ViewSonic VPC35 User manual

VPC33
VPC35
VPC37
User Guide
Model No. VS19693
P/N: VPC33 | VPC35 | VPC37
IMPORTANT: Please read this User Guide to obtain important information on installing and using your product in
a safe manner, as well as registering your product for future service. Warranty information contained in this User
Guide will describe your limited coverage from ViewSonic®Corporation, which is also found on our web site at
http://www.viewsonic.com in English, or in specific languages using the Regional selection box of our website.

2
Thank you for choosing ViewSonic®
As a world-leading provider of visual solutions, ViewSonic® is dedicated to exceeding
the world’s expectations for technological evolution, innovation, and simplicity.
At ViewSonic®, we believe that our products have the potential to make a positive
impact in the world, and we are confident that the ViewSonic® product you have
chosen will serve you well.
Once again, thank you for choosing ViewSonic®!

3
Contents
Introduction ................................................................ 4
Package Contents ...................................................................................................4
Product Overview...................................................................................................5
Initial Setup................................................................. 6
Installing the VPC33/VPC35/VPC37........................................................................6
Making Connections.................................................... 7
Network Connection...............................................................................................7
USB Connection......................................................................................................7
Using the Device.......................................................... 8
Selecting an Input Source .......................................................................................8
IFP Series ................................................................................................................. 8
CDE Series................................................................................................................ 9
Appendix................................................................... 10
Specifications........................................................................................................10
Regulatory and Service Information .......................... 11
Compliance Information.......................................................................................11
FCC Compliance Statement................................................................................... 11
CE Conformity for European Countries ................................................................. 12
Para su uso en México........................................................................................... 12
Declaration of RoHS2 Compliance......................................................................... 13
Indian Restriction of Hazardous Substances ......................................................... 14
Product Disposal at End of Product Life ................................................................ 14
Copyright Information ..........................................................................................15
Customer Service .................................................................................................. 16

4
Introducon
Package Contents
VPC33/VPC35/VPC37
VS19693
Slot in PC module
VPC33/VPC35/VPC37
VS19693
Slotin PC module
VPC33/VPC35/VPC37
VS19693
Slot in PC module
VPC33/VPC35/VPC37
VS19693
Slotin PC module
VPC33/VPC35/VPC37 Quick Start Guide
NOTE: If anything is missing or damaged, please contact your local reseller for
more informaon.

5
Product Overview
32 21 4 5
5 5 5
6 7 810 11 12
9
Number Item Descripon
1Security lock
2 Antenna Wi-Fi antenna interface
3Standard RJ45 (10M/100M/1G) internet connecon port
NOTE: This network port is only used for PC.
4 DisplayPort DisplayPort input. Connect to a PC or other device with
DisplayPort output.
5 USB USB 3.0 port
6 RESET Reset buon
7Power buon
8 Status LED Status indicator light
9 HDMI HDMI input. Connect to a PC or other device with HDMI
output.
10 USB Type C input (Data only; 5V/0.9A charging)
11 Audio out for connected headphones or speakers.
12 Microphone connecon

6
Inial Setup
Installing the VPC33/VPC35/VPC37
1. Remove the slot-in PC cover of the display.
2. Carefully insert the VPC33/VPC35/VPC37 into the PC slot of the display.
3. Secure the VPC33/VPC35/VPC37 to the display with the two (2) screws.
NOTE:
• Please note that the two (2) antennas must be installed on the VPC33/
VPC35/VPC37.
• Please pay aenon to the installaon direcon of the VPC33/VPC35/
VPC37, with the vents facing outwards to avoid damage.

7
Making Connecons
Network Connecon
To connect to the Internet or a network, connect one end of a RJ45 cable to the
RJ45 ( ) port of the VPC33/VPC35/VPC37, then connect the other end to your
network.
BSUBSUBSUIMDHTESER
DP
USB Connecon
USB peripherals such as keyboards, mice, storage devices, etc. can be connected to
the VPC33/VPC35/VPC37’s USB ports.
BSUBSUBSUIMDHTESER
DP

8
Using the Device
Selecng an Input Source
IFP Series
To select an input source:
1. Press INPUT/ on the remote control, press the seng buon on the front
panel, or press the Sengs icon from the toolbar to display the Input Sengs
menu.
2. Press ▼/▲/◄/►on the remote control to select the PC source.
3. Press OK/ENTER on the remote control, or touch the input source directly.
4. Press EPG/BACK/ on the remote control, or touch a blank area outside of the
menu to exit.
NOTE: The above image is for reference only and is subject to change without
noce.

9
CDE Series
VGA
Custom
To select an input source:
1. Press INPUT/ on the remote control.
2. Press ▼/▲on the remote control to select the PC source.
3. Press OK/ENTER on the remote control.
4. Press EPG/BACK/ on the remote control to exit.
NOTE: The above image is for reference only and is subject to change without
noce.

10
Appendix
Specicaons
Category Item Specicaons
I/O Ports
1 x LAN
1 x Display Port
1 x HDMI
4 x USB 3.0
1 x USB type C
1 x Earphone
1 x Microphone
Physical
Dimensions (mm) 180 x 119 x 30 mm
Dimensions (in.) 7.09” x 4.69” x 1.18”
Weight (kg) 0.6 kg
Weight (lbs.) 1.32 lbs.
Operang Condions
Altude
0~3,048 M (10,000 .)
Humidity 10% ~ 90% (non-condensing)
Temperature -5°C ~ 40°C (23°F ~ 104°F)
Storage Condions
Altude
0~12,192 m (40,000 .)
Humidity 10% ~ 90% (non-condensing)
Temperature -20°C ~ 70°C (-4°F ~ 158°F)
Power Voltage
12~19V DC
Consumpon 96W
Wi-Fi Module
Form Factor
Wi-Fi 6 (IEEE 802.11 a/b/g/n/ac/ax Wi-
Fi 2T/2R+)
Bluetooth 5.2 (V2.1/4.2/5.2
USB2.0/3.0 Module)
Frequency Range and
Output Power (Max.)
• 2402 to 2480 MHz(BT) (5.5dBm)
• 2402 to 2480 MHz(LE) (3.73 dBm)
• 2412 to 2472 MHz (17.41 dBm)
(14.38dbm)
• 5150 to 5250 MHz (18.94 dBm)
(13.25dbm)
• 5250 to 5350 MHz (18.94 dBm)
(13.25dbm)
• 5470 to 5725 MHz (18.94 dBm)
(12.75dbm)

11
Regulatory and Service Informaon
Compliance Informaon
This secon addresses all connected requirements and statements regarding
regulaons. Conrmed corresponding applicaons shall refer to nameplate labels
and relevant markings on the unit.
FCC Compliance Statement
This device complies with part 15 of FCC Rules. Operaon is subject to the following
two condions: (1) this device may not cause harmful interference, and (2) this
device must accept any interference received, including interference that may
cause undesired operaon. This equipment has been tested and found to comply
with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules.
These limits are designed to provide reasonable protecon against harmful
interference in a residenal installaon. This equipment generates, uses, and
can radiate radio frequency energy, and if not installed and used in accordance
with the instrucons, may cause harmful interference to radio communicaons.
However, there is no guarantee that interference will not occur in a parcular
installaon. If this equipment does cause harmful interference to radio or television
recepon, which can be determined by turning the equipment o and on, the user
is encouraged to try to correct the interference by one or more of the following
measures:
• Reorient or relocate the receiving antenna.
• Increase the separaon between the equipment and receiver.
• Connect the equipment into an outlet on a circuit dierent from that to which
the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Warning: You are cauoned that changes or modicaons not expressly approved
by the party responsible for compliance could void your authority to operate the
equipment.
Industry Canada Statement
FCC ID: PD9AX200NG
IC ID: 1000M-AX200NG
CAN ICES-003(B) / NMB-003(B)

12
CE Conformity for European Countries
The device complies with the EMC Direcve 2014/30/EU, Low Voltage
Direcve 2014/35/EU and Radio Equipment Direcve 2014/53/EU.
hps://www.viewsonicglobal.com/public/products_download/safety_
compliance/acc/VS19693_CE_DoC.pdf
The following informaon is only for EU-member states:
The mark shown to the right is in compliance with the Waste Electrical
and Electronic Equipment Directive 2012/19/EU (WEEE). The mark
indicates the requirement NOT to dispose of the equipment as unsorted
municipal waste, but use the return and collection systems according to
local law.
Para su uso en México
“La operación de este equipo está sujeta a las siguientes dos condiciones: (1) es
posible que este equipo disposivo no cause interferencia perjudicial y (2) este
equipo o disposivo debe aceptar cualquier interferencia, incluyendo la que pueda
causar su operación no deseada”.
“Este equipo ha sido diseñado para operar con antenas po monopolo con
ganancia de 5 dBi para 2.4 GHz y 5 GHz WLAN. El uso con este equipo de antenas
que tengan una ganancia mayor que 5 dBi quedan prohibidas. La antena es única y
la impedancia requerida es de 50 ohms”.

13
Declaraon of RoHS2 Compliance
This product has been designed and manufactured in compliance with Direcve
2011/65/EU of the European Parliament and the Council on restricon of the use
of certain hazardous substances in electrical and electronic equipment (RoHS2
Direcve) and is deemed to comply with the maximum concentraon values issued
by the European Technical Adaptaon Commiee (TAC) as shown below:
Substance Proposed Maximum
Concentraon
Actual
Concentraon
Lead (Pb) 0.1% < 0.1%
Mercury (Hg) 0.1% < 0.1%
Cadmium (Cd) 0.01% < 0.01%
Hexavalent Chromium (Cr6⁺) 0.1% < 0.1%
Polybrominated biphenyls (PBB) 0.1% < 0.1%
Polybrominated diphenyl ethers
(PBDE) 0.1% < 0.1%
Bis(2-ethylhexyl) phthalate (DEHP) 0.1% < 0.1%
Butyl benzyl phthalate (BBP) 0.1% < 0.1%
Dibutyl phthalate (DBP) 0.1% < 0.1%
Diisobutyl phthalate (DIBP) 0.1% < 0.1%
Certain components of products as stated above are exempted under the Annex
III of the RoHS2 Direcves as noted below:
• Copper alloy containing up to 4% lead by weight.
• Lead in high melng temperature type solders (i.e. lead-based alloys containing
85% by weight or more lead).
• Electrical and electronic components containing lead in a glass or ceramic other
than dielectric ceramic in capacitors, e.g. piezoelectronic devices, or in a glass or
ceramic matrix compound.
• Lead in dielectric ceramic in capacitors for a rated voltage of 125V AC or 250V DC
or higher.

14
Indian Restricon of Hazardous Substances
Restricon on Hazardous Substances statement (India). This product complies
with the “India E-waste Rule 2011” and prohibits use of lead, mercury, hexavalent
chromium, polybrominated biphenyls or polybrominated diphenyl ethers in
concentraons exceeding 0.1 weight % and 0.01 weight % for cadmium, except for
the exempons set in Schedule 2 of the Rule.
Product Disposal at End of Product Life
ViewSonic® respects the environment and is commied to working and living
green. Thank you for being part of Smarter, Greener Compung. Please visit the
ViewSonic® website to learn more.
USA & Canada:
hps://www.viewsonic.com/us/go-green-with-viewsonic
Europe:
hps://www.viewsonic.com/eu/go-green-with-viewsonic
Taiwan:
hps://recycle.epa.gov.tw/

15
Copyright Informaon
Copyright© ViewSonic® Corporaon, 2023. All rights reserved.
Macintosh and Power Macintosh are registered trademarks of Apple Inc.
Microso, Windows, and the Windows logo are registered trademarks of Microso
Corporaon in the United States and other countries.
ViewSonic®, the three birds logo, OnView, ViewMatch, and ViewMeter are
registered trademarks of ViewSonic® Corporaon.
VESA is a registered trademark of the Video Electronics Standards Associaon.
DPMS, DisplayPort, and DDC are trademarks of VESA.
Disclaimer: ViewSonic® Corporaon shall not be liable for technical or editorial
errors or omissions contained herein; nor for incidental or consequenal damages
resulng from furnishing this material, or the performance or use of this product.
In the interest of connuing product improvement, ViewSonic® Corporaon
reserves the right to change product specicaons without noce. Informaon in
this document may change without noce.
No part of this document may be copied, reproduced, or transmied by any means,
for any purpose without prior wrien permission from ViewSonic® Corporaon.
VPC33_VPC35_VPC37_UG_ENG_1b_20231123

16
Customer Service
For technical support or product service, see the table below or contact your
reseller.
NOTE: You will need the product’s serial number.
Country/ Region Website Country/ Region Website
Asia Pacic & Africa
Australia www.viewsonic.com/au/ Bangladesh www.viewsonic.com/bd/
中国 (China) www.viewsonic.com.cn 香港 (繁體中文) www.viewsonic.com/hk/
Hong Kong (English) www.viewsonic.com/hk-en/ India www.viewsonic.com/in/
Indonesia www.viewsonic.com/id/ Israel www.viewsonic.com/il/
日本 (Japan) www.viewsonic.com/jp/ Korea www.viewsonic.com/kr/
Malaysia www.viewsonic.com/my/ Middle East www.viewsonic.com/me/
Myanmar www.viewsonic.com/mm/ Nepal www.viewsonic.com/np/
New Zealand www.viewsonic.com/nz/ Pakistan www.viewsonic.com/pk/
Philippines www.viewsonic.com/ph/ Singapore www.viewsonic.com/sg/
臺灣 (Taiwan) www.viewsonic.com/tw/ ประเทศไทย www.viewsonic.com/th/
Việt Nam www.viewsonic.com/vn/ South Africa & Maurius www.viewsonic.com/za/
Americas
United States www.viewsonic.com/us Canada www.viewsonic.com/us
Lan America www.viewsonic.com/la
Europe
Europe www.viewsonic.com/eu/ France www.viewsonic.com/fr/
Deutschland www.viewsonic.com/de/ Қазақстан www.viewsonic.com/kz/
Россия www.viewsonic.com/ru/ España www.viewsonic.com/es/
Türkiye www.viewsonic.com/tr/ Україна www.viewsonic.com/ua/
United Kingdom www.viewsonic.com/uk/
