°C, Humidity 80%
Heating capacity (kW)
in Smart mode
8.5
11.0
14.0
17.5
22.0
27.0
27.0
35.0
Heating capacity (kW)
in Turbo mode
10.2
13.2
17.2
21.0
26.0
31.5
31.5
40.0
C.O.P in Smart mode
7.6
7.7
7.8
7.3
7.8
7.4
7.4
7.3
C.O.P
14.9~6.6
15.0~6.8
15.6~6.5
15.5~6.3
14.9~6.8
16.0~6.3
16.0~6.3
15.7~6.4
C.O.P at 50% capacity
11.2
11.5
11.7
11.6
11.3
11.2
11.2
11.1
Performance Condition: Air 15°C, Water 26°C, Humidity 70%
Heating capacity (kW)
in Smart mode
6.3
7.3
9.8
11.6
14.5
18.0
18.0
24.5
Heating capacity (kW)
in Turbo mode
7.5
8.8
11.6
14.3
17.5
21.5
21.5
28.5
C.O.P in Smart mode
5.0
5.0
4.9
4.9
5.0
5.3
5.3
5.1
C.O.P
7.0~4.3
7.3~4.5
7.8~4.5
7.4~4.4
7.3~4.8
7.8~4.9
7.8~4.9
7.7~4.8
C.O.P at 50% capacity
6.4
6.5
6.7
6.8
6.3
6.8
6.8
6.7
Performance Condition: Air 35°C, Water 28°C, Humidity 80%
Cooling capacity (kW)
4.5
5.8
7.1
8.2
12.0
14.0
14.0
16.5
Sound pressure at 1m dB(A)
38.8~46.5
38.8~47.9
42.2~48.6
43.1~52.1
41.0~52.9
43.6~53.8
43.6~53.8
42.8~54.0
Sound pressure of 50%
capacity at 1m dB(A)
39.0
41.9
44.3
45.2
45.3
46.7
46.7
46.9
Sound pressure at 10m dB(A)
18.8~26.5
18.8~27.9
22.2~28.6
23.1~32.1
21.0~32.9
23.6~33.8
23.6~33.8
22.8~34.0
Power supply
230V/1 Ph/50Hz
400V/3 Ph/50Hz
Rated input power(kW)
at air temperature 15°C
0.17~1.66
0.21~1.95
0.26~2.51
0.33~3.08
0.42~3.67
0.46~4.4
0.46~4.4
0.60~5.94
Rated input current(A)
at air temperature 15°C
0.74~7.21
0.91~8.48
1.14~10.9
1.43~13.4
1.82~15.9
2.01~19.1
0.66~6.35
0.87~8.57
Water pipe diameter (mm)
50
Pool pump water flow (m³/h)
2~4
3~4
4~6
6.5~8.5
8~10
10~12
10~12
12~18
Pool pump max. head (m)
10
Net Dimension LxWxH (mm)
710x753
x668
710x753
x668
710x775
x668
710x775
x668
710x775
x743
729x955
x917
729x955
x917
845x955
x917
Net Weight (kg)
61
66
71
78
102
110
117
141
The values indicated are valid under ideal conditions: pool covered with an isothermal cover, filtration system running
at least 15 hours a day. Related parameters subject to adjustment periodically for technical improvement without
further notice. For details please refer to nameplate.

Page 8 of 38 Visit www.neptuneheating.com.au for more information
MODEL
NHX10TD
NHX13TD
NHX17TD
NHX21TD
NHX26TD
NHX32TD
NHX32TD3
NHX40TD3
Breaker
Rated Current (A)
12.0
15.0
19.0
22.5
25.5
28.5
11.3
15.0
Rated Residual
Action Current (mA)
30
30
30
30
30
30
30
30
Power Supply
230V 50Hz
230V 50Hz
230V 50Hz
230V 50Hz
230V 50Hz
230V 50Hz
400V 50Hz
400V 50Hz
Fuse (A)
12.0
15.0
19.0
22.5
25.5
28.5
11.3
15.0
Power Cord (mm2)
3x2.5
3x2.5
3x4
3x4
3x6
3x6
5x2.5
5x2.5
Signal cable (mm2)
3x0.5
3x0.5
3x0.5
3x0.5
3x0.5
3x0.5
3x0.5
3x0.5
4.3: OPERATING CONDITIONS
ITEMS
RANGE
Operating Range
Ambient Air Temperature*
-15oC – 43oC
Temperature Setting
Heating
18oC – 40oC
Cooling
12oC – 30oC
*Ideal ambient air temperature is 15oC – 25oC.
SECTION 5: INSTALLATION
5.1: IMPORTANT INSTALLATION INFORMATION
•The heat pump must be installed in a well ventilated, outside area with sufficient space for installation and
maintenance.
•Gas leakage tests must be done before and after installation.
•The heat pump must be positioned on a solid concrete base.
•The frame must be secured using M10 bolts. Frame/brackets must be of a suitable strength and anti-rust
treated.
•Do not lift the heat pump using the water unions.
•Ensure power is disconnected during installation or service.
•Installation must be stopped if there is any gas leakage, and the unit must be returned to the authorised
dealer.
•Vacuum completely before welding. Field welding is not allowed.
•Always comply with the national and local electrical codes and standards.
•Ensure electrical cable size is adequate for heater requirements at the installation location.
•A licenced electrician must read these instructions before installing.
•Ground the heat pump to protect yourself against short circuits inside the unit.
•Check that there is adequate voltage and current available at the heater connection to run the unit.
Voltage ranges outside of the required parameters will damage the heat pump and void the warranty.
•Ensure the power cable and circuit breaker are of suitable size for the heat pump being installed.
•To ensure heating efficiency, the water pipe length should be 10m or less between the pool and the heat
pump.
•The heat pump must be earthed.
•The inlet and outlet water unions cannot bear the weight of soft/flexible plumbing. Hard/rigid plumbing
must be used.
•The main power switch should be out of the reach of children.

Visit www.neptuneheating.com.au for more information Page 9 of 38
5.2: POSITIONING AND LOCATION OF HEAT PUMP
The heat pump must be installed in accordance with the following diagrams. Distances in the diagram are the
minimum distance allowed. The heat pump must be positioned on solid level ground (concrete slab) outdoors in a
place with good ventilation. Do not install the heat pump in an enclosed area. Ensure there is sufficient access space
for installation and maintenance.
5.3: INSTALLATION OF THE HEAT PUMP
1. Install the 4 rubber feet onto the heat pump’s legs, using the supplied bolts.

Page 10 of 38 Visit www.neptuneheating.com.au for more information
2. Ensure the heat pump is equipped with a circuit breaker and electrical isolator switch.
3. The heat pump requires a pool pump (supplied by the user). Refer to the Specifications Table in Section 4.2 for
recommended pump water flow and maximum head information for the model being installed.
4. Install the unions as follows:
STEP 1 STEP 2 STEP 3
5. Connect the inlet downstream, after the pool pump and filter.
6. Connect the outlet upstream before chlorinator, acid injection or other chemical dosing systems.

Visit www.neptuneheating.com.au for more information Page 11 of 38
7. Create a flow bypass between the inlet and outlet pipework.
5.4: WIRING OF THE HEAT PUMP
1. Wiring must be connected by a qualified professional electrician, according to the details set out in this manual.
2. The heat pump must be hard wired.
3. Ensure power is disconnected during installation or service. Always comply with the national and local electrical
codes and standards. Ensure electrical cable size is adequate for heater requirements at the installation location.
4. The layout of power and signal cables should be neat and orderly. Considering environmental conditions (ambient
temperature, direct sunlight, rain, grid voltage, cable length etc), the cross-sectional area of the cable can be
appropriately increased.
5. Set breaker or fuse according to the below table.
6. Check that there is adequate voltage and current available at the heater connection to run the unit. Refer to the
below table. Voltage ranges outside these parameters will damage the heat pump.
MODEL
NHX10TD
NHX13TD
NHX17TD
NHX21TD
NHX26TD
NHX32TD
NHX32TD3
NHX40TD3
Breaker
Rated Current (A)
12.0
15.0
19.0
22.5
24.5
28.5
11.3
15.0
Rated Residual
Action Current (mA)
30
30
30
30
30
30
30
30
Power Supply
230V 50Hz
230V 50Hz
230V 50Hz
230V 50Hz
230V 50Hz
230V 50Hz
400V 50Hz
400V 50Hz
Fuse (A)
12.0
15.0
19.0
22.5
24.5
28.5
11.3
15.0
Power Cord (mm2)
3x2.5
3x2.5
3x4
3x4
3x6
3x6
5x2.5
5x2.5
Signal cable (mm2)
3x0.5
3x0.5
3x0.5
3x0.5
3x0.5
3x0.5
3x0.5
3x0.5
NOTE: The above data is adapted to a power cord length of ≤ 10m. If power cord is ＞10m, wire diameter must be
increased. The signal cable can be extended to 50m maximum.
7. Connect the power wiring according to the following relevant wiring diagrams.

Page 12 of 38 Visit www.neptuneheating.com.au for more information
5.5: WIRING DIAGRAM: SINGLE PHASE 230V 50Hz
5.6: WIRING DIAGRAM: 3 PHASE 400V 50Hz
Distribution Box (Customer prepare)
Swimming Pool Heat Pump Wiring Board
Power Cord
Power Supply
Earthing
Fuse
Breaker
Distribution Box (Customer prepare)
Swimming Pool Heat Pump Wiring Board
Power Cord
Power Supply
Fuse
Earthing
Breaker

Visit www.neptuneheating.com.au for more information Page 13 of 38
5.7: WIRING DIAGRAM FOR EXTREME WINTER CONDITIONS: SINGLE PHASE 230V ≤500W
Use this wiring diagram when installing a SINGLE PHASE 230V ≤500W heat pump in a location with extreme winter
conditions (water freezing in pipes).

Page 14 of 38 Visit www.neptuneheating.com.au for more information
5.8: WIRING DIAGRAM FOR EXTREME WINTER CONDITIONS: SINGLE PHASE 230V >500W
Use this wiring diagram when installing a SINGLE PHASE 230V >500W heat pump in a location with extreme winter
conditions (water freezing in pipes).

Visit www.neptuneheating.com.au for more information Page 15 of 38
5.9: WIRING DIAGRAM FOR EXTREME WINTER CONDITIONS: 3 PHASE 230V 400W
Use this wiring diagram when installing a 3 PHASE 230V 400W heat pump in a location with extreme winter conditions
(water freezing in pipes).

Page 16 of 38 Visit www.neptuneheating.com.au for more information
5.10: PARALLEL CONNECTION WITH FILTRATION CLOCK
A: Water pump timer
B: Water pump wiring of Heat Pump
Note: The installer should connect A parallel with B (as above picture). To start the water pump, condition A or B should
be connected. To stop the water pump, both A and B should be disconnected.
SECTION 6: INITIAL START-UP
Check all wirings carefully before turning on the heat pump.
6.1: PRE-STARTUP INSPECTION
1. Check installation of the entire heat pump and the pipe connections according to the installation instructions in
this manual.
2. Check the electrical wiring according to the electrical wiring diagram and earthing connection in this manual.
3. Ensure that the main power is connected properly.
4. Ensure there are no obstacle/blockages in front of the air inlet and outlet of the heat pump.
6.2: INITIAL STARTUP
1. Ensure the inlet, outlet and bypass water flow valves are fully open, then turn the pool pump on.
2. Check there are no water leaks and verify adequate flow to and from the pool.
3. As the heat pump is hardwired, turn on the isolation switch.
4. Press the Power symbol on the heat pump touchpad.
5. In order to protect the heat pump, the heat pump is equipped with a Delayed Start function. When starting the
heat pump, the pool water pump will start to run for 3 minutes, then after another 30 seconds, the heat pump
fan motor and compressor will start to run.
6. Check for any abnormal noises from the heat pump.
7. Check the air that is coming out of the heat pump fan, this air temperature should be 5oC-10oC cooler than the
ambient air temperature.
8. Test the Flow Switch is working correctly. With the heat pump still running, turn the pool water pump off. If the
Flow Switch is working, the heat pump should turn off automatically and the heat pump touchpad will display
an error code E3 (insufficient water flow protection).
9. It is time to adjust the bypass water flow valve and calibrate the flow rate though the heat pump. Ensure all
valves (inlet, outlet, bypass) are open. Then fully close the bypass valve and turn the heat pump to the
maximum temperature.
10. Wait 3-4 minutes for the heat pump to run.

Visit www.neptuneheating.com.au for more information Page 17 of 38
11. Check the difference in temperature between the inlet temperature and outlet temperature displayed on the
heat pump’s LCD screen.
12. Slowly open the water flow bypass valve to increase the temperature differential between the inlet and outlet.
Closing the bypass valve will decrease the temperature differential.
13. Adjust the bypass valve until optimum differential of 2oC-3oC is achieved. Wait two minutes between each
adjustment.
14. The water flow bypass valve is set up correctly when the temperature difference between the inlet and outlet is
2oC-3oC. Once this has been achieved, lock the position of the bypass valve if possible.
15. The initial startup is complete. Choose your desired speed and temperature settings, and allow the heat pump
to run 24 hours per day until the desired pool temperature is reached. This can take several days.
SECTION 7: OPERATING INSTRUCTIONS
7.1: IMPORTANT OPERATING INFORMATION
•For the heat pump’s ideal operating performance, the ideal ambient air temperature is 15oC-25oC.
•In case of power failure during the operation of the heat pump, the heat pump will automatically restart
when the power is restored.
•Turn off the power during thunderstorms and severe weather.
•Do not use or store combustible gas or liquid such as thinners, paint or fuel near the heat pump.
•Always keep the heat pump in the upright position.
•The heat pump is designed for heating swimming pools; do not use it for any other purpose.
•The surroundings of the heat pump must be kept clear to avoid restricting ventilation.
•The heat pump must be kept away from any source of fire.
•Do not put anything into the inlet or outlet, and do not remove the fan cover.
•If any abnormal circumstances occur e.g. abnormal noises, smells, smoke and leakage of electricity,
switch off the main power immediately and contact your authorised dealer.
•Do not try to repair the heat pump yourself or open the casing.
•To extend the life of your heat pump, ensure the pool water pump is on before starting the heat pump, and
turn the pool water pump off after the heat pump is turned off.

Page 18 of 38 Visit www.neptuneheating.com.au for more information
7.2: HEAT PUMP TOUCHPAD OVERVIEW
Symbol
Designation
Function
On/Off
1. Power On/Off
2. Wi-Fi setting
(This symbol will be lit up
constantly when power is on)
Unlock / Mode
1. Press for 3 seconds to unlock/lock screen
2. After screen is unlocked, press it to select mode
Auto (12oC -40oC)
Heating (18oC-40oC)
Cooling (12oC-30oC)
Speed
Select Turbo/Smart/Silence mode
Up / Down
Adjust/set temperature

Visit www.neptuneheating.com.au for more information Page 19 of 38
7.3: HEAT PUMP LCD SCREEN OVERVIEW
Auto
Heating
Cooling
Real-time power consumption display
Heating capacity percentage
WIFI connection
Water inlet
Water outlet
7.4: STANDBY MODE
•The LCD screen has a standby mode (screen lock). When in standby mode, the LCD screen will be dark and
will only display the kW information.
•The LCD screen will go into standby mode if there is no touchpad operation for 30 seconds.
•Press for 3 seconds to either lock or unlock the screen. All other buttons on the touchpad will not be
operational when the screen is locked.
7.5: TURNING ON THE HEAT PUMP
1. Ensure the inlet and outlet valves are open.
2. Ensure the bypass valve is set up correctly (refer to Section 6.2).
3. Ensure the main power supply to the heat pump is on.
4. Power on the heat pump by pressing for 3 seconds to light up the LCD screen, then press to
power on the heat pump.
Turbo/Smart/Silence
modes
Water outlet
temperature
Water inlet
temperature
Real-time power consumption
/ Heating capacity percentage

Page 20 of 38 Visit www.neptuneheating.com.au for more information
7.6: SETTING THE TEMPERATURE
1. Ensure the LCD screen is unlocked. If the screen is dark, Press for 3 seconds to unlock the screen.
2. Press either or button once to display the current set temperature.
3. Press or button to adjust the temperature.
7.7: SETTING THE HEATING/COOLING MODE
1. Ensure the LCD screen is unlocked. If the screen is dark, Press for 3 seconds to unlock the screen.
2. Press to select a mode:
Auto (12oC -40oC)
Heating (18oC-40oC)
Cooling (12oC-30oC)
7.8: SETTING THE SPEED (TURBO/SMART/SILENCE MODE)
MODE
ADVANTAGES
Turbomode
•Heatingcapacity:120%
•Fast heating
Smartmode
•Heatingcapacity: 100%~20%
•Intelligent optimisation according to ambient temperature and water temperature
•Energy efficient setting
Silence mode
•Heatingcapacity:60%~20%
•Use at night
1. Ensure the LCD screen is unlocked. If the screen is dark, Press for 3 seconds to unlock the screen.
2. Press the button to cycle through each mode:
Smart Mode: Smart mode is the default setting and will be activated when the heat pump is turned on.
The symbol will display on the LCD screen when the heat pump is set to Smart mode.
Turbo Mode: Press button to enter Turbo mode.
The symbol will display on the LCD screen when the heat pump is set to Turbo mode.
Silence Mode: Press button again to enter Silence mode.
The symbol will display on the LCD screen when the heat pump is set to Silence mode.
NOTE: Turbo mode can only be used when heating. Turbo mode will need to be selected each time you want
to use it, as the default mode is Smart mode. During Turbo mode, when the machine reaches the set
temperature, it will automatically return to Smart mode.
