Vifa VIFA070 User manual

Bluetooth
14:52
Bluetooth
Paired
31 3 1 2 4 2
BUTTONS AND INDICATORS BATTERY CHARGE CONNECTING WITH BLUETOOTH CONNECTING WITH BLUETOOTH WIRED CONNECTION WIRED CONNECTION SPEAKER PHONE SPEAKER PHONE
Answer/Terminate call
Mute/Pause
MODE button with
status indicator
Volume
Reset
Battery indicator
USB-C Charge Socket
AUX Socket
Stereo
Left channel
Right channel
To turn Reykjavik on, press
and hold the MODE button
until status indicator turns
solid WHITE.
* To turn off, press and hold the MODE
button until the status indicator ashes
WHITE. Then release.
*During music streaming, press the
Mute/Pause button to Mute/Unmute
music.
*During music streaming, press the
Mute/Pause button to play/pause music.
Enable Bluetooth pairing
on your device and select
VIFA_REYxxxxxx as your
Bluetooth device.
Press and hold the MODE
button until status indicator
ashes BLUE.
The status indicator turns
solid BLUE when a
connection is established.
To turn Reykjavik on, press
and hold the MODE button
until status indicator turns
solid WHITE.
Connect the wire,
( USB-C or AUX ) and
start music playback from
your device.
The status indicator turns
solid GREEN when wired
playback is enabled.
To charge, plug USB-C cable
in USB power adapter or
computer and connect to your
speaker. Light indicator shows
the charging progress.
*Please note that power adapter is not
included with the product. When not charging
and battery level is below 5%, the battery
indicator will light up.
Above 95%
Between 80 and 95%
Between 15 and 80%
Below 15%
Receive incoming call
The status indicator ashes
GREEN. Briey press the
Answer/Terminate call
button.
Reject incoming call
Press and hold the
Answer/Terminate call
button.
Terminate a call
Briey press the Answer/
Terminate call button again.
Mute a call
During a call, briey press
the Mute/Pause button
to mute or unmute the
microphone. The status
indicator ashes WHITE
when muted.
Link button with integrated indicator
2017_10_31_Vifa Reykjavik_QuickGuide_UK_V2.4.indd 1 31-10-2017 14:43:07

2
1
LINK TWO REYKJAVIK SPEAKERS LINK TWO REYKJAVIK SPEAKERS REGISTER AND TRADEMARKS SPECIFICATIONS SPECIFICATIONS SUPPORT
Portable wireless loudspeaker
Bluetooth® Wireless Technology
AUX 3.5 mm mini jack
USB playback
Lithium Ion battery
DSP crossover, optimized
for low distortionand high
precision
3 channel digital amplier
LINK two speakers
Speaker phone
(Incl noise/echo cancelling)
Bluetooth®
AUX 3.5 mm mini‐jack
USB-C
2 X 19 mm Vifa drive units
with coated fabric dome
and neodymium magnet
70 mm Vifa drive unit with
aluminum cone and neodymium
magnet
62 Hz – 20 kHz @ +/- 3 dB
USB, 5V.
After 3 minutes without signal
After 30 minutes without signal
Lithium-Ion 19Wh
65 mm / 139 mm
0.6 kg
Custom made Kvadrat textile,
anodized aluminum
Description
Technical features
Inputs
Tweeter
Woofer
Frequency response
Input voltage
Sleep mode
Automatic off
Battery, internal
Height/Diameter
Net weight
Grilles
Support
If you experience issues that are not described
in this quick-guide, please refer to
vifa.dk/support for more information
Register your Reykjavik
We encourage you to register your speaker at
vifa.dk/support
2017 10 Rev. 2.4
IN THE BOX
USB-C cable
Safety instructions
and warranty
Quick guide
1x Reykjavik +Travel bag
Make sure the two Reykjavik
speakers are turned ON.
Briey press the Link button on
one speaker (primary) until Link
indicator ashes YELLOW.
Repeat on the other speaker
(secondary).
When both speakers are linked,
their Link indicators become
solid YELLOW, showing they are
linked as stereo speakers.
*When the secondary speaker is
linked, it plays primary speaker’s
music.
To change to Left/Right channel,
briey press Link button.To break the
Link, press and hold Link button.
The Bluetooth®word mark and logos
are registered trademarks owned by
Bluetooth SIG, Inc., and any use of
such marks by
Vifa Denmark A/S is under license.
REYKJAVIK
Quick guide
Model: VIFA070
Briey press
