Storage Box Installation Guide
v20190923

Storage Box Installation Guide / v20190923 1
IMPORTANT:
Read All Sections Before You Start
For the most up to date information, please visit our website @ www.newtechwood.com
Prior to installing any composite product, it is recommended that you check with local building codes
for any special requirements or restrictions. The diagrams and instructions outlined in this guide are
for illustration purposes only and are not meant or implied to replace a licensed professional. Any
construction or use of NewTechWood must be in accordance with all local zoning and/or building codes.
The consumer assumes all risks and liability associated with the construction and use of this product.
Safety
When dealing with any type of construction project, it is necessary to wear appropriate safety equipment
to avoid any risk of injuries. NewTechWood recommends but is not limited to the following safety
equipment when handling, cutting, and installing the product: gloves, a respiratory protection, long
sleeves, pants, and safety glasses.
Tools
Standard woodworking tools may be used. It is recommended that all blades have a carbide tip.
Environment
A clean, smooth, at, and strong surface is needed to install the Storage Box correctly. Please check with
local building codes before ever installing any type of decking. If installation does not occur immediately,
NewTechWood's products need to be put on a at surface at all times. It should NEVER be put on a
surface that is NOT at.
Static
Static can also be more prevalent in areas that are of higher altitude because the humidity is lower. For
these areas, be careful of using conducive objects such as metal railing and chairs as static shocks might
occur more often. A potential way to lower the amount of static shocks occurring is to apply Staticide
(www.aclstaticide.com) on your deck or use anti-static mats before doorways.
Layout
Before installing the Storage Box, always make sure that you are installing it on a clean smooth flat
surface.
The Storage Box CANNOT be installed on places such as dirt, soil, or raised structure. It must be laid out
on a at solid surface.

Storage Box Installation Guide / v20190923 2
Storage Box Components
A - US56
(X1)
D - US08
(X18)
E - QDS0101
(X1)
C - QDS0202
(X4)
B - QDS0201
(X2)
F - QDG1
(X3)
A
D
B
EF
C

Storage Box Installation Guide / v20190923 3
1Lay & connect the grids (F-QDG1) on a at
surface as shown in Diagram 1, 2, and 3.
2Put the waterproof base (E-QDS0101) on
top of the three grids as shown in Diagram
4.
Now take aluminum frames (B-QDS0201)
and frame connectors (C-QDS0202) and
connect the aluminum frames together as
shown in Diagram 5, 6, 7, and 8.
3
The following installation is for the 1x3 storage stool.
DIAGRAM 4
DIAGRAM 1
DIAGRAM 2
DIAGRAM 3
DIAGRAM 5
DIAGRAM 6

Storage Box Installation Guide / v20190923 4
DIAGRAM 7
The frame will be sitting on the outside of
the entire grid system after being installed
as shown in Diagram 9 and 10.
4
After installing the frame over the grids now the
boards (D-US08) can be slotted into the metal
frame as shown in Diagram 11 and 12.
5
DIAGRAM 10
DIAGRAM 11
DIAGRAM 8
DIAGRAM 12
DIAGRAM 9

Storage Box Installation Guide / v20190923 5
After all the boards are slotted the cover (A-US56) can be put on top as shown in Diagram 13 and 14.
6
DIAGRAM 13
DIAGRAM 14

Storage Box Installation Guide
v20190923
©2019 Huidong Meixin Plastic Lumber Products Manufacturing Co., Ltd.
NewTechWood is a registered trademark of Huidong Meixin Plastic Lumber Products
Manufacturing Co., Ltd. To obtain a copy of the most current version of this installation guide,
visit us online at www.newtechwood.com.
®
