RXL1000 Users Manual
1
Equipment Uses
 Concrete leveling, grinding and polishing
 Terrazzo grinding and polishing
 Stone grinding and polishing
 Hardwood grinding, sanding and polishing
 Glue, Thinset and mastic removal
Address:
103B-81 Golden Drive
Coquitlam, BC
Canada V
3K 6R2
Contact:
1-888-467-0242
[e-mail]
Assembled in Canada using only the highest-quality USA components
RHINO RXL1000
USER MANUAL

RXL1000 Users Manual
2
Table of Contents
Equipment Uses................................................................................................................................................ 1
RXL1000 Diagram ............................................................................................................................................. 4
RXL1000 Bottom Diagram ................................................................................................................................ 5
Machine Specifications .................................................................................................................................... 6
Tooling .......................................................................................................................................................... 6
Average Production Rates............................................................................................................................. 6
Safety Instructions ............................................................................................................................................ 7
Work Area Safety .......................................................................................................................................... 7
Electrical Safety ............................................................................................................................................. 7
Personal Safety ............................................................................................................................................. 8
Equipment Safety and Care .......................................................................................................................... 8
Service Safety ................................................................................................................................................ 9
Operating the Grinder ........................................................................................................................................ 9
Prior to using the grinder ............................................................................................................................ 10
Starting the grinder ..................................................................................................................................... 10
Adjusting the speed .................................................................................................................................... 11
Stopping the equipment ............................................................................................................................. 11
Adjusting the handle ................................................................................................................................... 11
Using the biased weight kit ......................................................................................................................... 11
Changing the drive belt ............................................................................................................................... 11
Changing tools and accessories .................................................................................................................. 12
Parts and accessories .................................................................................................................................. 13
Grinder Maintenance ........................................................................................................................................ 13
General Maintenance ................................................................................................................................. 13
Daily Maintenance ...................................................................................................................................... 13
Monthly Maintenance ................................................................................................................................ 13
Yearly Maintenance .................................................................................................................................... 14
Troubleshooting ............................................................................................................................................... 15
VFD Fault Messages .................................................................................................................................... 15

RXL1000 Users Manual
3
LIMITED EQUIPMENT WARRANTY OF SALE ................................................................................................................. 17
FORCE MAJEURE .................................................................................................................................................. 18
LIABILITY LIMITATIONS ......................................................................................................................................... 18
TERMS & CONDITIONS ........................................................................................................................................... 19
AGREEMENTS ...................................................................................................................................................... 20

RXL1000 Users Manual
4
RXL1000 Diagram
Multi articulating handle
Hand grips
Biased weight-kit pegs
Power tilt arm
Vacuum connector port
Variable speed adjustment
potentiometer
Forward spin button
Reverse spin button
Stop button
Dual vacuum manifold port
Heavy duty wheels
UHMW dust skirt
20 HP motor
SM Vector Frequency Inverter
LED Light Bar
Emergency stop button
Control cable

RXL1000 Users Manual
5
RXL1000 Bottom Diagram
Counter-clockwise spinning Rhino tool plates
(Red)
Clockwise spinning Rhino tool plates (Black)
Single or double grommet mounting system
Rhino style tooling
(attaches using ½ “bolt)
Quick-change drive belt
Power tilt arms

RXL1000 Users Manual
6
Machine Specifications
Power
50 AMP/3 Phase
Maximum watts draw
15000
HP
20
Machine weight
1200 lbs
Biased weight kit max weight
600 lbs
Combined weight
1800
Disc speed
200-900 rpm
Variable speed control
YES
Number of grinding heads
6
Counter-rotating heads
YES
Disk size
11 inches
Grinding footprint
32 inches
Quick change tooling
YES
Quick belt changing system
YES
Wet or dry grinding
YES
UHMW floating dust skirt
YES
Multi-articulating handle
YES
Runs forward or reverse
YES
Power Tilt
Self-Propelled
LED Light Bar
YES
YES
YES
Dual vacuum manifolds
YES
Tooling
Rhino Style tooling
YES
Standard trapezoid
YES
Average Production Rates
Extremely heavy removal
1400-2000 sq./ft. per hour
Heavy removal
1600-2600 sq./ft. per hour
Light removal
2000-3300 sq./ft. per hour
Grinding and profiling
1800-2800 sq./ft. per hour
Polishing
2000-3000 sq./ft. per hour

RXL1000 Users Manual
7
Safety Instructions
WARNING! Read and understand all instructions.
Failure to follow all instructions listed below, may result in electric shock, fire and/or
serious personal injury. SAVE THESE INSTRUCTIONS.
Work Area Safety
1. Keep your work area clean and well lit. Cluttered floors and dark areas invite accidents.
2. Do not operate equipment in explosive environments, such as in the presence of -
flammable liquids, gases or dust. Grinding can create sparks which may ignite the dust or
fumes.
3. Keep bystanders, children, and visitors away while operating equipment. Distractions can
cause you to lose control.
Electrical Safety
1. Do not abuse the cord. Never use the cord to pull the equipment or pull the plug from
an outlet. Keep cord away from heat, oil, sharp edges or moving parts. Replace damaged
cords immediately. Damaged cords increase the risk of electric shock.
2. Make sure cord is clear of wheels and cutting discs. Do not wrap cord around your arm
or wrist. If control of equipment is lost, cord may become wrapped around you and
cause personal injury.
3. When operating equipment outside, use an outdoor extension cord marked "W-A" or
"W". These cords are rated for outdoor use and reduce the risk of electric shock.
4. Avoid accidental starting. Be sure stop button is depressed before plugging in. Starting
equipment with your finger on the start buttons or plugging in equipment that has the
buttons depressed invites accidents.
5. USE THE PROPER EXTENSION CORD. Make sure your extension cord is in good
condition. When using an extension cord, be sure to use one heavy enough to carry the
current your product will draw. An undersized cord will cause a drop in line voltage
resulting in loss of power and overheating.
For the RXL1000 use 10-gauge cord or larger.

RXL1000 Users Manual
8
Personal Safety
1. DO NOT let comfort or familiarity with product (gained from repeated use) replace strict
adherence to equipment safety rules. If you use this equipment unsafely or incorrectly,
you can suffer serious personal injury.
2. Stay alert, watch what you are doing and use common sense when operating equipment.
Do not use equipment while tired or under the influence of drugs, alcohol, or
medication. A moment of inattention while operating equipment may result in serious
personal injury.
3. Adequate ventilation of your work area is very important when using equipment. Use a
dust mask or appropriate respirator. Due to the dusty nature during use of
4. Do not overreach. Always keep proper footing and balance. Proper footing and balance
will enable better control of the equipment in unexpected situations.
5. Use safety equipment. Always wear eye protection, dust mask, non-skid safety shoes,
hard hat and hearing protection.
Ordinary eye or sunglasses are NOT eye protection.
6. DO NOT Turn on equipment while the machine is tilted back. Any tooling fastened to the
machine can eject and become a lethal projectile.
Equipment Safety and Care
1. The equipment is designed to remove excess surface material. To prevent damage to the
equipment and/or serious personal injury, beware of protruding objects or other debris
on or embedded in the surface being finished.
2. Disconnect the plug from the power source before making any adjustments, changing
accessories, or storing equipment. Such preventive safety measures reduce the risk of
starting the equipment accidentally.
3. Maintain equipment with care. Keep tools and accessories in good condition. Properly
maintained tools with sharp cutting edges are less likely to fail and are easier to control.
4. Check for binding of moving parts, breakage of parts, and any other condition that may
affect the equipment's operation. If damaged, have equipment serviced before using.
Many accidents are caused by poorly maintained equipment.
5. Use only tools and accessories that are recommended by the manufacturer for your
equipment. Tools and accessories that may be suitable for style of equipment, may
become hazardous when used on another style of equipment.
6. Tools and accessories must be rated for at least the speed stated on the equipment serial
plate. Tools and other accessories running faster than rated speed can fly apart and
cause injury.

RXL1000 Users Manual
9
7. Due to the dusty nature during use of this equipment, be sure to clean equipment often
to remove dust accumulations. Carefully blow the dust out of the motor, VFD and dust
covered areas frequently.
8. Always install the dust skirt before operation.
9. Check the tools and accessories carefully for cracks or damage before operation. Replace
cracked or damaged tools or and accessories immediately.
10. Hold the equipment firmly with both hands during operation.
11. Do not leave the equipment running unattended.
12. Do not touch the tools immediately after operation; they may be extremely hot and
could burn your skin.
Service Safety
1. DO NOT modify the machine. Modifications will void warranty and could result in unsafe
operation of equipment.
2. Equipment service should be performed only by qualified repair personnel. Service or
maintenance performed by unqualified personnel could result in a risk of injury.
3. When servicing equipment, use only identical replacement parts. Use of unauthorized
parts may create a risk of electric shock or injury.
WARNING: Misuse or failure to follow the safety rules stated in this instruction
manual may cause serious personal injury. SAVE THESE INSTRUCTIONS.
Operating the Grinder
The machine is outfitted with a Variable Frequency Drive (VFD) enabling the user to select the
desired operating speed.
The equipment can operate on either 50 Hz or 60 Hz frequencies.
The VFD will automatically adjust for phase or frequency input which will raise or lower head
speed on the machine.
VFD features:
 Under voltage protection - Over current protection
 60Hz and 50Hz capability (international)
 110V
 Soft start

RXL1000 Users Manual
10
 Speed display
 Load display
 Current limiting
NOTE: LED DISPLAY – Shows PAD speed when machine is running and says “STOP”
when plugged in but not running.
Prior to using the grinder
1. Inspect the grinder to make sure all bolts are tight, and that tools are properly mounted
2. Check that the plug is properly connected to the extension cord and inspect the cord for
wear and tear.
3. Make sure that speed dial is turned to its lowest setting
WARNING: This will prevent unexpected high speed start up which could cause
some tools to eject or cause undesirable marks to the surface being finished.
4. Plug the machine in – the VFD LED should read “STOP”
Starting the grinder
DO NOT LIFT THE EQUIPMENT OFF THE GROUND WHILE STARTING!
Doing so can cause the tools to release from the equipment and cause damage to
the surface being finished and harm to the user!
1. With the machine in an upright position, set the articulating handle to the desired
position.
2. Check that speed dial is set to slowest speed.
3. Plug the power cable in, making sure that extension cord is not tangled or wrapped
around any obstacles.
4. Ensure that the VFD LED reads “STOP”
5. Apply downward pressure on the handle to alleviate some pressure on the tools and
press the GREEN start button. (If you want the machine to run in reverse you can push
the yellow start button.
NOTE: Always use the equipment in the forward rotation mode (green button) unless
reverse rotation is needed. This will ensure consistent tool wear.
The use of the equipment in the reverse rotation is only needed when surface being finished
is uneven and causes the equipment to pull in an undesired direction or when the tooling is
glazed and needs to be re-dressed.
6. Once the equipment is started, gently release the downward pressure and start grinding.

RXL1000 Users Manual
11
NOTE: The equipment is designed to rotate the tooling in either the forward direction
(green button) or reverse direction (yellow button) depending on operating needs.
Adjusting the speed
1. Use the knob, located on the right side of the handle control box to adjust speed of
equipment.
Stopping the equipment
1. To stop the equipment, turn speed control knob to the slowest setting and,
2. push the red stop button on the face of the handle
Adjusting the handle
1. Make sure machine is unplugged
2. Pull the hand latch or step on foot latch on the handle and move handle up or down to
the desired position.
Avoid stepping on or tangling handle control cable when adjusting the handle position.
Make sure that the latch clicks in place when the desired position is achieved.
WARNING: Failure to check for positive handle latch engagement could result in
damage to the equipment or injury to the user as the handle could release
unexpectedly when the machine is being operated or tilted back!
Using the biased weight kit
The Rhino line of equipment was designed to be used with our biased weight kit, which
allows our machines to be loaded with weights to increase point pressure for very hard
floors and to rapidly expose aggregate.
Our unique patented biased weight system uses standard Olympic weight plates,
allowing placement on either side of the machine to increase pressure when grinding
edges with slab curl and high and low spots.
Weights can also be placed on the handle to alleviate pressure and weight from the
machine, enabling the Rhino to be easily and effectively used for soft & rained out slabs.
For best results and to increase production we highly recommend utilizing weights with
your Rhino grinder.
Changing the drive belt
To view a video on how to change the drive belt – please visit our website at:
www.newgrind.com

RXL1000 Users Manual
12
Changing tools and accessories
WARNING: Always turn grinder off and disconnect power from the machine when
performing any operations to the bottom of the machine!
When removing and inserting tool plates or adapter plates, be sure to inspect rubber grommets
for signs for wear and replace any damaged grommets.
WARNING: Using grommets that are damaged or missing can cause unexpected
equipment operation and increase the chance of tool plate / adapter plate ejection or
violent vibration leading to loss of control of equipment!
To change the tools:
1. Turn grinder off, and unplug power
2. Use the power tilt function to tilt the machine back so you can access the tool plates.
WARNING: Do not attempt to replace tools that have recently been in use as they may be
hot and could cause injury
3. Grasp the tool plate firmly with both hands and pull to remove tool plate from
grommets
4. Remove the bolt from the back of the tool plate behind each tool to release the tool
5. Hold the replacement tool up against the desired slot on the tool plate and
insert/tighten the bolt.
NOTE: Rhino tool plates have spaces for up to 6 tools. Using 3 evenly spaced tools per plate is
standard configuration.
6. Inspect the grommets to make sure they are not worn or missing
7. Reinsert tool plate into rubber grommets
8. Hold the plate firmly with both hands and jiggle it to make sure its properly attached
9. Repeat with each of the tool plates
WARNING: only use tools that have been designed for the machine, and make sure that
the same type of tool is being used on all plates/positions.
10. Use the power tilt function to return the machine to the upright position.
11. Follow the procedure for starting the grinder

RXL1000 Users Manual
13
Parts and accessories
A full range of parts and accessories for all of our grinders is available on our website.
Grinder Maintenance
WARNING: Disconnect power before performing any maintenance, cleaning, or repair to
your equipment!
General Maintenance
 When the equipment is not in use, make sure that the adapter plate assemblies have
something attached to them to protect the Velcro. Resting the machine directly on
unprotected Velcro will crush the fastening material causing the Velcro to become unusable.
Daily Maintenance
 Wipe down the equipment after every job.
 Gently remove dirt and debris from the Velcro hook material using a wire brush. This will
ensure maximum adhesion.
 Check that the handle bolts are tight.
 Vacuum or wipe underside of machine.
 Inspect plug ends for signs of carbon deposits or arcing.
 Check all fasteners and tighten if necessary.
Monthly Maintenance
 Inspect handle wires for damage.
 Blow off the VFD heat sink with compressed air.
 Blow out VFD cooling fan(s) with low pressure compressed air (30psi or less).
 Cleaning the fan(s) prevents fan failure and potential VFD overheating. Do not over-speed
the fan(s) with compressed air!
 Blow off motor fan with compressed air.
 Remove tool plate holders and wipe down bearing shields with a damp cloth. Do not use
any sharp object or abrasive pad to clean the bearing shields. This can compromise the
bearing seal!
 Re-install tool plate drivers using blue medium strength thread locking compound.

RXL1000 Users Manual
14
 Using a soft scrub pad, remove any excess dirt build up from the bottom plate and back side
of pad drivers.
 Inspect tool plate driver grommets for signs of wear. Replace grommets that show signs of
extensive wear.
Yearly Maintenance
 Check all strain reliefs and make sure they are tight so as to avoid cords being pulled out of
the VFD or handle.
 Remove tool plate drivers and inspect threads to make sure that there are no signs of cross
threading or stripping.
 Clean and lubricate wheels.
 Clean and lubricate latch mechanisms.

RXL1000 Users Manual
15
Troubleshooting
VFD Fault Messages

RXL1000 Users Manual
16

RXL1000 Users Manual
17
The VFD is protected from voltage fluctuations within the specified voltage range. Check voltage
before plugging in equipment to insure safe operation.
WARNING: If a machine is plugged into a power source that is above the machine’s
maximum voltage capability (ex. 230V model plugged into a 460V power source) this will
damage and/or destroy the internals of the VFD and void the warranty!
LIMITED EQUIPMENT WARRANTY OF SALE
NewGrind Inc. warrants that each new unit manufactured by NewGrind Inc. to be free from
defects in material and workmanship in normal use and service for a period of (3) three years
from date of shipment to the original owner. Accessories or equipment furnished and installed
on the product by NewGrind Inc. but manufactured by others, including, but not limited to
engines, motors, electrical components, transmissions etc., shall carry the accessory
manufacturers own warranty.
NewGrind Inc. will, at its option, repair or replace, at the NewGrind Inc. factory or at a point
designated by NewGrind Inc. any part which shall appear to the satisfaction of NewGrind Inc.
inspection to have been defective in material or workmanship. NewGrind Inc. reserves the right
to modify, alter and improve any part or parts without incurring any obligation to replace any
part or parts previously sold without such modified, altered or improved part or parts.
This warranty is in lieu of and excludes all other warranties, expressed, implied, statutory, or
otherwise created under applicable law. In no event shall seller or the manufacturer of the
product be liable for special, incidental, or consequential damages, including loss of profits,
whether or not caused by or resulting from the negligence of seller and/or the manufacturer of
the product unless specifically provided herein.
In addition, this warranty shall not apply to any products or portions there of which have been
subjected to abuse, misuse, improper installation, maintenance, or operation, electrical failure or

RXL1000 Users Manual
18
abnormal conditions and to products which have been tampered with, altered, modified,
repaired, reworked by anyone not approved by seller or used in any manner inconsistent with
the provisions of the above or any instructions or specifications provided with or for the
product.
FORCE MAJEURE
Seller’s obligation hereunder are subject to, and Seller shall not be held responsible for, any
delay or failure to make delivery of all or any part of the product due to labor difficulties, fires,
casualties, accidents, acts of the elements, acts of God, transportation difficulties, delays by a
common carrier, inability to obtain product, materials or components or qualified labor
sufficient to timely perform part of or all of the obligations contained in these terms and
conditions, governmental regulations or actions, strikes, damage to or destruction in whole or
part of manufacturing plant, riots, terrorist attacks or incidents, civil commotions, warlike
conditions, flood, tidal waves, typhoon, hurricane, earthquake, lightning, explosion or any other
causes, contingencies or circumstances within CANADA not subject to the Seller’s control which
prevent or hinder the manufacture or delivery of the products or make the fulfillment of these
terms and conditions impracticable. In the event of the occurrence of any of the foregoing, at
the option of Seller, Seller shall be excused from the performance under these Terms and
Conditions, or the performance of the Seller shall be correspondingly extended.
This document sets forth the terms and conditions pursuant to which the purchaser
(“Purchaser”) will purchase and New Grind Inc. (“Seller”) will sell the products, accessories,
attachments (collectively the products “) ordered by the Purchaser. These terms and conditions
shall govern and apply to the sale of Seller’s products to Purchaser, regardless of any terms and
conditions appearing on any purchase order or other forms submitted by Purchaser to Seller, or
the inconsistency of any terms therein and herein.
LIABILITY LIMITATIONS
The remedies of the user set forth under provisions of warranty outlined above are the exclusive
and total liability of New Grind Inc. with the respect to their sale or the equipment and service
furnished hereunder, in connection with the performance or breach thereof, or from the sale,
delivery, installation, repair or technical direction covered by or furnished under the sale,
whether based on contract, warranty, negligence, indemnity, strict liability, or otherwise shall not
exceed the purchase price of the unit of equipment upon which such liability is based. New
Grind Inc. will not in any event be liable to the user, any successors in interest or any beneficiary
or assignee relating to this sale for any consequential, incidental, indirect, special or punitive
damages arising out of this sale or any breach thereof, or any defects on, or failure of, or
malfunction of the equipment under this sale based upon loss of use, lost profits or revenue,
interest, lost goodwill, work stoppage, impairment of other goods, loss by reason of shutdown

RXL1000 Users Manual
19
or nonoperation, increased expenses of operation of the equipment, cost of purchase or
replacement power of claims of users or customers of the user for service interruption whether
or not such loss or damage is based on contract, warranty, negligence, indemnity, strict liability,
or otherwise. New Grind Inc. reserves the right to modify, alter and improve any part or parts
without incurring any obligation to replace any part or parts previously sold without such
modified, altered or improved part or parts. No person is authorized to give any other warranty
or to assume any additional obligation on New Grind Inc.'s behalf unless made in writing and
signed by an officer of New Grind Inc.
TERMS & CONDITIONS
1. PRICE
All prices set forth on any purchase order or other document are F.O.B. Sellers facility or
distribution point, as may be determined by Seller (F.O.B. Point). All prices are exclusive of any
and all taxes, including, but not limited to, excise, sales, use, property or transportation taxes
related to the sale or use of the products, now or hereafter imposed, together with all penalties
and expenses. Purchaser shall be responsible for collecting and/or paying any and all such taxes,
whether or not they are stated in any invoice for the Products. Unless otherwise specified herein,
all prices are exclusive of inland transportation, freight, insurance and other costs and expenses
relating to the shipment of the Products from the F.O.B. point to Purchaser’s facility. Any
prepayment by Seller of freight insurance and other costs shall be for the account of Purchaser
and shall be repaid to Seller.
2. PAYMENT TERMS
Payment terms are as follows: New Grind Inc. Machines - Payment prior to delivery.
*All past due accounts are subject to a late payment fee of 1.5% per month or a maximum
allowed by law if different, along with the expenses incidental to collection including reasonable
attorney’s fees and costs.
*Seller reserves the right to hold shipments against past due accounts.
*Seller reserves the right to alter payment terms.
3. FREIGHT TERMS
All shipments will be made F.O.B. shipping point as designated in these Terms and Conditions,
and title shall pass at the F.O.B. point. Delivery to the initial common carrier shall constitute
delivery to the Purchaser. Any claims for loss or damage during shipment are to be filed with
carrier by the Purchaser.
Seller will not assume responsibility for the performance of the carrier. Backorders will be
shipped in the most practical fashion with charges consistent with our freight policy established

RXL1000 Users Manual
20
with the original order. UPS, FED EX, MAIL or shipments by other couriers are subject to the
same terms and conditions as outlined in paragraph #3 ”Freight Terms”.
4. DELIVERY, DAMAGES, SHORTAGES
Seller shall use reasonable efforts to attempt to cause the Products to be delivered as provided
for in these Terms & Conditions. Delivery to the initial common carrier shall constitute the
delivery to the Purchaser. Sellers responsibility, in so far as transportation risks are concerned
ceases upon the delivery of the Products in good condition to such carrier at the F.O.B. point
and all the Products shall be shipped at the Purchaser’s risk. Seller shall not be responsible or
liable for any loss of income and/or profits, or incidental, special, consequential damages
resulting from Seller’s delayed performance in shipment and delivery.
5. RETURN OF DEFECTIVE PRODUCTS
Defective or failed material shall be held at the Purchaser’s premises until authorization has
been granted by Seller to return or dispose of Products. Products that are to be returned for
final inspection must be returned Freight Prepaid in the most economical way. Credit will be
issued for material found to be defective upon Seller’s inspection based on prices at time of
purchase.
6. PRODUCTS ORDERED IN ERROR
Products may be returned, provided that claim is made, and Seller is notified within 7 days of
receipt of Products, and the Products are in original buyer’s possession not more than 30 days
prior to return, subject to Seller’s approval. If Products are accepted for return, they must be
Freight Prepaid and buyer will be charged a minimum of 15% restocking charge, plus a charge
back for outbound freight charges if the original order was shipped prepaid. Returns are not
accepted for any Products that are specifically manufactured to meet the buyer’s requirement of
either specifications or quantity.
AGREEMENTS
These Terms and Conditions constitute the entire agreement between Seller and Purchaser as it
relates to terms and conditions of sale and supersedes any and all prior oral or written
agreements, correspondence, quotations or understandings heretofore in force between the
parties relating to the subject matter hereof.
There are no agreements between Seller and Purchaser with respect to the Product herein
except those specifically set forth in and made part of these terms and conditions.
Any additional terms, conditions and/or prices are rejected by Seller. These terms and conditions
may be modified, cancelled or rescinded only by a written agreement of both parties executed
by their duly authorized agents.
