New Air NPR080GA00 User manual

Portable 80 Quart 12V Electric
Cooler
SKU: NPR080GA00
OWNERS MANUAL
Read and save these instructions.
Manual v1.0

2
newair.com
READ AND SAVE THESE INSTRUCTIONS.
TABLE OF CONTENTS
Register Your Product Online............................................................................... 3
Safety Information & Warnings ...........................................................................4
Parts List............................................................................................................ 5
Electrical Circuit Diagram..................................................................................... 7
Operating Instructions………………………………………………………………………………………7
Cleaning & Storage.............................................................................................10
Troubleshooting.................................................................................................11
Limited Manufacturer’s Warranty.....................................................................13
SPECIFICATIONS
MODEL NO.
NPR080GA00
VOLTAGE:
(DC) 12/24V or (AC) 100/240V
POWER CONSUMPTION:
80 W
STORAGE CAPACITY:
80 quarts
TEMPERATURE RANGE:
-4°F - 68°F
REFRIGERANT:
R600a (1.41 Oz)
NOISE EMISSION:
<45dB
DIMENSIONS:
37.5” W x 21” D x 18.5" H
WEIGHT:
49lbs

3
newair.com
REGISTER YOUR PRODUCT ONLINE
Register Your NewAir Product Online Today!
Take advantage of all the benefits product registration has to offer:
Service and Support
Diagnose troubleshooting and service issues faster and more
accurately
Recall Notifications
Stay up to date for safety, system updates and recall notifications
Special Promotions
Opt-in for NewAir promotions and offers
Registering your product information online is safe & secure and takes less
than 2 minutes to complete:
Alternatively, we recommend you attach a copy of your sales receipt below and
record the following information, located on the manufacturer’s nameplate on
the rear of the unit. You will need this information if it becomes necessary to
contact the manufacturer for service inquiries.
Date of Purchase: ___________________________________________
Serial Number: ____________________________________________
Model Number: ____________________________________________
newair.com/register

4
newair.com
SAFETY INFORMATION & WARNINGS
To prevent damage to your product or injury to yourself or to others,
read the following safety precautions in their entirety before using
this electric cooler.
•Do not put any electrical devices inside the electric cooler as they could
damage the electric cooler.
•Do not soak the electric cooler in water.
•Do not turn upside down to drain.
•Do not allow children to play with or inside the electric cooler.
•Do not use the electric cooler if malfunctions such as smoke, overheating,
leakage or similar occur.
•Do not attempt to repair or replace any part of your cooler unless it is
specifically recommended in this manual. All other servicing should only be
performed by a qualified technician.
•Use a wet cloth to clean your electric cooler before use.
•Make sure the voltage is within the proper range for the socket and cable
being used.
•Contact customer service if you have any issues with your appliance.

5
newair.com
PARTS LIST
PRODUCT FEATURES
•Durable DC compressor and compressor module.
•Fast cooling to -4°F (-20°C) when ambient room temperature is 77°F (25°C).
•3-stage low voltage battery protection.
•CFC free and low energy consumption.
•(DC) 12/24V or (AC) 100/240V with adapter power supply.
•Robust wheels and stretchable handle.
•Dual zone for cooling and freezing.
•LCD display for temperature setting.

6
newair.com
REVERSING DOOR INSTRUCTIONS

7
newair.com
ELECTRICAL CIRCUIT DIAGRAM

8
newair.com
OPERATING INSTRUCTIONS
CONTROL PANEL SETTINGS
Plugging it in: Connect the (DC) 12/24V or (AC) 100/240V with a power adapter.
The unit will buzz/beep and the display screen will light up for 2 seconds,
entering regular operation mode.
USB charging port: +5V DC/1A, suitable for small devices like mobile phones or
tablets.
Turning it on: Press to switch the electric cooler on/off.
Adjusting the temperature: Press the button "+" or "—" until the figure on the
screen begins flashing, then you can adjust the temperature by "+" or “—” If you
stop holding the button for 4 seconds, the temperature will set.
Left zone: Press "+" or "—" to adjust temperature.
Right zone: Press"—" followed by . Then press "+" or "—" to adjust
temperature.
Note: the displayed temperature is the current temperature of the dual zones.
If the set temperatures are much higher or lower than the original
temperature, the display screen will not present the set temperature
immediately and will only do so once the dual zones reach the set
temperature.
Unlocking the control panel: Control panel will lock automatically after 20
seconds without touching any button. To unlock press “+” and “- “together for
2 seconds (the circle in the screen will change from clockwise to
counterclockwise once unlocked).

9
newair.com
Cooling Mode: press to switch the cooling mode between MAX (fast cooling) and
ECO (Economical).
ECO mode: the compressor will cool down at a slower rate to save energy.
MAX mode: the compressor will cool down at a faster rate consuming more energy.
Battery Protection Setting: hold over 3 seconds until screen flashes, then press
again to select battery protection setting from L (Low), M (Medium), H (High).
•The default setting is H (High) mode.
•When the electric cooler is powered by the car battery, it is
recommended to set H mode.
Temperature Unit Setting: Press to turn off the electric cooler, then press
over 3 seconds until E1 shows on the screen. Press until screen shows E5. When
the screen flashes, press "+" or"—" to change the unit between Celsius (°C) and
Fahrenheit (°F).
Note: the default temperature setting is Celsius.
Reset Setting: Power off the electric cooler by holding the setting button until
E1 is displayed on the screen. Hold the button "+" and "—" until the screen lights
up as follow:

10
newair.com
CLEANING & STORAGE
CLEANING INSTRUCTIONS
1. Unplug your cooler to avoid electric shock.
2. Remove the cover from the drain hole.
3. Use a wet cloth to clean the electric cooler and then use a dry cloth to dry it.
WARNING: Do not soak the electric cooler in water to clean it. This could
damage the unit.
LONG-TERM STORAGE INSTRUCTIONS
Follow these instructions if you plan on storing the cooler for long periods of
time:
•Turn off the power and unplug the unit from the power source.
•Remove the items stored in the refrigerator.
•Remove all remaining water in electric cooler with a dry cloth.
•Place the electric cooler in a cool and dry place.

11
newair.com
TROUBLESHOOTING
Try the troubleshooting tips below should you experience any problems or call a
NewAir support representative (1-855-963-9247) for more help or guidance.
Problem
Possible Causes and Solution
The electric
cooler is not
working.
•The plug and socket are not connected properly.
•The fuse has been burnt.
•The compressor protection mode may be on. Wait
3mins before turning the electric cooler on.
Cooler
compartments
are too warm.
•The door is opened frequently.
•A large amount of warm or hot food has been stored
recently. The cooler will eventually reach the desired
temperature.
•The cooler has been disconnected for a period of time;
it will reach the desired temperature eventually.
Food freezes
inside.
•The set temperature is too low.
The electric
cooler produces
water-like
noises.
•This is regular operation noise caused by the
refrigerant’s flow.
The electric
cooler is noisy
when starting.
•Humming like noises are common and caused by the
working compressor. The noise will be reduced after
running for a few minutes.
There is water
drops around
the refrigerator
casing or door
gap.
•It is naturally condensed water that drops when
moisture in the air meets the lower temperature of
the inner zones.
Code F1 is on
the display
panel
•This is the protection mode for a low voltage car.
Unplugging the adaptor from the car and connecting
to another power source is recommended if F1 shows
up, then set the battery protection mode from H to M
or from M to L.

12
newair.com
Problem
Possible Causes and Solution
Code F2 is on
the display
panel
•This is the protection mode for an overloaded fan.
Turn the electric cooler off and restart it after 30mins.
Code F3 is on
the display
panel
•This is the protection mode for a frequently restarted
compressor. Turn the electric cooler off and restart it
after 30 minutes.
Code F4 is on
the display
panel
•This is the protection mode for and overloaded
compressor that is working at a low speed. Please turn
it off and restart it after 30 minutes.
Code F5 is on
the display
panel
•This is warning code for an overheated compressor
module. Move the electric cooler to a ventilated area,
turn it off and restart it after 30mins.
Code F6 is on
the display
panel
•This warning code means no parameter can be
detected by the controller. Restart the electric cooler.
If this code shows again, please contact after-sale
department.
Code F7&F8 are
on the display
panel
•This is the error code for temperature sensor. Please
contact customer service for more details.

13
newair.com
LIMITED MANUFACTURER’S WARRANTY
This appliance is covered by a limited manufacturer’s warranty. For one year from the
original date of purchase, the manufacturer will repair or replace any parts of this
appliance that prove to be defective in materials and workmanship, provided the
appliance has been used under normal operating conditions as intended by the
manufacturer.
Warranty Terms:
During the first year, any components of this appliance found to be defective due to
materials or workmanship will be repaired or replaced, at the manufacturer’s discretion,
at no charge to the original purchaser. The purchaser will be responsible for any removal
or transportation costs.
Warranty Exclusions:
The warranty will not apply if damage is caused by any of the following:
•Power failure
•Damage in transit or when moving the appliance
•Improper power supply such as low voltage, defective household wiring or
inadequate fuses
•Accident, alteration, misuse or abuse of the appliance such as using non-
approved accessories, inadequate air circulation in the room or abnormal
operating conditions (extreme temperatures)
•Use in commercial or industrial applications
•Fire, water damage, theft, war, riot, hostility or acts of God such as hurricanes,
floods, etc.
•Use of force or damage caused by external influences
•Partially or completely dismantled appliances
•Excess wear and tear by the user
Obtaining Service:
When making a warranty claim, please have the original bill of purchase with purchase
date available. Once confirmed that your appliance is eligible for warranty service, all
repairs will be performed by a NewAir™ authorized repair facility. The purchaser will be
responsible for any removal or transportation costs. Replacement parts and/or units will
be new, re-manufactured or refurbished and is subject to the manufacturer’s discretion.
For technical support and warranty service, please email [email protected].
