V2.0.0
NLS-HR100
Hand-held 1D Barcode Scanner
手持式一维码扫描器
Quick Start
快速使用指南

Version/版本 Description/更新描述 Date/日期
V1.0 Initial release,only 6 pages .
最初版本，仅6页。 20090708
V 2.0.0 Support as from HR100 firmware V1.21.21 and higher.
支持V1.21.21 和更高的固件版本。 20100315
Revisions/版本信息

Getting to Start
Unpacking.......................................... E-01
Main Unit........................................... E-01
Accessories........................................ E-01
Outline and Function ......................... E-03
Specification...................................... E-04
Distance of Field................................ E-05
Connect HR100 to the Host............... E-06
Removal of Communication Cable ... E-07
ON, OFF, IDLE, RESTART .............. E-08
Reading
Hand-held Mode................................ E-09
Hands-Free Mode .............................. E-10
Programming Code
Query ................................................ E-11
Factory Default.................................. E-12
Reading Mode ................................... E-13
RS232 Programming ......................... E-14
USB Programming ............................ E-17
USB HID-KBW & PS/2 Keyboard Pro-
gramming........................................... E-18
Beeper................................................ E-21
Line Feed and Carriage Return.......... E-22
Symbols ............................................. E-23
Appendix
A. Testing Codes................................ E-26
B. Digit Code and Save ..................... E-27
C. Troubleshooting ............................ E-28
开始使用
打开包装 ........................................... C-01
主机 ................................................... C-01
配件 ................................................... C-01
产品外观 ........................................... C-03
性能参数 ........................................... C-04
识读景深 ........................................... C-05
如何连接HR100和信息接收主机.... C-06
如何拆卸通讯线 ............................... C-07
开机、关机、休眠、重启 ............... C-08
识读条码
手动识读模式 ................................... C-09
自动识读模式 ................................... C-10
常用设置码
查询命令 .......................................... C-11
恢复出厂设置 ................................... C-12
识读模式设置 ................................... C-13
RS232通讯设置 ................................ C-14
USB 通讯设置 .................................. C-17
USB HID-KBW 和PS/2 KBW 相关设置
........................................................... C-18
声音设置 ........................................... C-21
回车换行设置 ................................... C-22
条码使能设置 ................................... C-23
附件
A. 测试样码 ...................................... C-26
B. 数据码和保存 .............................. C-27
C. 常见故障及判处方法 .................. C-28
Content 目录

E-01
请更换节标题
Getting to Start
Unpacking
Unpack and check the main unit and accessories.In case there is any problem, please
contact with your dealer.
HR100»
PS/2 Cable»
Main Unit
Accessories

E-02
Getting to Start
Configuration
Stand»
USB Cable»
RS232 Cable + Power Adapter»

E-03
Getting to Start
Outline and Function
Scan Window
Trigger
Tag (S/N,Cetifications,etc)
LOGO
Reading /Power Indecator (Red/Green)
Cable Slot

E-04
Getting to Start
Specification
Performance
Image Sensor Linear CCD
Interface USB-HID, True RS232, TTL level RS232, Keyboard Wedge
Resoluing 2500
Decoded Speed 200/s
Symbologies Code128, EAN-13, EAN-8, Code39,UPC-A, UPC-E, Codabar, GS1 Databar,
Interleaved 2 of 5, ISBN/, Code 93, etc.
Precision ≥5mil
Light Source LED 630 nm ±10 nm
Print Contrast Signal ≥30%
Depth of Field
Code 39（10mil）:25-280; Code 39（15mil）:20-390;
ENA-13 （10mil）:45-230; ENA-13 （15mil）:30-375;
Code128（10mil）:30-300; Code128（15mil）:25-380;
Sensitivity
**
Pitch ±60°@ 0°Roll and 0°Skew
Roll ±30°@ 0°Pitch and 0°Skew
Skew ±75°@ 0°Roll and 0°Pitch
Illumination 0 ~ 100,000 LUX
Mechanical/ Electrical
Power Consumption 0.7W（Max）
Voltage DC 5.0V
Current
Peak 150mA
Operat. 120mA
Idle 45mA
Weight 105g
Environment
Operate Temperature -0℃~ +50℃
Storage Temperature -40℃~ +60℃
Humidity 5% ~ 95% ( non-condensing)
Certifications FCC Part 15 Class B，CE EMC Class B
**Test Condition:
Code39: 3 Bytes ; Resolution = 10mil; W:N = 2.5:1 ; PCS = 0.8 ;
Barcode Height = 11mm; Distance = 120mm; T=23°C; Illumination= 200 LUX

E-05
Getting to Start
Distance of Field
42°
45mm Code 39(10mil) 200mm
0 100 200 300 400 500
50mm Code 39(15mil) 390mm
60mm EAN-8(10mil) 210mm
25mm EAN-8(15mil) 330mm
60mm EAN-13(10mil) 200mm
40mm Code 128(10mil) 200mm

E-06
Getting to Start
Connect HR100 to the Host
Connecting with USB Cable
Connecting with PS/2 Cable
Insert PS/2 cable (RJ 45 male DIN) into HR1001、
cable slot;
Insert PS/2 cable (PS/2 male DIN) into Host PS/22、
female slot;
If necessary, connect PS/2 cable and the power3、
adapter;
If necessary, keyboard can connect to female slot4、
on the PS/2 cable.
Insert USB Cable (RJ45 male head) into HR1001、
cable slot;
Insert USB Cable (USB male head) into Host’s2、
(female) USB connector.
Connecting with RS232 Cable
Insert RS232 cable (RJ45 male head) into HR1001、
cable slot;
Insert RS232 cable (RS232 male head) into2、
Host’s (female) RS232 connector;
Connect RS232 cable and the power adapter.3、

E-07
Getting to Start
Removal of Communication Cable
A Pin that fit the HR100 “Dismount hole”is needed. A paper clip could be ideal. Stretch one
end of the paper clip to fit the “Dismount Hole”. Follow the steps:
For RS232 and PS/2 connections, unplug the power adaptor.1、
Insert the Pin into “Dismount Hole”and keep some pressure.2、
Pull out the cable gently.3、
Pull out the Pin after the cable is removed.4、
Unplug the connector from the Host.5、

E-08
Getting to Start
ON, OFF, IDLE, RESTART
Power On»
Connect HR100 and Host. One click the "Trigger". HR100 powers on and in "Idle" (ready to
use) state (factory default).
Power Off»
There are 4 ways to “Power OFF”:
Remove Cable Off HR100;1、
Remove Power Adapter Off RS232 Cable;2、
Remove USB Cable Off the Host;3、
Remove PS/2 cable off the Host or power adaptor off.4、
IDLE»
When reader is NOT reading, it is in "IDLE mode".
No reading attempt within a timeout, the Imager switch to IDLE mode automatically.
RESTART»
If HR100 halted and does not respond to operations, please "Restart" by "Power OFF", and
then "Power ON".

E-09
请更换节标题
Reading
Hand-held Mode
Ensure HR100, cables, and the Host are connected, then turn the unit Power ON1、
Press & hold Trigger. Illumination LED cast an Illumination Pattern (red light line) ;2、
Keep Illumination Pattern in the center of a bar code. Zoom in and zoom out to allocate3、
the Optimum Reading Stance.
On a successful reading, there’ll be a beep sound, illumination die out. The HR1004、
then transmits barcode message to the Host.
NOTE: Experiences tell a certain range of distances has higher successful reading rate. This
range is the Optimum Reading Stance.

E-10
Reading
Hands-Free Mode
Select reading mode “sensor mode”or “continuous mode”when working in hands-1、
free mode.
Adjust the stand height for the optimum reading stance.2、

E-11
请更换节标题
Programming Code
Code Programming ON
Code Programming OFF
Query
After reading interrelated programming barcodes, the engine
will feed information needed back to the Host to achieve the
purpose of query.
Query Product Information
Query Hardware Version
Query Product ID
Query Manufacturing Date
Query Product Model

E-12
Programming Code
Code Programming ON
Code Programming OFF
Factory Default
Part of Factory Default
Subject Factory Default
Interface
USB-HID, Keyboard Wedge
True RS232
TTL level RS232
Baud Rate 9600bit/s
Parity Check No Check
Data / Stop Bit 8 bits/1 bit
Beep On
Scan Mode Hand-held Mode
1D Symbols（Enable）Code128, EAN-13, EAN-8, Code39,UPC-A, UPC-E, Codabar,
GS1 Databar, Interleaved 2 of 5, ISBN/ISSN, Code 93, etc.
Load All Factory Default

E-13
Programming Code
Code Programming ON
Code Programming OFF
Reading Mode
Hand-held Mode：Factory Default, scan engine will begin1、
to scan when triggered. And when it scans successfully or the trig-
ger is released, the engine will stop scanning.
Sensor Mode：After programming, the engine will start to2、
sense the environment without trigger. After a scan, it will stop and
keep sensing to wait another illumination changing. In sesor mode,
a trigger also can start a scan. The sensitivity level could be chosen.
Auto Mode：First program the engine, then trigger it, the3、
engine will start to scan. After a scan, the engine will not stop but
start a new one automatically until another trigger. By default, the
engine will not repeat reading a same barcode.
Hand-held Mode
(Factory Default)
Sensor Mode
Auto Mode

E-14
Code Programming ON
Code Programming OFF
Programming Code
RS232 Programming
Baud Rate
Under RS232 connection, the engine and the Host should
set communication baud rate to the same to keep normal
communication.
Baud rate is the bits transmitted per second (8 bits per bytes). The
engine and the Host must communicate at the same baud rate.
The reader supports baud rate as the following:
9600
（Factory Default）
2400
14400
38400
115200
1200
4800
19200
57600

E-15
Programming Code
Code Programming ON
Code Programming OFF
RS232 Programming
Check
No Check
(Factory Default)
Odd Check Even Check
Stop Bit
0.5 Stop Bit
1 Stop Bit
(Factory Default)
1.5 Stop Bit
2 Stop Bit

E-16
Programming Code
Code Programming ON
Code Programming OFF
RS232 Programming
Data Bit
8 Data Bit
(Factory Default)
7 Data Bit
Flow Control
No Flow Control
(Factory Default)
RTS Flow Control
CTS Flow Control
RTS_CTS Flow Control
