Nespresso BARISTA W10 User manual

BARISTA

EN User manual 4
HK 使用指南 14
TW 使用手冊 24
KR 󻸛󼐘󾖴󻺓󻟴󻺋 34
MY Manual pengguna 44












4
Jug Lid (dishwasher safe)
Rubber Seal (dishwasher safe)
Whisk for all preparations (2 parts, dishwasher safe)
MAX level indicator (250 ml)
INTERMEDIATE level indicator (150 ml)
MIN level indicator (100 ml)
Jug (dishwasher safe)
Power base
START / STOP Button
Navigation Arrows (touch interface)
Barista Spoon (dishwasher safe)
Device instruction Screen
❶
❷
❸
❹
❺
❻
❼
❽
❾
11
12
❿
Overview
Content
Overview 4
Barista 4
Important safeguards 5
Get the App 8
Pairing 8
Connectivity functions 8
Preparation 9
Tips when using your device 10
How to access the hidden menu 10
Cleaning instructions 11
Troubleshooting 12
Specifications 13
Warranty 13
The Nespresso Barista is an invitation to discover a wide world of recipe possibilities. Prepare anything from refreshing iced coffees to
elaborate Latte Art at home. With its touch screen and connected app, navigating through the recipes becomes surprisingly easy. Thanks
to the connectivity, you’ll be able to discover new recipes via the App.
Barista

5
EN
Important safeguards
CAUTION /WARNING
ELECTRICAL DANGER
DISCONNECT DAMAGED
SUPPLY CORD
CAUTION HOT SURFACE
MAGNETS INSIDE
NO FERROMAGNETIC TOOLS
OR MATERIALS
CAUTION STRONG
MAGNETIC FIELD
CAUTION: The instructions are part
of the appliance. Read and follow
all instructions to avoid possible harm
and damage. Save these instructions
and pass them on to any subsequent
owner.
Avoid risk of fatal electrical
shock and fire
• Only plug the power base into a
suitable, earthed power socket. Make
sure that the voltage of the power
source is the same as that specified on
the rating plate.
• Unplug from outlet when not in use
and before cleaning. Allow to cool
before putting on or taking off parts,
and before cleaning the appliance.
• Plug cord into the wall outlet. To
disconnect, switch off, then remove
plug from wall outlet.
• Do not pull the cable over sharp edges,
clamp it or allow it to hang down.
• If the supply cord or the plug are
damaged, they must be replaced by
the manufacturer, its service agent or
similarly qualified persons.
• Disconnect the power base from the
power socket, when not in use for long
periods. Disconnect by pulling out the
plug and not pulling the cable itself, as
this may damage the cable.
• Never immerse the power base of
appliance in water or other liquids.
Electricity and water together can
cause a fatal electric shock.
• To protect against fire, electric shock
and injury to persons do not immerse
cord, plugs, or the device base in
water or other liquid.
• Disconnect the device from the mains
before the appliance is cleaned, and
ensure that the inlet is dried before the
appliance is used again.
• The appliance is only to be used with
the jug provided.
• Short power-supply cords reduce risks
resulting from becoming entangled in
or tripping over a long cord.
• Longer (or detachable) cords may be
used if care is exercised in their use,
and:1) the marked electrical rating is at
least as great as the electrical rating of
the appliance 2) a grounding-type 3-
wire cord is used 3) cord(s) is arranged
so that it will not drape over the counter
top or table top, where it can be pulled
on or tripped over by anyone.
• If an extension lead is required, use only

6
Important safeguards
an earthed cable with a conductor cross-
section of at least 1.5 mm2.
• The Barista jug is dishwasher safe, but
cannot be washed at a temperature
higher than 70° C.
• Magnets inside.
• Hot elements after heating: jug,
use handle.
• Hot surface under jug: risk of
damaging of table (wood, plastic) or
surface when put.
• Don’t use without lid, risk of hot
beverage projection and don’t
remove lid during appliance working.
• Don’t put your fingers or foreign
body during preparation: rotating
parts, risk of injury.
• Don’t fill jug with more liquid than max
level, risk of overflowing.
• Don’t close opening (cooling air
circulation) under device: risk of
overheating.
• Don’t block fan (under device): risk of
overheating.
Avoid possible harm when operating
the appliance
• Never leave the appliance unattended
during operation. Keep it out of the
reach of children. The appliance is only
for use by persons who have sufficient
experience and knowledge and are
physically, sensory, and mentally
able to operate the machine safely in
accordance with these instructions.
• The appliance is intended to prepare
beverages according to these
instructions.
• This appliance is intended to be used
in households.
• Except for US and Canada, this
appliance is intended to be used in
similar applications such as: staff
kitchen areas in shops, offices,
farm houses and other working
environments.
• This appliance can be used by
children 8 years old and older, as well
as persons with reduced physical,
sensory, mental capabilities or lack
of experience, only if they have been
given supervision and instruction
concerning the use of the appliance
in a safe way and understand the
hazards involved. Children shall not
play with the appliance.
• Cleaning and user maintenance
shall not be made by children unless
they are older than 8 and supervised.
Keep the appliance and its cord out
of reach of children under the age of
8 years old.
• Do not use the appliance if damaged.
A damaged appliance can cause
electric shocks, burns and fire.
• Only use the appliance with the power
base provided.
• Do not touch hot surfaces. Use
handles.
• Do not operate any appliance with a
damaged cord or plug in the appliance
if it has malfunctioned, dropped or
is damaged in any manner. Return

7
EN
appliance to the nearest authorized
service facility for examination, repair,
or electrical or mechanical adjustment.
• Do not use outdoors.
• Do not use the appliance for anything
other than its intended use.
• Scalding may occur if the lid is
removed during the recipe preparation.
• Extreme caution must be used when
moving an appliance containing hot
liquids.
• Avoid contact with moving parts.
• The use of accessory attachements
not recommended by the appliance
may result in fire, electric shock or
injury to persons.
• The appliance is intended to prepare
beverages according to these
instructions. It is for use in private
households. No liability is accepted
for any other purposes, faulty
operations or non professional repairs.
Guaranteed services are also excluded
in such cases.
• To avoid hazards, never place the
appliance on or beside hot surfaces,
for example, radiators, stove tops, gas
burners or similar.
• Don’t pour liquid into the power base.
• Only use the appliance with the power
base provided.
• Ensure correct placement of the jug
inside of the base before use.
• Cleaning: disassemble whisk disk of
the whisk for complete cleaning.
• In case of start of recipe without liquid,
sides of jug could become hot, use the
handle.
• Use only ingredients mentioned in
recipe booklet and App.
• Use device only on flat horizontal
surface.
Disposal
• Your appliance contains
materials which can be
recovered or recycled.
Separation of the remaining waste
products into different types facilitates
the recycling of raw materials. You can
obtain information on disposal from
your local authority.
SAVE THESE INSTRUCTIONS

+=ON
8
Pairing
Connectivity functions
Nespresso Barista is compatible with: IOS (iPhone + iPad), Android.
Get the App
Download the Nespresso App. If you
have it already, we recommend to
update the App to the latest version.
Launch the App on your smartphone
or tablet.
From the Nespresso app homepage,
click on the Machine icon.

Please make sure that:
- Your Barista is turned on.
- Your mobile device has Bluetooth®turned ON.
- You are close to your Barista while pairing.
Follow pairing instruction on
the App. When the pairing is
completed, Barista icon will appear
on the screen. The pairing takes
approximately 30-40 seconds.
You can add, remove and reorganise
your recipes on your Barista via your
mobile phone by following the mini-
tutorial on the app.
- Recipes management: navigate through the recipes and personalize your Barista
- Recipes step by step: a step by step instructions for each recipe
- Recipes discovery: discover a wide world of recipe possibilities
- Machine status: check machine status
- Alarms: check error messages




CAPPUCCINO
Max
9
EN
CAUTION: Always ensure the whisk is firmly inserted into jug before adding
liquid. Make sure the lid and seal is firmly in place before starting the
preparation.
Preparation
Remove the warning label on the
whisk before use. Clean before
the first use and after each
use according to the cleaning
instructions. Place the whisk in
the jug.
Chocolate recipe
For chocolate based recipes, add
the chocolate squares directly in
the device.
Fill jug according to level specified in
the recipe instuctions (in the recipe
book or in the app). To avoid any
overflow, please note the highest
“Max milk” level indicator is 250 ml.
Put the lid on the device. Make sure
the jug is dry before you put it in the
power base. Always make sure the
whisk is in place before adding the
ingredients.
Choose your recipe preparation via
the dedicated App or by pressing the
device button to start. Via the arrows,
navigate left or right to select the
desired recipe. You can also connect
via the application to select and view
the recipes instructions. There will be
an animation on the screen during
preparation and become steady on
when the preparation is ready.
Iced Recipes
For Iced Recipes, add the ice cubes
directly in the device.
Milk recipe (hot and cold)
TIPS: For optimal milk froth, use cold semi skimmed cow milk at refrigerated temperature (about 4-6 °C). To guarantee hygiene
conditions, use heat treated milk (pasteurized), refrigerated & freshly opened only. Milk which has been frozen will not froth. To
ensure hygienic conditions and proper maintenance of the equipment, it is highly recommended to not use special enriched milks,
powdered reconstituted milks nor flavoured milks.
WARNING: Risk of electrical shock and fire! Make sure the under side of the
milk device’s power base and area underneath the power base is dry.
 



10
Tips when using your device
How to access the hidden menu
CAUTION: Surface of the jug will be hot during and after recipe preparation. Do
not place hot jug on heat sensitive surface. Take the hot jug only by the handle.
• Always use cold and fresh milk (4-6° C).
• Always respect the recommended milk quantity indicated in the recipe.
• Never exceed the MAX marking inside the jug.
• Before pouring the recipe, swirl the frothed milk in a circular motion.
• Frothed milk that is not used immediately should not be reheated.
• Ensure the jug and whisk are clean before use.
• Suitable liquids: cow milk (Fresh or UHT, full cream, low fat, skim) and any vegetable milk (milk froth is not guaranteed with these milks).
• The milk froth volume depends on the kind of milk that is used and its temperature.
• Suitable Ingredients: chocolate, chocolate flakes, honey, syrup, flavoured powders, sugar, ice cubes.
• Before preparing cold recipes, make sure the jug is cold or quickly cool it down under cold water or with ice.
• Do not use any enriched or special enriched milk or liquid products on the equipment.
• This equipment is specific for milk, not to use other products, therefore not fit for lactose intolerants or milk allergics.
• Language: choose your language by navigating via the arrows
and confirm with the center button.
• Reset: press the center button to confirm factory reset.
• Bluetooth®: to activate or deactivate the Bluetooth®mode.
• Exit: to exit the hidden menu.
Press simultaneously the 2 arrows for 3 seconds.
Pour the required amount of cold fresh milk into the jug and cover with jug lid. Always use cold milk and fill the jug between MIN and
MAX level markings. To avoid any scratches, use only the dedicated Barista spoon or a non-metal spoon to collect the foam in the
jug. For hot and cold milk froth, preparation takes approx. 80 sec. For hot milk, preparation takes approx. 150 sec. Preparation can
be stopped at any time by pressing the button or removing the device from the power base.
Device turns off automatically after 3 minutes of non-use and
the display will shutdown. Press any arrows buttons to switch
the device ON again, the display will start again. To turn off
your device before the auto off, press and hold the main
button for 5 seconds.
NOTE: Do not remove jug during preparation. To stop operation at any time, press the START / STOP button once.
NOTE: Never operate the appliance without the minimum
level of liquid in the jug. For optimum frothing results, do not
exceed the MAX indicator inside the jug.
NOTE: When pouring your recipe, make sure to hold the
whisk (or remove it) before pouring your recipe.


Preparation
