New Air AB-1200X User manual

Manual v1.3
126-Can Beverage Fridge
AB-1200X
OWNER’S MANUAL
Read and save these instructions.

2
newair.com
A Name You Can Trust
Trust should be earned and we will earn yours. Customer happiness is the focus
of our business.
From the factory to the warehouse, from the sales floor to your home, the
whole NewAir family promises to provide you with innovative products,
exceptional service, and support when you need it the most.
Count on NewAir.
As a proud NewAir owner, welcome to our family. There are no robots here;
real people shipped your product and real people are here to help you.
Contact Us:
For questions regarding your product, please contact us at:
Call:
1-855-963-9247
Email:
[e-mail]
Online:
www.newair.com
Connect with Us:
facebook.com/newairusa instagram.com/newairusa
youtube.com/newairusa twitter.com/newairusa

3
READ AND SAVE THESE INSTRUCTIONS.
TABLE OF CONTENTS
Register Your Product Online............................................................................... 4
Safety Information & Warnings ........................................................................... 5
Parts List/Diagram................................................................................................ 6
Dimensions .................................................................................................. 7
Assembly & Installation ....................................................................................... 7
Reversing The Door...................................................................................... 8
Operating Instructions ......................................................................................... 9
Temperature Adjustment ............................................................................ 9
Optimizing Performance .............................................................................. 9
Cleaning & Maintenance.................................................................................... 10
Cleaning Your Cooler.................................................................................. 10
Defrosting Your Cooler............................................................................... 10
Moving Your Cooler ................................................................................... 10
Troubleshooting................................................................................................. 11
Limited Manufacturer’s Warranty ..................................................................... 13
SPECIFICATIONS
MODEL NO.
AB-1200X
VOLTAGE:
110-120V
CURRENT:
1.3A
FREQUENCY:
60Hz
POWER CONSUMPTION:
85W
CAN CAPACITY:
126 cans
STORAGE CAPACITY:
3.4 cu. ft.
TEMPERATURE RANGE:
34°F - 64°F
REFRIGERANT:
R600a (1.27 oz)

4
newair.com
REGISTER YOUR PRODUCT ONLINE
Register Your Pepsi Product Online Today!
Take advantage of all the benefits product registration has to offer:
Service and Support
Diagnose troubleshooting and service issues faster and more
accurately
Recall Notifications
Stay up to date for safety, system updates and recall notifications
Special Promotions
Opt-in for NewAir promotions and offers
Registering your product information online is safe & secure and takes
less than 2 minutes to complete:
Alternatively, we recommend you attach a copy of your sales receipt below and
record the following information, located on the manufacturer’s nameplate on
the rear of the unit. You will need this information if it becomes necessary to
contact the manufacturer for service inquiries.
Date of Purchase: ___________________________________________
Serial Number: ____________________________________________
Model Number: ____________________________________________
newair.com/register

5
SAFETY INFORMATION & WARNINGS
When using any electrical appliance, basic safety precautions
must be followed in order to reduce the risk of fire, electrical
shock and/or injury to persons or property. Be sure to read all
instructions before using this appliance and observe the
following safety tips:
Attention: Child Entrapment Risk!
To prevent the risk of child entrapment, do not allow children to operate,
play with, or crawl inside the unit. If the unit will not be used for an
extended period of time, keep the door sealed shut (or taped/tied closed)
and leave the shelves in place so that children cannot crawl inside.
Shock Hazard – Electrical Grounding Required
•Never attempt to repair or perform maintenance on the unit while it is
plugged in.
•Never remove the round grounding prong from the plug and never use a
two-prong grounding adaptor.
•Altering or cutting of power cord, plug, or wiring can cause serious injury,
fire, and loss of property and/or life, and will void the warranty.
•Avoid using an extension cord or putting this unit on the same electrical
circuit as another appliance.
•Avoid operating this beverage fridge in excessively moist or humid
environments.
Important Precautions:
•Allow unit to sit upright for 24 hours prior to first use.
•Do not lift the unit by the door handle.
•Never install or operate the unit inside cabinets or without proper
clearances.
•Clean the the condenser every six months to prevent malfunction.
•Do not block any internal fans.
•Keep the beverage fridge away from hazardous or combustible materials.
•Use only replacement parts from the supplier. Do not attempt to service
personally.
•Do not use this unit outdoors.

6
newair.com
PARTS LIST
When you receive your unit, carefully remove the exterior and interior
packaging. It is recommended that you retain the packaging for future use.
Check to make sure the following parts are included:
•6 Shelves (4 Full Size, 1 ¾ Size, 1 Split Shelf)
•1 Instruction Manual
•1 Handle Assembly Kit
PARTS DIAGRAM
1. Temperature Controls
(Inside)
2. Stainless Door Frame
3. Fridge Foot (x4)
4. Door Hinge
5. Interior LED light
6. Shelf
7. Door Lock

7
DIMENSIONS
ASSEMBLY & INSTALLATION
Before connecting the appliance to a power source, let it stand
upright for approximately 2 hours. This will reduce the possibility
of a malfunction in the cooling system from handling during
transportation.
This beverage cooler is a freestanding unit and should not be built into
surrounding cabinetry. Allow for proper air clearance around the cooler. The
recommended clearances are as follows:
Sides: ¾” (19 mm)
Top: 4” (100 mm)
Back: 2” (50 mm)
Before operating your beverage cooler for the first time, follow these steps:
1. Clean the interior surface of the unit with lukewarm water and a soft
cloth.
2. Place the cooler on a level surface that will be strong enough to
support the unit when it is fully loaded. To level your cooler, adjust the
front feet located at the bottom of the unit.
3. Install the cooler away from direct sunlight and heat sources such as
stoves, heaters, or radiators. Direct sunlight may affect the unit’s
acrylic coating, and nearby heat sources can increase electrical
Product Dimensions
Width
18.9 in
Depth
18.5 in
(20.5 in with handle)
Height
33 in
Weight
64.5 lb
Package Dimensions
Width
22.6 in
Depth
22 in
Height
36.6 in
Weight
76.5 lb

8
newair.com
consumption. Extreme cold or hot ambient temperatures may also
prevent proper performance.
4. Once the cooler is plugged in, let the beverage cooler run for at least
30 minutes. Do not change the temperature or adjust any settings at
this time.
ASSEMBLING THE DOOR
1. Remove all packaging from the door handle and screws.
2. Pull back the rubber gasket on the inside of the door, so that the openings
for the screws can be seen.
3. Hold the door handle lined up with the screw holes, and screw them into
the back of the handle from the inside of the door.
4. Once the screws are fully inserted and the handle is snugly attached, press
the rubber gasket back into the door frame.
REVERSING THE DOOR SWING
5. To reverse the door swing of the unit, remove the plastic hinge cover at
top of the unit.
6. Unscrew the door hinge.
7. Flip door upside-down.
8. Attach door to opposite side of unit with screws.
9. Replace plastic door hinge cover.
INSTALLING YOUR SPLIT SHELF
The top zone of the fridge comes with an adjustable split shelf configuration for
your beverages, enabling you to have either a full-sized shelf or a half-sized
shelf to accommodate different sized cans or bottles.
To install, simply remove the first shelf from the top zone of the fridge and
replace with the included half-sized shelf.

9
OPERATING INSTRUCTIONS
TEMPERATURE ADJUSTMENT
1. Thermostat
2. Light Switch
3. Led Light
Your beverage cooler can be set to your desired temperature. The unit’s
temperature range is 34°F to 64°F (1°C to 18°C).
The temperature scale runs from 1, the warmest setting, to 7 the coldest
setting. The 0 position is an OFF setting which can be used when the beverage
cooler is standing empty.
Avoid setting the thermostat too high or the beverage cooler may be unable to
achieve satisfactory cooling temperatures.
OPTIMIZING PERFORMANCE
1
2
3

10
newair.com
•To ensure maximum performance and efficiency, be sure to place your
beverage cooler in an area where there is proper air circulation. (See
Installation instructions above for proper clearances.)
•For proper internal air circulation, do not overfill your beverage cooler.
When storing beverages, keep them away from the rear wall. To allow free
circulation of cold air, don’t pack beverages too tightly on the shelves.
•Do not place the unit in direct sunlight.
•Do not place heated beverages or food in your cooler.
•Do not store perishable food in your beverage cooler. The unit’s interior
temperature may not be low enough to prevent spoilage.
•Do not place heavy objects on top of the beverage cooler.
CLEANING & MAINTENANCE
CLEANING YOUR COOLER
To clean your cooler:
•Unplug the cooler and remove anything inside.
•Wash the inside of the unit with a solution made of warm water and neutral
detergent. Do not use abrasive cleaners.
•Use mild, soapy water to clean the unit’s door seal.
•To ensure efficient operation, also thoroughly clean the back and bottom of
the beverage cooler.
•To clean the outside of the unit, use a mild detergent and warm water.
DEFROSTING YOUR COOLER
To prevent ice buildup on the inside of the beverage cooler, it may be
necessary to defrost occasionally:
1. Turn the temperature control to #4 or #5.
2. Wait 30 to 60 minutes.
3. Turn control knob back to #1 or #2.
If you notice an excess amount of frost buildup inside the unit, follow these
steps to remove it:
1. Unplug the beverage cooler.

11
2. Allow frost to melt from the inside of the cooler. If necessary, use a
plastic utensil to scrape ice from the interior surface.
3. Dry thoroughly before plugging it in again.
MOVING YOUR COOLER
To move your cooler:
•Remove anything stored inside.
•Securely tape down all loose parts located inside the unit.
•Turn the leveling feet up to the base in order to avoid damage.
•Tape the door shut.
•Be sure the cooler stays in an upright position during transportation.
TROUBLESHOOTING
Problem
Possible Causes
Solution
The beverage cooler
does not cool.
The unit may be
plugged in using a
different voltage.
Check if using the wrong
voltage.
The circuit breaker may
be tripped or there is a
blown fuse.
Reset the circuit breaker
or check for a broken
fuse.
The beverage cooler
is not cold enough.
The external
environment may
require a higher setting.
Lower the temperature
of the cooler.
The cooler may be
placed too close to a
heat source.
Keep the cooler away
from direct sunlight or
other heat sources.
There is insufficient
ventilation.
Place the beverage
cooler in an area with
proper ventilation and
clearances.
The door is not
completely closed or
the door seal is not
working properly.
Close the door tightly.
Do not open the door
frequently and do not
keep the door open for
extended periods of
time. Replace the seal
on the door if necessary.

12
newair.com
Problem
Possible Causes
Solution
The beverage cooler
seems to make too
much noise.
The unit is not leveled.
Adjust the unit’s feet
and ensure the product
is level.
There is insufficient
ventilation. The unit is
too close to a wall or
another surface.
Allow sufficient
clearance around the
unit.
An interior red light is
flashing.
The set temperature is
too low.
Adjust the set
temperature so that it is
higher than the
beverage cooler’s
interior temperature.
Frost is building up in
the unit.
There is excess
humidity or the interior
temperature is too low.
Turn off the beverage
cooler, unplug it, and
remove the frost
buildup manually.
Reconnect the power
once the ice has
thawed.

13
LIMITED MANUFACTURER’S WARRANTY
This appliance is covered by a limited manufacturer’s warranty. For one year
from the original date of purchase, the manufacturer will repair or replace any
parts of this appliance that prove to be defective in materials and
workmanship, provided the appliance has been used under normal operating
conditions as intended by the manufacturer.
Warranty Terms:
During the first year, any components of this appliance found to be defective
due to materials or workmanship will be repaired or replaced, at the
manufacturer’s discretion, at no charge to the original purchaser. The
purchaser will be responsible for any removal or transportation costs.
Warranty Exclusions:
The warranty will not apply if damage is caused by any of the following:
•Power failure
•Damage in transit or when moving the appliance
•Improper power supply such as low voltage, defective household
wiring or inadequate fuses
•Accident, alteration, misuse or abuse of the appliance such as using
non-approved accessories, inadequate air circulation in the room or
abnormal operating conditions (extreme temperatures)
•Use in commercial or industrial applications
•Fire, water damage, theft, war, riot, hostility or acts of God such as
hurricanes, floods, etc.
•Use of force or damage caused by external influences

14
newair.com
•Partially or completely dismantled appliances
•Excess wear and tear by the user
Obtaining Service:
When making a warranty claim, please have the original bill of purchase with
purchase date available. Once confirmed that your appliance is eligible for
warranty service, all repairs will be performed by a NewAir™ authorized repair
facility. The purchaser will be responsible for any removal or transportation
costs. Replacement parts and/or units will be new, re-manufactured or
refurbished and is subject to the manufacturer’s discretion. For technical
support and warranty service, please email [e-mail]
