NetterVibration AP 117 User manual

Operating Instructions for October 2015
Netter Electronic Timer BA No. 1651E
Type AP 117 Page 1/16
These operating instructions apply to: Type AP 117

2
Contents
1GENERAL NOTES 3
2SAFETY 5
3TECHNICAL DATA 6
4DESIGN AND FUNCTION 8
5TRANSPORT AND STORAGE 9
6INSTALLATION 10
6.1 Mounting the Electronic Timer 10
6.2 Electrical Connection 10
7START-UP / OPERATION 12
8MAINTENANCE / SERVICE 15
9TROUBLESHOOTING 15
10 WASTE DISPOSAL 16
11 ENCLOSURES 16
Scope of delivery
The AP 117 are delivered with the follow-
ing components as standard:
•Electronic Timer AP 117
•Operating Instructions
•Packaging
For changes to the scope of delivery
please refer to the delivery note.
Check the packaging for possible signs of
transport damage.
In the event of damage to the packaging,
check that the contents are com
plete and
undamaged. If there is any damage, inform
the shipping agent. Compare the scope of
the delivery with the delivery note.

3
1 General Notes
Information on the operating instructions
Use and storage of the operating
instructions
Before use of the type AP 117 elec-
tronic timers read this operating man-
ual carefully. It is the basis for any
action taken with regard to the AP 117
and may be used for training purpos-
es. The operating manual should sub-
sequently be stored near the product.
Target group
The target group of these operating in-
structions is qualified technical per-
sonnel from the mechanical engineer-
ing sector who have a fundamental
knowledge of electrics and mechanics.
Installation, commissioning, mainte-
nance, fault elimination and disassem-
bly of the AP 117 must only be per-
formed by persons who have been
instructed in the proper handling of the
units.
Persons who have not been instructed
accordingly must not carry out any
works on the AP 117.
Copyright
This documentation is subject to copy-
right.
All rights e.g. for translation, photo-
mechanical reproduction, printing or
reproduction (e.g. data processing,
data carriers and data networks) of this
operating manual, or parts thereof, are
strictly reserved to NetterVibration.
Limitation of liability
All technical information, data and in-
structions on installation, operation
and maintenance in these operating
instructions are based on the latest
information available at the time of
printing and take into account our past
experience to the best of our
knowledge.
No claims can be derived from the infor-
mation, illustrations and descriptions in
these operating instructions.
The manufacturer does not assume
liability for damages resulting from:
•failure to observe the operating in-
structions
•improper use
•unauthorized repairs
•technical modifications
•use of inadmissible spare parts
Translations are made to the best
knowledge. NetterVibration does not
assume liability for translation errors,
even if the translation was made by us
or on our behalf. Only the original
German version is binding.

4
The following instruction and warning symbols are used in these operating instructions:
DANGER refers to a possible risk, which,
if not avoided, can result in death or serious injury
DANGER
AUTOMATIC START refers to a possible risk, which,
if not avoided, can result in death or serious injury.
CAUTION refers to a possible risk, which,
if not avoided, can result in serious injury and/or equip-
ment damage.
DISCONNECT
POWER SUPPLY refers to a possible risk, which,
if not avoided, can result in serious injury.
IMPORTANT note with especially useful information and tips.
ENVIRONMENTALLY
FRIENDLY
DISPOSAL
refers to the obligation of an environmentally friendly dis-
posal.
Information on the AP 117
Netter type AP 117 electronic timers
comply with the directive for electromag-
netic compatibility 2014/30/EU
and the
low voltage directive 2014/35/EU.
Standards DIN EN 61010-1
and
DIN EN 61326-
1 have been particularly
observed.
Special features
•Digital adjustment, exact to the second
•Dust and water-splash protected
•Protection type IP 65, radio interfer
ence
suppression
•Operation mode: electronic, non-contact

5
2 Safety
Designated use:
Electronic timers are used wherever a
procedure needs to be time-controlled.
AP 117 electronic timers are suitable
for timed activation of electric external
vibrators, solenoid valves and motor
overheating protection.
With these timers electric vibrators,
pneumatic vibrators, pneumatic im-
pactors and other drives can be
switched on and off exactly to the sec-
ond.
By selecting suitable pause times, the
operation of the vibrators is optimized,
drive energy can be saved and the
noise level lowered.
Any other usage is considered to be
improper.
The electronic timer has no safety de-
vices of its own.
Qualified Personnel:
Installation, start-up, maintenance and
fault correction of the electronic timer
may only be carried out by authorized,
qualified personnel.
Handling the electronic timer always
lies in the responsibility of the opera-
tor.
CAUTION
Netter GmbH does not assume liability for damage or injury result-
ing from technical modifications to the product or failure to ob-
serve the instructions and warnings in this operating manual.
DANGER
Live parts can cause severe or even deadly injury.
DANGER
DANGER
AUTOMAT-
IC START
If, following a voltage interruption, power is again applied to the power
supply conn
ection, the next cycle will always begin with the set duty
time.
The output is immediately energized.
DISCON-
NECT
POWER
SUPPLY
When working on the electronic timers they must be isolated from the
mains supply. To do so please proceed as follows:
1. Switch off the electronic timer
2. Secure against switching on again
3. Make sure it is de-energized
4. Earth and short-circuit
5. Cover or isolate any neighboring voltage parts

6
3 Technical Data
IM-
PORTANT
Duty time (RUN): Exact to the second, up to max. 99h 59min 59s
Clock duty time: Exact to the second, from 0 to max. 59 s
Clock pause time: Exact to the second, from 0 to max. 59 s
Pause time (PAUSE): Exact to the second, up to max. 99h 59min 59s
Own consumption: 2 VA in operation, 0.25 VA standby
Operating voltage AC: 90 V to 240 V
Switching current AC: 1.25 A
or
Operating voltage DC: 24 V – 48 V ± 5%, protected against reverse
polarity
Switching current DC: 1.25 A
Switching current DC: at 24 V and max. +40°C to ≤ 2 A
Ambient temperature: -20°C to +60°C
The operating temperatures must not be ex-
ceeded or fallen short of.
Protection:IP 65, RFI suppressed
Cable diameter: 4.5 mm to 10 mm
The technical data of your electronic timer can be found on the nameplate:

7
Dimensions
Cable gland

8
4 Design and Function
The electronic timer consists of two basic components:
•Voltage supply with electronic switching unit and
•Display unit with operating elements.
1
2
3
4
5
6
7
8
9
10
11
12
Housing
RUN Duty time adjustment
(Clock) duty time display
PAUSE Pause time adjustment
Housing opening slit
(Clock) pause time display
Increasing the selected time value
and adjusting the clock pause time
Standby and sensor key LED
Decreasing the selected time value
and adjusting the clock duty time
Mounting bores
Sensor cover
ON /OFF switch (standby)
no disconnection!
AP 117 has two functions:
•Function “standard”
•Function “cascade / interval / pulse
mode”
Function “standard”:
The sequence begins with the duty time
(RUN), which can be adjusted from 1 s
to 99 h. During this time the supply volt-
age is applied to the timer output.
When the duty time ends, the pause
time (PAUSE) of 1 s to 99 h runs, then
the duty time, etc.
Function “cascade / interval / pulse
mode”:
The sequence begins with the duty
time, which can be adjusted from 1 s to
99 h. The duty time begins with the
clock duty time (pulses), which is ad-
justable from 0 to 59 s. When the clock
duty time ends, the clock pause time of
0 to 59 s runs, then the duty time
again, etc. until the duty time ends.
After that, the pause time runs.
The elapsed time is visible on the dis-
play. The respective time digits are
brightly illuminated when active.

9
Function “standard”
Function “cascade / interval / pulse mode”
RUN = duty time R 2 = clock duty time
PAUSE = pause time P 2 = clock pause time
5 Transport and Storage
IM-
PORTANT
Check the packaging for possible signs of transport damage. In the event
of damage to the packaging, check that the contents are complete and
undamaged. If there is any damage, inform the shipping agent.
The electronic timer is packed ready-
to-install.
At delivery the fuse is located in the
socket.
When transporting electronic timers, it
should be ensured that they are not
subjected to severe impacts or vibra-
tions.
The units should be stored in a clean,
dry environment.
If electronic timers are in storage for
longer periods, the temperature in the
store-room must not be below -20°C or
above 40°C and the relative air humid-
ity must not exceed 60%.
R 2
R 2
R 2
R 2
RUN
RUN
PAUSE
P 2
P 2
RUN
RUN
PAUSE

10
6 Installation
CAUTION
During installation, the safety regulations in chapter 2 and the accident
prevention rules must be strictly observed!
The electronic timers have
been manufactured in accordance with the
current EC directives.
Installation, start-up and maintenance may only be carried out by author-
ized qualified personnel.
For installation and operation of the electronic timers the regulations and
directions of the
local engineering associations (e.g. VDE) and the known
accident prevention rules have to be observed.
6.1 Mounting the Electronic Timer
AP 117 electronic timers can be
mounted in any position.
The 4 bores (Ø 4.25 mm) for attach-
ment of the unit are accessible once
the cover has been opened.
Dimensions of the mounting bores:
108 mm × 127 mm (see Ch. 3 Tech-
nical Data).
The mounting surface must be even
and level, in order to avoid damaging
of the housing.
6.2 Electrical Connection
DANGER
ATTENTION:
The AP 117 must not be mounted or dismounted with voltage applied!
Electrical installation of the AP 117 electronic timer may only be per-
formed by authorized specialists.
The authorized specialists
must work only with insulated tools which are
suitable for the application.
CAUTION
Only suitable and flexible supply cables should be used for the connec-
tion of the electronic timers AP 117. Cables and earthing conductors must
be connected according to the respective regulations.
The conductors in the supply cable for
connection of the AP 117 to the power
supply must be temperature-resistant and have a sufficiently large cross-
section matching the used cable length.
DANGER
The electric lines must be carefully routed. It must be ensured that cables
cannot be worn through by vibrating components.
It should be checked that the electric lines and their connectors are in
perfect working condition at regular intervals (generally every six months).
Any faults which are discovered must be immediately remedied.
Protect cables from high temperatures, lubricants and sharp edges.
CAUTION
At delivery the fuse is located in the socket.
The operating voltage for the electronic timer is also the supply voltage for the
device to be controlled (solenoid valve, contactor, vibrator, motor, etc.).

11
Opening housing cover:
DANGER
ATTENTION:
The AP 117 cover may only be opened by authorized specialists.
Slide screwdriver into the opening slit
and turn.
Flip cover open to the left side.
Connection:
-Open housing cover as described
above.
-The electronic timer can now be
connected via the terminal strip.
The voltage is supplied via the power
connection block 1 and 2 (DC or AC),
terminal 3 PE (AC).
The output voltage is applied to the
terminals 4 and 5 (AC or DC), terminal
6 PE (AC).
Direct voltage
If direct voltage (DC) is applied to the
terminals 1 and 2, direct voltage (DC) is
also applied to the terminals 4 and 5.
Alternating voltage
If alternating voltage (AC) is applied to
the terminals 1 and 2, alternating voltage
(AC) is also applied to the terminals 4
and 5.
If alternating voltage is applied, the pro-
tective conductor PE must always be
connected (terminals 3 and 6).

12
The voltage level of input
and output voltage is al-
ways the same.
AC/DC fuse
(1.25 A slow blow)
Output strip terminals 4-6
(AC or DC)
Power supply connection strip
terminals 1-3 (DC or AC)
Terminal strips
Terminals 1-3
Terminals 4-6
AC/DC power supply
PE
AC/DC output
7 Start-up / Operation
IMPORTANT
In standby mode the red LED flashes. In the adjusting or operating mode
the LED lights when active keys are touched.
DANGER
AUTOMATIC
START
When switched on the AP 117
starts immediately with the
stored time values. The connected devices also start immediately.
IMPORTANT
The sensor keys react to slight touching, not to pressing.
DANGER
DANGER
AUTOMATIC
START
If, following a voltage interruption, power is again applied to the power
supply connection, the next cycle will always b
egin with the set duty
time.
The output is immediately energized.

13
Function “standard”
Adjusting the duty time:
•If the timer is switched off, the out-
puts (terminals 4-5) are de-
energized.
•Touch the key ON/OFF until
the displays are illuminated. The
electronic timer starts immediately
with the stored time values.
•Touch the key until two addi-
tional illuminated points appear in
the display (adjusting mode). The
outputs (terminals 4-5) are de-
energized.
•Touch the key and select the
position to be adjusted (seconds,
minutes or hours) by actuating
or (the points will change).
•To increase or decrease the time
value actuate or (and do
not touch RUN).
•If the required duty time has been
adjusted, it must be confirmed by
touching again the key (for at
least 3 seconds).
•The values are stored when the
points have extinguished.
•The outputs (terminals 4-5) are en-
ergized while the duty time is run-
ning.
Adjusting the pause time:
•If the timer is switched off, the out-
puts (terminals 4-5) are de-
energized.
•Touch the key ON/OFF until
the displays are illuminated. The
electronic timer starts immediately
with the stored time values.
•Touch the key until two addi-
tional illuminated points appear in
the display (adjusting mode). The
outputs (terminals 4-5) are de-
energized.
•Touch the key and select the
position to be adjusted (seconds,
minutes or hours) by actuating
or (the points will change).
•To increase or decrease the time
value actuate or (and do
not touch PAUSE).
•If the required pause time has been
adjusted, it must be confirmed by
touching again the key (for at
least 3 seconds).
•The values are stored when the
points have extinguished.
•The outputs (terminals 4-5) are de-
energized while the pause time is
running.

14
Function “cascade / interval / pulse mode”
IMPORTANT
The adjustment of the duty and pause time is carried out in the same way
as in the function “standard”.
Adjusting the clock duty time:
•If the timer is switched off, the out-
puts (terminals 4-5) are de-
energized.
•Touch the key ON/OFF until
the displays are illuminated. The
electronic timer starts immediately
with the stored time values.
•Touch the key until two addi-
tional illuminated points appear in
the display (adjusting mode). The
cascade adjusting mode is indicated
by the “P” preceding the value. The
outputs (terminals 4-5) are de-
energized.
•Touch the key .
•To increase or decrease the time
value actuate or (do not
touch RUN).
•If the required clock duty time has
been adjusted, it must be confirmed
by touching again the key (for
at least 3 seconds).
•The values are stored when the
points have extinguished.
•The outputs (terminals 4-5) are en-
ergized while the clock duty time is
running.
Adjusting the clock pause time:
•If the timer is switched off, the out-
puts (terminals 4-5) are de-
energized.
•Touch the key ON/OFF until
the displays are illuminated. The
electronic timer starts immediately
with the stored time values.
•Touch the key until two addi-
tional illuminated points appear in
the display (adjusting mode). The
cascade adjusting mode is indicated
by the “P” preceding the value. The
outputs (terminals 4-5) are de-
energized.
•Touch the key .
•To increase or decrease the time
value actuate or (do not
touch PAUSE).
•If the required clock pause time has
been adjusted, it must be confirmed
by touching again the key (for
at least 3 seconds).
•The values are stored when the
points have extinguished.
•The outputs (terminals 4-5) are de-
energized while the clock pause time
is running.

15
IMPORTANT
A cycle has to consist of at least two clock duty times and one
clock pause
time.
IMPORTANT
The total sum of clock duty times and clock pause times is the duty time. If
the clock duty time and the clock pause time are selected in a way that
their total sum cannot correspond to the duty time, the duty time is auto-
matically rounded up.
Example:
Clock duty time = 5 sec., Clock pause time = 3 sec.,
selected duty time =
11 sec.
→The duty time is rounded up to 5+3+5 = 13 sec.
8 Maintenance / Service
IMPORTANT
Please observe the safety regulations in chapter 2 when servic
ing
the device.
If the timer is continually subjected to atmospheric influences the seal in the cover
and the electric lines should be regularly checked (at least every 6 months) for signs
of porosity.
All other parts are maintenance-free.
9 Troubleshooting
DANGER
ATTENTION:
Troubleshooting of AP 117 electronic timers should only be conduct
ed
by an authorized specialist.
Fault
Possible causes
Troubleshooting
Remedy
Timer does
not start
Phase interruption Check fuses and con-
nection cables Replace fuse or connection cable
Supply voltage too
low Check supply voltage and cables Use correct supply voltage
Cable wires have
been connected po-
larity-reversed
Check polarity
Connect cable
wires with correct
polarity
Timer fails
when operat-
ing in „RUN”
Voltage drop under
load Check supply connec- tion Use correct supply voltage

16
10 Waste disposal
Material specifications:
Electronic timer AP 117
Polycarbonate
Housing
Cover
ENVIRONMENTALLY
FRIENDLY DISPOSAL
All devices can be disposed of through Netter GmbH.
The applicable disposal prices are available upon request.
11 Enclosures
Enclosure(s):
Declaration of Conformity
IMPORTANT
Additional information available
upon request:
Leaflet No. 35, etc.
