Nexia RP200 User manual

RP200
Home Dimmer Module
D158183
FOR INDOOR USE ONLY!
DO NOT use with non-resistive loads, such as florescent lighting, CFL bulbs or motors.
To reduce the risk of electric shock, this product has a grounding type plug that has a third (grounding) pin.
This plug will only fit into a grounding type power outlet. If the plug does not fit into the outlet, contact a
qualified electrician to install the proper outlet. Do not change the plug in any way.
Any modification or use other than described may damage the unit and will void the warranty.
Install the home dimmer module.
•Install into any indoor, three-prong, 120 volt A/C outlet.
1
(Optional) Plug a lamp into the Z-Wave™ (two-prong) side of
the light module.
•A lamp (25 watts minimum and 300 watts maximum) can be
controlled through Z-Wave™ side of light module.
•DO NOT use a CFL (compact fluorescent light bulb).
The home dimmer module works like a dimmer switch and will
not function properly with CFL and LED bulbs or electric devices
with motors, like fans.
•Make sure that lamp switch is in the ON position.
•Pass-through (three-prong) outlet (1500 watts maximum) is NOT
controlled by the system and functions as a standard electrical
outlet.
2
Max. 300W
Incandescent
Z-W ave™
Side
Pass-through
Side
Enroll the light module into the bridge.
a. Disconnect power and Ethernet from the bridge.
b. Install a new 9 volt battery into the bridge.
c. Hold the bridge within 6 feet (1.8 meters) of the light module
throughout all of step 3.
d. Press and release the plus (+) button on the bridge.
e. Double-click the button on the light module.
f. Observe the lights on bridge.The orange light will blink while
enrollment is taking place. Enrollment is complete when the
orange light becomes solid.
g. Reconnect power and Ethernet to the bridge.
3
First
Press
+
Then Press
Within
6’ (1.8 m)

©2015 Ingersoll Rand Residential Solutions
Printed in U.S.A.
D158183 Rev. A
Specifications
•Power 120 VAC, 60 Hz
•Signal (Frequency) 908.42 MHz
Software Fuse
The RP200 is designed to protect itself against loads that exceed it’s maximum power rating.The application of a load that exceeds that rating
is quickly sensed by the dimmer and it responds by immediately shutting o all power to that load. If the home dimmer module doesn’t seem to
work, or if it only works momentarily, check to see that the total light wattage doesn’t exceed the 300W rating of the RP200. If a properly sized
load is restored to the dimmer, it can be operated normally once again.
Over-current protection
The RP200 hardware has an over current detection circuit, which is final protection against overload. If the software fuse should fail to shut
down the dimmer when overloaded, backup protection is provided by an internal fuse.This fuse is not user serviceable. Check your home
circuit breakers before concluding that the product must be returned to the manufacturer for repair at a nominal charge.
FCC NOTICE
Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to
part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference
in a residential installation.This equipment generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning the equipment o
and on, the user is encouraged to try to correct the interference by one or more of the following measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and receiver.
•Connect the equipment into an outlet on a circuit dierent from that to which the receiver is connected.
•Consult the dealer or an experienced radio/TV technician for help.
IC NOTICE
This Class B digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada.
Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any
interference, including interference that may cause undesired operation of the device.
About RP200’s Certification
In addition to compliance with product safety standards, the RP200 is also certified to comply with applicable FCC and IC rules and
regulations governing RF and EMI emissions.
Customer Service: [phone] (U.S.A. /Canada)
Warranty information is available at www.nexiahome.com.
www.mynexia.com
4Log into your account at www.mynexia.com.
•Click the Lighting & Automation tab.
•The newly enrolled light module will be displayed.
