This chapter is designed to take you through the installation process for the High Performance (HP) Turbine.

The HP Turbine offers the widest operating range of any turbine meter on the market. To achieve optimum

performance in actual service, it is essential that you follow these installation instructions.

INSTALLATION INSTRUCTIONS

All HP Turbine meters operate more accurately and reliably if installed properly. Turbine meter performance

is directly related to the flow conditions of the water stream entering the meter.If the flow conditions

are distorted because of upstream fittings or piping changes, a turbine meter’s performance can be

adversely affected.

Neptune recommends that you install all HP Turbine meters with a Neptune strainer at the meter inlet. The

strainer,in addition to protecting the meter from debris in the line, also corrects the velocity profile of the

flow to the meter and reduces the effects of upstream piping variations or other obstructions in the line.

When installing Neptune meters with a strainer, a minimum of four (4) pipe diameters of straight run pipe

(can include components that are fully open in their normal operating position) is required upstream and

downstream of the meter/strainer assembly.

If you do not use a strainer, a length of straight pipe equal to 8 to 10 diameters of the nominal pipe size

should be allowed immediately upstream of the meter inlet and 2 to 4 diameters downstream. When

installing an HP Turbine meter, please use the following instructions.

RECOMMENDED INSTALLATION

Figure 1.1 shows the recommended installation of an HP Turbine meter. This installation incorporates a

Neptune strainer attached to the inlet of the meter and includes a downstream tee to facilitate field

testing. This illustration also shows an optional bypass that provides uninterrupted service capability

during periods of meter service.

As indicated previously, the Neptune strainer located upstream provides protection against meter damage

from debris in the lines and virtually eliminates the effects of variations in upstream piping. Neptune

specifically recommends use of a Neptune strainer of the same line size as the meter.

1-2 HP TURBINE INSTALLATION AND MAINTENANCE GUIDE

CHAPTER INSTALLING THE HP TURBINE

TOP VIEW

Bypass

Gate Valve

Strainer

SIDE VIEW

Testing Tee

Turbine Meter

This strainer design provides optimum velocity profile correction at minimum additional head loss.

The installation of the test tee can be at any convenient location where the test outlet is two pipe diameters or more

downstream of the water meter outlet. We recommend this to provide a means to field test the meter without removing it

from the line.

When installing HP Turbine meters, always follow normal good piping practice. Specifically, all gaskets should be centrally

located on the flanges with no overlap or interference with the pipe diameter. This is particularly important at the inlet

connection to the meter where a gasket protruding into the flow stream will cause unpredictable velocity conditions.

Turbine meters must operate in a completely filled line at all times. The downstream piping must always provide sufficient

back pressure to maintain a full line at the meter.

Figure 1.1 Top and Side View of the HP Turbine

1

HP TURBINE INSTALLATION AND MAINTENANCE GUIDE 1-3

CHAPTER INSTALLING THE HP TURBINE

Caution should be exercised to avoid air in the line, sudden flow surges, or excessive flow rates, as these

conditions may cause damage to the turbine measuring element.

BEFORE OPERATION

Before putting the HP Turbine meter in service follow these steps:

1With outlet-side gate valve closed, SLOWLY open inlet-side valve to pressurize meter.

2SLOWLY open outlet-side gate valve until downstream line is pressurized.

After installation, it is important that you put the the upstream (inlet) valve in the “full open” condition

during service. A partially throttled upstream valve without a strainer installed will cause flow profile

distortion that will adversely affect meter accuracy. All throttling should be done ONLY on the downstream

(outlet) side of the meter.

1

1-4 HP TURBINE INSTALLATION AND MAINTENANCE GUIDE

NOTES

........................................................................................................................................................................................................

HP TURBINE INSTALLATION AND MAINTENANCE GUIDE 2-1

CHAPTER MAINTENANCE

2

CHAPTER MAINTENANCE

2

When maintenance is necessary, the complete Unitized Measuring Element (UME) may be quickly and easily

interchanged with a factory-calibrated unit (see Figure 2.1).

This unit includes register,cover, and turbine measuring element.

Follow these steps:

1Close valves.

2Remove cover bolts.

3Remove UME from maincase.

4Remove old maincase gasket and replace a new gasket.

5Install factory-calibrated unit into maincase.

6Replace cover bolts.

7Tighten cover bolts.

8Open valves.

All UMEs have been factory calibrated and should not require field calibration.

Figure 2.1 Factory-Calibrated Unit

2-2 HP TURBINE INSTALLATION AND MAINTENANCE GUIDE

CHAPTER MAINTENANCE

2

Refer to meter installation instructions.

The complete UME should be returned for service to Neptune. If the customer does not have a spare unit, a factory-calibrated

exchange unit may be purchased from Neptune. Neptune encourages all customers to purchase either a spare UME complete

or a UME exchange contract to enable them to avoid service interruptions.

ADJUSTING THE HP TURBINE CALIBRATION VANE

Neptune equips all HP Turbine meters and UMEs with a calibration vane. Should the turbine element require field calibration,

follow these steps:

1-1/2” and 2” HP Turbines

1Cut seal wire and remove tamper resist cap.

2Loosen lock nut by turning counter-clockwise.

3Insert slotted screwdriver into slot in top of adjusting stem and

aTurn clockwise to decrease registration, or;

bTurn counter-clockwise to increase registration.

Turning the adjustment stem 3 in either direction results in approximately 1% change in registration. The full range of the

calibration vane is 30 degrees (see Figure 2.2).

HP TURBINE INSTALLATION AND MAINTENANCE GUIDE 2-3

CHAPTER MAINTENANCE

2

3” - 20” HP Turbines

The calibration adjusting stem is located inside the register mounting ring for the 3”-20” HP Turbines. Should

the turbine element require field calibration, follow these steps:

1Remove seal pin from register and twist off register (3”-10); or remove lead seal and unscrew

register adapter screws (12”-20”).

2Loosen lock nut on adjusting stem by turning counter-clockwise.

3Insert slotted screwdriver into slot in top of adjusting stem and

aTurn clockwise to decrease registration, or;

bTurn counter-clockwise to increase registration.

Turning the adjustment stem 15 in either direction results in approximately 1% change in registration. The

full range of the adjustment stem is 180 (see Figure 2.3).

Figure 2.2 1-1/2” and 2” HP Turbines

Figure 2.3 3” - 20” HP Turbines
