next audiocom Pro Series User manual

USER MANUAL
Multi-Purpose Passive/Active Speaker
v202205
www.nextaudiocom.com

www.nextaudiocom.com

www.nextaudiocom.com
CONTENTS
INTRODUCTION
GENERAL DESCRIPTION -2-
UNPACKING -2-
SAFETY FIRST -2-
WARNINGS -2-
GETTING STARTED
PRO SERIES OVERVIEW -3-
MULTI-PURPOSE FEATURE -3-
CONNECTIONS -3-
PASSIVE VERSION -3-
ACTIVE VERSION -4-
PRESETS -4-
PRESET LIST -4-
PRESET CHANGING PROCEDURE -4-
BLUETOOTH PAIRING/UNPAIRING -4-
HANDS-ON
INSTALLATION -5-
GENERAL CONSIDERATIONS -5-
PREPARATION -5-
U-BRACKET INSTALL INSTRUCTIONS -5-
WALL BRACKET INSTALL INSTRUCTIONS -6-
SUSPENDED INSTALL INSTRUCTIONS -6-
HF HORN ROTATION PROCEDURE -6-

www.nextaudiocom.com
CONTENTS
SERVICE
TROUBLESHOOTING -7-
PASSIVE VERSION -7-
ACTIVE VERSION -7-
WARRANTY POLICY -7-
SIMPLIFIED EU DECLARATION OF CONFORMITY -7-
CORRECT DISPOSAL -8-
TECHNICAL SPECIFICATIONS -8-
PRO 12 -8-
PRO 15 -8-
PRO 12A -8-
PRO 15A -8-
TECHNICAL DRAWINGS -8-
PRO 12 + U-BRACKET DIMENSIONS -8-
PRO 15 + U-BRACKET DIMENSIONS -8-

GENERAL DESCRIPTION
Thank you for purchasing a NEXT Audiocom Pro Series
speaker. This user manual will provide you with useful and
important information about your equipment. Please devote
some time reading it and keep it at hand for future reference.
The NEXT Audiocom Pro Series is composed by both active
and passive point-source speakers designed for installations
and portable solutions. The premium-quality components
provide a balanced sound with an excellent low frequency
extension. This series can be an ideal solution for hotels,
restaurants, bars, lounges, conference rooms and many
others.
ATTENTION! Because of the continuous evolution of
techniques and standards, NEXT Audiocom reserves the right
to change the specications of its products without warning.
For the most updated version of this manual and general
information about this and other products, please visit our
website www.nextaudiogroup.com.
UNPACKING
NEXT Audiocom’s products are built under strict quality
guidelines and supervision, according to the highest
standards. When unpacking your product, carefully examine
it for any signs of possible transit damage and inform your
dealer immediately if any such damage has occurred. It is
suggested that you retain the original packaging so that the
product can be repacked in the future when necessary. Please
note that NEXT Audiocom and its authorized distributors
cannot accept any responsibility for damage to any returned
product using non-approved packaging.
SAFETY FIRST
Please take some time to review the following statements
concerning safe use of your NEXT Audiocom Pro Series.
• Read these instructions
• Keep these instructions
• Heed all warnings
• Follow all instructions
• Use the equipment only for its intended purpose as
instructed in this manual
• Before installing, observe the applicable safety regulations
for your country
• Always check if the equipment is installed securely and will
not fall
• Do not attempt to move the enclosures while connected
• When mounted on a pole, always ensure that the oor or
structure where the stack will take place is even and can
withstand the weight
• Never install close to ignition or heat sources such as
radiators, ovens or any other apparatus that produce heat
• Do not use or install the equipment near water or exposed to
rain
• If the equipment is not functioning properly or has been
damaged in any way, switch it o immediately
• Do not open or try to service the equipment. It may only be
repaired by authorized, qualied personnel
• Clean the equipment using only a clean dry cloth
• Do not operate the unit for an extended period with the
sound distorting
WARNINGS
INTRODUCTION
2
NEXT Audiocom | Pro Series
CAUTION:
Never remove the cover, because otherwise there may be a
risk of electric shock. There are no user serviceable parts
inside. Have repairs carried out only by qualied service
personnel.
The lightning ash with arrowhead symbol within an
equilateral triangle is intended to alert the user to the
presence of uninsulated “dangerous voltage” within the
product’s enclosure that may be of sucient magnitude to
constitute a risk of electrical shock.
The exclamation mark within an equilateral triangle is
intended to alert the user to the presence of important
operating and maintenance instructions.
CAUTION:
This equipment is intended for professional use. Therefore,
commercial use of this equipment is subject to the
respectively applicable national accident prevention rules
and regulations. As a manufacturer, NEXT Audiocom is
obligated to notify you formally about the existence of
potential health risks. Hearing damage due to high volume
and prolonged exposure: When in use, this product is capable
of producing high sound-pressure levels (SPL) that can lead to
irreversible hearing damage in performers, employees, and
audience members.
For this reason, avoid prolonged exposure to volumes in
excess of 90dB.

BLUETOOTH
12" MULTIPURPOSE
ACTIVE SPEAKER
PRO SERIES OVERVIEW
1 - Input Signal / Peak LED
2 - XLR / TRS 1/4” Combo Inputs
3 - MIC/LINE Selector
Line is used for audio mixing console, audio playback
device or electronic musical instrument
4- Input Level
5- AUX Input - 3.5mm audio jack / CD Player Input - RCA
connector
6 - XLR Output
7 - Mains Power Input - IEC connector / Protection Fuse - F6.3A
250V
8 - Power On/Off Switch
9 - Power LED
Blue - ON
10 - Output Limiter LED Indicator
Red - Limiting
11 - Preset Selection Section
12 - Bluetooth Section
LED State:
Quick Blink - Unpaired / Solid - Paired / Slow Blink - Playing
A - One of the 12 Hanging points (M8 threaded)
B - Connections’ Plate (SpeakON 4-pin connected to 1+/1-)
C - Wall Bracket Bolts (only available on Pro12)
D - Side Rubber Feet (only available on passive versions)
MULTI-PURPOSE FEATURE
CONNECTIONS
PASSIVE VERSION
The NEXT Audiocom Pro Series speakers, in the passive
version, have a nominal impedance of 8Ω. Use a Neutrik NL4
to connect the amplier to the speaker. On the speaker side
connect the wires to 1+/1-. To avoid speaker damage, be sure
to deliver not more than 500W to Pro12 and 700W to Pro15.
Above is a stereo connection of the speakers to the amplier.
Below is a parallel connection of the speakers to the amplier.
When connecting multiple speakers in parallel, be sure to
follow the amplier’s specications in relation to the
minimum allowed impedance. Most ampliers allow for a
minimum 4Ω impedance which corresponds to two Pro Series
speakers connected in parallel.
GETTING STARTED
3NEXT Audiocom | Pro Series
AMPLIFIER
8Ω
8Ω
AMPLIFIER
8Ω
8Ω
Pole Mount
Wall Mount
(accessories not included)
Stage Monitor
(only passive version)

BLUETOOTH
12"MULTIPURPOSE
ACTIVESPEAKER
ACTIVE VERSION
You can connect any instrument, microphone, CD Player or
audio mixer to the active Pro Series input. The Pro speakers
can be connected between each other using the “Mix Out”
connector. An active external subwoofer can be added to
extend the system frequency response.
You can use your mobile device to play wireless music, using
the bluetooth technology, to one Pro speaker. The Pro
speakers can be connected between each other using the
“Mix Out” connector. An active external subwoofer can be
added to extend the system frequency response connecting it
as the example above.
PRESETS
PRESET LIST
FLAT - Speaker’s Flat Response - use this preset in live
performances for clarity of voice and instruments.
HF BOOST - Speaker’s EQ for Long Distances - use this preset
when long throw is needed or when used on very absorbent
room (dead room).
MUSIC - Speaker’s EQ for Music Reproduction - use this preset
for recorded music playback and electronic dance music
applications.
WALL - Speaker’s EQ for Wall Applications - use this preset
when the speaker is installed on the wall/ceiling using the
wall bracket or U-Braket.
HPF 100Hz - Speaker’s High Pass Filter - use this preset to
enable the HPF when using the speaker with a subwoofer. It
will change the speaker’s high pass lter to 100Hz
Linkwitz-Riley 24dB/oct.
PRESET CHANGING PROCEDURE
1. Press the Preset button once to change the preset among
Flat, HF Boost, Music and Wall.
2. Press and hold the Preset button for 2 seconds to activate
the High Pass Filter (100Hz). All the presets can be used with
or without HPF.
BLUETOOTH PAIRING/UNPAIRING
1. Press and hold the bluetooth pair button for 3 seconds.
Now, the speaker is looking for bluetooth devices and the
Bluetooth LED will start blinking quickly.
2. On your mobile device, select NEXT Pro12 or NEXT Pro15 to
initiate the pairing process.
3. Once the device is paired, the Bluetooth LED will turn solid
blue.
4. Play the audio from the mobile device. The Bluetooth LED
will blink slowly during audio reproduction.
To unpair the speaker from the mobile device click once on
the pair button.
To turn o the bluetooth on the speaker press and hold the
pair button for 3 seconds.
GETTING STARTED
4
NEXT Audiocom | Pro Series
AUDIO
BLUETOOTH
12"MULTIPURPOSE
ACTIVESPEAKER
12"MULTIPURPOSE
ACTIVESPEAKER
12"MULTIPURPOSE
ACTIVESPEAKER

HANDS-ON
5NEXT Audiocom | Pro Series
INSTALLATION
GENERAL CONSIDERATIONS
The NEXT Audiocom Pro Series speakers are ready to be
installed in a variety of dierent environments and
applications. Each speaker can be hanged using 12 different
hanging points, U-bracket (not included), wall bracket (not
included and only available on Pro12 passive version) and
ceiling bracket (not included and only available on Pro12).
Remember to rotate the HF horn when installing the Pro
Series horizontally (see the instructions on page 6).
PREPARATION
Listed below is the hardware equipment needed to install the
Pro Series.
U-BRACKET INSTALL INSTRUCTIONS
The U-Bracket has a total angle adjustment span of 115º.
Depending on the adjustment bolt used, the nal speaker’s
angle may vary.
1. 100º to -15º
2. 10º to -105º
3. -80º to -195º
Remove the two bolts from the top of the speaker. Remove
the bolts from the pole ange and remove it. Install the new
screw ange provided with the u-bracket and fasten 3 bolts
(the selected adjustment bolt will be fastened later on).
Mount the U-bracket at a designated location on the wall or
ceiling (when mounted horizontally on the wall, the UP arrow
must be pointing upwards). The screws are inserted into the
holes provided on the bracket. Use the correct fasteners for
the surface on which the bracket is to be mounted.
Insert the large (M8) bolts into the center threaded holes
(speaker’s top and bottom). These should stay up just high
enough so that the intended slot in the bracket can be
hooked in.
Add the additional (small) safety/adjustment bolts and
washers. This is placed in the rotation slot of the bracket. Do
not totally fasten it.
Adjust the speaker angle and totally fasten the bolts.
Pencil
Ladder

HANDS-ON
6
NEXT Audiocom | Pro Series
WALL BRACKET INSTALL INSTRUCTIONS
A two-axis wall bracket can be used on the Pro12 passive
speaker. The adjustment angle span will vary according to the
selected pan and tilt angles. The maximum tilt angle is -30º.
Disassemble the wall bracket into the two main parts. Mount
the bracket part at a designated location on the wall or
ceiling. The screws are inserted into the holes provided on the
bracket. Use the correct fasteners for the surface on which the
bracket is to be mounted.
Remove the 6 bolts from the speaker’s back. Install the other
part of the wall bracket.
Attach the speaker + wall bracket set into the already installed
wall part. Insert the bolts but do not fully tighten them.
Adjust the pan and tilt angles and fully tighten the indicated
bolts on the image.
SUSPENDED INSTALL INSTRUCTIONS
Remove the M8 bolts from the speaker where it’s pretended
to hang from. Insert the M8 eye bolts and fully tighten them.
The speakers can be hanged vertically or horizontally. Always
use a safety cable.
HF HORN ROTATION PROCEDURE
To mantain the original vertical and horizontal coverage of
the speaker (80º x 50º), when installing it horizontally, the
high frequency horn must be rotated by 90º.
Remove the grill unscrewing the 4 screws on each side and
pulling it out. Remove the 8 bolts from the horn, and pull it.
Rotate the horn by 90º and reinstall it. Place the grill back on.

SERVICE
7NEXT Audiocom | Pro Series
TROUBLESHOOTING
PASSIVE VERSION
Problem: No sound coming from the speaker
Action to Solution:
- Check volume levels on the amplier and signal sources and
the connections between them. If your amplier has signal
detection or measuring visuals, test if it is reacting to the
signal source. If everything seems to be ok, connect another
speaker known to be working to the amplier. If it works, the
wiring to the Pro Speaker may have problems.
- Check that you have the correct pair of wires connected to
the speakers you are trying to work with. Look for signs of
damage if possible and check that the wires are correctly
mounted on the connector and the connecter is correctly
inserted on the speaker.
Problem: Little to no Bass
Action to Solution:
- This happens most of the times when two or more speakers
near each other, are wired out of polarity. In this case low
frequencies will cancel each other acoustically. Check that the
“+” on the amplier, is connected to the 1+ on the NL4 and
the “-“ marked on the amplier terminal is connected to the 1-
on the NL4.
ACTIVE VERSION
Problem: Buzzing, hissing or humming
Action to Solution:
- If there is noise and no program material is playing, check
your entire signal chain for the bad component. It can also be
a matter of poor grounding or a ground loop. Check and
correct the system grounding.
Problem: No sound from microphone on CH1
Action to Solution:
- Check if the microphone is a condenser one. If it is, change to
a dynamic one or use an external phantom power for
condenser microphones.
Problem: Sound is distorting with PEAK led OFF
Action to Solution:
- Reduce the level from the audio source, such as the mixer,
increase the level on the input potentiometer.
Problem: Sound is distorting with PEAK led mostly ON
Action to Solution:
- Reduce the level on the input or audio source
Problem: Too much low end when installed on wall or ceiling
Action to Solution:
- Due to wall and/or ceiling reections the bass response is
increased. To linearize the low end, select the Wall preset.
Problem: Poor high frequency response
Action to Solution:
- Probably the room is too absorbent or you are listening from
a long distance. To increase the HF frequency response, select
the HF Boost preset.
Problem: Poor low frequency response
Action to Solution:
- Probably the High-Pass Filter is enabled. Press and hold the
PRESET button for two seconds to disable de HPF.
WARRANTY POLICY
NEXT Audiocom products are warranted, by NEXT Audiocom,
against manufacturing defects in materials or craftsmanship
over a period of 2 years counting from the date of original
purchase for nal costumer. The original receipt of purchase is
mandatory for warranty validation purposes, and the product
must have been bought from a NEXT Audiocom authorized
dealer. The warranty can be transferred to a subsequent
owner during the warranty period, however, this cannot
extend the warranty period beyond the original warranty
period of two years from the original date of purchase stated
on the NEXT Audiocom’s invoice. During the warranty period
NEXT Audiocom will, at its own discretion, either repair or
replace a product which prove to be defective provided that
the product is returned in its original packaging, shipping
prepaid, to an authorized NEXT Audiocom service agent or
distributor. NEXT Audiocom cannot be held responsible for
defects caused by unauthorized modications, improper use,
negligence, exposure to inclement weather conditions, act of
God or accident, or any use of this product that is not in
accordance with the instructions provided by this manual
and/or NEXT Audiocom. NEXT Audiocom is not liable for
consequential damages. This warranty is exclusive, and no
other warranty is expressed or implied. This warranty does not
aect your statutory rights.
SIMPLIFIED EU DoC
Hereby, CVA ELECTRONICA, LDA declares that this equipment
type is in compliance with the mandatory directives for the CE
certication. The full text of the EU declaration of conformity
is available at the following internet address:
www.nextaudiogroup.com/en/apoio-ao-cliente/downloads

CORRECT DISPOSAL
When the Pro series speakers are to be denitively discarded,
take the product to a local recycling plant for a disposal which
is not harmful to the environment. This equipment should not
be treated as general household waste.
Devices marked with this symbol must not be disposed of as
household waste. For more information, please contact your
retailer or local authorities.
TECHNICAL SPECIFICATIONS
PRO 12
Product Type: 2-Way Professional Passive Speaker
Frequency Response (-6dB): 52Hz - 20kHz
Nominal Coverage: 80° H x 50º V (User Rotatable)
Program Power: 500W
Nominal Impedance: 8Ω
Sensitivity (1W, 1m): 97dB
Maximum SPL (Calculated): 124dB / 127dB
LF Driver: 12" Woofer | 2.5" Voice Coil
HF Driver: 1" Titanium Driver | 1.7" Voice Coil
Input Connectors: 2 x NL4 SpeakON (compatible)
Construction: Plywood with Polyurea Coating
Grille: Powder Coated Steel Grille with Acoustical Foam
Net Weight: 19kg (41.9lb)
Shipping Weight: 22kg (48.5lb)
PRO 15
Product Type: 2-Way Professional Passive Speaker
Frequency Response (-6dB): 48Hz - 20kHz
Nominal Coverage: 80° H x 50º V (User Rotatable)
Program Power: 700W
Nominal Impedance: 8Ω
Sensitivity (1W, 1m): 98dB
Maximum SPL (Calculated): 126.5dB / 129.5dB
LF Driver: 15" Woofer | 3" Voice Coil
HF Driver: 1" Titanium Driver | 1.7" Voice Coil
Input Connectors: 2 x NL4 SpeakON (compatible)
Construction: Plywood with Polyurea Coating
Grille: Powder Coated Steel Grille with Acoustical Foam
Net Weight: 26.5kg (58.4lb)
Shipping Weight: 30kg (66.1lb)
PRO 12A
Product Type: 2-Way Professional Active Speaker
Frequency Response (-6dB): 46Hz - 20kHz
Nominal Coverage: 80° H x 50º V (User Rotatable)
Amplifier Power: RMS: 800W | Peak: 1400W
Audio Signal Inputs: Bluetooth | Microphone | Instrument |
CD Player | AUX
Maximum SPL (Calculated): 122dB / 128dB
LF Driver: 12" Woofer | 2.5" Voice Coil
HF Driver: 1" Titanium Driver | 1.7" Voice Coil
Input Connectors: 2 x XLR / TRS combo | 1 x 3.5mm Stereo
Jack | 1 x Stereo RCA
Output Connectors: 1 x XLR
Construction: Plywood with Polyurea Coating
Grille: Powder Coated Steel Grille with Acoustical Foam
Net Weight: 20kg (44.1lb)
Shipping Weight: 23kg (50.7lb)
PRO 15A
Product Type: 2-Way Professional Active Speaker
Frequency Response (-6dB): 42Hz - 20kHz
Nominal Coverage: 80° H x 50º V (User Rotatable)
Amplifier Power: RMS: 800W | Peak: 1400W
Audio Signal Inputs: Bluetooth | Microphone | Instrument |
CD Player | AUX
Maximum SPL (Calculated): 124dB / 130dB
LF Driver: 15" Woofer | 3" Voice Coil
HF Driver: 1" Titanium Driver | 1.7" Voice Coil
Input Connectors: 2 x XLR / TRS combo | 1 x 3.5mm Stereo
Jack | 1 x Stereo RCA
Output Connectors: 1 x XLR
Construction: Plywood with Polyurea Coating
Grille: Powder Coated Steel Grille with Acoustical Foam
Net Weight: 27.5kg (60.6lb)
Shipping Weight: 31kg (68.34lb)
TECHNICAL DRAWINGS
PRO 12 + U-BRACKET DIMENSIONS
PRO 15 + U-BRACKET DIMENSIONS
SERVICE
8
NEXT Audiocom | Pro Series
356
578
398
95
562
120
10
13
460
45
420
718
410
80
702
120
10
13
600
45
