Nescafe STELIA User manual

www.dolce-gusto.com
USER MANUAL
STELIA

32
TABLE OF CONTENTS
1. SAFETY PRECAUTIONS ..................................................3
2. OVERVIEW ..................................................................5
3. BEVERAGE EXAMPLES ...................................................6
4. RECOMMENDATIONS FOR SAFE USE ...............................7
5. FIRST USE ...................................................................8
6. PREPARING A BEVERAGE ...............................................9
6.1 ONE CAPSULE (E.G. LUNGO) ....................................9
6.2 TWO CAPSULES (E.G. CAPPUCCINO) ....................... 10
7. CLEANING ............................................................... 12
8. DESCALING AT LEAST EVERY 3 – 4 MONTHS .................. 13
9. TROUBLESHOOTING ................................................... 15
9.1 NO LIQUID COMES OUT – NO WATER?..................... 15
9.2 NO LIQUID COMES OUT – CAPSULE / INJECTOR BLOCKED? ... 15
9.3 VARIOUS ................................................................... 17
1. SAFETY PRECAUTIONS
1. Read all instructions and keep these safety instructions.
2. Connect the appliance to a mains socket with an earth
connection only. Mains voltage must be the same as
the details on the rating plate. The use of incorrect con-
nection will negate the guarantee and may be hazard-
ous.
3. This appliance is intended to be used in household
only. It is not intended to be used in following applica-
tions, and the guarantee will not apply for:
- stakitchenareasinshops,ocesandother
working environments;
- farm houses;
- by clients in hotels, motels and other
residential type environments;
- bed and breakfast type environments;
4. Your appliance is intended for domestic use inside the
home only at an altitude below 3400 m.
5. In case of any inappropriate use or failure to comply
with the instructions, the manufacturer accepts no re-
sponsibility and the guarantee may not apply.
6. We recommend using the NESCAFÉ® Dolce Gusto®
capsules designed and tested for the NESCAFÉ® Dolce
Gusto® machine. They were designed to interact to-
gether – the interaction provides the in-cup quality that
NESCAFÉ® Dolce Gusto® is known for. Each capsule
is designed to prepare a perfect cup, and cannot be
reused.
7. Do not remove hot capsules by hand. Use handles or
knobs.
8. Alwaysusetheapplianceonaat,stable,heatresist-
ant surface away from sources of heat or water splash-
es.
9. Toprotectagainstre,electricshockandinjurytoper-
sons do not immerse the power cord, plugs or the ap-
pliance in water or other liquid. Never touch the power
cordwithwethands.Donotoverllthewatertank.
10. In case of an emergency remove the plug from the
power socket immediately.
11. Close supervision is necessary when the appliance is
used near children. Keep the appliance / power cord /
capsule holder out of reach of children. Children should
be supervised to ensure that they do not play with the
appliance. Never leave the appliance without surveil-
lance while making a beverage.
12. This appliance is not intended for use by children or
persons with reduced physical, sensory or mental ca-
pabilities, or lack of experience and knowledge, unless
they have been given supervision or instruction con-
cerning use of the appliance by a person responsible
for their safety. Persons who have a limited or no un-
derstanding of the operation and use of this appliance
mustrstreadandfullyunderstandthecontentsofthe
user manual, and where appropriate seek additional
guidance on its operation and use from the person re-
sponsible for their safety.
13. Do not use the appliance without the drip tray and drip
grid, except when a very tall mug is used. Do not use
the appliance for hot water preparation.
14. Forhealthreasons,alwaysllthewatertankwithfresh
drinking water.
15. After use of the appliance always remove the capsule
and clean the capsule holder. Empty and clean the
drip tray and capsule bin daily. Users allergic to dairy
products: Rinse the appliance according to the clean-
ing procedure.
16. Unplug from the mains socket when not in use.
17. Unplug from the mains socket before cleaning. Allow
to cool before putting on or taking o parts, before
cleaning the appliance. Never clean wet or immerse
applianceinanyuid.Nevercleantheappliancewith
running water. Never use detergents to clean the ap-
pliance. Clean the appliance only using soft sponges/
brushes. The water tank should be cleaned with a
baby bottle brush.
18. Never turn the machine upside down.
19. If away for prolonged periods, on holiday, etc. the ap-
pliance must be emptied, cleaned and unplugged.
Rinse before reuse. Operate the rinse cycle before re-
using your appliance.
20. Donotturnotheapplianceduringthedescalingpro-
cess. Rinse the water tank and clean the appliance to
avoid any residual descaling agent.
21. Any operation, cleaning and care other than normal
use must be undertaken by after-sales service centres
designated by NESCAFÉ® Dolce Gusto® Hotline. Do not
dismantle appliance and do not put anything into open-
ings.

54
2. OVERVIEW
7
1
5
2
1Water tank cap
2
3Cold water icon
Water tank
Touch volume
selector / Bar display
5
7
10
4Hot water icon
Injector
6
Capsule holder
Drip tray
17/23mm
17/18mm
C
17/23mm
1 L 5-45 °C
41-113 °F
~3 kg
A = 17.2 cm
A
C
B
max. 15 bar B = 30.2 cm
C = 32.1 cm
UK/CH/DE/AT/FR/ES/PT/IT/NL/LU/BE/GR 230 V, 50 Hz, max. 1500 W
SG/MY 230 V/伏特, 50 Hz/赫兹, max./最大 1500 W/瓦
Canada 120 V, 60 Hz, max. 1500 W
AR/PY/UY 220 V, 50-60 Hz, màx. 1340 W
A
C
B
13
8
10
9
Power button / Descaling signal / Error signal
11
34
11
12
9
12
13
8Drip grid
Capsule bin
Cleaning needle
Injector tool
6
Economy mode:
after 5 min of non-usage
ON OFF
22. Incaseofintensiveusewithoutallowingsucientcool-
ing time, the appliance will stop functioning temporarily
with the red indicator light blinking. This is to protect your
appliancefromoverheating.Switchtheapplianceofor
20 minutes to let it cool down.
23. Do not operate any appliance with a damaged cord or
plug. If the power cord is damaged, it must be replaced
by the manufacturer, its service agent or similarly quali-
edpersonsinordertoavoidahazard.Donotoperate
any appliance that malfunctions or has been damaged
in any manner. Unplug cord immediately. Return the
damaged appliance to the nearest authorised service
facility designated by NESCAFÉ® Dolce Gusto® hotline.
24. The use of accessory attachments not recommended
bytheappliancemanufacturermayresultinre,electric
shockorinjurytopersons.
25. Do not let the cord hang over the edge of a table or
counter, or touch hot surfaces or sharp edges. Do not
allow the cord to dangle (risk of tripping up). Never touch
the cord with wet hands.
26. Do not place on or near a hot gas or electric burner, or
in a heated oven.
27. To disconnect, turn the power button OFF, then remove
the plug from the wall socket. Do not unplug by pulling
the cord.
28. Always insert the capsule holder in the machine to pre-
pare a beverage. Do not pull out the capsule holder be-
fore the indicator stops blinking. The appliance will not
work if the capsule holder is not inserted.
29.Do not put ngers under the outlet during beverage
preparation.
30. Do not touch the needle of the extraction head.
31. Never carry the appliance by the extraction head.
32. The capsule holder is equipped with permanent mag-
nets. Avoid placing the capsule holder near appliances
andobjectsthatcanbedamagedbymagnetism,e.g.
credit cards, USB drives and other data devices, video
tapes, television and computer monitors with picture
tubes, mechanical clocks, hearing aids and loud speak-
ers.
33.Patientswithpacemakersordebrillators:Donothold
thecapsuleholderdirectlyoverthepacemakerorde-
brillator.
34. If the power socket does not match the plug on the ap-
pliance, have the plug replaced with a suitable type by
after-sales service centres designated by NESCAFÉ®
Dolce Gusto® hotline.
35. Packaging is made of recyclable materials. Contact
your local council / authority for further information on
recycling programs. Your appliance contains valuable
materials which can be recovered or recycled.
36. For additional guidance on how to use the appliance, re-
fer to the user manual on www.dolce-gusto.com or call
NESCAFÉ® Dolce Gusto® hotline number.
37. Please be aware that the appliance is still using electric-
ity whilst in eco-mode (0.4 W/hour).
EUROPEAN MARKETS ONLY:
38. Keep the appliance and its cord out of reach of children
aged less than 8 years. Children shall not play with the
appliance.
39. This appliance can be used by children aged from 8
years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience and
knowledge if they have been given supervision or in-
struction concerning use of the appliance in a safe way
and if they understand the hazards involved.
40. Cleaning and user maintenance shall not be made by
children unless they are older than 8 and supervised by
an adult.
This appliance is labeled in accordance with European
Directive 2002/96/EC concerning used electrical and
electronic appliances equipment – WEEE). The directive
determines the framework for the return and recycling
of used appliances as applicable throughout the EU.
The guarantee does not cover appliances that do not work or do not work properly because they have not been main-
tained and/or descaled.
To reduce the risk of re or electric shock, do not
remove the cover. No user serviceable parts inside.
Repair should be done by authorized service per-
sonnel only!

6 7
3. BEVERAGE EXAMPLES
ESPRESSO
CAPPUCCINO
CHOCOCINO
Ristretto Espresso
Espresso Intenso
CAPPUCCINO ICE
1212
1 2
1 2
12
12
5 sec
4. RECOMMENDATIONS FOR SAFE USE
Never add hot water to the water tank! Afternishingpreparationthebar
displayashesandthepowerbutton
blinks red for about 5 seconds.
During that time do not try to pull
out the capsule holder!
Do not touch used capsule after bever-
age preparation! Hot surface, risk of
burns!
Never use a wet sponge. Only use a
soft damp cloth to clean the top of the
machine.
Always keep the machine upright!
Nevertouchneedlewithsurfaceofnger!
17/23mm
17/18mm
C
17/23mm
Do not use machine without needle!
Do not touch machine with wet hands!
For rinsing and beverage preparation
use only drinking water.
Do not touch plug with wet hands.
IF LEFT UNUSED FOR MORE THAN 2 DAYS:
Fill water tank with fresh drinking water and
insert it into machine. Rinse machine, therefore
follow instructions in “7. CLEANING“ on page 12,
beginning with step 4. Remove water from water
tank. Dry water tank. Reinsert water tank
.
Cold Beverage Hot Beverage

8 9
30 sec
ON
5. FIRST USE
1
4
7
2
5
8
3
6
Rinsewatertankatrstmanuallywithfresh,
drinking water. Fill water tank with fresh,
drinking water. Place cap and insert water
tank into machine.
Start rinsing with cold water: Set bar display
to max. level with touch volume selector.
Touch cold water icon. Machine starts rinsing.
Insert empty capsule holder. Place an empty
largecontainerunderneaththecoeeoutlet.
Ensure to use the correct mains voltage as
given in “2. OVERVIEW“ on page 5. Connect
power plug to mains power socket.
Waituntilcountdownisnishedandmachine
stops.
Waituntilcountdownisnishedandmachine
stops.
Switch machine on. While machine is heating
up, power button starts blinking red. After
approx. 30 seconds, power button lights
steady green and machine is ready.
Continue rinsing with hot water: Set bar display
to maximum level with touch volume selector.
Touch hot water icon. Machine starts rinsing.
Emptycontainer.Rellwatertankwithfresh,
drinking water. Insert water tank back into
machine. Place drip grid on drip tray. Then
insert drip tray at desired position of machine.
Take cup from drip tray.
8
5 sec
Afternishingpreparation,bardisplay
ashesandpowerbuttonblinksredfor
about 5 seconds.
During that time do not try to pull out
the capsule holder!
7
Touch hot (or cold water icon–depending on
beverage). Beverage preparation starts. Stay
beside the machine throughout the prepara-
tion! Bar display lights vanish progressively.
Machine stops preparation automatically.
3
5
Check whether water tank contains enough
fresh drinking water. Switch machine on.
While machine is heating up, power button
starts blinking red. After approx. 30 seconds,
power button lights steady green and machine
is ready.
Pull out capsule holder. Insert capsule in
capsule holder and insert capsule holder
back into machine.
ON
Use the touch volume selector to illuminate the
bars in accordance with the number of bars
shown on capsule, or set the bar display to
your own taste.
6
12
4
Adjustdriptrayposition.Placecupwithcorrect
cup size on drip tray. See “3. BEVERAGE
EXAMPLES“ on page 6 or package.
6.1 ONE CAPSULE (E.G. LUNGO)
Pull out capsule holder and remove used
capsule. Put used capsule in capsule bin.
Rinse capsule holder with fresh drinking
water from both sides. Dry capsule holder.
Insertitintomachine.Enjoyyourbeverage!
9
30 sec
6. PREPARING A BEVERAGE

10 11
6.2 TWO CAPSULES (E.G. CAPPUCCINO)
3
5
Check whether water tank contains enough
water. Switch machine on. While machine is
heating up, power button starts blinking red.
After approx. 30 seconds, power button lights
steady green and machine is ready.
Pulloutcapsuleholder.Insertrstcapsulein
capsule holder and insert it back into machine.
ON
Use the touch volume selector to illuminate the
bars in accordance with the number of bars
shown on capsule, or set the bar display to
your own taste.
6
12
4
Adjustdriptrayposition.Placecupwithcorrect
cup size on drip tray. See “3. BEVERAGE
EXAMPLES“ on page 6 or package.
7
Touch hot (or cold water button–depending on
beverage). Beverage preparation starts. Stay
beside the machine throughout the prepara-
tion! Bar display lights vanish progressively.
Machine stops preparation automatically.
9
Pull out capsule holder. Remove used capsule.
Put used capsule in capsule bin.
Use the touch volume selector to illuminate the
bars in accordance with the number of bars
shown on capsule, or set the bar display to
your own taste.
10
Touch hot (or cold water icon depending on
beverage). Beverage preparation starts. Stay
beside the machine throughout the prepara-
tion. Bar display lights vanish progressively.
Machine stops preparation automatically.
Afternishingpreparation,bardisplay
ashesandpowerbuttonblinksredfor
about 5 seconds.
During that time do not try to pull out
the capsule holder!
30 sec
5 sec
14
6.2 TWO CAPSULES (E.G. CAPPUCCINO)
Take cup from drip tray.
12
5 sec
Afternishingpreparation,bardisplay
ashesandpowerbuttonblinksredfor
about 5 seconds.
During that time do not try to pull out
the capsule holder!
Pull out capsule holder and remove used
capsule. Put used capsule in capsule bin.
Rinse capsule holder with fresh drinking
water from both sides. Dry capsule holder.
Insert capsule holder to machine.
Enjoyyourbeverage!
11
8
Insert second capsule in capsule holder.
Insert it back into machine.
6. PREPARING A BEVERAGE 6. PREPARING A BEVERAGE
13

12 13
7. CLEANING
2
4
78
3
5
1
6
30 sec
Rinse drip tray with fresh drinking water
and clean it with a clean food-safe brush.
Insert empty capsule holder. Place an empty
largecontainerunderneaththecoeeoutlet.
Remove and empty container.
Warning: Hot water! Handle with care!
Place drip grid on drip tray. Then insert drip
tray at desired position of machine. If any,
remove water from water tank.
Clean with washing-up liquid and fresh
drinking water both sides of capsule holder.
Alternatively wash in dishwasher. Afterwards
dry.
Switch machine on. While machine is
heating up, power button starts blinking
red. After approx. 30 seconds, power button
light turns green. Machine is ready to use.
Rinse and clean water tank. Use a clean
food-safe brush and washing-up liquid as
needed.Afterwardsrellwithfresh,drinking
water and insert it to machine. The water
tank is not dishwasher proof!
Rinse the machine: Light up all bars to max.
level using touch volume selector. Touch hot
water icon. Machine starts rinsing. Lights on
bar display display vanish progressively.
Switchmachineo.Unplugpowerplug.
Clean machine with a soft damp cloth.
Dry it afterwards with a soft dry cloth.
9
OFF
ON
8. DESCALING AT LEAST EVERY 3 – 4 MONTHS
1
4
7
2
8
3
6
9
2 min
0.5 L 5 sec
www.dolce-gusto.com
OFF
5
ON
If the beverage comes out slower than usual (even in droplets),
or if it is cooler than usual or if the power button is steady orange
(descaling signal), the machine has to be descaled.
Mix 0.5 litre fresh drinking water with
descaler sachet in a measuring cup.
Pour descaling solution into water tank
and insert water tank into machine.
Touch hot water icon. Bar display begins to
count down. Machine descales in start-stop
operation for approximately 2 minutes.
Wait until extraction stops.
Call the NESCAFÉ® Dolce Gusto®
Hotline or go on the NESCAFÉ® Dolce
Gusto® website. For hotline numbers
see last page.
Insert empty capsule holder. Place an empty
containerunderneaththecoeeoutlet.
Touch cold water icon. Bar display begins to
count down. Machine descales in start-stop
operation for approximately 2 minutes until
the water tank is empty.
Switchomachine.Ifany,
remove water from water tank.
Press and hold power button for at least
5seconds.Powerbuttonblinksalternately
green / orange and machine enters descaling
mode.
Forabettereectofthedescaler,themachine
enters a waiting time of 2 min. The power
button blinks alternately green / orange during
the waiting time.

14 15
IMPORTANT HINTS
Follow instructions on descaling
kit user manual.
Avoid contact of descaling liquid
with any part of the machine.
Do not use vinegar for descaling. Do not push power button
during descaling cycle.
9. TROUBLESHOOTING
2
4
3
1
1
No liquid comes out: Beverage preparation
stops part way during delivery or does not
start at all. Bar display ashes and power
button blinks red and green rapidly.
No liquid comes out: The capsule may be
blocked and under pressure.
Donotdrinkthecoee!Ifcapsuleholder
can be pulled out: Throw away the capsule.
If capsule holder cannot be pulled out,
wait for 20 minutes, try again. If capsule
holder is still blocked, unplug machine.
Call NESCAFÉ® Dolce Gusto® Hotline.
Check if there is water in the water tank: if not,
rellwithfresh,drinkingwaterandtouchhot/
cold water icon again to continue preparation;
if the water tank is full proceed as follows.
Always keep machine upright! To stop
preparation, touch again activated hot/
cold water icon. Do not unplug the machine!
Machine releases pressure.
Coeemixispressedoutoftopofcapsule
holder. Waituntilpressingprocessisnished.
This is the case if you hear no noise coming
from the machine.
Rinse machine, therefore follow instructions
in “5. FIRST USE“ on page 8. Clean with
washing-up liquid and fresh drinking water
both sides of capsule holder. Rinse drip tray
with fresh drinking water and clean it with a
clean food-safe brush.
9.1 NO LIQUID COMES OUT – NO WATER?
9.2 NO LIQUID COMES OUT – CAPSULE / INJECTOR BLOCKED?
10
13
11 12
14 15
OFF
8. DESCALING AT LEAST EVERY 3 – 4 MONTHS
Empty and clean container. Rinse and clean
water tank. Use a clean food-safe brush and
washing-up liquid as needed. Afterwards
rellwithfreshdrinkingwaterandinsertitto
machine.
At the end of the rinsing cycle, power button
lights up red. Wait until power button light
turnsgreen.Thenswitchmachineo.
Touch hot water icon to start rinsing.
Bar display begins to count down.
Wait until extraction stops.
Empty and clean container. Rinse and
cleanwatertank.Afterwardsrellitwithfresh,
drinking water and insert it into machine.
Rellwatertankwithfreshdrinkingwater.
Touch cold water icon to start rinsing.
Bar display begins to count down.
Wait until extraction stops.
Clean machine with a soft damp cloth. Dry it
afterwards with a soft dry cloth. Place drip grid
on drip tray. Then insert drip tray at desired
position of machine.

16 17
9. TROUBLESHOOTING
Remove injector only on cold machine!
Turninjectortoolanti-clockwise.Remove
injector.Do not leave injector unattended!
Keep injector out of reach of children!
Put cleaning needle from both sides into
injectortounclogit.Ifnotpossible,prepare
a descaling solution with one sachet and
0.5Ldrinkingwater.Putinjectorindescaling
solution.
Check whether both o-rings are not
damaged and in the right place on the
injector.Putinjectorontoinjectortool.
Insertinjectorfrombelowintoopeningof
machine.Supportinjectorwithhand.Rotate
injectorclockwiseuntilitts.Followinstructions
in “8. DESCALING AT LEAST EVERY 3 – 4
MONTHS“ on page 13.
8910
12
45
*
♫■☼
ghi
@
1 2
1 2
1
Machine cannot be switched on.
Beverage is splashing out of coee outlet.
Check if the power plug is plugged correctly
into a mains power socket. If yes check your
electricity supply.
If machine still cannot be switched on
call NESCAFÉ® Dolce Gusto® Hotline.
For hotline numbers see last page.
To stop preparation, touch active hot or cold
water icon. Pull out capsule holder and check
capsule. Throw away the capsule.
Insert a new capsule in the capsule holder and
insert it back into the machine.
Beverage only comes out in droplets or
beverage is cooler than usual: the machine
has to be descaled.
Call NESCAFÉ® Dolce Gusto® Hotline or go
on the NESCAFÉ® Dolce Gusto® website.
For hotline numbers see last page, see “8.
DESCALING AT LEAST EVERY 3 – 4 MONTHS“
on page 13.
www.dolce-gusto.com
67
9.2 NO LIQUID COMES OUT – CAPSULE / INJECTOR BLOCKED? 9.3 VARIOUS
9. TROUBLESHOOTING
17/23mm
17/18mm
C
17/23mm
5
Unplug power plug! Turn drip tray over.
Onbottomtakeouttheinjectortool.
Pulloutcleaningneedleoutofinjectortool.
Keep needle out of reach of children!
Removecapsuleholder.Pushinjectortoolon
injector.

18 19
1
12
45
*
♫■☼
ghi
@
2
20 min
OFF
ON
Power button ashes red fast. Switchmachineo.Checkifcapsuleisblocked,
see “9.2 NO LIQUID COMES OUT – CAPSULE /
INJECTOR BLOCKED?“ on page 15. Unplug
power plug and wait 20 minutes. Afterwards
plug power plug into mains power socket and
switch machine on.
Ifpowerbuttonstillashesredcall
NESCAFÉ® Dolce Gusto® Hotline.
For hotline numbers see last page.
• Water underneath or around machine.
• Clear water leaking around capsule
holder during beverage preparation.
Unplug machine.
12
45
*
♫■☼
ghi
@
2
Call NESCAFÉ® Dolce Gusto® Hotline.
For hotline numbers see last page.
1
9. TROUBLESHOOTING
9.3 VARIOUS

www.dolce-gusto.com
UMDL-STE-EN-2015/01
HOTLINES
AE 800 348786,
8008 971 971
A L
0842 640 10
AR
0800 999 81 00
AT
0800 365 23 48
AU
1800 466 975
BA
0800 202 42
BE
0800 93217
BG 0 800 1 6666
BR 0800 7762233
CA 1 888 809 9267
CH
0800 86 00 85
CL
800 4000 22
CO
01800-05-15566
CN
400 630 4868
CR
0800-507-4000
CZ 800 135 135
DE
0800 365 23 48
DK 35460100
EE
6 177 441
ES
900 10 21 21
FI
0800 0 6161
FR
0 800 97 07 80
G B 0800 707 6066
ROI: 00800 6378 5385
GR 800 11 68068
GT 1-800-299-0019
HK 2179 8888
HN
800-2220-6666
HR 0800 600 604
HU 06 40 214 200
ID 001803657121
I E 00800 6378 5385
IT
800365234
JO
[phone]
JP
(machines) 81-35651-6848
(capsules) 81-35651-6847
KR
080-234-0070
KG 0842 640 10
KW [phone]
KZ 8-800-080-2880
LB [phone]
LU 8002 3183
LT 8 700 55 200
LV 67508056
MA 080 100 52 54
ME 020 269 902
Middle East:
[phone]
MX
5267 3304,
01800 365 2348
MK 0800 00 200
MT 80074114
MY 1800 88 3633
NI 1-800-4000
NL
0800-3652348
NO 800 80 730
NZ 0800 365 234
PA 800-0000
PE 80010210
PH 898-0061
PL
0800 174 902
PT
800 200 153
PY
0800-112121
QA [phone]
RO 0 800 8 637 853
RU 8-800-700-79-79
SA
8008 971 971
SE
020-29 93 00
SG
1 800 836 7009
SK
0800 135 135
SL
080 45 05
SR
0800 000 100
SV
800-6179
TH
1-800-295588,
0-2657-8601
TR 0800 211 02 18,
4 44 31 60
TW 0800-000-338
UA 0 800 50 30 10
US
1-800-745-3391
UY 0800-2122
VN 1800 6699
ZA
[phone]
(toll free) 086 009 6116
