New Air NWB080SS00 User manual

Manual v1.1
24” French Door Dual Zone
Wine and Beverage Fridge
SKU: NWB080SS00
OWNER’S MANUAL
Read and save these instructions.
.

2
newair.com
READ AND SAVE THESE INSTRUCTIONS.
TABLE OF CONTENTS
Register Your Product Online............................................................................... 3
Safety Information & Warnings ........................................................................... 4
Assembly Instructions.......................................................................................... 5
Operating Instructions.........................................................................................7
Cleaning & Maintenance...................................................................................... 9
Troubleshooting.................................................................................................10
Limited Manufacturer’s Warranty.....................................................................11
SPECIFICATIONS
MODEL NO.
NWB080SS00
VOLTAGE:
110-120V
CURRENT:
0.9 Amps
REFRIGERANT:
R600a
FREQUENCY:
60Hz
PRODUCT DIMENSIONS:
24.10"D (w/handles) x 23.50"W x 34.30"H
POWER CONSUMPTION:
100 Watts
STORAGE CAPACITY:
20 Bottles & 60 Cans (4.1 cubic feet)
TEMPERATURE RANGE:
36-72° F (beverage, left side)
40-72° F (wine, right side)

3
REGISTER YOUR PRODUCT ONLINE
Register Your NewAir Product Online Today!
Take advantage of all the benefits product registration has to offer:
Service and Support
Diagnose troubleshooting and service issues faster and more
accurately
Recall Notifications
Stay up to date for safety, system updates and recall notifications
Special Promotions
Opt-in for NewAir promotions and offers
Registering your product information online is safe & secure and takes less
than 2 minutes to complete:
Alternatively, we recommend you attach a copy of your sales receipt below and
record the following information, located on the manufacturer’s nameplate on
the rear of the unit. You will need this information if it becomes necessary to
contact the manufacturer for service inquiries.
Date of Purchase: ___________________________________________
Serial Number: ____________________________________________
Model Number: ____________________________________________
newair.com/register

4
newair.com
SAFETY INFORMATION & WARNINGS
Before Using Your Wine And Beverage Fridge for the First Time:
Carefully read all instructions before using this fridge for the first time. Also
make sure the fridge stays in an upright position during transportation. After
removing the appliance from its packaging, make sure it is in good condition,
and let the fridge stand for 24 hours before connecting to power, to allow
refrigerant to settle. If there are any issues with the unit, please contact us
immediately at [email protected].
•Place the unit on a level floor that will be strong enough to support it
when it is at full capacity. To level the fridge, adjust the leveling feet
located at the bottom of the unit.
•Do not use this fridge in applications for which it is not intended.
Damage that occurs from improper use or from unauthorized repairs
will void the warranty.
•For proper air circulation, please maintain a 2-inch minimum clearance
in between the back of the fridge and the wall.
•Do not operate this fridge in excessively moist or humid environments.
•Keep the fridge away from direct sunlight.
•Keep the fridge away from hazardous materials or
combustible/flammable substances.
★CAUTION:
•This wine and beverage fridge is designed for built-in or freestanding
applications.
•DANGER: RISK OF CHILD ENTRAPMENT: An empty fridge can be
dangerous to children. Remove any latches, lids, locks, and/or doors
from unused or discarded appliances to prevent child entrapment and
suffocation. Never allow children to operate, play with, or crawl inside
this appliance.

5
ASSEMBLY INSTRUCTIONS
INITIAL SETUP
Remove exterior and interior packing materials and let the fridge stand for 24
hours before connecting to power, to allow refrigerant to settle. Once it is
plugged in, let it run for at least 30 minutes before stocking. Do not change the
temperature or adjust any settings during this time.
INSTALLATION OF YOUR APPLIANCE
•Use two or more people to move and install the fridge. Failure to do so can
result in back or other injury.
•Place your fridge on a floor that is strong enough to support it when it is
fully loaded.
•Choose a well-ventilated area with temperatures above 60℉and below
90℉.
•This fridge is designed for built-in, recessed or freestanding installation.
•For built-in installation, leave a 1/4” (6.35mm) space on each side and at
the top of the fridge to ensure proper air circulation to cool the
compressor and condenser.
•For freestanding installation, leave the proper clearance around the fridge.
Below are the recommended clearances:
Side: 3/4” (19mm); Top: 4” (100mm); Back: 2” (50mm)
•Even for built-in installation, you must keep space on each side and at the
top. If you plan to use the unit for a built-in application please leave at
least 0.25 in of space on all sides.
•The fridge must be installed with all electrical, water and drain connections
in accordance with state and local codes.
•Make certain that the pipes are not pinched, kinked or damaged during
installation. Check for leaks after connection.

6
newair.com
NOTE: Designed for indoor, home use only. The fridge should not be located next to
sources of high heat or in direct sunlight. Do not store or install the fridge
outdoors, in a garage, basement or in moist areas. Don’t install in a location
where the temperature will fall below 60℉. For best performance and to ensure
proper ventilation, do not install the fridge behind a cabinet door or block the
ventilation grille at the bottom of the front of the unit.
HANDLE INSTALLATION
•Pull away the door gasket in the area where the handle is to be installed.
The gasket is easily removed by hand, no tools are necessary. It does not
need to be cut or removed completely.
•Insert the two (2) Phillips head screws with the lock washers and flat
washers through the gasket side of the door frame until the screws pass
through the door frame.
•Align the handle with the screws installed in the above step. Tighten the
screws using a Phillips head screwdriver until the handles secure tightly
against the door frame. (Do NOT over tighten) Replace the gasket.

7
OPERATING INSTRUCTIONS
Press the power button to turn the fridge on and off, even while the unit is
plugged in. The fridge will be on by default but pressing and holding the power
button for 5 seconds will shut it off. This feature is handy if you want to shut
the unit off but are unable to reach the plug. Press and hold for 5 seconds to
turn the fridge back on.
Press the light buttons to switch between “auto” lighting and “always on”
lighting. Auto lighting is the default setting, which keeps the lights off when the
door is closed. Lights will only turn on when a door is opened. Press the button
once to keep the lights on even when the doors are closed.
Press the up and down arrows to adjust the temperature for each zone in one
degree increments. The left zone temperature can be set between 36°and
72℉, and the right zone temperature can be set between 40°and 72℉. To view
the current set temperature, press the up or down arrow once.
Press the C/F button to change between Celsius and Fahrenheit for the
temperature display.
LEFT
ZONE
RIGHT
ZONE

8
newair.com
NOTE: If the unit is unplugged, turned off, or power is lost, you must wait 3
to 5 minutes before restarting the unit. If you attempt to restart before this
time delay, the unit will not start. When you use the unit for the first time or
restart the unit after having been shut off for a long time, there could be a
few degrees of variance between the temperature you select and the
ambient temperature indicated on the LED readout. This is normal. Once the
unit is running for a few hours, temperatures will stabilize.
DOOR LOCK
Your unit comes with a lock and key. The keys are located inside the plastic bag
that contains the owner’s manual. Insert the key into the lock and turn it
counter clockwise to unlock the door. To lock the door, do the reverse, and
make sure the metal pin is engaged completely. Remove the key and store in a
secure location—you don’t want to get locked out of your own fridge!
SHELVES
To avoid damaging the door gasket, make sure to have the door completely
opened when pulling the shelves out of the unit.
•For easy access to your drinks, we recommend pulling the shelf out until it
stops. Locks on the shelves keep them from falling out due to the weight of
the drinks.
•If you want to remove a shelf entirely, make sure to remove all items first.
Then, move the shelf to the position where the notch in the shelf is
positioned under the lock (a small round peg on each side that prevents
the shelves from falling out). Lift the shelf so that the notch passes over
the lock, then remove the shelf. Do the reverse to reinsert the shelf.

9
OTHER TIPS
•This unit comes equipped with a “door open” alarm, which will start
beeping if one of the doors is left open for more than 3 minutes. If you
hear this alarm, double check to make sure the doors are closed properly.
•To ensure maximum performance and efficiency, be sure to place your
fridge in an area where there is proper air circulation.
•For proper internal air circulation, do not overfill your fridge.
•Do not place the unit in direct sunlight.
•Do not place heated beverages in your fridge.
•Do not store perishable food in your fridge. The unit’s interior temperature
may not be low enough to prevent spoilage.
•Do not place heavy objects on top of the fridge.
CLEANING & MAINTENANCE
•Shut off the power supply before cleaning the fridge.
•Remove all cans and storage shelves.
•Clean the interior with a warm water and neutral detergent solution. Do
the same with the outside of the unit.
•Thoroughly dry all surfaces before plugging the unit in again.
•DO NOT use abrasive cleaners to clean the fridge. Use warm, soapy water
to clean the door gasket.

10
newair.com
TROUBLESHOOTING
Problem
Possible Causes
Solution
The fridge does
not cool.
The unit may be plugged
in using a different
voltage than required.
Check if using the wrong
voltage.
The circuit breaker may
be tripped or there is a
blown fuse.
Reset the circuit breaker or
check for a broken fuse.
The fridge does
not get cold
enough.
The unit may be placed
too close to a heat
source.
Keep the unit away from
direct sunlight or other heat
sources.
There is insufficient
ventilation.
Place the unit in an area with
proper ventilation and
clearances.
The door is not
completely closed or the
door seal is not working
properly.
Close the door tightly. Do not
open the door frequently or
keep the door open for
extended periods.
The fridge seems
to make too much
noise.
The unit is not leveled or
positioned properly.
Adjust the feet and ensure the
product is level on the floor.
There is insufficient
ventilation.
Allow sufficient clearance
around the unit.
The unit is too close to a
wall or other surface.
Allow sufficient clearance
around the unit.

11
Problem
Possible Causes
Solution
Frost is building up
in the unit.
There is excess humidity
or the interior
temperature is too low.
Turn the unit off, unplug it
and remove the frost
manually by letting it thaw, or
using a plastic/rubber pick.
Reconnect once the ice has
thawed.
LIMITED MANUFACTURER’S WARRANTY
This appliance is covered by a limited manufacturer’s warranty. For one year from
the original date of purchase, the manufacturer will repair or replace any parts of
this appliance that prove to be defective in materials and workmanship, provided
the appliance has been used under normal operating conditions as intended by the
manufacturer.
Warranty Terms:
During the first year, any components of this appliance found to be defective due to
materials or workmanship will be repaired or replaced, at the manufacturer’s
discretion, at no charge to the original purchaser. The purchaser will be responsible
for any removal or transportation costs.
Warranty Exclusions:
The warranty will not apply if damage is caused by any of the following:
•Power failure
•Damage in transit or when moving the appliance
•Improper power supply such as low voltage, defective household wiring or
inadequate fuses
•Accident, alteration, misuse or abuse of the appliance such as using non-
approved accessories, inadequate air circulation in the room or abnormal
operating conditions (extreme temperatures)
•Use in commercial or industrial applications
•Fire, water damage, theft, war, riot, hostility or acts of God such as
hurricanes, floods, etc.

12
newair.com
•Use of force or damage caused by external influences
•Partially or completely dismantled appliances
•Excess wear and tear by the user
Obtaining Service:
When making a warranty claim, please have the original bill of purchase with
purchase date available. Once confirmed that your appliance is eligible for warranty
service, all repairs will be performed by a NewAir™ authorized repair facility. The
purchaser will be responsible for any removal or transportation costs. Replacement
parts and/or units will be new, re-manufactured or refurbished and is subject to the
manufacturer’s discretion. For technical support and warranty service, please email
[email protected]
