NewTechWood OD-RPT-722 User manual

1
Outdoor Bar Table
OD-RPT-722
Assembly Instructions
v20230316US

2
#722 Outdoor Bar Table Assembly Instructions / v20230316US
Important Note
Please Read All Sections Carefully Before You Start
1. Parts
Before assembling, please check the packing parts carefully according to the sections
on page 2 and page 3 , "Tools" , "Fasteners" and "Components" of this Assembly Instruction
sheet. If parts are missing, please contact the retailer from which you acquired this table
to get the missing parts.
2. Safety
2.1 It is recommended to wear appropriate safety equipment to avoid any risk of injuries
but it is not limited to the following safety equipment when assembling the Bar Table:
gloves, safety shoes, safety goggles, long sleeves, and pants.
2.2 We recommended assembling the Bar Table by two people to avoid any risk of
injuries. DO NOT attempt assembling by one person.
2.3 The Bar Table is not designed for use as a standing platform or a ladder. DO NOT
stand on the table as there is a risk of falling and injury.
3. Tools
Always use the proper tools for assembly.
4. Assembling Procedure
4.1 Please follow the steps of the Assembly Instructions sheet in order.
4.2 DO NOT tighten all the screws until all the parts are in place and assembling in
alignment. Otherwise, it should cause the assembly to be misaligned. It is recommended
to turn back the screws in half-turn when the head of the screws touches the parts
before tightening all the screws in order.
Tools
T1 x 1pc
Hex Key
Fasteners
Screw
M6 x 5/8" (16mm)
Shim
Out Ø16 x In Ø6.5
T 1/16" (1mm)
S1 x 4pcs S2 x 4pcs S3 x 6pcs S4 x 6pcs
Spring Washer
Screw
M8 x 1" (25mm)
S5 x 6pcs
Shim
Out Ø16 x In Ø8.5
T 1/16" (1.5mm)
For the most up to date information, please visit our website @ www.newtechwood.com
Warranty: Please visit our website for full warranty @www.newtechwood.com

#722 Outdoor Bar Table Assembly Instructions / v20230316US 3
Components
C
B
D
A
A x 1pc B x 1pc
C x 1pc D x 1pc

4
#722 Outdoor Bar Table Assembly Instructions / v20230316US
Assemblying Procedure
Step 1
T1
S3
S4
B
AS5
Step 2
C

#722 Outdoor Bar Table Assembly Instructions / v20230316US 5
Step 3
S2
S1 T1
Step 4
D
T1
S4
S3
S5

6
#722 Outdoor Bar Table Assembly Instructions / v20230316US
Step 5
Turn Over
Thank You
For Your Purchase
We want you to be completely satised
