New Air AI-215 Series User manual

Portable Ice Maker
AI-215 Series
OWNERS MANUAL
Read and save these instructions.
.

2
http://www.NewAir.com
A Name You Can Trust
Trust has to be earned and we will earn yours. Customer happiness is
the focus of our business.
From the factory to the warehouse, from the sales floor to your home,
the whole NewAir family promises to provide you with innovative
products, exceptional service, and support when you need it the most.
Count on NewAir.
As a proud NewAir owner, welcome to our family. There are no robots
here, real people shipped your product and real people are here to help
you.
Thank you for your purchase and remember NewAir, A Name You Can
Trust.
Call us today at 855-963-9247
Or email [email protected]
For future reference, we recommend you attach a copy of your sales receipt
here and record the following information. You will need this information if it
becomes necessary to contact the manufacturer for service inquiries.
Date of Purchase: ___________________________________
Serial Number: ___________________________________
Model Number: ___________________________________
Connect with us online.

3
Love Your Home
READ AND SAVE THESE INSTRUCTIONS.
TABLE OF CONTENTS
Safety Information & Warnings ........................................................................... 4
Parts List............................................................................................................... 5
Basic Parts Diagram ..................................................................................... 5
Control Panel Diagram ................................................................................. 6
Assembly & Installation ....................................................................................... 7
Operating Instructions ......................................................................................... 8
Making Ice.................................................................................................... 8
Using the Timer............................................................................................ 9
Cleaning & Maintenance.................................................................................... 10
Storage............................................................................................................... 11
Troubleshooting................................................................................................. 11
Limited Manufacturer’s Warranty ..................................................................... 13
SPECIFICATIONS
MODEL NO.
AI-215
RATED VOLTAGE:
115V / 60Hz
CURRENT:
2.1/3.2 amps
POWER CONSUMPTION:
170 watts
CAPACITY (DAILY):
50 pounds
CAPACITY (PER CYCLE):
12 pieces
ICE SIZES:
3

4
http://www.NewAir.com
SAFETY INFORMATION & WARNINGS
As with any electrical appliance, basic safety precautions must be
followed in order to reduce the risk of fire, electrical shock
and/or injury to persons or property. Be sure to read all
instructions before using this appliance and observe the
following safety tips:
Do not operate this appliance if it has a damaged cord.
Only connect the ice maker to a properly polarized outlet. No other
appliance should be plugged into the same outlet. Make sure the plug is
fully inserted into the receptacle.
An extension cord is not recommended, as it may overheat and become a
fire risk. If necessary, use an extension cord with a minimum size of No. 14
AWG and rated for no less than 1875 watts.
Do not place hands or objects on or near the ice maker’s evaporator when
it is in operation.
Do not run the power cord over carpeting or heat insulators. Do not cover
the cord. Keep the cord away from high traffic areas and never submerge it
in water.
Always turn off and unplug the ice maker from the power supply before
cleaning and servicing.
Do not use your ice maker outdoors.
Do not use liquids other than water to make ice cubes.
Exercise caution and make sure there is supervision when this appliance is
being used near children.
If the ice maker is brought in from the outside in the winter, allow the ice
maker to warm up to your room’s temperature for a few hours before
plugging it in.
Do not clean your ice maker with flammable fluids. The fumes can create a
fire hazard or cause an explosion.

5
Love Your Home
PARTS LIST
BASIC PARTS DIAGRAM
1
6
5
2
4
7
3
Do not touch the
evaporator while the
unit is in use or during
the ice making process.
It may cause severe
burning.
1. Cover
2. Control Panel
3. Water Drain Cap
4. Ice Basket
5. Ice Scoop
6. Ice Shovel
7. Handle

6
http://www.NewAir.com
CONTROL PANEL DIAGRAM
BUTTONS:
ON/OFF –Use to start or stop the unit
SELECT - Selects ice size
TIMER –Set or cancel timer (refer to page 9)
CLEAN –Begin self-cleaning function (refer to page 7)
LCD DISPLAY SYMBOLS:
Power indicator
Ice Bucket Full Indicator
Ice size selected
(small, medium
or large)
Add Water Indicator
(flashes when water
needs to be added)
Timer display
Warning Indicator –
problem with unit
Self-Cleaning Indicator

7
Love Your Home
ASSEMBLY & INSTALLATION
1. Remove the exterior and interior packaging. Check that the ice basket and
ice scoop are included. If any parts are missing, please contact customer
service.
2. Clean the interior with lukewarm water and a soft cloth. Take out the ice
basket and clean it.
3. Place your ice maker in a location that is protected from direct sunlight and
other heat sources (e.g., stove, furnace, and radiator). Make sure it is on a
level surface with at least 4 inches of space between the back and sides of
the unit and the wall.
4. Allow two hours for the refrigerant fluid to settle in the compressor before
plugging the ice maker in.
NOTICE: After unpacking your ice maker, it must
rest in an upright position for at least two hours
before you plug it in or the compressor may be
damaged, shortening the life span of the unit.
5. Plug your appliance into an exclusive, properly installed and grounded wall
outlet. Do not under any circumstances cut or remove the third (ground)
prong from the power cord. Any questions concerning power and/or
grounding should be directed to a certified electrician.
We recommend you clean your ice maker thoroughly before using it. Please
see Cleaning & Maintenance on page 10 of this guide.

8
http://www.NewAir.com
OPERATING INSTRUCTIONS
MAKING ICE
1. Open the unit’s cover, remove the ice basket, and pour water into the
water reservoir. Keep the water level below the “MAX” line marked inside
the reservoir.
2. Plug in the unit to the grounded power supply outlet.
3. Press the “ON/OFF” button on the control panel to begin the ice making
cycle.
4. Select the size of the ice cube by pressing the “SELECT” button. If the room
temperature is lower than 60°F, it is recommended to select small or
medium ice in order to avoid the ice sticking together.
5. The ice making cycle lasts anywhere from 7 to 13 minutes, depending on
the size of the ice cubes you select and the ambient room temperature. Ice
making time may vary significantly in extremely high room temperatures.
6. Periodically verify the water level in the water reservoir when the ice
maker is on. If the water level is too low, the ice maker will automatically
stop and the “Add Water” indictor light will flash in the LCD display
window. Press the “POWER” button to stop the unit and unplug it. Fill the
reservoir with water up to the level mark. Plug it in and press the “POWER”
button again to restart the unit. Allow at least 3 minutes for the
refrigerant inside the compressor to settle before restarting.
7. The ice maker automatically stops working when the ice basket is full. The
“Ice Bucket Full”indicator will also turn on at this time.
8. Change the water in the reservoir every 24 hours to ensure hygienic ice. If
the ice maker will not be used for an extended period of time, drain the
water from the reservoir by unplugging the drain off cap located on the
side of the ice maker.

9
Love Your Home
USING THE TIMER
How to Set the ON-TIMER Program
When the unit is off, you can program the timer to start the unit after a set
number of hours.
1. Press the TIMER button on the control panel. “1.0H” will flash in the
Timer Set Display Window.
2. Press the SELECT button to set the Timer delay to a time between 1.0
and 18.0 hours, in half hour increments.
3. After the desired time is set, the display will show the time remaining
and will decrease in 0.1 hour increments. When the timer reaches
ZERO and disappears, the unit will start to run automatically according
to your settings.
To cancel when the time is set but not yet running, press the TIMER button
twice to cancel it.
How to Set the OFF-TIMER Program
When the unit is on, program the OFF-TIMER to stop the unit after a set time.
1. Press the TIMER button on the control panel. “1.0H” will flash in the
Timer Set Display Window.
2. Press the SELECT button to set the Timer delay to a time between 1.0
and 18.0 hours, in half hour increments.
3. After the desired time is set, the display will show the time remaining
and will decrease in 0.1 hour increments. When the timer reaches
ZERO and disappears, the unit will stop running automatically.
To cancel while the unit is running, press the TIMER button twice to cancel the
TIMER-OFF setting.

10
http://www.NewAir.com
CLEANING & MAINTENANCE
Clean the outside of the ice maker with a mild detergent solution and warm
water. Use a soft cloth to wipe to avoid scratching or damaging the surface of
the unit.
Use the unit’s self-clean function to clean the interior of the unit:
1. Remove the ice basket.
2. Add 1:1 mixture of water and vinegar.
3. Plug in the unit. Hold down the CLEAN button for at least 6 seconds and
release. The unit will automatically enter the self-clean program. This
process will last about 5-6 minutes, after which the unit will automatically
power down again. During this process the “Add Water Indicator” and the
“Self Cleaning Indicator” will light in the LCD display window, and the fan
blades in the self-clean symbol will always rotate. This process will rinse
the inside parts of the ice maker thoroughly.
4. After the self-clean program is completed, drain out the water by
unplugging the drain cap on the side. Then close the drain cap.
5. Unplug the unit and add fresh water into the interior tank, up to the water
level mark.
6. Re-plug the unit to the power supply, and rerun the self-cleaning program
again as described in Step 3.
7. When the self-cleaning program is completed, unplug the unit and drain
out the water by unplugging the drain cap on the side.
8. Dry the interior and exterior with a soft cloth.
9. Tighten the drain cap. Replace the ice basket and plug the unit in again.
To remove the build-up of calcium or other impurities, add a capful of vinegar
or lemon juice to the water in the reservoir and run for two or three ice-making
cycles. Drain and refill the reservoir with clean, warm water. Run two more
cycles to rinse the vinegar or lemon-juice.
When the machine is not in use open the water drain cap to completely drain
the water reservoir.

11
Love Your Home
STORAGE
Before storing your ice maker, clean it according to the directions above and
allow it to dry thoroughly –at least 24 hours –in order to prevent the growth
of mold or mildew.
Store your ice maker in the original packaging, or cover with a soft cloth or
plastic sheet.
TROUBLESHOOTING
Problem
Possible Cause
Solution
The “ADD WATER”
indicator light is on.
There is not enough
water in the tank.
Press “POWER” to turn
off the unit. Fill the
reservoir with water.
Press “POWER” to
restart.
The “ICE BUCKET FULL”
indicator light is on.
The ice basket is full.
Remove ice from the
basket.
The “WARNING”
indicator light is on.
Ice shovel cannot
rotate.
Check if ice cubes are
blocking the ice shovel;
otherwise, consult a
certified technician to
check the motor and
micro switch.
The “WARNING”
indicator flashes for 20
seconds when starting
or during operation.
Ice-full detecting
sensor on the edge of
interior tank is
malfunctioning.
Consult a qualified
technician to check the
sensor or change to a
new one.
Ice cubes stick together.
The ice cycle is too
long.
Stop the ice maker and
allow ice block to melt.
Select smaller size and
restart.
Water temperature in
inner tank is too low.
Change the water in the
inner tank. Temperature
of water is best between
45°F - 90°F.

12
http://www.NewAir.com
Problem
Possible Cause
Solution
The ice making cycle
appears to be normal
but no ice is being
produced.
The refrigerant may be
leaking.
Consult a qualified
technician.
A pipe in the cooling
system may be
blocked.
Consult a qualified
technician.
Ambient temperature
or water temperature
in inner tank is too
high.
Please run the ice maker
below 90°F and pour
colder water into the
tank.
The ice cubes are too
small.
The ambient
temperature or water
temperature may be
too high.
Select large sized ice
cubes by pressing the
“SELECT” button.
The compressor may
need to warm up.
If this is the first time the
unit is being used, allow
the ice maker to cycle a
few times. This should
result in larger cubes.
The ice has a “plastic”
taste.
The unit’s interior may
need to be cleaned.
Add a tablespoon of
lemon juice or vinegar to
a full tank of water and
allow the ice maker to
cycle a few times.
The unit produces a
large block of ice instead
of cubes.
The ambient
temperature may be
too low.
Unplug the unit and let
the ice thaw out. Allow
the ice maker to defrost
for a few hours and
restart the unit.
The ice cubes have a
cloudy appearance.
There may be trace
minerals in your water
or ice is being
produced too quickly.
Ice cubes may develop
cloudiness when water is
frozen quickly. As ice
develops on the surface
of water, certain gases
can no longer remain
dissolved and begin to
surface as microscopic
bubbles. This cloudiness
is normal.

13
Love Your Home
LIMITED MANUFACTURER’S WARRANTY
This appliance is covered by a limited manufacturer’s warranty. For one year
from the original date of purchase, the manufacturer will repair or replace any
parts of this appliance that prove to be defective in materials and
workmanship, provided the appliance has been used under normal operating
conditions as intended by the manufacturer.
Warranty Terms:
During the first year, any components of this appliance found to be defective
due to materials or workmanship will be repaired or replaced, at the
manufacturer’s discretion, at no charge to the original purchaser. The
purchaser will be responsible for any removal or transportation costs.
Warranty Exclusions:
The warranty will not apply if damage is caused by any of the following:
Power failure
Damage in transit or when moving the appliance
Improper power supply such as low voltage, defective household
wiring or inadequate fuses
Accident, alteration, misuse or abuse of the appliance such as using
non-approved accessories, inadequate air circulation in the room or
abnormal operating conditions (extreme temperatures)
Use in commercial or industrial applications
Fire, water damage, theft, war, riot, hostility or acts of God such as
hurricanes, floods, etc.
Use of force or damage caused by external influences
Partially or completely dismantled appliances
Excess wear and tear by the user
Obtaining Service:
When making a warranty claim, please have the original bill of purchase with
purchase date available. Once confirmed that your appliance is eligible for
warranty service, all repairs will be performed by a NewAir™ authorized repair
facility. The purchaser will be responsible for any removal or transportation
costs. Replacement parts and/or units will be new, re-manufactured or
refurbished and is subject to the manufacturer’s discretion. For technical
support and warranty service, please email [email protected].
