Newer Technology NuPower Charge & Sync + User manual

Thank you for purchasing the Newer Technology
NuPower Charge & Sync +! Please read over these
instructions to understand how to properly charge
and use this device.
Features:
• Charges most mobile phones and other devices that
recharge via USB Dock Connection, Mini-USB or Micro-USB
• Works as a data cable / synchronization cable / charge cable
• Portable, stylish design
Specications:
Input Voltage: AC 100 - 240V 50/60Hz
Output Voltage: DC 5.1V - 5.5V
Output Current: 650mA
Battery Capacity: 1400mAh
➁➂
➄
➃
➅
➆
➀
➀ USB Connection
➁ Li-ion Charging Indicator LED
➂ On/Battery Active LED
➃ On/O Switch
➄ Access Door
➅ AC Power Slide
➆ AC Power Connection
Function Overview
Operation - Initial Charge
➁ ➂
➄➃
➀
The rst time you use the Newer Technology Nu-
Power Charge & Sync +, you need to fully charge it.
➀ Turn the battery over so you can see the bottom.
➁ Remove the access door.
➂ Remove the USB cable and unwrap it.
➃ Slide the AC Power connection out
➄ Plug the Newer Technology NuPower Charge & Sync
+ into a power outlet. The Li-Ion LED (See gure 2 in
Function Overview) will illuminate while charging.
Once the battery is fully charged, the LED will turn
o.

Once the battery is fully charged, you can then begin using the
Newer Technology NuPower Charge & Sync +. In this example, we
show the battery being used to power an Apple iPhone. The the
Newer Technology NuPower Charge & Sync + is shipped with a 30
Pin Apple Dock cable installed, but includes both a mini USB and a
micro USB connector also. You can easily switch the USB cable out
on the Newer Technology NuPower Charge & Sync +to use either of
these other cables by simply pulling the white body of the USB con-
nector out of it’s socket on the Newer Technology NuPower Charge
& Sync + - do not pull directly on the USB cable or you can damage
it. Using your ngernail to gently release the body of the connector
is highly recommended.
Simply connect the USB or Dock connector to the mobile device,
and turn the on/o switch to the on (or out) position on the battery
and your device will begin charging. When you are done charging
your device, turn the battery power switch o to conserve the inter-
nal battery for future charging.
The 3 USB cables that come with the Newer Technology NuPower
Charge & Sync + can also be used as connectivity cables between
your computer and your device, simply plug the USB connector into
your USB port on your computer and whichever accessory cable you
chose into your mobile device.
Operation (continued)
The Newer Technology NuPower Charge & Sync + can be used simultaneously while charging the internal bat-
tery on the Newer Technology NuPower Charge & Sync +, and also your device. While performing this type of
charge, the internal battery on the Newer Technology NuPower Charge & Sync + will charge rst for about 5 to 10
minutes, and then begin charging the connected device as well. Please note - if the Newer Technology NuPower
Charge & Sync + OR your device’s internal battery is fully depleted, they may not immediately turn on when con-
necting to either the internal battery or to a power source. Some devices, such as the Apple iPhone take a few
minutes to recharge the internal battery before it will boot to the operating system.
Tips & Troubleshooting
• When connecting devices to the Newer Technology NuPower Charge & Sync +, make sure that they are ad-
equately supported on a at surface and not hanging o of the cord, such as when plugged into a wall outlet.
Excess strain on the cable will cause failure of the connections and shorten the life of the product.
• When using the cables to connect your device to your computer, be sure to properly orient the USB connector
so that the gold pins connect the right direction into your computer’s USB port. On most laptops, that would be
with the gold contacts in the UP position. If the pins are not oriented correctly, the computer will not recognize
that the device is connected and will not work. Simply turn the cable over if this happens and reconnect it.
Advanced Operation
USB
Micro Mini Dock
