Ness - Quick Guide - RL DVB-T range of Modulators Page 1
QUICK START
Ness RL DVB-T range of Modulators
Single Channel (Ness part # 101-541),
Dual Channel (Ness Part # 101-544)
Quad Channel (Ness Part No. 101-54 )
September 23
rd
. 2011.
The Ness RL DVB-T range of Modulators comes in either a Single (Ness part # 101-541),
Dual (Ness Part # 101-544) or Quad (Ness Part No. 101-546) Digital Modulators.
Digi-MOD DVB-T Digital RF Modulation system will allow you to distribute any AV
devices (Foxtel, Austar, DVD, CCTV Camera etc) around the home or business with ease.
Quick Start.
1. The RL DVB-T comes with the following factory pre-sets

Ness - Quick Guide - RL DVB-T range of Modulators Page 2
Before starting perform a Factory Default, power down, and power up before commencing.
In order to do this -:
(a) Power Up the RL DVB-T, wait until the booting process is complete.
(b) Use the Scroll Down Key to reach “Default Config” in the menu. Once “Default
Config” is located select “OK” button and scroll until you reach EXIT menu – select
“OK” on Exit.
(c) Power Down
(d) Power Up.
2. Once the unit has completed its booting process, enter the menu by selecting the
“OK” button
3. The LCD screen will now display “Advanced Menu Output Channel” Select the
“OK” button. The LCD screen will now display “Output Channel 21” with the
frequency in MHz.
In some TV sets Channel 21 in not available, so it is recommended to change this to
Output Channel 40, 50, 60 etc.
4. Once you have scrolled and selected a channel number, Select “OK” and use the UP
scroll button until the LCD display reads “Advanced Menu EXIT”
5. Select “OK”, the LCD will now read “EXIT, EXIT Menu”. Select “OK”.
(a) The LCD display will now show “Running”.
(b) The RL DVB-T unit is now ready to have sources connected.
(c) Auto Scan for Channels on the TV set with the RL DVB-T connected and powered.
(d) Sources for selected RL DVB-T Channel selection, (e.g. channel 40), are found on
TV channels 101, 102, 103, 104.
(e) If the RL DVB-T is powered down, there is no need to reconfigure. All settings will
remain unless a factory default is done.
Notes -:
i. Re-Boot does nothing at this stage / version.
ii. CHANNEL NAME. Channels can be named by using the Scroll UP key until
you reach CHANNEL NAME. Use the UP/DOWN scroll keys to change each
letter. Click OK to confirm channel name change.
iii. LCN (Logic Channel Number) can be moved from its default position (101,
102, 103 and 104) to a different channel number (e.g. 4, 5, 6, 8) by scrolling
up/down in the LCN option for each channel. Once selected, press the “OK”
button to lock your channel change.
