owner’s manual
NB Series 380
NB 380 Assembly Manual
NB380AssemblyManual
QUESTIONS?CALL781Ͳ935Ͳ3450REV:10Ͳ18Ͳ2016 Pg.1
Note:someaccessoriesmaybeplacedinthepowercabinetorgreentrashcanfor
shippingpurposes.
NB380AssemblyManual
QUESTIONS?CALL781Ͳ935Ͳ3450REV:10Ͳ18Ͳ2016 Pg.2
NB380AssemblyManual
QUESTIONS?CALL781Ͳ935Ͳ3450REV:10Ͳ18Ͳ2016 Pg.3
3. Remove battery & hardware (includes (2) bolts,
(2) nuts, (4) flat washers and (2) lock washers) from
cardboard box
4. Unclip nylon battery straps and place
battery in cabinet as shown
5. For the first battery connection, there are
(4) wires (shown above) to be connected to
the positive (red) terminal on battery
Black
/
red inverter cable
/
red
/
blue charger wire
/
green meter wire
/
red meter wire
6. Place wires (in order shown above) onto
bolt
NB380AssemblyManual
QUESTIONS?CALL781Ͳ935Ͳ3450REV:10Ͳ18Ͳ2016 Pg.4
7. Retrieve nut, lock washer and flat washer (as
shown above)
8. Place flat washer, lock washer, then nut onto
bolt and tighten with ½” wrenches
10. For negative battery connection, place the
3 remaining black wires onto bolt as shown
9. Pull rubber boot over tightened terminal
(as shown above)
NB380AssemblyManual
QUESTIONS?CALL781Ͳ935Ͳ3450REV:10Ͳ18Ͳ2016 Pg.5
11. Insert bolt through negative (black) battery
terminal (as shown below)
NOTE: Sparking is normal for the first
connection.
Retrieve nut, lock washer and flat washer (as
shown below)
12. Place flat washer, lock washer, then nut
onto bolt and tighten with 1/2 wrenches
13. Make sure all fittings are tight and battery
is strapped down in the cabinet.
14. Turn inverter on as shown above. Inverter
is located behind the battery
NB380AssemblyManual
QUESTIONS?CALL781Ͳ935Ͳ3450REV:10Ͳ18Ͳ2016 Pg.6
Operating Tips:
1. Charge your battery before using it to ensure
it is fully charged. Simply plug the charger cord
(located on side of unit) into a standard wall
unit.
2. Monitor the battery status meter on the cart
(shown below)
3. Batteries should not be discharged below 11.5
volts as this will shorten the life of the battery.
4. If battery is discharged below 11 volts, you may
need a separate 10A trickle charger to get the
battery above 11 volts. To avoid this, be sure to
charge your unit after every use.
5. Batteries SHOULD NOT be stored in a
discharged state. They should be charged as soon
as possible after each use (otherwise it will void the
warranty). If a battery is left in a discharged state
for a period of time it will damage the battery and it
may no longer take a charge.
15. Turn powerstrip on. Light should turn red
16. Place power box cover on and tighten the
thumb screws
NB380AssemblyManual
QUESTIONS?CALL781Ͳ935Ͳ3450REV:10Ͳ18Ͳ2016 Pg.7
Accessory assembly manual can be downloaded
at:
www.newcastlesys.com/accessory-assembly
6. Do not use the cart when charging the unit. Turn
off the power strip, then plug the cart into a wall
outlet.
7. Cart’s charging system is a trickle charger;
leaving it plugged in will NOT damage the battery.
8. Avoid exposing battery to heat, service life is
shortened at ambient temperatures above 85F.
For additional questions, please call Technical
Support at 781-935-3450.
Be sure to charge your cart after every use.
Simply turn off the cart’s power strip and plug
cart into wall outlet.
