Specifications
Environment Unbalanced line-level analog audio.
Devices DVD players, audio receivers, audio amplifiers and
audio mixers, audio matrix switchers and other
unbalanced line-level audio equipment.
Transmission Transparent to the user
Bandwidth 20 Hz to 20 kHz
Peripherals’ Impedance Source 100 ΩMx, Receiver 10 kΩmin.
Insertion Loss Less than 2 dB per pair over the frequency range
Common Mode Rejection Ratio Greater than 60 dB at 1 kHz
THD Less then 0.007% @ 1 kHz
Maximum Input Level 1.1 Vp-p
Impedance Transformation Ratio Single unit: 4:1 (source: line)
Cable: Cat 5E UTP/STP 24 AWG or lower solid copper twisted pair wire
Impedance: 100 ohms at 1 MHz
Maximum capacitance: 20 pf/ft
Attenuation: 6.6 dB/1,000 ft at 1 MHz
Unbalanced In/ Out Cable Shielded, coaxial
Ground Loop Isolation Range of +/-50VDC
Connectors Four (4) RCA-F receptacles for audio
One (1) RJ45 jack
Pin Configuration Audio 1: Pins 7(R) & 8(T)
Audio 2: Pins 3(R) & 6(T)
Audio 3: Pins 4(R) & 5(T)
Audio 4: Pins 1(R) & 2(T)
Max. Distance:
Cat 5E/6 UTP/STP 3,250 ft (1.0 km)
Temperature Operating: 0° to 55°C
Storage: -20° to 85°C
Humidity: Up to 95% non-condensing
Enclosure Fire retardant plastic
Weight 4.8 oz. (136 g)
Dimensions 86 mm x 86 mm x 36 mm. Choose 40 mm deep back
box to allow for Cat 5E/6 wiring connection.
Warranty Lifetime
Order Information 500033-WP-UK Quad Audio WallPlate Balun
UPC: 6-27699-91033-7
Quad Audio Wall Balun
500033-WP-UK
Quick Installation Guide
Overview
The Quad Audio Wall Balun (500033-WP-UK) allows up to four (4) analog line audio
signals to be transmitted via a single Cat 5E/6 cable in a point-to-point connection. Used in
pairs, or in conjunction with the 500033, the Quad Audio Wall Balun features full audio
bandwidth response for high fidelity applications and features built-in color-coded RCA
connectors for ease of installation. The Quad Audio Wall Balun also works in conjunction
with other MuxLab analog audio baluns such as the 500019. Applications include; Audio
distribution, high-fidelity sound systems, and custom residential audio systems.
Installation
One (1) pair of baluns is needed to complete one quad audio connection via Cat 5E/6 twisted
pair. To install the baluns, perform the following steps:
1. Identify the pin configuration of the baluns. One (1) twisted
pair is required for four (4) analog line audio signals. The pin
configuration follows the EIA/TIA 568A/B standard. The
Quad Audio Video Balun is reverse polarity sensitive. Please
ensure that wiring is straight-through (Ring to Ring, Tip to
Tip).

© MuxLab Inc. 2011
2. To install the balun in a single back box, choose a back box
with a depth of 40 mm or more. Connect the RJ45 plug into
the rear of the balun. Secure the balun with the 2 front screws.
3. Plug one (1) balun into the stereo audio outputs of the video
source(s) according to the color code of the RCA connectors.
4. Plug the second balun into the stereo audio inputs of the receiver(s) at the remote end.
5. Complete the connection between the two baluns, using standard Cat 5E/6 twisted pair
cable and connecting hardware, terminated by RJ45 plugs at both ends. Ensure that
there are no split pairs or taps.
6. Power-on the audio equipment. The audio should be clear within the maximum
specified distances. The following diagram shows a typical configuration.
7. To mount the wall plate balun in a gang plate, you must first remove the 4 rear screws,
then remove the balun. Next unclip the balun front plastic panel.
8. Clip the front plastic panel to a standard gang plate and secure the
balun using its 4 screws. Multiple wall baluns can be mounted side
by side on a gang plate.
Front view Side view Rear view
Troubleshooting
The following tables describe some of the symptoms, probable causes and possible
solutions in respect to the installation of the Quad Audio Balun. If you still cannot
diagnose the problem, please call MuxLab Customer Technical Support at 877-689-
5228 (toll-free in North America) or ([phone] (International).
Symptom Probable Cause Possible Solutions
Poor Quality Audio
EMI interference Check that wiring is not too close to transformers
and ballasts.
Split pair Check if the UTP pairs are split and correct.
Each signal pair must be twisted.
No Audio
Power-off Check power supply.
Open contact Check wiring to ensure continuity.
Defective Audio Balun Change Audio Baluns for another pair.
Weak Audio
Distance exceeds specs
Check DC loop resistance and verify if distance
spec is exceeded.
Reduce cable length or eliminate high-loss
components.
Lower grade UTP cable
is introducing high
signal losses.
Use signal repeater for extended distance.
Replace cable by higher grade.
