NETVIO EX-HT2-401-10 User manual

 Maintain twists within the Cat5e/Cat6/Cat7 cores up to the point of termination.
 Maintain gradual bends when installing category cable, ensuring a minimum radius of 25mm where possible. Avoid sharp bends or twists
in the cable avoiding taught or stretched cable at all times.
 When dressing the cable use moderate to low pressure, avoiding pinching of the cable jacket.
 Do not splice, join or bridge the cable at anytime, as this will undoubtedly cause transmission issues.
 Use moderate to low pressure when pulling category cable avoiding pressures in excess of 25 lbs (of force).
 Keep category cable away from sources of EMI (electrical cables, transformers, light fixtures) ensuring a minimum parallel distance of
300mm, crossing at right angles if absolutely necessary.
 Ensure cable is correctly tested, understanding that a basic continuity check may not be sufficient to identify issues or to certify cable
performance.
 Always check local regulations relating to building and fire codes.
 Advertised cable distances are there for a guidance. Many factors can effect
transmission distances including cable construction, quality, install standards,
patch panels, faceplates and external factors such as electrical magnetic
interference (EMI).
 This product is designed to run over unshielded twisted pair Cat5e/6/7 cable.
Some consideration is required when installing shielded (STP) category cable
ensuring all drain wires and shielding materials are correctly grounded.
 All RJ45 terminations should follow EIA/TIA-568-B terminations and not simply
wired Pin 1-1, Pin 2-2.The 568-B standard involves the splitting of the green
pair to pins 3 & 6.
BOX CONTENTS
 Netvio HDBaseT TX & RX Device.
 2x Wall mount brackets
 2x Infrared receiver (capture) cables
 2x Infrared emitter (sender) cables
 2x 3-way screw termination connectors
 1x Compatible plug-in PSU
WARRANTY INFORMATION
 2-Year standard parts & labour warranty
 FREE 3-Year warranty subject to product registration.
 5-Year & 10-Year extended warranty options available.
 Full warranty details including coverage, registration &
warranty extensions available at www.netvio.co.uk
Thank you for purchasing this Netvio product. The quick-start-guide is designed
to provide all required information to install your product successfully, ensuring
correct installation standards, therefore guaranteeing performance in
accordance with published features and specifications. Netvio therefore greatly
appreciates your time in reviewing the provided information and following our
recommended guidelines.
Entry level 4K HDBaseT Extender over single category cable. Capable of
sending many popular 4K/30 HDR sources. Compact yet powerful
extender solution.
PRODUCT SUPPORT
Please contact your authorised Netvio reseller.
 UK/EMEA Support | [phone]
 US Support | [phone]
 Email | [email protected]
 Live Chat | www.netvio.co.uk
EX-HT2-401-10_QSG_V4_020821

IR Signal
Power
Ground
IR Receiver
(Remote Signal
Capture)
/
Anode
Cathode
IR Emitter
(Remote Signal
Sender)
1A B C D E F
1 A BC D E F
Power Status LED
DC 24V Power In
HDBaseT Output (from source)
1
HDMI (Source) Input
IR Capture Port
IR Sender Port
RS-232 Pass Through
D
E
F
Each Netvio extender kit comes complete with all required accessories to fully maximise product features and functionality. We
recommend the use of Netvio approved IR accessories to ensure guaranteed performance and compatibility. In perfect conditions, IR
performance is rated at 8m from display to remote control, but understanding this will vary in differing light conditions. It may be necessary
to adjust both the capture, sender device positions to achieve best performance, ensuring that remote batteries are in good condition.
Should IR ports require connections to a 3
rd
party device, the following wiring diagrams are provided to ensure successful signal transfer.
EX-HT2-401-10_QSG_V4_020821
Secure hardwired bi-directional
serial control between source
and display. Extender kit comes
complete with 3-Pin screw type
connectors for ease of install.
Connect TX to RX, RX to TX and SG to ground
when connecting to 3
rd
party devices.
A
B
C
Power Status LED
DC 24V Power In
HDBaseT Input (from display)
1
HDMI Display) Output
IR Capture Port
IR Sender Port
RS-232 Pass Through
D
E
F
A
B
C

HDMI 10.2 Gbp | HDBaseT 10.2Gbs
3840x2160 30fps HDR 8b 4:4:4
300MHz
HDR10, HDR10+, Hybrid Log-Gamma, Dolby Vision
Inclusive up to 2.2
Automatic | HDMI sink from RX to TX
LPCM 2ch, LPCM 5.1, LPCM 7.1, Dolby Digital, Dolby Digital Plus, Dolby TrueHD, DTS,
DTS Master, Dolby Atmos, DTS:X.
Pass-thru subject to source and display compatibility
-20°C / +60°C | 20% - 90% RH
0°C / 40°C | 20% - 90% RH
2-Way, Bi-Directional 24v PoC power over HDBaseT. 1x PSU at either TX or RX
160g| H: 17mm | W: 115mm | D: 65mm
CE | UKCA | FCC | RoHS
2-Yr Standard, 3-Yr with registration, 5-Yr & 10-Yr extended warranty available.
Encoding Data Rates
Video Resolutions (Max)
Max Pixel Clock
HDR
HDCP
EDID
Audio Formats
CEC
Storage
Operating
Power
Weight | Dimensions
Regulations
Warranty
2
Solid | HDMI with HDCP
Flashing | HDMI no HDCP
Dark | No Connection
1
Solid | Good Connection
Flashing | Poor Connection
Dark | No Connection
Attempts to remove product casings could result in electrical shock. Please do not attempt to repair the device. In the event of product service
requirements, please contact Netvio Ltd or an authorised reseller for service procedures. Any unauthorised attempt to repair the product or
attempts to replace components with non-approved parts will invalidate the product warranty. For full warranty conditions, please visit
www.netvio.co.uk
Please dispose and recycle responsibly in accordance with local laws and regulations
Ability to connect a single PSU to
either transmitter or receiver adding
extra convenience to your install. 24V
PoC is standardardised accross all
Netvio HDBaseT products.
EX-HT2-401-10_QSG_V4_020821
1 2
HDBaseT provides useful troubling shooting
status indicators showing status of connection
and source content.
Cost effective 5-yr (for 5%) and 10-yr (for 10%) extended
warranties available at
www.netvio.co.uk/safeguard

Netvio Ltd – INFOLAB21, Lancaster University, Bailrigg Road, Lancaster, LA1 4WA, UK
EX-TS-401-10_QSG_V4_020821
